Материал: 3_Справочные материалы для КП_2008 Котиков Г.С

Профиль

b

s

r1

A

Iy=Iz

Wy=Wz

iy=iz

Sy=Sz

P

см

см

см

см2

см4

см3

см

см3

кг/см

160x3

16.0

0.3

0.6

18.5

750.0

93.7

6.4

53.9

0.14

160x4

16.0

0.4

0.8

24.3

969.0

121.0

6.3

70.3

0.19

160x5

16.0

0.5

1.0

29.9

1174.0

147.0

6.3

85.8

0.23

160x6

16.0

0.6

1.2

35.4

1365.0

171.0

6.2

101.0

0.28

160x7

16.0

0.7

1.4

40.7

1542.0

193.0

6.2

115.0

0.32

160x8

16.0

0.8

1.6

45.9

1705.0

213.0

6.1

128.0

0.36

180x4

18.0

0.4

0.8

27.5

1399.0

155.0

7.1

89.9

0.22

180x5

18.0

0.5

1.0

33.9

1702.0

189.0

7.1

110.0

0.27

180x6

18.0

0.6

1.2

40.2

1986.0

221.0

7.0

129.0

0.32

180x7

18.0

0.7

1.4

46.3

2252.0

250.0

7.0

148.0

0.36

180x8

18.0

0.8

1.6

52.3

2500.0

278.0

6.9

165.0

0.41

200x4

20.0

0.4

0.8

30.7

1940.0

194.0

7.9

112.0

0.24

200x5

20.0

0.5

1.0

37.9

2367.0

237.0

7.9

137.0

0.30

200x6

20.0

0.6

1.2

45.0

2770.0

277.0

7.8

162.0

0.35

200x7

20.0

0.7

1.4

51.9

3150.0

315.0

7.8

185.0

0.41

200x8

20.0

0.8

1.6

58.7

3510.0

351.0

7.7

208.0

0.46

Профиль

b

s

r1

A

Iy=Iz

Wy=Wz

iy=iz

Sy=Sz

P

см

см

см

см2

см4

см3

см

см3

кг/см

80x4

8.0

0.4

1.0

11.3

104.2

26.0

3.0

15.7

0.09

80x5

8.0

0.5

1.2

13.8

121.5

30.4

3.0

18.7

0.11

80x6

8.0

0.6

1.4

16.0

135.5

33.9

2.9

21.2

0.13

100x4

10.0

0.4

1.0

14.5

215.7

43.2

3.8

25.6

0.11

100x4

10.0

0.4

0.8

14.7

234.1

48.9

3.9

26.0

0.12

100x5

10.0

0.5

1.2

17.8

255.6

51.1

3.8

30.8

0.14

100x6

10.0

0.6

1.4

20.8

290.1

58.0

3.7

35.4

0.16

110x3

11.0

0.3

0.7

12.4

233.6

42.5

4.3

24.7

0.10

110x6

11.0

0.6

1.4

23.3

398.8

72.5

4.2

43.9

0.19

120x8

12.0

0.8

2.2

32.3

624.0

84.3

4.4

64.6

0.25

140x5

14.0

0.5

1.0

25.9

761.1

109.9

5.4

64.6

0.20

140x5

14.0

0.5

1.2

25.8

780.5

108.6

5.4

64.0

0.20

140x6

14.0

0.6

1.4

30.3

873.5

110.6

5.4

74.3

0.24

140x7

14.0

0.7

1.8

34.7

974.2

139.2

5.3

83.9

0.28

140x8

14.0

0.8

2.2

38.7

1055.3

150.8

5.2

92.1

0.30

150x8

15.0

0.8

2.2

