DICOM PS3.17 2020a - Explanatory Information​



Page 121​

Node​

Code Meaning of Concept Name​Code Meaning of Example Value​

TID​

1.3.1.2​

Rendering Intent​

Presentation Required: …​

TID 4102​



1.3.1.3​

Tracking Identifier​

"Watchlist #1"​

TID 4108​



1.3.1.4​

Algorithm Name​

"Chest/CT Correlator"​

TID 4019​



1.3.1.5​

Algorithm Version​

"V2.1"​

TID 4019​



1.3.1.6​

Composite type​

Target content items are related​

TID 4103​







spatially​





1.3.1.7​

Scope of Feature​

Feature detected on images from​

TID 4103​







multiple modalities​





1.3.1.8​

Diameter​

4 cm​

TID 1400​



1.3.1.8.1​

Path​



TID 1400​



1.3.1.8.1.1​



IMAGE 3 [CT slice 104]​

TID 1400​



1.3.1.9​

Volume estimated from single 2D​

3.2 cm3​

TID 1402​





region​







1.3.1.9.1​

Perimeter Outline​



TID 1402​



1.3.1.9.1.1​



IMAGE 3 [CT slice 104]​

TID 1402​



1.3.1.10​

Size Descriptor​

Small​

TID 4105​



1.3.1.11​

Border Shape​

Lobulated​

TID 4105​



1.3.1.12​

Location in Chest​

Mid lobe​

TID 4105​



1.3.1.13​

Laterality​

Right​

TID 4105​



1.3.1.14​

Composite Feature​

Abnormal opacity​

TID 4102​



1.3.1.15​

Single Image Finding​

Abnormal opacity​

TID 4104​



Node​

Code Meaning of Concept Name​ Code Meaning of Example Value​

TID​

1.3.1.14​

Composite Feature​

Abnormal opacity​

TID 4102​

1.3.1.14.1​

Composite Feature Modifier​

Nodule​

TID 4102​

1.3.1.14.2​

Rendering Intent​

Presentation Required: …​

TID 4102​

1.3.1.14.3​

Tracking Identifier​

"Nodule #1"​

TID 4108​

1.3.1.14.4​

Algorithm Name​

"Nodule Builder"​

TID 4019​

1.3.1.14.5​

Algorithm Version​

"V1.4"​

TID 4019​

1.3.1.14.6​

Composite type​

Target content items are related​

TID 4103​





spatially​





1.3.1.14.7​

Scope of Feature​

Featuredetectedonmultipleimages​TID 4103​

1.3.1.14.8​

Diameter​

4 cm​

TID 1400​

1.3.1.14.9​

Volume estimated from single 2D​

3.2 cm3​

TID 1402​



region​







1.3.1.14.10​

Single Image Finding​

Abnormal opacity​

TID 4104​

1.3.1.14.11​

Single Image Finding​

Abnormal opacity​

TID 4104​

1.3.1.14.12​

Single Image Finding​

Abnormal opacity​

TID 4104​

Node​

CodeMeaningofConceptName​Code Meaning of Example Value​

TID​

1.3.1.14.10​

Single Image Finding​

Abnormal opacity​

TID 4104​



1.3.1.14.10.1​

Single Image Finding Modifier​

Nodule​

TID 4104​



1.3.1.14.10.2​

Rendering Intent​

Presentation Required: …​

TID 4104​



1.3.1.14.10.3​

Tracking Identifier​

"Detection #1"​

TID 4108​



- Standard -​

Page 122​

DICOM PS3.17 2020a - Explanatory Information​





Node​

CodeMeaningofConceptName​Code Meaning of Example Value​

TID​

1.3.1.14.10.4​

Algorithm Name​

"CT Nodule Detector"​

TID 4019​

1.3.1.14.10.5​

Algorithm Version​

"V2.5"​

TID 4019​

1.3.1.14.10.6​

Center​

POINT​

TID 4107​

1.3.1.14.10.6.1​



IMAGE 2 [CT slice 103]​

TID 4107​

1.3.1.14.10.7​

Outline​

POLYLINE​

TID 4107​

1.3.1.14.10.7.1​



IMAGE 2 [CT slice 103]​

TID 4107​

Node​

CodeMeaningofConceptName​Code Meaning of Example Value​

TID​

1.3.1.14.11​

Single Image Finding​

Abnormal opacity​

TID 4104​

1.3.1.14.11.1​

Single Image Finding Modifier​

Nodule​

TID 4104​

1.3.1.14.11.2​

Rendering Intent​

Presentation Required: …​

TID 4104​

1.3.1.14.11.3​

Tracking Identifier​

"Detection #2"​

TID 4108​

1.3.1.14.11.4​

Algorithm Name​

"CT Nodule Detector"​

TID 4019​

1.3.1.14.11.5​

Algorithm Version​

"V2.5"​

TID 4019​

1.3.1.14.11.6​

Center​

POINT​

TID 4107​

1.3.1.14.11.6.1​



IMAGE 3 [CT slice 104]​

TID 4107​

1.3.1.14.11.7​

Outline​

POLYLINE​

TID 4107​

1.3.1.14.11.7.1​



IMAGE 3 [CT slice 104]​

TID 4107​

