Page 726​ DICOM PS3.16 2020a - Content Mapping Resource​

CID 4050 Drug or Contrast Agent Characteristics​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20070124​

UID:​

1.2.840.10008.6.1.313​

Table CID 4050. Drug or Contrast Agent Characteristics​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​UMLSConceptUnique​

Designator​







ID​

SCT​

127489000​

Active Ingredient​

G-C52F​

C1292749​

DCM​

121380​

Active Ingredient Undiluted​









Concentration​





DCM​

121381​

Contrast/Bolus Ingredient Opaque​





SCT​

118565006​

Volume​

G-D705​

C0449468​

CID 4051 General Devices​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20160525​

UID:​

1.2.840.10008.6.1.314​



Table CID 4051. General Devices​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









Include CID 8 “Angiographic Interventional Devices”​





Include CID 3451

“Calibration Objects”​







Include CID 4052

“Phantom Devices”​







SCT​



61968008​

Syringe​

A-10150​

C0039142​

CID 4052 Phantom Devices​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20061023​

UID:​

1.2.840.10008.6.1.315​

Table CID 4052. Phantom Devices​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

113681​

Phantom​

DCM​

113682​

ACR Accreditation Phantom - CT​

DCM​

113683​

ACR Accreditation Phantom - MR​

DCM​

113684​

ACR Accreditation Phantom - Mammography​

DCM​

113685​

ACR Accreditation Phantom - Stereotactic Breast Biopsy​

DCM​

113686​

ACR Accreditation Phantom - ECT​

DCM​

113687​

ACR Accreditation Phantom - PET​

DCM​

113688​

ACR Accreditation Phantom - ECT/PET​

DCM​

113689​

ACR Accreditation Phantom - PET Faceplate​

- Standard -​





DICOM PS3.16 2020a - Content Mapping Resource​

Page 727​

Coding Scheme Designator​



Code Value​

Code Meaning​

DCM​



113690​

IEC Head Dosimetry Phantom​

DCM​



113691​

IEC Body Dosimetry Phantom​

DCM​



113692​

NEMA XR21-2000 Phantom​

CID 4100 T1 Measurement Methods​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​





Version:​

20141110​





UID:​

1.2.840.10008.6.1.985​









Table CID 4100. T1 Measurement Methods​



Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​



126350​

T1 by Multiple Flip Angles​

DCM​



126351​

T1 by Inversion Recovery​

DCM​



126352​

T1 by Fixed Value​

CID 4101 Tracer Kinetic Models​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​





Version:​

20160316​





UID:​

1.2.840.10008.6.1.986​









Table CID 4101. Tracer Kinetic Models​



Coding Scheme Designator​



Code Value​

Code Meaning​

DCM​



126340​

Standard Tofts Model​



DCM​



126341​

Extended Tofts Model​



DCM​



126343​

First Pass Leakage Profile (FPLP) Model​

DCM​



126344​

Shutter-Speed Model (SSM)​

DCM​



126345​

Gamma Capillary Transit Time (GCTT) Model​

DCM​



126346​

Adiabatic Tissue Homogeneity (ATH) Model​

DCM​



126347​

Two Compartment Exchange (2CX) Model​

CID 4102 Perfusion Measurement Methods​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​





Version:​

20141110​





UID:​

1.2.840.10008.6.1.987​







Table CID 4102. Perfusion Measurement Methods​

Coding Scheme Designator​



Code Value​

Code Meaning​

DCM​



126300​

Perfusion analysis by Stable Xenon CT technique​

DCM​



126301​

Perfusion analysis by IV Iodinated Contrast CT technique​

DCM​



126302​

Perfusion analysis by Arterial Spin Labeling MR technique​

DCM​



126303​

Perfusion analysis by Susceptibility MR technique​

- Standard -​

Page 728​ DICOM PS3.16 2020a - Content Mapping Resource​

CID 4103 Arterial Input Function Measurement Methods​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20141110​

UID:​

1.2.840.10008.6.1.988​

Table CID 4103. Arterial Input Function Measurement Methods​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

126360​

AIF Ignored​

DCM​

126361​

Population Averaged AIF​

DCM​

126362​

User-defined AIF ROI​

DCM​

126363​

Automatically Detected AIF ROI​

DCM​

126364​

Blind Estimation of AIF​

Note​

TheanatomiclocationrelevanttotheapplicationofanyAIFmethodisnotpre-coordinatedinconceptsinthisContextGroup.​ Typically these would be described by the Finding Site of any related measurements in the appropriate Template.​

CID 4104 Bolus Arrival Time Derivation Methods​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20141110​

UID:​

1.2.840.10008.6.1.989​

Table CID 4104. Bolus Arrival Time Derivation Methods​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

126373​

Temporal Derivative Exceeds Threshold​

DCM​

126370​

Time of Peak Concentration​

DCM​

126372​

Time of Leading Half-Peak Concentration​

CID 4105 Perfusion Analysis Methods​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20141110​

UID:​

1.2.840.10008.6.1.990​

Table CID 4105. Perfusion Analysis Methods​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