41.9

1330.0

177.2

5.6

107.6

0.33

Профиль

b

s

A

Iy=Iz

Wy=Wz

iy=iz

P

см

см

см2

см4

см3

см

кг/см

80x3

8.0

0.3

9.2

91.4

22.8

3.1

0.07

80x4

8.0

0.4

12.2

117.3

29.3

3.1

0.10

80x5

8.0

0.5

15.0

141.2

35.3

3.1

0.12

80x6

8.0

0.6

17.8

163.1

40.7

3.0

0.14

100x3

10.0

0.3

11.6

182.7

36.5

4.0

0.09

100x4

10.0

0.4

15.4

236.3

47.2

3.9

0.12

100x5

10.0

0.5

19.0

286.5

57.3

3.9

0.15

100x6

10.0

0.6

22.6

333.5

66.7

2.8

0.18

120x3

12.0

0.3

14.0

320.5

53.4

4.8

0.11

120x4

12.0

0.4

18.6

416.7

69.4

4.7

0.15

120x5

12.0

0.5

23.0

507.9

84.6

4.7

0.18

120x6

12.0

0.6

27.4

594.2

99.0

4.7

0.21

140x4

14.0

0.4

21.8

671.3

95.9

5.6

0.17

140x5

14.0

0.5

27.0

821.2

117.3

5.5

0.21

140x6

14.0

0.6

32.2

964.3

137.7

5.5

0.25

140x7

14.0

0.7

37.2

1100.9

157.2

5.4

0.29

140x8

14.0

0.8

42.2

1231.1

175.8

5.4

0.33

160x4

16.0

0.4

25.0

1013.0

126.6

6.4

0.20

160x5

16.0

0.5

31.0

1242.5

155.3

6.3

0.24

160x6

16.0

0.6

37.0

1463.1

182.8

6.3

0.29

160x7

16.0

0.7

42.8

1674.9

209.3

6.3

0.34

160x8

16.0

0.8

48.6

1878.1

234.7

6.2

0.38

180x5

18.0

0.5

35.0

1787.9

198.6

7.2

0.27

180x6

18.0

0.6

41.8

2109.7

234.4

7.1

0.33

180x7

18.0

0.7

48.4

2420.2

268.9

7.1

0.38

180x8

18.0

0.8

55.0

2719.7

302.1

7.0

0.43

Профиль

h

b

s

A

Iy

Wy

Iz

Wz

P

см

см

см

см2

см4

см3

см4

см3

кг/см

15x10x1

1.5

1.0

0.1

0.5

0.1

0.1

0.1

0.2

0.00

15x10x1.5

1.5

1.0

0.2

0.7

0.1

0.2

0.2

0.2

0.01

15x10x2

1.5

1.0

0.2

0.8

0.1

0.2

0.2

0.3

0.01

20x10x1

2.0

1.0

0.1

0.6

0.1

0.2

0.3

0.3

0.00

20x10x1.5

2.0

1.0

0.2

0.8

0.1

0.2

0.4

0.4

0.01

20x10x2

2.0

1.0

0.2

1.0

0.1

0.3

0.5

0.5

0.01

20x15x1

2.0

1.5

0.1

0.7

0.2

0.3

0.4

0.4

0.01

20x15x1.5

2.0

1.5

0.2

1.0

0.3

0.4

0.5

0.5

0.01

20x15x2

2.0

1.5

0.2

1.3

0.4

0.5

0.6

0.6

0.01

20x15x2.5

2.0

1.5

0.3

1.5

0.4

0.6

0.7

0.7

0.01

25x10x1

2.5

1.0

0.1

0.7

0.1

0.2

0.5

0.4

0.01

25x10x1.5

2.5

1.0

0.2

1.0

0.1

0.3

0.7

0.5

0.01

25x10x2