Node​

CodeMeaningofConceptName​Code Meaning of Example Value​

TID​

1.3.1.14.12​

Single Image Finding​

Abnormal opacity​

TID 4104​

1.3.1.14.12.1​

Single Image Finding Modifier​

Nodule​

TID 4104​

1.3.1.14.12.2​

Rendering Intent​

Presentation Required: …​

TID 4104​

1.3.1.14.12.3​

Tracking Identifier​

"Detection #3"​

TID 4108​

1.3.1.14.12.4​

Algorithm Name​

"CT Nodule Detector"​

TID 4019​

1.3.1.14.12.5​

Algorithm Version​

"V2.5"​

TID 4019​

1.3.1.14.12.6​

Center​

POINT​

TID 4107​

1.3.1.14.12.6.1​



IMAGE 4 [CT slice 105]​

TID 4107​

1.3.1.14.12.7​

Outline​

POLYLINE​

TID 4107​

1.3.1.14.12.7.1​



IMAGE 4 [CT slice 105]​

TID 4107​

Node​

CodeMeaningofConceptName​Code Meaning of Example Value​

TID​

1.3.1.15​

Single Image Finding​

Abnormal opacity​

TID 4104​



1.3.1.15.1​

Single Image Finding Modifier​

Nodule​

TID 4104​



1.3.1.15.2​

Rendering Intent​

Presentation Required: …​

TID 4104​



1.3.1.15.3​

Tracking Identifier​

"Watchlist #1"​

TID 4108​



1.3.1.15.4​

[Observation Context content​



TID 4022​





items]​







1.3.1.15.5​

Algorithm Name​

"Lung Nodule Detector"​

TID 4019​



1.3.1.15.6​

Algorithm Version​

"V1.3"​

TID 4019​



1.3.1.15.7​

Center​

POINT​

TID 4107​



1.3.1.15.7.1​



Reference to node 1.2.1​

TID 4107​



1.3.1.15.8​

Outline​

POLYLINE​

TID 4107​



- Standard -​



DICOM PS3.17 2020a - Explanatory Information​



Page 123​

Node​

CodeMeaningofConceptName​Code Meaning of Example Value​

TID​

1.3.1.15.8.1​



Reference to node 1.2.1​

TID 4107​



1.3.1.15.9​

Diameter​

4 cm​

TID 1400​



1.3.1.15.9.1​

Path​

POLYLINE​

TID 1400​



1.3.1.15.9.1.1​



Reference to Node 1.2.1​

TID 1400​



Node​

Code Meaning of Concept​

Code Meaning of Example Value​

TID​



Name​





1.4​

Summary of Detections​

Succeeded​

TID 4100​

1.4.1​

Successful Detections​



TID 4015​

1.4.1.1​

Detection Performed​

Nodule​

TID 4017​

1.4.1.1.1​

Algorithm Name​

"CT Nodule Detector"​

TID 4019​

1.4.1.1.2​

Algorithm Version​

"V2.5"​

TID 4019​

1.4.1.1.3​



IMAGE 2 [CT slice 103]​

TID 4017​

1.4.1.1.4​



IMAGE 3 [CT slice 104]​

TID 4017​

1.4.1.1.5​



IMAGE 4 [CT slice 105]​

TID 4017​

1.5​

Summary of Analyses​

Succeeded​

TID 4100​

1.5.1​

Successful Analyses​



TID 4016​

1.5.1.1​

Analysis Performed​

"Spatial colocation analysis"​

TID 4018​

1.5.1.1.1​

Algorithm Name​

"Chest/CT Correlator"​

TID 4019​

1.5.1.1.2​

Algorithm Version​

"V2.1"​

TID 4019​

1.5.1.1.3​



Reference to node 1.2.1​

TID 4018​

1.5.1.1.4​



IMAGE 2 [CT slice 103]​

TID 4018​

1.5.1.1.5​



IMAGE 3 [CT slice 104]​

TID 4018​

1.5.1.1.6​



IMAGE 4 [CT slice 105]​

TID 4018​

1.5.1.2​

Analysis Performed​

"Spatial colocation analysis"​

TID 4018​

1.5.1.2.1​

Algorithm Name​

"Nodule Builder"​

TID 4019​

1.5.1.2.2​

Algorithm Version​

"V1.4"​

TID 4019​

1.5.1.2.3​



IMAGE 2 [CT slice 103]​

TID 4018​

1.5.1.2.4​



IMAGE 3 [CT slice 104]​

TID 4018​

1.5.1.2.5​



IMAGE 4 [CT slice 105]​

TID 4018​

- Standard -​

Page 124​

DICOM PS3.17 2020a - Explanatory Information​

- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 125​

G Explanation of Grouping Criteria For​ Multi-frame Functional Group IODs​ (Informative)​

This Annex was formerly located in Annex N “Explanation of Grouping Criteria for Multi-frame Functional Group IODs (Informative)”​ in PS3.3 in the 2003 and earlier revisions of the Standard.​

When considering how to group an Attribute, one needs to consider first of all whether or not the values of an Attribute are different​ per frame. The reasons to consider whether to allow an Attribute to change include:​

