DICOM PS3.16 2020a - Content Mapping Resource​

Page 651​

The base terms from those hierarchies are included in the table below for reference. The per lead base terms are pre-coordinated​ with concept discriminators for specific leads, and the code values for those pre-coordinated terms are arithmetically derived from​ the code values of the base terms. For the complete current list of terms and discriminator values, see the ISO/IEEE Standard. All​ pre-coordinated terms (measurements plus discriminators) within the identified hierarchies are part of this Context Group.​

Note​

1.​A prior version of this context group used codes from the SCP-ECG coding system.​

2.​Codes reprinted by permission of IEEE, Copyright 2004 by IEEE. ISO/IEEE 11073-10102 available through http://​ standards.ieee.org/.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20110330​

UID:​

1.2.840.10008.6.1.202​

Table CID 3688. Electrophysiology Waveform Voltages​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent​

Designator​





Reference ID (Informative)​

MDC​

2:1024​

J point Amplitude, per lead​

MDC_ECG_AMPL_J​

MDC​

2:14848​

Amplitude at 20 ms into ST segment, per​MDC_ECG_ELEC_POTL_ST_20​





lead​



MDC​

2:15104​

Amplitude at 40 ms into ST segment, per​MDC_ECG_ELEC_POTL_ST_40​





lead​



MDC​

2:14336​

Amplitude at 60 ms into ST segment, per​MDC_ECG_ELEC_POTL_ST_60​





lead​



MDC​

2:14592​

Amplitude at 80 ms into ST segment, per​MDC_ECG_ELEC_POTL_ST_80​





lead​



MDC​

2:1280​

P maximum amplitude, per lead​

MDC_ECG_AMPL_P_MAX​

MDC​

2:1536​

P minimum amplitude, per lead​

MDC_ECG_AMPL_P_MIN​

MDC​

2:3072​

P3 amplitude, per lead​

MDC_ECG_AMPL_P3​

MDC​

2:1792​

Q amplitude, per lead​

MDC_ECG_AMPL_Q​

MDC​

2:2048​

R amplitude, per lead​

MDC_ECG_AMPL_R​

MDC​

2:12800​

R1 amplitude, per lead​

MDC_ECG_ELEC_POTL_R_1​

MDC​

2:13056​

R2 amplitude, per lead​

MDC_ECG_ELEC_POTL_R_2​

MDC​

2:13312​

R3 amplitude, per lead​

MDC_ECG_ELEC_POTL_R_3​

MDC​

2:2304​

S amplitude, per lead​

MDC_ECG_AMPL_S​

MDC​

2:13568​

S1 amplitude, per lead​

MDC_ECG_ELEC_POTL_S_1​

MDC​

2:13824​

S2 amplitude, per lead​

MDC_ECG_ELEC_POTL_S_2​

MDC​

2:14080​

S3 amplitude, per lead​

MDC_ECG_ELEC_POTL_S_3​

MDC​

2:2560​

T maximum amplitude, per lead​

MDC_ECG_AMPL_T_MAX​

MDC​

2:2816​

T minimum amplitude, per lead​

MDC_ECG_AMPL_T_MIN​

MDC​

2:768​

ST amplitude, per lead​

MDC_ECG_AMPL_ST​

CID 3689 ECG Global Waveform Durations​

This Context Group consists of the global terms under the hierarchy of Reference ID MDC_ECG_TIME_PD in the ISO/IEEE 11073-​ 10102 nomenclature.​

- Standard -​

Page 652​

DICOM PS3.16 2020a - Content Mapping Resource​

Thebasetermsfromthathierarchyareincludedinthetablebelowforreference.Thebasetermsmaybepre-coordinatedwithconcept​ discriminators,andthecodevaluesforthosepre-coordinatedtermsarearithmeticallyderivedfromthecodevaluesofthebaseterms.​ Forthecompletecurrentlistoftermsanddiscriminatorvalues,seetheISO/IEEEStandard.Allpre-coordinatedterms(measurements​ plus discriminators) within the identified hierarchy are part of this Context Group.​

