Page 1026​ DICOM PS3.16 2020a - Content Mapping Resource​

CID 9535 Radiotherapy Dose Calculation Roles​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181112​

UID:​

1.2.840.10008.6.1.1245​

Table CID 9535. Radiotherapy Dose Calculation Roles​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130057​

Planning Organ At Risk Volume​

DCM​

130058​

Avoidance Volume​

DCM​

130060​

Organ At Risk​

DCM​

130061​

Radiation Dose Shaping Volume​

DCM​

130062​

Conformality Shell​

DCM​

130065​

Dose Calculation Bounding Volume​

DCM​

130066​

Radiation Interaction Volume​

CID 9536 Radiotherapy Prescribing and Segmenting Person Roles​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181112​

UID:​

1.2.840.10008.6.1.1246​

Table CID 9536. Radiotherapy Prescribing and Segmenting Person Roles​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLSConceptUniqueID​

Designator​









SCT​

158965000​

Medical Practitioner​

J-0016E​

C1306754​

SCT​

309343006​

Physician​

J-004E8​

C0031831​

SCT​

159016003​

Radiologic Technologist​

J-00187​

C0402007​

DCM​

128674​

Lead Radiologic Technologist​





SCT​

3430008​

Radiation Therapist​

J-06173​

C0278604​

SCT​

159016003​

Radiographer​

J-00187​

C0402007​

SCT​

405277009​

Resident​

J-005E6​

C1320928​

UMLS​

C1441532​

Consulting Physician​



C1441532​

UMLS​

C2985483​

Radiation Physicist​



C2985483​

UMLS​

C1708969​

Medical Physicist​



C1708969​

CID 9537 Effective Dose Calculation Method Categories​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181112​

UID:​

1.2.840.10008.6.1.1247​

Table CID 9537. Effective Dose Calculation Method Categories​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130126​

Radiation transport-based methods​

DCM​

130127​

Fractionation-based or temporally-based methods​

- Standard -​

DICOM PS3.16 2020a - Content Mapping Resource​ Page 1027​

CID 9538 Radiation Transport-based Effective Dose Method Modifiers​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181112​

UID:​

1.2.840.10008.6.1.1248​

Table CID 9538. Radiation Transport-Based Effective Dose Method Modifiers​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130128​

Local Effect Model​

DCM​

130129​

Microdosimetric Kinetic Model​

CID 9539 Fractionation-based Effective Dose Method Modifiers​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181112​

UID:​

1.2.840.10008.6.1.1249​

Table CID 9539. Fractionation-Based Effective Dose Method Modifers​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130130​

Equivalent 2-Gray Fractions Model​

DCM​

130131​

Linear-Quadratic Model​

DCM​

130132​

Linear-Quadratic Model with Time Factor​

DCM​

130133​

Linear-Quadratic-Linear Model​

DCM​

130134​

Linear-Quadratic Model for Low-Dose Rate Brachytherapy​

CID 9541 Beam Limiting Device Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Non-Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1288​

Table CID 9541. Beam Limiting Device Types​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130330​

Jaw Pair​

DCM​

130331​

Leaf Pairs​

DCM​

130332​

Variable Circular Collimator​

DCM​

130333​

Single Leaves​

Include CID 9545 “Fixed Beam Limiting Device Types”​

CID 9542 Compensator Device Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1289​

- Standard -​

Page 1028​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 9542. Compensator Device Types​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130340​

Physical Compensator​

CID 9543 Radiotherapy Treatment Machine Modes​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1290​

Table CID 9543. Radiotherapy Treatment Machine Modes​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130341​

Total Body Irradiation​

DCM​

130342​

Total Skin Irradiation​

CID 9544 Radiotherapy Distance Reference Locations​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Non-Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1291​

Table CID 9544. Radiotherapy Distance Reference Locations​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130358​

Nominal Radiation Source Location​

DCM​

130359​

Treatment Machine Isocenter​

CID 9545 Fixed Beam Limiting Device Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1292​

Table CID 9545. Fixed Beam Limiting Device Types​

Coding Scheme Designator​

Code Value​

Code Meaning​

Include CID 9517 “Radiotherapy Block Device Types”​



DCM​

130343​

Electron Fixed Aperture​

DCM​

130344​

Photon Fixed Aperture​

DCM​

130345​

Intraoperative Fixed Aperture​

CID 9546 Radiotherapy Wedge Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1293​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1029​



Table CID 9546. Radiotherapy Wedge Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



130346​

Hard Wedge​



DCM​



130347​

Motorized Wedge​



DCM​



130348​

Dynamic Wedge​



CID 9547 RT Beam Limiting Device Orientation Labels​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20190715​







UID:​

1.2.840.10008.6.1.1294​





Table CID 9547. RT Beam Limiting Device Orientation Labels​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



130334​

X Orientation​



DCM​



130335​

Y Orientation​



CID 9548 General Accessory Device Types​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20190715​







UID:​

1.2.840.10008.6.1.1295​







Table CID 9548. General Accessory Device Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



130349​

Graticule​



DCM​



130350​

Reticle​



DCM​



130351​

Image Detector​



DCM​



130352​

Film Holder​



DCM​



130353​

Winston-Lutz Pointer​



DCM​



130354​

Bowtie Filter​



CID 9549 Radiation Generation Mode Types​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20190715​







UID:​

1.2.840.10008.6.1.1296​







Table CID 9549. Radiation Generation Mode Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



130355​

Flattening Filter Beam​



DCM​



130356​

Non-Flattening Filter Beam​



DCM​



130357​

Partial Flattening Filter Beam​



CID 9550 C-Arm Photon-Electron Delivery Rate Units​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



- Standard -​

Page 1030​

DICOM PS3.16 2020a - Content Mapping Resource​

Type:​

Non-Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1297​

Table CID 9550. C-Arm Photon-Electron Delivery Rate Units​

Coding Scheme Designator​

Code Value​

Code Meaning​

UCUM​

{MU}/s​

Monitor Units/Second​

CID 9551 Treatment Delivery Device Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1298​

Table CID 9551. Treatment Delivery Device Types​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130361​

Radiotherapy Treatment Device​

CID 9552 C-Arm Photon-Electron Dosimeter Units​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Non-Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1299​

Table CID 9552. C-Arm Photon-Electron Dosimeter Units​

Coding Scheme Designator​

Code Value​

Code Meaning​

UCUM​

{MU}​

Monitor Units​

CID 9553 Treatment Points​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1300​

Table CID 9553. Treatment Points​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130073​

Isocentric Treatment Location Point​

CID 9554 Equipment Reference Points​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190715​

UID:​

1.2.840.10008.6.1.1301​



Table CID 9554. Equipment Reference Points​

Coding Scheme Designator​

Code Value​

Code Meaning​

Include CID 9544 “Radiotherapy Distance Reference Locations”​



DCM​

130360​

Fixed Laser Setup Point​

- Standard -​