•​The more Attributes that change, the more parsing a receiving application has to do in order to determine if the multi-frame object​ has frames the application should deal with. The more choices, the more complex the application becomes, potentially resulting in​ interoperability problems.​

•​The frequency of change of an Attribute must also be considered. If an Attribute could be changed every frame then obviously it is​ not a very good candidate for making it fixed, since this would result in a multi-frame size of 1.​

•​ThenumberofapplicationsthatdependonframelevelAttributegroupingisanotherconsideration.Forexample,onemightimagine​ apulsesequencebeingchangedinareal-timeacquisition,butthevastmajorityofacquisitionswouldleavethisconstant.Therefore,​ it was judged not too large a burden to force an acquisition device to start a new object when this happens. Obviously, this is a​ somewhat subjective decision, and one should take a close look at the Attributes that are required to be fixed in this document.​

•​The Attributes from the image pixel module must not change in a multi-frame object due to legacy tool kits and implementations.​

•​The potential frequency of change is dependent on the applications both now and likely during the life of this Standard. The penalty​ for failure to allow an Attribute to change is rather high since it will be hard/impossible to change later. Making an Attribute variable​ that is static is more complex and could result in more header space usage depending on how it is grouped. Thus there is a trade-​ off of complexity and potentially header size with not being able to take advantage of the multi-frame organization for an application​ that requires changes per frame.​

Once it is decided which Attributes should be changed within a multi-frame object then one needs to consider the criteria for grouping​ Attributes together:​

•​Groupings should be designed so those Attributes that are likely to vary together should be in the same sequence. The goal is to​ avoid the case where Attributes that are mostly static have to be included in a sequence that is repeated for every frame.​

•​Care should be taken so that we define a manageable number of grouping sequences. Too few sequences could result in many​ static Attributes being repeated for each frame, when some other element in their sequence was varying, and too many sequences​ becomes unwieldy.​

•​The groupings should be designed such that modality independent Attributes are kept separate from those that are MR specific.​ This will presumably allow future working groups to reuse the more general groupings. It also should allow software that operates​ on multi-frame objects from multiple objects maximize code reuse.​

•​Grouping related Attributes together could convey some semantics of the overall contents of the multi-frame object to receiving​ applications. For instance, if a volumetric application finds the Plane Orientation Macro present in the Per-frame Functional Groups​ Sequence, it may decide to reject the object as inappropriate for volumetric calculations.​

Specific notes on Attribute grouping:​

•​Attributes not allowed to change: Image Pixel Module (due to legacy toolkit concerns); and Pulse Sequence Module Attributes​ (normally do not change except in real-time - it is expected real time applications can handle the complexity and speed of starting​ new IODs when pulse sequence changes).​

•​Sequences not starting with the word "MR" could be applied to more modalities than just MR.​

•​All Attributes that must be in a frame header were placed in the Frame Content Macro.​

- Standard -​
