Table TID 3906. Parameters​

Parameter Name​

Parameter Usage​

$VascularSection​

The concept name of the region or structure of which the anatomy is part​

$SectionLaterality​

The laterality (if any) of the anatomy in this section heading​

$Anatomy​

The concept name of the vascular anatomy​

$AnalysisPerformed​

The context of the measurements performed during the analysis​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

NL​

Rel with​

VT​

Concept Name​

VM​

Req​

Condition​

Value Set​

Parent​

Type​

Constraint​

1​

CONTAINS​

CONTAINER​$VascularSection​

1​

M​

2​

>​

HAS​

CODE​

EV (272741003, SCT,​

1​

MC​ IFF $SectionLaterality​

$SectionLaterality​

CONCEPT​

"Laterality")​

has a value​

MOD​

3​

>​

CONTAINS​

CONTAINER​EV (121070, DCM,​

1-n​

M​

"Findings")​

4​

>>​

HAS​

CODE​

EV (363698007, SCT,​

1​

M​

$Anatomy​

CONCEPT​

"Finding Site")​

MOD​

5​

>>​

CONTAINS​

CODE​

EV (122686, DCM,​

1-n​

U​

DCID 3810​

"ParentVesselFinding")​

“Vascular​

Morphology”​

6​

>>>​

INCLUDE​

DTID 1350 “Negation​

1​

U​

Modifier, Presence of​

Finding”​

7​

>>​

CONTAINS​

INCLUDE​

DTID 3905 “Calcium​

1​

UC​ IF the value of​

Scoring Results”​

$AnalysisPerformed​

equals (122605, DCM,​

"Vascular Morphological​

Analysis")​

8​

>>​

CONTAINS​

CONTAINER​EV (121070, DCM,​

1-n​

U​

"Findings")​

9​

>>>​

HAS​

CODE​

EV (125101, DCM,​

1-n​

UC​ IF concept value of row 4​DCID 12117​

CONCEPT​

"Vessel Branch")​

is not equal to​

“Vessel Branch​

MOD​

(41801008, SCT,​

Modifiers”​

"Coronary Artery​

Structure")​

10​

>>>​

HAS​

CODE​

EV (106233006, SCT,​

1​

UC​ IF concept value of row 4​DCID 12116​

CONCEPT​

"Topographical​

is not equal to​

“Vessel Segment​

MOD​

Modifier")​

(41801008, SCT,​

Modifiers”​

"Coronary Artery​

Structure")​

Page 272​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​

Rel with​

VT​

Concept Name​

VM​

Req​

Condition​

Value Set​

Parent​

Type​

Constraint​

11​

>>>​

HAS​

CODE​

EV (106233006, SCT,​

1​

UC​ IF concept value of row 4​DCID 3019​

CONCEPT​

"Topographical​

equals (41801008, SCT,​“Cardiovascular​

MOD​

Modifier")​

"Coronary Artery​

AnatomicLocation​

Structure")​

Modifiers”​

12​

>>>​

CONTAINS​

INCLUDE​

DTID 3907 “Vessel​

1​

U​

Measurements”​

13​

>>>​

CONTAINS​

INCLUDE​

DTID 3908 “Vascular​

1-n​

UC​ IF the value​

Lesion”​

of$AnalysisPerformed​

equals (122605, DCM,​

"Vascular Morphological​

Analysis")​

14​

>>>​

CONTAINS​

INCLUDE​

DTID 3910 “Flow​

1​

UC​ IF the value​

Quantification”​

of$AnalysisPerformed​

equals (122606, DCM,​

"Vascular Functional​

Analysis")​

Content Item Descriptions​

Row 3​

This Findings container allows an application to group related vessels or branches​

Row 5​

The characteristics associated with the parent vessel shall also be reported in the findings Container for the​

parent vessel. Negative findings (characteristics not present) need not be reported in the parent vessel​

Container.​

TID 3907 Vessel Measurements​

Contains measurements made on vessel level.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3907. Vessel Measurements​

