Page 876​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 7195. Function Segmentation Property Types​

CodingSchemeDesignator​ Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique ID​

Include CID 7161 “Physiology Segmentation Types”​





CID 7196 Spatial and Relational Concept Segmentation Property Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.1195​

Table CID 7196. Spatial and Relational Concept Segmentation Property Types​

CodingSchemeDesignator​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept​







Unique ID​

DCM​

112082​

Interface​



DCM​

112083​

Line​



DCM​

112084​

Lucency​



Include CID 7165 “Abstract Segmentation Types”​

Note​

Some of the concepts in this context group are derived from CID 6109 “Radiographic Anatomy Finding or Feature”.​

CID 7197 Body Substance Segmentation Property Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.1196​

Table CID 7197. Body Substance Segmentation Property Types​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

70150004​

Bile​

T-60650​

C0005388​

SCT​

32457005​

Body fluid​

T-D0070​

C0005889​

SCT​

39477002​

Feces​

T-59666​

C0015733​

SCT​

74947009​

Gas​

C-10080​

C0017110​

SCT​

78014005​

Urine​

T-70060​

C0042036​

CID 7198 Substance Segmentation Property Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.1197​



Table CID 7198. Substance Segmentation Property Types​

CodingSchemeDesignator​ Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique ID​

Include CID 6402 “Non-lesion Object Type - Substances”​



- Standard -​

DICOM PS3.16 2020a - Content Mapping Resource​ Page 877​

CID 7201 Referenced Image Purposes of Reference​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20180916​

UID:​

1.2.840.10008.6.1.508​

Table CID 7201. Referenced Image Purposes of Reference​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121311​

Localizer​

DCM​

121312​

Biopsy localizer​

DCM​

121313​

Other partial views​

DCM​

121314​

Other image of biplane pair​

DCM​

121315​

Other image of stereoscopic pair​

DCM​

121316​

Images related to standalone object​

DCM​

121317​

Spectroscopy​

DCM​

121338​

Anatomic image​

DCM​

121339​

Functional image​

DCM​

121340​

Spectral filtered image​

DCM​

121341​

Device localizer​

DCM​

121346​

Acquisition frames corresponding to volume​

DCM​

121347​

Volume corresponding to spatially-related acquisition frames​

DCM​

121348​

Temporal Predecessor​

DCM​

121349​

Temporal Successor​

DCM​

129201​

Image used for Treatment Planning​

DCM​

129202​

Image used for Dose Calculation​

DCM​

129203​

Image Acquired during Treatment​

DCM​

129204​

Image used as Reference Image for Treatment​

CID 7202 Source Image Purposes of Reference​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170405​

UID:​

1.2.840.10008.6.1.509​

Table CID 7202. Source Image Purposes of Reference​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121320​

Uncompressed predecessor​

DCM​

121321​

Mask image for image processing operation​

DCM​

121322​

Source image for image processing operation​

DCM​

121329​

Source image for montage​

DCM​

121330​

Lossy compressed predecessor​

DCM​

121358​

For Processing predecessor​

DCM​

113130​

Predecessor containing group of imaging subjects​

DCM​

128250​

Structural image for image processing​

- Standard -​

Page 878​

DICOM PS3.16 2020a - Content Mapping Resource​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

128251​

Flow image for image processing​

CID 7203 Image Derivation​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​



Version:​

20180904​



UID:​

1.2.840.10008.6.1.510​





Table CID 7203. Image Derivation​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

