Section I λ General Principles
In A Nutshell
Key ANS Receptors
M1, M3, α1:
Gq activation of phospholipase C
M2, α2, D2:
Gi inhibition of adenylyl cyclase
β1, β2, D1:
Gs activation of adenylyl cyclase
Receptors Linked Via Coupling Proteins to Intracellular Effectors
λMany receptor systems are coupled via GTP-binding proteins (G-proteins) to adenylyl cyclase, the enzyme that converts ATP to cAMP, a second messenger that promotes protein phosphorylation by activating protein kinase A. These receptors are typically “serpentine,” with seven transmembrane spanning domains, the third of which is coupled to the G-protein effector mechanism.
λProtein kinase A serves to phosphorylate a set of tissue-specific substrate enzymes or transcription factors (CREB), thereby affecting their activity.
GS PROTEINS
λBinding of agonists to receptors linked to Gs proteins increases cAMP production.
λSuch receptors include those for catecholamines (beta), dopamine (D1), glucagon, histamine (H2), prostacyclin, and some serotonin subtypes.
GI PROTEINS
λBinding of agonists to receptors linked to Gi proteins decreases cAMP production.
λSuch receptors include adrenoreceptors (alpha2), ACh (M2), dopamine (D2 subtypes), and several opioid and serotonin subtypes.
GQ PROTEINS
λOther receptor systems are coupled via GTP-binding proteins (Gq), which activate phospholipase C. Activation of this enzyme releases the
second messengers inositol triphosphate (IP3) and diacylglycerol (DAG) from the membrane phospholipid phosphatidylinositol bisphosphate
(PIP2). The IP3 induces release of Ca2+ from the sarcoplasmic reticulum (SR), which, together with DAG, activates protein kinase C. The protein kinase C serves then to phosphorylate a set of tissue-specific substrate enzymes, usually not phosphorylated by protein kinase A, and thereby affects their activity.
λThese signaling mechanisms are invoked following activation of recep-
tors for ACh (M1 and M3), norepinephrine (alpha1), angiotensin II, and several serotonin subtypes.
24
|
|
|
|
|
|
|
|
|
|
|
Chapter 2 λ |
Pharmacodynamics |
|||
Receptors for: |
cAMP System |
|
|
|
|
|
PIP2 System |
|
|
|
|
||||
β1, |
NH2 |
|
|
|
|
|
NH2 |
Receptors for: |
|
|
|
|
|||
• Catecholamines |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
• Catecholamines α |
|
|||||||||
|
|
|
|
|
|
|
|
||||||||
β2 (Gs), α2 (Gi) |
|
|
|
|
|
|
|
• Acetylcholine M |
M1 |
|
|||||
• Acetylcholine M2 |
(Gi) |
|
|
|
|
|
|
• Angiotensin II |
|
1 |
3 |
|
|||
• Glucagon (Gs) |
|
|
|
|
|
|
|
|
• Vasopressin |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
PIP2 |
|
|
DAG |
|
|
|
|
α |
|
β |
Adenyl |
ATP |
|
α |
β |
Phospho- |
|
|
Ca2+ |
Protein |
|
|
COOH |
γ |
Cyclase |
COOH |
γ |
lipase C |
|
|
kinase C |
|||||
|
|
|
|
|
|
IP3 |
|
|
|
|
|||||
|
|
G protein |
|
|
Gq |
|
|
|
|
||||||
|
|
CREB |
(Gs |
orGi) |
cAMP |
|
|
|
|
|
|
|
|
|
|
|
|
|
+ |
|
|
|
|
SR |
Ca2+ |
|
|
|
|
|
|
|
|
|
|
|
|
+ |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Gene |
|
|
|
CREB |
P |
|
Protein kinase A |
|
|
|
Ca2+ |
|
|
|
|||
|
|
|
|
|
|
|
|
|
expression |
||||||
|
|
|
|
|
|
|
|
|
|
|
Calmodulin |
|
|
|
|
|
|
CREB |
P |
|
|
|
|
|
|
|
|
|
|
+ |
|
|
|
+1 |
|
|
|
|
|
+ (Protein kinases) |
|
||||||
|
|
CRE |
Gene |
|
|
Proteins |
|
|
|
|
Proteins P |
||||
|
|
|
+ |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
dephosphorylated |
phosphorylated |
||||||
Gene expression in nucleus |
|
|
|
|
|
(Protein |
|
|
|
|
|||||
|
|
|
|
phosphatases) |
|
|
|||||||||
Figure I-2-6.Receptors Using Cyclic AMP and IP3, DAG, Ca2+ as Second Messengers
Cyclic GMP and Nitric Oxide Signaling
λcGMP is a second messenger in vascular smooth muscle that facilitates dephosphorylation of myosin light chains, preventing their interaction with actin and thus causing vasodilation.
λNitric oxide (NO) is synthesized in endothelial cells and diffuses into smooth muscle.
λNO activates guanylyl cyclase, thus increasing cGMP in smooth muscle.
λVasodilators ↑ synthesis of NO by endothelial cells.
Receptors That Function as Enzymes or Transporters
λThere are multiple examples of drug action that depend on enzyme inhibition, including inhibitors of acetylcholinesterase, angiotensinconverting enzyme, aspartate protease, carbonic anhydrase, cyclooxygenases, dihydrofolate reductase, DNA/RNA polymerases, monoamine oxidases, Na/K-ATPase, neuraminidase, and reverse transcriptase.