Note​

Codes reprinted by permission of IEEE, Copyright 2004 by IEEE. ISO/IEEE 11073-10102 available through http://​ standards.ieee.org/.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20110330​

UID:​

1.2.840.10008.6.1.927​

Table CID 3689. ECG Global Waveform Durations​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent Reference​

Designator​





ID (Informative)​

MDC​

2:16184​

P duration, global​

MDC_ECG_TIME_PD_P_GL​

MDC​

2:16140​

PP time period, global​

MDC_ECG_TIME_PD_PP_GL​

MDC​

2:16144​

PQ time period, global​

MDC_ECG_TIME_PD_PQ_GL​

MDC​

2:15872​

PR time period, global​

MDC_ECG_TIME_PD_PR_GL​

MDC​

2:16148​

PQ segment time period, global​

MDC_ECG_TIME_PD_PQ_SEG_GL​

MDC​

2:16156​

QRS duration, global​

MDC_ECG_TIME_PD_QRS_GL​

MDC​

2:16160​

QT duration, global​

MDC_ECG_TIME_PD_QT_GL​

MDC​

2:16000​

RR time period, global​

MDC_ECG_TIME_PD_RR_GL​

MDC​

2:16004​

QTU time period, global​

MDC_ECG_TIME_PD_QTU_GL​

CID 3690 ECG Control Variables Numeric​

ThisContextGroupincludestheECGcontrolvariablesspecifiedintheISO/IEEE11073-10102nomenclaturethattakenumericvalues.​

Thetermsareincludedinthetablebelowforreference;thesemaynotconstitutethecompletecurrentlist(seetheISO/IEEEStandard).​

Note​

Codes reprinted by permission of IEEE, Copyright 2004 by IEEE. ISO/IEEE 11073-10102 available through http://​ standards.ieee.org/.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20110330​

UID:​

1.2.840.10008.6.1.895​

Table CID 3690. ECG Control Variables Numeric​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE11073MDCEquivalentReferenceID(Informative)​

Designator​







MDC​

10:11393​

Sample rate​

MDC_ECG_CTL_VBL_SAMPLE_RATE​

MDC​

10:11394​

Sensitivity​

MDC_ECG_CTL_VBL_SENSITIVITY​

MDC​

10:11395​

Zero offset​

MDC_ECG_CTL_VBL_ZERO_OFFSET​

MDC​

10:11397​

Pad value​

MDC_ECG_CTL_VBL_PAD_VALUE​

MDC​

10:11398​

Time skew​

MDC_ECG_CTL_VBL_TIME_SKEW​

MDC​

10:11399​

Sample skew​

MDC_ECG_CTL_VBL_SAMPLE_SKEW​

- Standard -​





DICOM PS3.16 2020a - Content Mapping Resource​

Page 653​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE11073MDCEquivalentReferenceID(Informative)​

Designator​









MDC​

10:11400​

Time offset​

MDC_ECG_CTL_VBL_TIME_OFFSET​



MDC​

10:11403​ Low pass filter cutoff freq​MDC_ECG_CTL_VBL_ATTR_FILTER_CUTOFF_FREQ​

MDC​

10:11408​

Notch filter frequency​

MDC_ECG_CTL_VBL_ATTR_FILTER_NOTCH_FREQ​

MDC​

10:11409​

Notch filter bandwidth​

MDC_ECG_CTL_VBL_ATTR_FILTER_NOTCH_BANDWIDTH​

MDC​

10:11418​

Interpolator SNR​

MDC_ECG_CTL_VBL_INTERPOLATOR_SNR​



CID 3691 ECG Control Variables Text​

This Context Group includes the ECG control variables specified in the ISO/IEEE 11073-10102 nomenclature that take text or coded​ values. The terms are included in the table below for reference; these may not constitute the complete current list (see the ISO/IEEE​ Standard).​

Note​

Codes reprinted by permission of IEEE, Copyright 2004 by IEEE. ISO/IEEE 11073-10102 available through http://​ standards.ieee.org/.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20110330​