2.5

1.0

0.2

1.2

0.2

0.3

0.8

0.7

0.01

25x10x2.5

2.5

1.0

0.3

1.5

0.2

0.4

1.0

0.8

0.01

25x15x1

2.5

1.5

0.1

0.8

0.3

0.4

0.6

0.6

0.01

25x15x1.5

2.5

1.5

0.2

1.1

0.4

0.5

0.9

0.7

0.01

25x15x2

2.5

1.5

0.2

1.4

0.5

0.6

1.1

0.9

0.01

25x15x2.5

2.5

1.5

0.3

1.8

0.5

0.7

1.3

1.0

0.01

28x25x1.5

2.8

2.5

0.2

1.5

1.4

1.1

1.7

1.2

0.01

30x10x1.5

3.0

1.0

0.2

1.1

0.2

0.3

1.1

0.7

0.01

30x10x2

3.0

1.0

0.2

1.4

0.2

0.4

1.4

0.9

0.01

30x10x2.5

3.0

1.0

0.3

1.8

0.2

0.4

1.6

1.1

0.01

30x10x3

3.0

1.0

0.3

2.0

0.2

0.5

1.8

1.2

0.02

30x15x1

3.0

1.5

0.1

0.9

0.3

0.4

1.0

0.7

0.01

30x15x1.5

3.0

1.5

0.2

1.3

0.5

0.6

1.4

0.9

0.01

30x15x2

3.0

1.5

0.2

1.6

0.6

0.7

1.8

1.2

0.01

30x15x2.5

3.0

1.5

0.3

2.0

0.6

0.8

2.1

1.4

0.02

30x15x3

3.0

1.5

0.3

2.3

0.7

0.9

2.3

1.5

0.02

30x20x1

3.0

2.0

0.1

1.0

0.6

0.6

1.2

0.8

0.01

30x20x1.5

3.0

2.0

0.2

1.4

0.9

0.9

1.7

1.1

0.01

30x20x2

3.0

2.0

0.2

1.8

1.1

1.1

2.2

1.4

0.01

30x20x2.5

3.0

2.0

0.3

2.2

1.3

1.3

2.5

1.7

0.02

30x20x3

3.0

2.0

0.3

2.6

1.5

1.5

2.9

1.9

0.02

30x10x1

3.0

1.0

0.1

0.8

0.1

0.3

0.8

0.5

0.01

35x15x2

3.5

1.5

0.2

1.8

0.6

0.9

2.6

1.5

0.01

35x15x2.5

3.5

1.5

0.3

2.2

0.7

1.0

3.1

1.8

0.02

35x15x3

3.5

1.5

0.3

2.6

0.8

1.1

3.5

2.0

0.02

35x15x3.5

3.5

1.5

0.3

3.0

0.9

1.1

3.9

2.2

0.02

35x20x1.5

3.5

2.0

0.2

1.6

1.0

1.0

2.5

1.4

0.01

35x20x2

3.5

2.0

0.2

2.0

1.1

1.3

3.2

1.8

0.02

35x20x2.5

3.5

2.0

0.3

2.5

1.5

1.5

3.8

2.2

0.02

35x20x3

3.5

2.0

0.3

2.9

1.7

1.7

4.3

2.5

0.02

35x20x3.5

3.5

2.0

0.3

3.3

1.8

1.8

4.8

2.7

0.03

35x25x1.5

3.5

2.5

0.2

1.7

1.7

1.4

2.9

1.7

0.01

35x25x2

3.5

2.5

0.2

2.2

2.2

1.7

3.7

2.1

0.02

35x25x2.5

3.5

2.5

0.3

2.8

2.5

2.0

4.4

2.5

0.02

35x25x3

3.5

2.5

0.3

3.2

2.9

2.3

5.1

2.9

0.03

35x25x3.5

3.5

2.5

0.3

3.7

3.2

2.5

5.6

3.2

0.03

35x15x1.5

3.5

1.5

0.2

1.4

0.5

0.7

2.1

1.2

0.01

40x15x2.5

4.0

1.5

0.3

2.5

0.8

1.1

4.4

2.2

0.02

40x15x3

4.0

1.5

