Page 916​

DICOM PS3.17 2020a - Explanatory Information​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

-​

-​

-​

0x0201​513​Image​ JPEGInterchange​

Long​

The offset to the start byte​

Format​

(SOI)ofJPEGcompressed​

thumbnail data. This is not​

used for primary image​

JPEG data.​

-​

-​

-​

0x0202​514​Image​ JPEGInterchange​

Long​

The number of bytes of​

FormatLength​

JPEG compressed​

thumbnail data. This is not​

used for primary image​

JPEG data. JPEG​

thumbnails are not divided​

but are recorded as a​

continuousJPEGbitstream​

from SOI to EOI. Appn and​

COM markers should not​

be recorded. Compressed​

thumbnails must be​

recorded in no more than​

64 Kbytes, including all​

other data to be recorded​

in APP1.​

-​

-​

-​

0x0203​515​Image​ JPEGRestartInterval​

Short​

This Field indicates the​

lengthoftherestartinterval​

used in the compressed​

image data.​

-​

-​

-​

0x0205​517​Image​ JPEGLossless​

Short​

This Field points to a list of​

Predictors​

losslesspredictor-selection​

values, one per​

component.​

-​

-​

-​

0x0206​518​Image​ JPEGPointTransforms​ Short​

This Field points to a list of​

pointtransformvalues,one​

per component.​

-​

-​

-​

0x0207​519​Image​ JPEGQTables​

Long​

This Field points to a list of​

offsets to the quantization​

tables,onepercomponent.​

-​

-​

-​

0x0208​520​Image​ JPEGDCTables​

Long​

This Field points to a list of​

offsets to the DC Huffman​

tables or the lossless​

Huffman tables, one per​

component.​

-​

-​

-​

0x0209​521​Image​ JPEGACTables​

Long​

This Field points to a list of​

offsets to the Huffman AC​

tables,onepercomponent.​

DICOM PS3.17 2020a - Explanatory Information​

Page 917​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

-​

-​

-​

0x0211​529​Image​ YCbCrCoefficients​

Rational​The matrix coefficients for​

transformation from RGB​

to YCbCr image data. No​

defaultisgiveninTIFF;but​

here the value given in​

Appendix E, "Color Space​

Guidelines", is used as the​

default. The color space is​

declared in a color space​

information tag, with the​

defaultbeingthevaluethat​

gives the optimal image​

characteristics​

Interoperability this​

condition.​

-​

-​

-​

0x0212​530​Image​ YCbCrSubSampling​

Short​ The sampling ratio of​

chrominance components​

inrelationtotheluminance​

Page 918​

DICOM PS3.17 2020a - Explanatory Information​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

-​

-​

-​

0x0213​531​Image​ YCbCrPositioning​

Short​ The position of​

chrominance components​

inrelationtotheluminance​

component. This field is​

designated only for JPEG​

compressed data or​

uncompressed YCbCr​

data. The TIFF default is 1​

(centered); but when​

Y:Cb:Cr = 4:2:2 it is​

recommended in this​

standard that 2 (co-sited)​

be used to record data, in​

ordertoimprovetheimage​

qualitywhenviewedonTV​

systems. When this field​

does not exist, the reader​

shall assume the TIFF​

default. In the case of​

Y:Cb:Cr = 4:2:0, the TIFF​

default (centered) is​

recommended. If the​

reader does not have the​

capability of supporting​

both kinds of <YCb​

CrPositioning>, it shall​

follow the TIFF default​

regardless of the value in​

this field. It is preferable​

that readers be able to​

support both centered and​

co-sited positioning.​

-​

-​

-​

0x0214​532​Image​ ReferenceBlackWhite​

Rational​The reference black point​

value and reference white​

pointvalue.Nodefaultsare​

given in TIFF, but the​

values below are given as​

defaults here. The color​

spaceisdeclaredinacolor​

spaceinformationtag,with​

the default being the value​

that gives the optimal​

image characteristics​

Interoperability these​

conditions.​

-​

-​

-​

0x02bc​700​Image​ XMLPacket​

Byte​

XMP Metadata (Adobe​

technote 9-14-02)​

-​

-​

-​

0x4746​18246​Image​ Rating​

Short​ Rating tag used by​

Windows​

-​

-​

-​

0x4749​18249​Image​ RatingPercent​

Short​

Rating tag used by​

Windows, value in percent​

DICOM PS3.17 2020a - Explanatory Information​

Page 919​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

-​

-​

-​

0x800d​32781​Image​ ImageID​

Ascii​

ImageID is the full​

pathname of the original,​

high-resolution image, or​

any other identifying string​

that uniquely identifies the​

original image (Adobe​

OPI).​

-​

-​

-​

0x828d​33421​Image​ CFARepeatPatternDim​ Short​ Contains two values​

representing the minimum​

rowsandcolumnstodefine​

the repeating patterns of​

the color filter array​

-​

-​

-​

0x828e​33422​Image​ CFAPattern​

Byte​

Indicates the color filter​

array (CFA) geometric​

patternoftheimagesensor​

whenaone-chipcolorarea​

sensor is used. It does not​

apply to all sensing​

methods. [Not EXIF but​

TIFF/EP]​

(0016,0003)​Battery Level​ VL​

0x828f​33423​Image​ BatteryLevel​

Rational​Contains a value of the​

Photographic​

battery level as a fraction​

Acquisition​

or string​

Module​

Page 920​

DICOM PS3.17 2020a - Explanatory Information​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

-​

-​

-​

0x8298​33432​Image​ Copyright​

Ascii​

Copyright information. In​

this standard the tag is​

used to indicate both the​

photographer and editor​

copyrights. It is the​

copyright notice of the​

person or organization​

claiming rights to the​

image.TheInteroperability​

copyright statement​

including date and rights​

should be written in this​

field;e.g.,"Copyright,John​

Smith, 19xx. All rights​

reserved.".Inthisstandard​

the field records both the​

photographer and editor​

copyrights, with each​

recordedinaseparatepart​

of the statement. When​

there is a clear distinction​

between the photographer​

and editor copyrights,​

these are to be written in​

the order of photographer​

followed by editor​

copyright, separated by​

NULL (in this case since​

the statement also ends​

with a NULL, there are two​

NULL codes). When only​

thephotographercopyright​

is given, it is terminated by​

oneNULLcode.Whenonly​

the editor copyright is​

given, the photographer​

copyright part consists of​

one space followed by a​

terminating NULL code,​

then the editor copyright is​

given. Whenthe fieldis left​

blank, it is treated as​

unknown.​

-​

-​

-​

0x83bb​33723​Image​ IPTCNAA​

Long​

Contains an IPTC/NAA​

record​

-​

-​

-​

0x8649​34377​Image​ ImageResources​

Byte​

Contains information​

embedded by the Adobe​

Photoshop application​
