DICOM PS3.16 2020a - Content Mapping Resource​

Page 751​



Table CID 4271. En Face Image Types​



CodingSchemeDesignator​

Code Value​

Code Meaning​



DCM​

128257​

Retina depth encoded vasculature flow​



DCM​

128258​

Retina depth encoded structural reflectance map​



DCM​

128259​

Retina vasculature flow​



DCM​

128260​

Retina structural reflectance map​



DCM​

128261​

Vitreous vasculature flow​



DCM​

128262​

Vitreous structural reflectance map​



DCM​

128263​

Radial peripapillary vasculature flow​



DCM​

128264​

Radial peripapillary structural reflectance map​



DCM​

128265​

Superficial retina vasculature flow​



DCM​

128266​

Superficial retina structural reflectance map​



DCM​

128267​

Middle inner retina vasculature flow​



DCM​

128268​

Middle inner structural reflectance map​



DCM​

128269​

Deep retina vasculature flow​



DCM​

128270​

Deep retina structural reflectance map​



DCM​

128271​

Outer retina vasculature flow​



DCM​

128272​

Outer retina structural reflectance map​



DCM​

128273​

Choriocapillaris vasculature flow​



DCM​

128274​

Choriocapillaris structural reflectance map​



DCM​

128275​

Choroid vasculature flow​



DCM​

128276​

Choroid structural reflectance map​



DCM​

128277​

Whole eye vasculature flow​



DCM​

128278​

Whole eye structural reflectance map​



CID 4272 Opt Scan Pattern Types​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​





Version:​

20170405​





UID:​

1.2.840.10008.6.1.1152​







Table CID 4272. OPT Scan Pattern Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​

128279​

Cube B-scan pattern​



DCM​

128280​

Raster B-scan pattern​



DCM​

128281​

Line B-scan pattern​



DCM​

128282​

Radial B-scan pattern​



DCM​

128283​

Cross B-scan pattern​



DCM​

128284​

Circle B-scan pattern​



DCM​

128285​

Concentric circle B-scan pattern​



DCM​

128286​

Circle-raster B-scan pattern​



DCM​

128287​

Circle-radial B-scan pattern​



DCM​

128288​

Grid B-scan pattern​



- Standard -​

Page 752​ DICOM PS3.16 2020a - Content Mapping Resource​

CID 4273 Retinal Segmentation Surfaces​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170405​

UID:​

1.2.840.10008.6.1.1153​

Table CID 4273. Retinal Segmentation Surfaces​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT​

UMLS​

Designator​





ID​

Concept​









Unique ID​

SCT​

280677004​

ILM - Internal limiting membrane​

T-AA62D​

C0459664​

DCM​

128289​

Outer surface of RNFL​





DCM​

128290​

Outer surface of GCL​





DCM​

128291​

Outer surface of IPL​





DCM​

128292​

Outer surface of INL​





DCM​

128293​

Outer surface of OPL​





DCM​

128294​

Outer surface of HFL​





SCT​

76710003​

ELM - External limiting membrane​

T-AA650​

C0229209​

DCM​

128295​

Surface between Inner and Outer Segments of​







the photoreceptors​





DCM​

128296​

Surfaceoftheinterdigitatingzonebetweenretina​







and RPE​





DCM​

128297​

Anterior surface of the RPE​





DCM​

128298​

Surface of the center of the RPE​





DCM​

128299​

Posterior surface of the RPE​





DCM​

128300​

Outer surface of the BM​





DCM​

128301​

Surface of the choroid-sclera interface​





DCM​

128302​

Outer surface of the CC​





CID 5000 Languages​

Context Group ID 5000 comprises the language tag coding scheme of [RFC 5646]. The Coding Scheme Designator (0008,0102)​ shall be RFC5646.​

Note​

1.​The [RFC 5646] coding scheme is constructed from a primary subtag component encoded using the shortest language​ codes of [ISO 639], plus codes for extensions for languages not represented in [ISO 639]. The code optionally includes​ additional subtag components, for scripts encoded using the four letter codes of [ISO 15924], and for regions encoded​ using the two letter country codes of [ISO 3166].​

2.​[RFC 5646] may be obtained at http://www.ietf.org/rfc/rfc5646.txt. [RFC 5646] obsoletes [RFC 4646], [RFC 3066] and​ [RFC 1766], but is forward compatible with those specifications. In previous editions of the Standard, [RFC 4646] codes​ were used with a Coding Scheme Designator of IETF4646. [RFC 5646] is a superset of [RFC 4646], which formalizes​ support for [ISO 639-3].​

3.​[ISO 639] codes may be obtained at http://www.loc.gov/standards/iso639-2/langhome.html.​

4.​The two letter country codes of [ISO 3166] may be obtained at http://www.iso.org/obp/ui/#search/code/​

5.​IANA language tag registrations may be obtained at http://www.iana.org/assignments/language-subtag-registry/​ language-subtag-registry​

- Standard -​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 753​

6.​In previous editions of the Standard, this Context Group formerly included the three letter language codes of [ISO 639-​ 2]/B, using Coding Scheme Designator ISO639_2, or the language codes of [RFC 3066], using Coding Scheme Desig-​ natorRFC3066,andseveralIANA-registeredlanguagecodeextensions,usingCodingSchemeDesignatorIANARFC1766.​