0.3

2.9

0.9

1.2

5.1

2.5

0.02

40x15x3.5

4.0

1.5

0.3

3.3

1.0

1.3

5.6

2.8

0.03

40x15x4

4.0

1.5

0.4

3.8

1.0

1.4

6.1

3.0

0.03

Профиль

h

b

s

A

Iy

Wy

Iz

Wz

P

см

см

см

см2

см4

см3

см4

см3

кг/см

40x20x2

4.0

2.0

0.2

2.2

1.4

1.4

4.4

2.2

0.02

40x20x2.5

4.0

2.0

0.3

2.8

1.7

1.7

5.3

2.7

0.02

40x20x3

4.0

2.0

0.3

3.2

1.9

1.9

6.1

3.0

0.03

40x20x3.5

4.0

2.0

0.3

3.7

2.1

2.1

7.8

3.4

0.03

40x20x4

4.0

2.0

0.4

4.2

2.2

2.2

7.4

3.7

0.03

40x25x2

4.0

2.5

0.2

2.4

2.4

1.9

5.2

2.6

0.02

40x25x2.5

4.0

2.5

0.3

3.0

2.9

2.3

6.2

3.1

0.02

40x25x3

4.0

2.5

0.3

3.5

3.3

2.6

7.1

3.5

0.03

40x25x3.5

4.0

2.5

0.3

4.1

3.6

2.9

7.9

4.0

0.03

40x25x4

4.0

2.5

0.4

4.6

3.9

3.1

8.7

4.3

0.04

40x30x2

4.0

3.0

0.2

2.6

3.7

2.5

5.9

2.9

0.02

40x30x2.5

4.0

3.0

0.3

3.2

4.4

3.0

7.1

3.5

0.03

40x30x3

4.0

3.0

0.3

3.8

5.1

3.4

8.1

4.1

0.03

40x30x3.5

4.0

3.0

0.3

4.4

5.7

3.8

9.1

4.6

0.03

40x30x4

4.0

3.0

0.4

4.9

6.2

4.1

10.0

5.0

0.04

40x15x2

4.0

1.5

0.2

2.0

0.7

1.0

3.7

1.9

0.02

40x28x1.5

4.0

2.8

0.2

2.0

2.5

1.8

4.4

2.2

0.02

42x20x2

4.2

2.0

0.2

2.3

1.5

1.5

5.0

2.4

0.02

42x20x2.5

4.2

2.0

0.3

2.8

1.8

1.8

6.0

2.9

0.02

42x20x3

4.2

2.0

0.3

3.3

2.0

2.0

6.9

3.3

0.03

42x20x3.5

4.2

2.0

0.3

3.8

2.2

2.2

7.7

3.7

0.03

42x20x4

4.2

2.0

0.4

4.3

2.3

2.3

8.4

4.0

0.03

42x30x2

4.2

3.0

0.2

2.7

3.9

2.6

6.6

3.2

0.02

42x30x2.5

4.2

3.0

0.3

3.3

4.6

3.1

8.0

3.8

0.03

42x30x3

4.2

3.0

0.3

4.0

5.3

3.5

9.2

4.4

0.03

42x30x3.5

4.2

3.0

0.3

4.6

5.9

3.9

10.3

4.9

0.04

42x30x4

4.2

3.0

0.4

5.1

6.4

4.3

11.3

5.4

0.04

45x20x3

4.5

2.0

0.3

3.5

2.1

2.1

8.3

3.7

0.03

45x20x3.5

4.5

2.0

0.3

4.1

2.3

2.3

9.2

4.1

0.03

45x20x4

4.5

2.0

0.4

4.6

2.5

2.5

10.1

4.5

0.04

45x30x2

4.5

3.0

0.2

2.8

4.1

2.7

7.8

3.5

0.02

45x30x2.5

4.5

3.0

0.3

3.5

4.9

3.3

9.4

4.2

0.03

45x30x3

4.5

3.0

0.3

4.1

5.6

3.8

10.9

4.8

0.03

45x30x3.5

4.5

3.0

0.3

4.8

6.3

4.2

12.3

5.4

0.04

45x30x4