UID:​

1.2.840.10008.6.1.896​

Table CID 3691. ECG Control Variables Text​

Coding Scheme​

Code Value​

Code Meaning​

ISO/IEEE 11073 MDC Equivalent Reference ID​

Designator​





(Informative)​

MDC​

10:11402​

Low pass filter​

MDC_ECG_CTL_VBL_ATTR_FILTER_LOW_PASS​

MDC​

10:11404​

High pass filter​

MDC_ECG_CTL_VBL_ATTR_FILTER_HIGH_PASS​

MDC​

10:11406​

High pass filter description​

MDC_ECG_CTL_VBL_ATTR_FILTER_DESCRIPTION​

MDC​

10:11407​

Notch filter​

MDC_ECG_CTL_VBL_ATTR_FILTER_NOTCH​

MDC​

10:11410​

Notch filter description​

MDC_ECG_CTL_VBL_ATTR_FILTER_NOTCH​







_DESCRIPTION​

MDC​

10:11412​

Baseline description​

MDC_ECG_CTL_VBL_BASELINE_DESC​

MDC​

10:11414​

Interpolator​

MDC_ECG_CTL_VBL_INTERPOLATOR​

MDC​

10:11416​

Interpolator description​

MDC_ECG_CTL_VBL_INTERPOLATOR_DESC​

CID 3692 ICDs​

ThisContextGroupincludesthefullsetofcodesfortypesofimplantedcardioverter/defibrillators(ICDs)specifiedintheNASPE/BPEG​ Defibrillator Code (NBD). The Coding Scheme Designator (0008,0102) shall be NBD.​

Note​

Further information at http://www.hrsonline.org/News/ep-history/topics-in-depth/modecodehistory.cfm. For reference, the​ scheme is reproduced here:​

Code Position​

Shock chamber​

Antitachycardia pacing​ Tachycardia detection​ Antibradycardia pacing​





chamber​

chamber​

- Standard -​

Page 654​

DICOM PS3.16 2020a - Content Mapping Resource​



Code values​ O = None​

O = None​

E = Electrogram​

O = None​

A = Atrium​

A = Atrium​

H = Hemodynamic​

A = Atrium​

V = Ventricle​

V = Ventricle​



V = Ventricle​

D = Dual (A+V)​

D = Dual (A+V)​



D = Dual (A+V)​

Short Form​

ICD-S = ICD with shock capability only​

ICD-B = ICD with bradycardia pacing as well as shock​

ICD-T = ICD with tachycardia (and bradycardia) pacing as well as shock​

CID 3700 Cath Diagnosis​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.203​

Table CID 3700. Cath Diagnosis​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique​

