Chapter 2 • Thorax

PA= pulmonary artery

RA = right atrium

AA= ascending aorta

LA= left atrium

E = esophagus

DA= descending aorta



Figure 111-2-43. Chest: CT, T5

Right

Left

Atrium

Ventricle

Esophagus

Figure 111-2-44. Chest: CT, T6

MEDICAL 227

Section Ill • Gross Anatomy

ChapterSummary

•The chest wall is formed by 1 2 thoracic vertebrae, 1 2 pairs of ribs, and the sternum. An important landmark on the anterior chest wall is the sternal angle found where the 2nd rib articulates with the sternum.

•The respiratory system develops as an endodermal outgrowth ofthe foregut. The tracheoesophageal septum separates the lung buds from the foregut. Improper development ofthis septum will produce an abnormal communication between the trachea and esophagus, a tracheoesophageal fistula.

•The lungs are surrounded by the pleura, which is divided into the parietal

pleura lining, the inner surface ofthe thoracic cavity, and the visceral pleura that is attached to the surface ofthe lung. Between these 2 layers is the pleural cavity containing a small amount of serous fluid. The lungs demonstrate costal, mediastinal, and diaphragmatic surfaces and an apex

that projects through the thoracic inlet into the root ofthe neck. Oblique and horizontal fissures divide the lungs into lobes.

•Heart development begins with the formation of a primitive heart tube, which develops from the lateral plate mesoderm in the third week. The arterial end of the heart tube is called the truncus arteriosus and will develop into the aorta and pulmonary trunk. The sinus venosus at the venous end ofthe heart tube will develop into the coronary sinus and the smooth part ofthe right atrium. The primitive atrial and ventricle chambers divide into right and left chambers following development of interatrial and interventricular septae. Ventricular septal defects result from failure of the membranous septum

to develop. Failure ofthe foramen ovale to close at birth results in atrial septal defects. Fetal circulation involves 3 shunts: ductus venosus, ductus arteriosum, and the foramen ovale. After birth these shunts shut down following changes in the circulatory system.

•The thoracic cavity is divided into the superior mediastinum above the plane of the sternal angle and the inferior mediastinum (anterior, middle, and posterior mediastina) below that sternal plane. The superior mediastinum contains the superiorvena cava, aortic arch and its branches, trachea, esophagus, thoracic duct, and the vagus and phrenic nerves. The anterior mediastinum is anterior to the heart and contains remnants ofthe thymus. The middle mediastinum contains the heart and great vessels and the posterior mediastinum containing the thoracic aorta, esophagus, thoracic duct, azygos veins, and vagus nerve. The inferiorvena cava passes through the diaphragm atthe caval hiatus at the level ofthe 8th thoracic vertebra, the esophagus through the esophageal hiatus at the 10th thoracic vertebra, and the aorta course through the aortic hiatus at the level ofthe 12th thoracic vertebra.

•Covering the heart is the pericardium formed by an outer, tough fibrous layer and a doubled-layered serous membrane divided into parietal and visceral layers. The pericardia! cavity is located between these 2 serous layers and includes the transverse and oblique pericardiaI sinuses.

(Continued)

228 MEDICAL

Chapter 2 • Thorax

ChapterSummary

•The external surface of the heart consists of several borders: the right border formed by the rightatrium, the left border formed by the leftventricle, the base formed bythe 2 atria, and the apex at the tip ofthe leftventricle. The anterior surface is formed bythe rightventricle, the posterior surface formed mainly by the left atrium, and a diaphragmatic surface is formed primarily by the left ventricle.

•Arterial supply to the heart muscle is provided by the right and left coronary arteries, which are branches ofthe ascending aorta. The right coronary artery supplies the right atrium, the right ventricle, the sinoatrial and atrioventricular nodes, and parts ofthe left atrium and left ventricle. The distal branch ofthe right coronary artery is the posterior interventricular artery that supplies, in part, the posterior aspect of the interventricular septum.

•The left coronary artery supplies most ofthe leftventricle, the left atrium, and the anterior part ofthe interventricular septum. The 2 main branches ofthe left coronaryartery are the anterior interventricular artery and the circumflex artery.

•Venous drainage ofthe heart is provided primarily by the great cardiac and middle cardiac veins and the coronary sinus, which drains into the right atrium.

•Sympathetic innervation increases the heart rate while the parasympathetics slows the heart rate. These autonomics fibers fire upon the conducting system ofthe heart.

-The sinoatrial node initiates the impulse for cardiac contraction.

-The atrioventricular node receives the impulse from the sinoatrial node and transmits that impulse to the ventricles through the bundle of His. The bundle divides into the right and left bundle branches and Purkinje fibers to the 2 ventricles.

MEDICAL 229

Abdomen, Pelvis, and Perineum

3

ANTERIOR ABDOMINAL WALL

Surface Anatomy

Linea Alba

The linea alba is a shallow groove that runs vertically in the median plane from the xiphoid to the pubis. It separates the right and left rectus abdominis muscles. The components of the rectus sheath intersect at the linea alba.

Linea Semilunaris

The linea semilunaris is a curved line defining the lateral border of the rectus abdorninis, a bilateral feature.

Planes and Regions

The anterior abdominal wall is divided into 9 regions separated by several planes and lines (Figure III-3- 1) .

Subcostalplane

The subcostal plane (horizontal) passes through the inferior margins of the 10th costal cartilages at the level of the third lumbar vertebra.

Transpyloricplane

The transpyloric plane passes through the Ll vertebra, being half the distance be­ tween the pubis and the jugular notch. The plane passes through several important abdominal landmarks useful for radiology: pylorus of the stomach (variable), fun­ dus of gallbladder, neck and body of the pancreas, hila of kidneys, first part of the duodenum, and origin ofthe superior mesenteric artery

Midclavicularlines

The midclavicular lines (vertical) are the 2 planes that pass from the midpoint of the clavicle to the midpoint of the inguinal ligament on each side.

MEDICAL 231