4.5

3.0

0.4

5.3

6.8

4.6

13.5

6.0

0.04

45x20x2

4.5

2.0

0.2

2.4

1.6

1.6

6.0

2.7

0.02

45x20x2.5

4.5

2.0

0.3

3.0

1.9

1.9

7.2

3.2

0.02

50x25x3

5.0

2.5

0.3

4.1

4.0

3.2

12.6

5.0

0.03

50x25x3.5

5.0

2.5

0.3

4.8

4.4

3.5

14.1

5.6

0.04

50x25x4

5.0

2.5

0.4

5.3

4.8

3.8

15.5

6.2

0.04

50x30x2

5.0

3.0

0.2

3.0

4.5

3.0

10.2

4.1

0.02

50x30x2.5

5.0

3.0

0.3

3.8

5.4

3.6

12.3

4.9

0.03

50x30x3

5.0

3.0

0.3

4.4

6.2

4.1

14.2

5.7

0.03

50x30x3.5

5.0

3.0

0.3

5.1

6.9

4.6

16.0

6.4

0.04

50x30x4

5.0

3.0

0.4

5.8

7.5

5.0

17.7

7.1

0.05

50x35x2

5.0

3.5

0.2

3.2

6.4

3.7

11.3

4.5

0.03

50x35x2.5

5.0

3.5

0.3

4.0

7.7

4.4

13.7

5.5

0.03

50x35x3

5.0

3.5

0.3

4.7

8.9

5.1

15.9

6.3

0.04

50x35x3.5

5.0

3.5

0.3

5.4

10.0

5.7

17.9

7.2

0.04

50x35x4

5.0

3.5

0.4

6.2

11.0

6.3

19.8

7.9

0.05

50x40x2

5.0

4.0

0.2

3.4

8.8

4.4

12.5

5.0

0.03

50x40x2.5

5.0

4.0

0.3

4.3

10.6

5.3

15.1

6.0

0.03

50x40x3

5.0

4.0

0.3

5.0

12.3

6.1

17.5

7.0

0.04

Профиль

h

b

s

A

Iy

Wy

Iz

Wz

P

см

см

см

см2

см4

см3

см4

см3

кг/см

50x40x3.5

5.0

4.0

0.3

5.8

13.8

6.9

19.8

7.9

0.05

50x40x4

5.0

4.0

0.4

6.6

15.2

7.6

21.9

8.8

0.05

50x25x2.5

5.0

2.5

0.3

3.5

3.5

2.8

10.8

4.3

0.03

50x25x2

5.0

2.5

0.2

2.8

3.0

2.4

90.1

3.6

0.02

60x25x3.5

6.0

2.5

0.3

5.4

5.2

4.2

22.7

7.6

0.04

60x25x4

6.0

2.5

0.4

6.2

5.7

4.5

25.1

8.4

0.05

60x25x5

6.0

2.5

0.5

7.5

6.4

5.1

29.4

9.8

0.06

60x30x2.5

6.0

3.0

0.3

4.3

6.3

4.2

19.3

6.4

0.03

60x30x3

6.0

3.0

0.3

5.0

7.3

4.8

22.5

7.5

0.04

60x30x3.5

6.0

3.0

0.3

5.8

8.1

5.4

25.5

8.5

0.05

60x30x4

6.0

3.0

0.4

6.6

8.9

5.9

28.2

9.4

0.05

60x30x5

6.0

3.0

0.5

8.0

10.2

6.8

33.2

11.1

0.06

60x40x3

6.0

4.0

0.3

5.6

14.3

7.2

27.4

9.1

0.04

60x40x3.5

6.0

4.0

0.3

6.5

16.1

8.1

31.0

10.4

0.05

60x40x4

6.0

4.0

0.4

7.3

17.8

8.9

34.5

11.5

0.06

60x40x5

6.0

4.0

0.5

9.0

20.8

10.4

40.7

13.6

0.07

60x25x3

6.0

2.5

0.3

4.7

4.7

3.8

20.1

6.7

0.04

60x25x2.5