λExamples of drug action on transporter systems include the inhibitors of reuptake of several neurotransmitters, including dopamine, GABA, norepinephrine, and serotonin.
Bridge to Biochemistry
See Chapter 9 of the Biochemistry Lecture Notes for additional discussion of signal transduction.
Clinical Correlate
Drugs acting via NO include nitrates (e.g., nitroglycerin) and M-receptor agonists (e.g., bethanechol).
Endogenous compounds acting via NO include bradykinin and histamine.
25
Section I λ General Principles
Clinical Correlate
Imatinib is a specific tyrosine-kinase (TK) inhibitor, while sorafenib is a non-specific TK inhibitor.
Receptors That Function as Transmembrane Enzymes
λThese receptors mediate the first steps in signaling by insulin and growth factors, including epidermal growth factor (EGF) and platelet-derived growth factor (PDGF). They are membrane-spanning macromolecules with recognition sites for the binding of insulin and growth factors located externally and a cytoplasmic domain that usually functions as a tyrosine kinase. Binding of the ligand causes conformational changes (e.g., dimerization) so that the tyrosine kinase domains become activated, ultimately leading to phosphorylation of tissue-specific substrate proteins.
λGuanyl cyclase−associated receptors: stimulation of receptors to atrial natriuretic peptide activates the guanyl cyclase and ↑ cyclic GMP (cGMP)
Receptors for Cytokines
λThese include the receptors for erythropoietin, somatotropin, and interferons.
λTheir receptors are membrane spanning and on activation can activate a distinctive set of cytoplasmic tyrosine kinases (Janus kinases [JAKs]).
λJAKs phosphorylate signal transducers and activators of transcription (STAT) molecules.
λSTATs dimerize and then dissociate, cross the nuclear membrane, and modulate gene transcription.
26
Chapter 2 λ Pharmacodynamics
DRUG DEVELOPMENT AND TESTING
The Food and Drug Administration (FDA)
The FDA regulates both the efficacy and safety of drugs but not of foods, nutritional supplements, and herbal remedies.
Table I-2-1. Drug Development and Testing
Preclinical |
Phase 1 |
Phase 2 |
Phase 3 |
Phase 4 |
Two different |
~50 |
~200 |
~2,000 |
Post- |
animal species |
healthy |
patients |
patients |
marketing |
|
volunteers |
|
|
surveillance |
|
|
|
|
(after FDA |
|
|
|
|
approval) |
Safety and bio- |
Safety and |
Evaluate |
Confirm |
Common as |
logic activity |
dosage |
effectiveness |
effectiveness, |
well as rare |
|
|
|
common side- |
side effects |
|
|
|
effects |
|
|
|
|
|
|
Teratogenicity
λThe FDA has classified drugs into five categories (A, B, C, D, and X).
λClass A has no risks, and Class X designates absolute contraindication.
λIt is based on animal studies and, when available, human studies.
λIn Class D, benefits outweigh the risk.
Table I-2-2. FDA Classification of Drugs and Pregnancy
|
|
|
Risk |
Category |
|
|
|
|
Animals |
Humans |
|
|
|
||
A |
|
– |
– |
B |
|
+/– |
–/o |
C |
|
+/o |
o |
D |
+ |
+ |
|
X |
+ |
+ |
|
– = Studies have proven absense of teratogenicity; o = no studies available;
+ = studies have proven teratogenicity
27
Section I λ General Principles
Chapter Summary
λPlots of dose or log dose against response to a drug (agonist) can be used to assess the drug’s affinity to a receptor, its potency (the amount of drug required to achieve half its maximal effect), and its efficacy (the maximal effect).
λFull agonists achieve full efficacy; partial agonists do not. Therefore, when a partial agonist is added to a system in which a full agonist is acting at its maximal efficacy, the partial agonist acts as a competitive inhibitor, as if it were an antagonist. These effects can be studied graphically.
λAntagonists are compounds which inhibit the activity of an agonist but have no effect of their own. Generally, antagonists act competitively by sharing a binding site on the receptor, but some act noncompetitively. Whether an antagonist acts competitively or noncompetitively can also be determined graphically.
λAntagonism may be pharmacologic (shared receptor), physiologic (acting on different systems having opposing physiologic responses), or chemical.
λSome effector molecules potentiate (i.e., enhance) the effect of an agonist.
λQuantal curves are plots of the percentage of a population responding to a specific drug versus the concentration (or log concentration) of that drug. They are used to gauge the median effective pharmacological dose (ED50) or the median toxic dose (TD50). These values can be used to evaluate the relative safety of a drug (the therapeutic index).
λDrugs may act on intracellular receptors, membrane receptors directly coupled to ion channels, receptors linked via coupling proteins to intracellular effectors, receptors influencing cGMP and nitric oxide signaling, receptors that function as enzymes or transporters, receptors that function as transmembrane enzymes, or receptors for cytokines.
λThe FDA regulates the efficacy and safety of drugs but not of foods, herbs, or nutritional supplements. Before being approved by the FDA, a drug must first undergo preclinical animal studies and then phase 1, 2, 3, and 4 clinical studies. The FDA also classifies drugs and their relative risks of teratogenicity during pregnancy.
28