126310​

Least Mean Square (LMS) deconvolution​

DCM​

126311​

Singular Value Decomposition (SVD) deconvolution​

CID 4106 Quantitative Methods used for Perfusion And Tracer Kinetic Models​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20141110​

UID:​

1.2.840.10008.6.1.991​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 729​

Table CID 4106. Quantitative Methods used for Perfusion And Tracer Kinetic Models​

Coding Scheme Designator​

Code Value​



Code Meaning​

Include CID 4100 “T1 Measurement Methods”​







Include CID 4101 “Tracer Kinetic Models”​







Include CID 4102

“Perfusion Measurement Methods”​







Include CID 4103

“Arterial Input Function Measurement Methods”​





Include CID 4104

“Bolus Arrival Time Derivation Methods”​





Include CID 4105

“Perfusion Analysis Methods”​









DCM​

126342​

Model-free concentration-time quantitification​

Note​

1.​Concepts from this context group may be used in measurement Templates to describe the measurement method of​ measurement on an ROI.​

E.g., NUM (126312, DCM, "Ktrans") = 0.0185 /min; (370129005, SCT, "Measurement Method") = (126341, DCM, "Ex-​ tended Tofts Model")​

CID 4107 Tracer Kinetic Model Parameters​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20141110​

UID:​

1.2.840.10008.6.1.992​

Table CID 4107. Tracer Kinetic Model Parameters​

Coding Scheme Designator​

Code Value​

Code Meaning​

Units​

DCM​

126312​

Ktrans​

DT (/min, UCUM, "/min")​

DCM​

126313​

kep​

DT (/min, UCUM, "/min")​

DCM​

126314​

ve​

DT ({ratio}, UCUM, "ratio")​

DCM​

126330​

tau_m​

DT (s, UCUM, "s")​

DCM​

126331​

vp​

DT ({ratio}, UCUM, "ratio")​

CID 4108 Perfusion Model Parameters​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190326​

UID:​

1.2.840.10008.6.1.993​



Table CID 4108. Perfusion Model Parameters​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT​ UMLS​

Units​

Designator​





ID​

Concept​









UniqueID​

DCM​

126390​

AbsoluteRegionalBloodFlow​



DT (ml/(100.ml)/min, UCUM,​











"ml/(100.ml)/min")​

DT (ml/(100.g)/min, UCUM,​ "ml/(100.g)/min")​

- Standard -​

Page 730​



DICOM PS3.16 2020a - Content Mapping Resource​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT​ UMLS​

Units​

Designator​





ID​

Concept​









UniqueID​

DCM​

126391​

Absolute Regional Blood​





DT (ml/(100.ml), UCUM,​





Volume​





"ml/(100.ml)")​











DT (ml/(100.g), UCUM,​











"ml/(100.g)")​

DCM​

126397​

Relative Regional Blood Flow​



DT ({ratio}, UCUM, "ratio")​

DCM​

126398​

Relative Regional Blood​





DT ({ratio}, UCUM, "ratio")​





Volume​







DCM​

113052​

Mean Transit Time​





DT (s, UCUM, "s")​

DCM​

113069​

Time To Peak​





DT (s, UCUM, "s")​

DCM​

126392​

Oxygen Extraction Fraction​







DCM​

113084​

Tmax​





DT (s, UCUM, "s")​

Note​

Previously, concepts specific to the brain (e.g., regional cerebral blood flow) were included in this Context Group, but these​ have been retired in favor of using the non-body-part-specific concepts. See DICOM PS3.16 2019a.​

CID 4109 Model-Independent Dynamic Contrast Analysis Parameters​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20150916​

UID:​

1.2.840.10008.6.1.994​

Table CID 4109. Model-Independent Dynamic Contrast Analysis Parameters​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT​UMLS​

Units​

Designator​





ID​

Concept​









Unique​









ID​



DCM​

126320​

IAUC​





DT(mmol/l.s,UCUM,"mmol/l.s")​

DCM​

126321​

IAUC60​





DT(mmol/l.s,UCUM,"mmol/l.s")​

DCM​

126322​

IAUC90​





DT(mmol/l.s,UCUM,"mmol/l.s")​

DCM​

126323​

IAUC180​





DT(mmol/l.s,UCUM,"mmol/l.s")​

DCM​

126324​

IAUCBN​





DT {normalized}, UCUM,​











"normalized"​

DCM​

126325​

IAUC60BN​





DT {/AIF}, UCUM, "/AIF"​

DCM​

126326​

IAUC90BN​





DT {/AIF}, UCUM, "/AIF"​

DCM​

126327​

IAUC180BN​





DT {/AIF}, UCUM, "/AIF"​

DCM​

126370​

Time of Peak Concentration​



DT (s, UCUM, "s")​

DCM​

126372​

Time of Leading Half-Peak​





DT (s, UCUM, "s")​





Concentration​







DCM​

126371​

Bolus Arrival Time​





DT (s, UCUM, "s")​

DCM​

113069​

Time To Peak​





DT (s, UCUM, "s")​

DCM​

126374​

Temporal Derivative​











Threshold​







DCM​

126375​

Maximum Slope​







- Standard -​