6.0

2.5

0.3

4.0

4.1

3.3

17.3

5.8

0.03

70x30x3

7.0

3.0

0.3

5.6

8.4

5.6

33.3

9.5

0.04

70x30x5

7.0

3.0

0.5

9.0

11.7

7.8

49.7

14.2

0.07

70x30x6

7.0

3.0

0.6

10.6

12.9

8.6

56.5

16.1

0.08

70x40x3

7.0

4.0

0.3

6.2

16.4

8.2

40.0

11.4

0.05

70x40x3.5

7.0

4.0

0.3

7.2

18.5

9.2

45.6

13.0

0.06

70x40x4

7.0

4.0

0.4

8.1

20.4

10.2

50.8

14.5

0.06

70x40x5

7.0

4.0

0.5

10.0

23.8

11.9

60.3

17.2

0.08

70x40x6

7.0

4.0

0.6

11.8

26.7

13.4

68.8

19.6

0.09

70x50x3

7.0

5.0

0.3

6.8

27.5

11.0

46.8

13.4

0.05

70x50x3.5

7.0

5.0

0.3

7.9

31.2

12.5

53.3

15.2

0.06

70x50x4

7.0

5.0

0.4

8.9

34.6

13.9

59.5

17.0

0.07

70x50x5

7.0

5.0

0.5

11.0

40.9

16.4

70.9

20.3

0.09

70x50x6

7.0

5.0

0.6

13.0

46.4

18.5

81.1

23.2

0.10

70x30x3.5

7.0

3.0

0.3

6.5

9.4

6.2

37.8

10.8

0.05

70x30x4

7.0

3.0

0.4

7.3

10.2

6.8

42.0

12.0

0.06

70x50x7

7.0

5.0

0.7

14.8

51.1

20.4

90.2

25.8

0.12

80x40x5

8.0

4.0

0.5

11.0

26.9

13.4

84.9

21.2

0.09

80x40x6

8.0

4.0

0.6

13.0

30.2

15.1

97.3

24.3

0.10

80x40x7

8.0

4.0

0.7

14.8

33.0

16.5

108.3

27.1

0.12

80x50x3

8.0

5.0

0.3

7.4

30.8

12.3

64.8

16.2

0.06

80x50x3.5

8.0

5.0

0.3

8.6

35.0

14.0

73.9

18.5

0.07

80x50x4

8.0

5.0

0.4

9.8

38.9

15.6

82.7

20.7

0.08

80x60x3.5

8.0

6.0

0.3

9.3

53.4

17.8

84.2

21.0

0.07

80x60x4

8.0

6.0

0.4

10.6

59.6

19.9

94.3

23.6

0.08

80x60x5

8.0

6.0

0.5

13.0

71.1

23.7

113.0

28.3

0.10

80x60x6

8.0

6.0

0.6

15.4

81.3

27.1

130.2

32.5

0.12

80x60x7

8.0

6.0

0.7

17.6

90.5

30.1

145.7

36.4

0.14

80x40x3.5

8.0

4.0

0.3

7.9

20.8

10.4

63.7

15.9

0.06

80x40x4

8.0

4.0

0.4

9.0

23.0

11.5

71.1

17.8

0.07

80x40x3

8.0

4.0

0.3

6.8

18.4

9.2

55.8

14.0

0.05

90x40x6

9.0

4.0

0.6

14.2

33.7

16.9

132.2

29.4

0.11

90x40x7

9.0

4.0

0.7

16.2

36.9

18.4

147.8

32.9

0.13

90x60x4

9.0

6.0

0.4

11.4

65.9

22.0

125.5

27.9

0.09

90x60x5

9.0

6.0

0.5

14.0

78.7

26.2

151.1

33.6

0.11

90x60x6

9.0

6.0

0.6

16.6

90.1

30.0

174.6

38.8

0.13