NL​

Rel with Parent​ VT​

Concept Name​

VM​

Req​ Condition​Value Set Constraint​

Type​

1​

CONTAINS​

NUM​

EV(408715008,SCT,"Lumen​

1​

U​

UNITS = DT (%,​

Diameter Stenosis")​

UCUM, "%")​

2​

CONTAINS​

NUM​

EV(408714007,SCT,"Lumen​

1​

U​

UNITS = DT (%,​

Area Stenosis")​

UCUM, "%")​

3​

CONTAINS​

NUM​

EV (121206, DCM,​

1-n​

U​

UNITS = DT (mm,​

"Distance")​

UCUM, "mm")​

4​

>​

HAS CONCEPT​ CODE​

EV (122340, DCM, "Fiducial​

2​

M​

MOD​

Feature")​

5​

>>​

HAS CONCEPT​ CODE​

EV (272741003, SCT,​

1​

U​

DCID 244 “Laterality”​

MOD​

"Laterality")​

6​

>​

INCLUDE​ DTID 320 “Image or Spatial​

1​

U​

Coordinates”​

7​

CONTAINS​

NUM​

EV(397413000,SCT,"Vessel​ 1-n​

U​

UNITS = DT (mm,​

Lumen Diameter")​

UCUM, "mm")​

8​

>​

HAS CONCEPT​ CODE​

EV (121401, DCM,​

1​

U​

DCID 3488​

MOD​

"Derivation")​

“Min/Max/Mean”​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 273​

NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​Value Set Constraint​

Type​

9​

>​

HAS​

NUM​

EV (122337, DCM, "Relative​

1​

U​

UNITS = EV (mm,​

PROPERTIES​

Position")​

UCUM, "mm")​

10​

>>​

HAS CONCEPT​ CODE​

EV (122340, DCM, "Fiducial​

1​

M​

DCID 3837 “Fiducial​

MOD​

Feature")​

Feature”​

Content Item Descriptions​

Rows 3-5​

The distance between two identified fiducial features​

Rows 7-10​

Measurement of vessel diameter made at a position relative to a fiducial feature​

Row 9​

A positive value indicates a distance in the direction of flow within the vessel​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

