Page 126​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req Type​ Condition​ Value Set​

Constraint​

5​

>​

R-INFERREDFROM​IMAGE​

BCID 7003 “Diagnostic​

1-n​

UC​

XOR Row 2, 6​

Imaging Report​

PurposesofReference”​

6​

>​

INFERRED FROM​ IMAGE​

BCID 7003 “Diagnostic​

1-n​

UC​

XOR Row 2, 5​

Imaging Report​

PurposesofReference”​

7​

>​

HASOBSCONTEXT​INCLUDE​

DTID 4108 “Tracking​

1​

U​

Identifier”​

Row 2​

TheSCOORDmayindicatethepointsorareawherethemeasurementwastaken(e.g.,aPOINTshowing​

thepixellocationofadensitymeasurement,oranopenPOLYLINEofthreepointsshowingthecalculation​

of an angle).​

Rows 3, 5​

Valid only in IODs that permit relationships by-reference.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 1406. Three Dimensional Linear Measurement​

NL​ Rel with Parent​ VT​

Concept Name​

VM​ ReqType​Condition​ Value Set Constraint​

1​

NUM​

DCID 7470 “Linear​

1​

M​

UNITS=DCID7460“Units​

Measurements”​

of Linear Measurement”​

2​

>​

INFERRED​

SCOORD3D​EV (121055, DCM,​

1​

M​

GRAPHIC TYPE =​

FROM​

"Path")​

{POLYLINE, ELLIPSE,​

POLYGON}​

3​

>​

HAS OBS​

INCLUDE​

DTID 4108 “Tracking​

1​

U​

CONTEXT​

Identifier”​

Content Item Descriptions​

Row 2​

Path shall represent the measured path in a reference coordinate space. The Graphic Type (0070,0023) of the Path​

SCOORD3D shall be:​

Table TID 1410. Parameters​

$Measurement​

Coded term or Context Group for Concept Name of measurement​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 127​

$Units​

Units for the measurement​

$ModType​

Modifier Name for Concept Name of measurement​

$ModValue​

Modifier Value for Concept Name of measurement​

$Method​

Value for Measurement Method​

$Derivation​

Value for Measurement Derivation​

$TargetSite​

Value for Anatomic Location of measurement​

$TargetSiteMod​

Modifier Value for Anatomic Location of measurement​

$Equation​

Coded term or Context Group for the equation or table from which the measurement​

was derived or computed​

$RefAuthority​

Bibliographic reference or authority for statistical properties of a reference population​

$RangeAuthority​

Bibliographic reference or authority for the normal range of the measurement​

$DerivationParameter​

Coded term or Context Group for Concept Name of a derivation parameter​

$DerivationParameterUnits​

Units of derivation parameter​

$QualType​

Evaluations encoded with code or text responses​

$QualValue​

Value of evaluations encoded with code responses​

$QualModType​

Modifier Name of evaluations encoded with code or text responses​

$QualModValue​

Modifier Value of evaluations encoded with code or text responses​

$FindingType​

Type of the finding​

Type:​

Extensible​

Order:​

Non-Significant​

Root:​

No​

Table TID 1410. Planar ROI Measurements and Qualitative Evaluations​

NL​RelwithParent​ VT​

Concept Name​

VM​

Req​Condition​ Value Set Constraint​

Type​

1​

CONTAINER​EV (125007, DCM,​

1​

M​

"Measurement Group")​

1b​

>​

HAS OBS​

TEXT​

EV (C67447, NCIt,​

1​

U​

CONTEXT​

"Activity Session")​

2​

>​

HAS OBS​

TEXT​

DT (112039, DCM,​

1​

M​

CONTEXT​

"Tracking Identifier")​

3​

>​

HAS OBS​

UIDREF​

EV (112040, DCM,​

1​

M​

CONTEXT​

"Tracking Unique​

Identifier")​

3b​

>​

CONTAINS​

CODE​

EV (121071, DCM,​

1​

U​

$FindingType​

"Finding")​

3c​

>​

CONTAINS​

CODE​

EV (130400, DCM,​

1​

U​

BCID219“GeometryGraphical​

"Geometric purpose of​

Representation”​

region")​

4​

>​

HAS OBS​

INCLUDE​

DTID 1502 “Time Point​

1​

U​

CONTEXT​

Context”​

5​

>​

CONTAINS​

SCOORD​

EV (111030, DCM,​

1​

MC​ XOR Row​GRAPHIC TYPE = not​

"Image Region")​

7​

{MULTIPOINT}​

6​

>>​

SELECTED​

IMAGE​

1​

M​

FROM​

Page 128​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​RelwithParent​ VT​

Concept Name​

VM​

Req​Condition​ Value Set Constraint​

Type​

7​

>​

CONTAINS​

IMAGE​

EV (121214, DCM,​

1​ MC​ XOR Row​Reference shall be to a​

"Referenced​

5​

Segmentation Image, with a​

Segmentation Frame")​

single value specified in​

Referenced Frame Number,​

and with a single value​

specified in Referenced​

Segment Number​

7b​

>​

CONTAINS​

SCOORD3D​EV (111030, DCM,​

1​

MC​ XOR​

GRAPHIC TYPE = not​

"Image Region")​

Rows 5, 7​{MULTIPOINT, POLYLINE or​

ELLIPSOID}​

8​

>​

CONTAINS​

IMAGE​

EV (121233, DCM,​

1​ MC​ IFF Row 7​

"Source image for​

segmentation")​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 129​

Content Item Descriptions​

Row 1b​

Identifiesthesessionduringwhichthemeasurementsweremade.TheNCIThesaurusdefinitionis"time,period,​

or term devoted to some activity".​

Rows 2, 3​

TheTrackingIdentifierandTrackingUniqueIdentifieraredefinedasatextlabeloruniqueidentifier(respectively)​

used for tracking a finding or feature, potentially across multiple reporting objects, over time. As such, they are​

distinct from the Observation UID (0040,A171), which is unique identifier of the specific Content Item and its​

subsidiaryContentItemsthatconstituteanindividualobservation,andwouldbedifferentfordifferentobservations​

on different occasions of the same finding or feature. The values of these content items shall match the​

correspondingvaluesofTrackingID(0062,0020)andTrackingUID(0062,0021),ifpresent,inthecorresponding​