7.​In previous editions of the Standard, this Context Group provided only language identifiers, with national or regional​ variant identified in a separate attribute or Content Item.​

CID 5001 Countries​

Context Group ID 5001 comprises the two letter country code scheme of ISO 3166. The Coding Scheme Designator (0008,0102)​ shall be ISO3166_1.​

Note​

The two letter country codes of ISO 3166 may be obtained at http://www.iso.org/obp/ui/#search/code/​

CID 5002 Organizations​

Context Group ID 5002 comprises the object identifier scheme of ISO 8824-1 and ISO 9834-1, when applied to organizational identi-​ fiers (see Section 8.2). The Coding Scheme Designator (0008,0102) shall be ISO_OID.​

CID 6000 Overall Breast Composition​

Note​

In future extensions, Overall Breast Composition terms that are not derived from BI-RADS® should be added to this context​ group.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.330​



Table CID 6000. Overall Breast Composition​

Coding Scheme Designator​ Code Value​ Code Meaning​

Include CID 6001 “Overall Breast Composition from BI-RADS®”​

CID 6001 Overall Breast Composition from BI-RADS®​

Note​



From BI-RADS® Third Edition (National Mammography Database, E77)​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.331​

Table CID 6001. Overall Breast Composition from BI-RADS®​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLSConceptUniqueID​

Designator​









SCT​

129716005​

Almost entirely fat​

F-01711​

C0231248​

SCT​

129717001​

Scattered fibroglandular​

F-01712​

C0544447​





densities​





SCT​

129718006​

Heterogeneously dense​

F-01713​

C0231249​

SCT​

129719003​

Extremely dense​

F-01714​

C1268647​

- Standard -​

Page 754​

DICOM PS3.16 2020a - Content Mapping Resource​

CID 6002 Change Since Last Mammogram or Prior Surgery​

Note​

In future extensions, Change Since Last Mammogram or Prior Surgery terms that are not derived from BI-RADS® should​ be added to this context group.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.332​



Table CID 6002. Change Since Last Mammogram or Prior Surgery​

Coding Scheme Designator​ Code Value​ Code Meaning​

Include CID 6003 “Change Since Last Mammogram or Prior Surgery from BI-RADS®”​

CID 6003 Change Since Last Mammogram or Prior Surgery from BI-RADS®​

Note​

From BI-RADS® Third Edition (National Mammography Database, E79)​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.333​

Table CID 6003. Change Since Last Mammogram or Prior Surgery from BI-RADS®​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique​

Designator​





ID​

SCT​

129721008​

New finding​

SCT​

129722001​

Finding partially removed​

SCT​

129723006​

Nosignificantchangesinthefinding​

SCT​

15454001​

Increase in size​

SCT​

19776001​

Decrease in size​

SCT​

129726003​

Increase in number of calcifications​

SCT​

129727007​

Decreaseinnumberofcalcifications​

SCT​

129728002​

Less defined​

SCT​

129729005​

More defined​

SCT​

129730000​

Removal of implant since previous​





mammogram​

SCT​

129731001​

Implant revised since previous​





mammogram​

F-01721​

C1268649​

F-01722​

C1268650​

F-01723​

C1268651​

M-02520​

C0332509​

M-02530​

C0332511​

F-01726​

C1268654​

F-01727​

C1268655​

F-01728​

C1268656​

F-01729​

C1268657​

F-0172A​

C1268658​

F-0172B​

C1268659​

CID 6004 Mammography Characteristics of Shape​

Note​

In future extensions, Mammography Characteristics of Shape terms that are not derived from BI-RADS® should be added​ to this context group.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 755​

UID:​

1.2.840.10008.6.1.334​







Table CID 6004. Mammography Characteristics of Shape​

Coding Scheme Designator​

Code Value​



Code Meaning​

Include CID 6005 “Characteristics of Shape from BI-RADS®”​





CID 6005 Characteristics of Shape from BI-RADS®​



Note​









From BI-RADS® Third Edition (National Mammography Database, E80)​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20020904​







UID:​

1.2.840.10008.6.1.335​







Table CID 6005. Characteristics of Shape from BI-RADS®​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

42700002​

Round shape​

M-02100​

C0332490​

SCT​

84360004​

Ovoid shape (Oval)​

M-02120​

C0332492​

SCT​

40266001​

Lobular​

G-A640​

C0205417​

SCT​

49608001​

Irregular​

G-A402​

C0205271​

CID 6006 Mammography Characteristics of Margin​

Note​

In future extensions, Mammography Characteristics of Margin terms that are not derived from BI-RADS® should be added​ to this context group.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020904​

UID:​

1.2.840.10008.6.1.336​



Table CID 6006. Mammography Characteristics of Margin​

Coding Scheme Designator​ Code Value​ Code Meaning​

Include CID 6007 “Characteristics of Margin from BI-RADS®”​

CID 6007 Characteristics of Margin from BI-RADS®​

Note​



From BI-RADS®​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20050822​

UID:​

1.2.840.10008.6.1.337​

- Standard -​