113040​

Lossy Compression​

DCM​

113042​

Pixel by pixel addition​

DCM​

113046​

Pixel by pixel division​

DCM​

113047​

Pixel by pixel mask​

DCM​

113048​

Pixel by pixel Maximum​

DCM​

113049​

Pixel by pixel mean​

DCM​

113050​

Metabolite Maps from spectroscopy data​

DCM​

113051​

Pixel by pixel Minimum​

DCM​

113053​

Pixel by pixel multiplication​

DCM​

113062​

Pixel by pixel subtraction​

DCM​

113072​

Multiplanar reformatting​

DCM​

113073​

Curved multiplanar reformatting​

DCM​

113074​

Volume rendering​

DCM​

113075​

Surface rendering​

DCM​

113076​

Segmentation​

DCM​

113077​

Volume editing​

DCM​

113078​

Maximum intensity projection​

DCM​

113079​

Minimum intensity projection​

DCM​

113085​

Spatial resampling​

DCM​

113086​

Edge enhancement​

DCM​

113087​

Smoothing​

DCM​

113088​

Gaussian blur​

DCM​

113089​

Unsharp mask​

DCM​

113090​

Image stitching​

DCM​

113091​

Spatially-related frames extracted from the volume​

DCM​

113092​

Temporally-related frames extracted from the set of volumes​

DCM​

113097​

Multi-energy proportional weighting​

DCM​

113093​

Polar to Rectangular Scan Conversion​

DCM​

113131​

Extraction of individual subject from group​

DCM​

128303​

OCT B-scan analysis​

DCM​

129104​

Perfusion image analysis​

DCM​

129105​

Diffusion image analysis​

DCM​

129106​

Diffusion tractography​

- Standard -​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 879​

Note​

This context group contains relaively generic descriptions of image processing, e.g., (129104, DCM, "Perfusion image ana-​ lysis"). More specific descriptions of the exact derivation method can be expected in the Quantity Definition Sequence​ (0040,9220) in a Real World Value Map describing pixel values, or the describing numeric measurements from regions of​ interest, e.g., using CID 4102 “Perfusion Measurement Methods”.​

CID 7205 Purpose of Reference to Alternate Representation​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20040322​

UID:​

1.2.840.10008.6.1.511​

Table CID 7205. Purpose of Reference to Alternate Representation​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121324​

Source image​

DCM​

121325​

Lossy compressed image​

DCM​

121326​

Alternate SOP Class instance​

DCM​

121327​

Full fidelity image​

DCM​

121328​

Alternate Photometric Interpretation image​

CID 7210 Related Series Purposes of Reference​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20140627​

UID:​

1.2.840.10008.6.1.512​

Table CID 7210. Related Series Purposes of Reference​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

122400​

Simultaneously Acquired​

DCM​

122401​

Same Anatomy​

DCM​

122402​

Same Indication​

DCM​

122403​

For Attenuation Correction​

DCM​

121323​

Source series for image processing operation​

CID 7215 Spectroscopy Purpose of Reference​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20140105​

UID:​

1.2.840.10008.6.1.970​

Table CID 7215. Spectroscopy Purpose of Reference​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121318​

Spectroscopy Data for Water Phase Correction​

CID 7220 RT Dose Derivation​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

- Standard -​

Page 880​

DICOM PS3.16 2020a - Content Mapping Resource​

Version:​

20140106​





UID:​

1.2.840.10008.6.1.968​





Table CID 7220. RT Dose Derivation​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​



121370​

Composed from prior doses​

DCM​



121371​

Composed from prior doses and current plan​

CID 7221 RT Dose Purpose of Reference​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​





Version:​

20140106​





UID:​

1.2.840.10008.6.1.969​





Table CID 7221. RT Dose Purpose of Reference​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​



121372​

Source dose for composing current dose​

CID 7222 Parametric Map Derivation Image Purpose of Reference​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​





Version:​

20141110​





UID:​

1.2.840.10008.6.1.1009​



Table CID 7222. Parametric Map Derivation Image Purpose of Reference​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121322​

Source Image for Image Processing Operation​

CID 7250 Multi-Frame Subset Type​

ThisContextGroupspecifiesthetermsusedtoidentifyasubsetofframesofamulti-frameimage.Itisusedforencodinganequivalent​ of the Image SOP Instance Reference Macro (see PS3.3) in an HL7 v3 data structure (see HL7 v3 CMET, COCT_RM830120​ "A_DicomCompositeObjectReference minimal").​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20070625​

UID:​

1.2.840.10008.6.1.513​

Table CID 7250. Multi-Frame Subset Type​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121190​

Referenced Frames​

DCM​

121191​

Referenced Segment​

CID 7260 Diffusion Acquisition Value Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20150918​

UID:​

1.2.840.10008.6.1.1059​

- Standard -​