Segment of any Segmentation instance referenced in Row 7.​

Row 3b​

The type of the finding describes whatever entity (finding or feature) is identified by Rows 2 and 3. E.g., a finding​

might be a lesion, a tumor, or a reference region (as distinct from its anatomical location, which is encoded in a​

different content item (Finding Site).​

Row 5​

To describe an infinitely small area, such as the center of a lesion, a Graphic Type of POINT may be used.​

Rows 6, 7​

Referenced Frame Number (0008,1160) is an attribute of the IMAGE Content Item, and shall be present with a​

single value.​

If the Referenced Segmentation SOP Instance has Segmentation Type (0062,0001) value BINARY, it identifies​

the area of defined (measured) region of interest by pixel values in the referenced frame with value 1. For​

Segmentation Type value FRACTIONAL, the area is computed by an implementation dependent method.​

Frame number shall be specified even if the Segmentation SOP Instance has only a single frame.​

Row 7b​

The area may be defined independently of an image by reference to 3D coordinates in any type of DICOM​

ReferenceCoordinateSystem,whetheritbepatient-relative(PatientBasedCoordinateSystem),volume-relative​

(including acquired and presentation state volumes), or whole slide relative (Slide Coordinate System).​

Row 8​

Identifies the source image that was segmented to identify the ROI, and whose properties are described in this​

container.​

Row 9​

This referenced image may contain a "screen shot" illustrating a rendered version of the ROI.​

Row 9b​

This referenced image may contain a visual explanation of how an algorithm produces its results, and may be​

a"screenshot"oftheexplanationalreadysuperimposedonthesourceimage(e.g.,a"heatmap"),oraparametric​

map intended to be superimposed on the source image by the receiving application. The type of image and the​

typeofvisualexplanationisdescribedinthereferencedimage'sownmetadata.Morethanonereferencedimage​

maybepresent,ifthereismorethanonetypeofvisualexplanation,oritneedstospanmorethanonesingle-frame​

image.​

Row 10​

The reference to an RWV in Row 10 allows measurements to be made in units that differ from the stored pixel​

values in the images referenced elsewhere in the Template. E.g., for a PET SUVbw measurement, the mapping​

from activity/concentration units in the referenced image that was used (and which may be reused for​

measurements in the future) may be encoded in a referenced RWV instance. This reference applies to any​

measurements in included Templates, unless overridden).​

Row 11​

Measurements may be omitted, for example if it is desired to describe only the location of a finding or to provide​

categorical information about it.​

Table TID 1411. Parameters​

$Measurement​

Coded term or Context Group for Concept Name of measurement​

$Units​

Units for the measurement​

$ModType​

Modifier Name for Concept Name of measurement​

$ModValue​

Modifier Value for Concept Name of measurement​

$Method​

Value for Measurement Method​

$Derivation​

Value for Measurement Derivation​

$TargetSite​

Value for Anatomic Location of measurement​

$TargetSiteMod​

Modifier Value for Anatomic Location of measurement​

$Equation​

Coded term or Context Group for the equation or table from which the measurement​

was derived or computed​

$RefAuthority​

Bibliographic reference or authority for statistical properties of a reference population​

$RangeAuthority​

Bibliographic reference or authority for the normal range of the measurement​

$DerivationParameter​

Coded term or Context Group for Concept Name of a derivation parameter​

$DerivationParameterUnits​

Units of derivation parameter​

$QualType​

Evaluations encoded with code or text responses​

$QualValue​

Value of evaluations encoded with code responses​

$QualModType​

Modifier Name of evaluations encoded with code or text responses​

$QualModValue​

Modifier Value of evaluations encoded with code or text responses​

$FindingType​

Type of the finding​

Type:​

Extensible​

Order:​

Non-Significant​

Root:​

No​

Table TID 1411. Volumetric ROI Measurements and Qualitative Evaluations​

NL​RelwithParent​ VT​

Concept Name​

VM​

Req​ Condition​ Value Set Constraint​

Type​

1​

CONTAINER​EV (125007, DCM,​

1​

M​

"Measurement Group")​

1b​

>​

HAS OBS​

TEXT​

EV (C67447, NCIt,​

1​

U​

CONTEXT​

"Activity Session")​

2​

>​

HAS OBS​

TEXT​

DT (112039, DCM,​

1​

M​

CONTEXT​

"Tracking Identifier")​

3​

>​

HAS OBS​

UIDREF​

EV (112040, DCM,​

1​

M​

CONTEXT​

"Tracking Unique​

Identifier")​

3b​

>​

CONTAINS​

CODE​

EV (121071, DCM,​

1​

U​

$FindingType​

"Finding")​

3c​

>​

CONTAINS​

CODE​

EV (130400, DCM,​

1​

U​

BCID219“GeometryGraphical​

"Geometric purpose of​

Representation”​

region")​

4​

>​

HAS OBS​

INCLUDE​

DTID 1502 “Time Point​

1​

U​

CONTEXT​

Context”​

5​

>​

CONTAINS​

SCOORD​

EV (111030, DCM,​

1-n​

MC​ XORRows​GRAPHIC TYPE = not​

"Image Region")​

7, 10​

{MULTIPOINT}​