Designator​







ID​

SCT​

53741008​

Coronary artery disease​

D3-13040​

C1956346​

SCT​

57054005​

Acute myocardial infarction​

D3-15100​

C0155626​

SCT​

102589003​

Atypical chest pain​

F-37012​

C0262384​

SCT​

233819005​

Stable Angina​

D3-13020​

C0340288​

SCT​

87343002​

Atypical Angina, Variant Angina​

D3-12400​

C0002963​

SCT​

4557003​

Unstable Angina, Progressive​

D3-12700​

C0002965​





Angina​





SCT​

314116003​

Post-infarction angina​

D3-13014​

C1278535​

SCT​

371808007​

Recurrent angina Post-PTCA​

R-00368​

C1299436​

SCT​

371812001​

Recurrent angina Post-DCA​

R-00367​

C1299440​

SCT​

371811008​

Recurrent angina Post-Rotational​

R-00369​

C1299439​





Atherectomy​





SCT​

371809004​

Recurrent angina Post-Stent​

R-00366​

C1299437​

SCT​

371810009​

Recurrent angina Post-CABG​

R-00365​

C1299438​

SCT​

42343007​

Congestive heart failure​

D3-16010​

C0018802​

SCT​

19242006​

Pulmonary edema​

D2-61100​

C0034063​

SCT​

89138009​

cardiogenic shock​

D3-00200​

C0036980​

SCT​

371817007​

Acute ventricular septal rupture​

R-002CB​

C1299445​

SCT​

11851006​

Mitral valve disease​

D3-29010​

C0026265​

SCT​

79619009​

Mitral stenosis​

D3-29011​

C0026269​

SCT​

48724000​

Mitral regurgitation​

D3-29012​

C0026266​

SCT​

373116009​

Acute mitral regurgitation​

D3-29096​

C1298807​

SCT​

233823002​

Silent ischemia​

D3-13021​

C0340291​

SCT​

371824008​

s/p MI positive stress for ischemia​

R-00336​

C1300077​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 655​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique​

Designator​







ID​

SCT​

50920009​

Myocarditis​

D3-26000​

C0027059​

SCT​

73774007​

Subacute bacterial endocarditis​

D3-28102​

C0014122​

SCT​

360465008​

Idiopathic hypertrophic subaortic​

D3-2906A​

C0700053​





stenosis​





SCT​

70995007​

Pulmonary hypertension​

D3-40300​

C0020542​

SCT​

20721001​

Tricuspid valve disease​

D3-29040​

C0264882​

SCT​

111287006​

Tricuspid regurgitation​

D3-29042​

C0040961​

SCT​

409712001​

Mitral valve prolapse​

D3-1081C​

C0026267​

SCT​

25569003​

Ventricular tachycardia​

D3-31700​

C0042514​

SCT​

71908006​

Ventricular fibrillation​

D3-31720​

C0042510​

SCT​

399020009​

Congestive cardiomyopathy​

D3-20021​

C0007193​

SCT​

64715009​

Hypertensive heart disease​

D3-02500​

C0152105​

SCT​

90828009​

Restrictive cardiomyopathy​

D3-22100​

C0007196​

SCT​

55855009​

Pericardial disease​

D3-90000​

C0265122​

SCT​

35304003​

Pericardial tamponade​

D3-90100​

C0007177​

SCT​

8722008​

Aortic valve disease​

D3-29020​

C1260873​

SCT​

60573004​

Aortic stenosis​

D3-29021​

C0003507​

SCT​

194983005​

Aortic insufficiency​

D3-29025​

C0340377​

SCT​

70142008​

Atrial septal defect​

D4-31220​

C0018817​

SCT​

308546005​

Aortic dissection​

D3-80016​

C0340643​

SCT​

76267008​

Pulmonic valve disease​

D3-29050​

C0034087​

SCT​

30288003​

Ventricular septal defect​

D4-31150​

C0018818​

SCT​

67362008​

Aortic aneurysm​

D3-83300​

C0003486​

SCT​

698247007​

Arrhythmia​

R-FAE6C​

C0003811​

SCT​

49436004​

Atrial fibrillation​

D3-31520​

C0004238​

SCT​

13213009​

heart disease, congenital​

D4-31000​

C0152021​

SCT​

85598007​

Constrictive pericarditis​

D3-91030​

C0031048​

CID 3701 Cardiac Valves and Tracts​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​





Version:​

20030327​





UID:​

1.2.840.10008.6.1.204​







Table CID 3701. Cardiac Valves and Tracts​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

91134007​

Mitral Valve​

SCT​

34202007​

Aortic Valve​

SCT​

46030003​

Tricuspid valve​

SCT​

39057004​

Pulmonary valve​

SCT​

13418002​

Left ventricle outflow tract​

T-35300​

C0026264​

T-35400​

C0003501​

T-35100​

C0040960​

T-35200​

C0034086​

T-32650​

C0225912​

- Standard -​

Источник: https://studfile.net/preview/14585769/

Смотрите также:

08_Вероятн произведения событий
1
1 Кариес зубов Задача 1
1_9продолжАБРАКАДАБРА
144969
16.04.20 г. Определение цены и объёма сбыта
1655
16фз
2_5298781932820103487
20. Ступенчатая диссоциация многоосновных кислот и многокислотных оснований