NL​

Rel with​

VT​

Concept Name​

VM​

Req​

Condition​ Value Set Constraint​

Parent​

Type​

1​

CONTAINS​

CONTAINER​EV (300577008, SCT,​

1​

M​

"Lesion Finding")​

2​

>​

CONTAINS​

TEXT​

EV (121151, DCM,​

1​

M​

"Lesion Identifier")​

3​

>​

CONTAINS​

INCLUDE​

DTID 3909 “Best​

1-n​

U​

Illustration of Findings”​

4​

>​

CONTAINS​

TEXT​

EV (121106, DCM,​

1-n​

U​

"Comment")​

5​

>​

CONTAINS​

NUM​

EV (122337, DCM,​

1​

U​

UNITS = EV (mm,​

"Relative Position")​

UCUM, "mm")​

6​

>>​

HAS​

CODE​

EV (122340, DCM,​

1​

M​

DCID 3837 “Fiducial​

CONCEPT​

"Fiducial Feature")​

Feature”​

MOD​

7​

>​

CONTAINS​

INCLUDE​

DTID300“Measurement”​1-n​

U​

$Measurement = EV​

(397413000, SCT,​

"Vessel Lumen​

Diameter")​

Page 274​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​

Rel with​

VT​

Concept Name​

VM​

Req​ Condition​

Value Set Constraint​

Parent​

Type​

8​

>​

CONTAINS​

INCLUDE​

DTID300“Measurement”​1-n​

U​

$Measurement = EV​

(397415007, SCT,​

"Vessel Lumen​

Cross-Sectional Area")​

$Derivation = DCID​

3838 “Diameter​

Derivation”​

$FindingSite = DCID​

3486 “Vascular​

Measurement Sites”​

$Units = DT (mm2,​

UCUM, "mm2")​

9​

>​

CONTAINS​

CODE​

EV (116676008, SCT,​

1-n​

M​

DCID 3810 “Vascular​

"AssociatedMorphology")​

Morphology”​

10​

>>​

INCLUDE​

DTID 3909 “Best​

1-n​

U​

Illustration of Findings”​

11​

>>​

HAS​

TEXT​

EV (121106, DCM,​

1-n​

U​

PROPERTIES​

"Comment")​

12​

>>​

INCLUDE​

DTID 3911 “Plaque​

1​

MC​ IFF value of row 9​

Properties”​

equals (1522000,​

SCT, "Plaque")​

13​

>>​

INCLUDE​

DTID 3912 “Stenosis​

1​

MC​ IFF value of row 9​

Properties”​

equals(415582006,​

SCT, "Stenosis")​

14​

>>​

INCLUDE​

DTID 3913 “Aneurysm​

1​

MC​ IFF value of row 9​

Properties”​

equals (85659009,​

SCT, "Aneurysm")​

15​

>>​

INCLUDE​

DTID 3914 “Arterial​

1​

MC​ IFF value of row 9​

Dissection Properties”​

equals(710864009,​

SCT, "Arterial​

Dissection")​

16​

>>​

HAS​

CODE​

EV (116676008, SCT,​

1​

MC​ IFF value of row 9​DCID 3817 “Vascular​

PROPERTIES​

"AssociatedMorphology")​

equals(107671003,​Sclerosis Types”​

SCT, "Vascular​

Sclerosis")​

17​

>>​

INCLUDE​

DTID 3915 “Vascular​

1​

MC​ IFF value of row 9​

Occlusion Properties”​

equals EV​

(26036001, SCT,​

"Occlusion")​

18​

>>​

INCLUDE​

DTID 3916 “Stent​

1​

MC​ IFF value of row 9​

Properties”​

equals (65818007,​

SCT, "Stent")​

Content Item Descriptions​

Row 5​

A positive value indicates a distance in the direction of flow within the vessel​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 275​

Row 7, 8​

Theserowsareassociatedwiththepositionofthemostsignificanteffectofthelesion,i.e.,maximumdiameter​

of aneurysm or the minimum diameter of stenosis​

TID 3909 Best Illustration of Findings​

Specification of images, waveforms, spatial and temporal coordinates used to illustrate findings.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3909. Best Illustration of Findings​

NL​

Rel with Parent​

VT​

Concept Name​

VM​ Req Type​Condition​ Value Set​

Constraint​

1​

CONTAINS​

IMAGE​

EV(121080,DCM,"Best​

1​

U​

illustration of finding")​

2​

CONTAINS​

WAVEFORM​ EV(121080,DCM,"Best​

1​

U​

illustration of finding")​

3​

CONTAINS​

SCOORD​

EV(121080,DCM,"Best​

1​

U​

illustration of finding")​

4​

>​

SELECTED FROM​ IMAGE​

1​

M​

5​

CONTAINS​

TCOORD​

EV(121080,DCM,"Best​

1​

U​

illustration of finding")​

6​

>​

SELECTED FROM​ SCOORD​

1​

MC​

XOR row 8,​

9​

7​

>>​

SELECTED FROM​ IMAGE​

1​

M​

must be a​

multi-frame​

image​

8​

>​

SELECTED FROM​ WAVEFORM​

1​

MC​

XOR row 6,​

9​

9​

>​

SELECTED FROM​ IMAGE​

1​

MC​

XOR row 6,​must be a​

8​

multi-frame​

image​

Content Item Descriptions​

Rows 4, 7, 8, 9​

No purpose of reference is specified.​

TID 3910 Flow Quantification​

Contains the flow quantification measurement results​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3910. Flow Quantification​

NL​

Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

1​

CONTAINS​

CONTAINER​EV (121070, DCM,​

1​ M​

"Findings")​
