DICOM PS3.16 2020a - Content Mapping Resource​

Page 1001​

Version:​

20080626​









UID:​

1.2.840.10008.6.1.1053​











Table CID 8115. Specimen Embedding Media​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​













SCT​

311731000​

Paraffin wax​





F-616D8​

C0030415​

SCT​

433469005​

Tissue freezing medium​



F-62232​

C2315537​

SCT​

61088005​

Plastic​





C-2A000​

C0032167​

SCT​

10249006​

Agar​





C-84085​

C0001771​

SCT​

65345002​

Epoxy resin​





C-2A400​

C0014631​

SCT​

261712009​

Acrylic resin​





C-100EA​

C0444831​

CID 8120 WSI Referenced Image Purposes of Reference​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​









Version:​

20100824​









UID:​

1.2.840.10008.6.1.897​











Table CID 8120. WSI Referenced Image Purposes of Reference​

Coding Scheme Designator​

Code Value​





Code Meaning​

DCM​



121311​

Localizer​





DCM​



121350​

Same acquisition at lower resolution​

DCM​



121351​

Same acquisition at higher resolution​

DCM​



121352​

Same acquisition at different focal depth​

DCM​



121353​

Same acquisition at different spectral band​

DCM​



121354​

Imaged container label​



CID 8121 Microscopy Lens Type​









Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​









Version:​

20100824​









UID:​

1.2.840.10008.6.1.898​











Table CID 8121. Microscopy Lens Type​



Coding Scheme​

Code Value​

Code Meaning​



SNOMED-RT ID​

UMLSConceptUniqueID​

Designator​













SCT​

445621001​ Highpowernon-immersionlens​

A-0011A​

C2919938​

SCT​

445622008​

Oil immersion lens​





A-0011B​

C2919939​

SCT​

445601002​

Slide overview lens​





A-00118​

C2919940​

CID 8122 Microscopy Illuminator and Sensor Color​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​









Version:​

20100824​









UID:​

1.2.840.10008.6.1.899​









- Standard -​

Page 1002​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 8122. Microscopy Illuminator and Sensor Color​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

414298005​

Full Spectrum​

R-102C0​

C1532530​

SCT​

414497003​

Infrared​

R-102BE​

C1532326​

SCT​

371240000​

Red​

G-A11A​

C1260956​

SCT​

371246006​

Green​

G-A11E​

C0332583​

SCT​

405738005​

Blue​

G-A12F​

C1260957​

SCT​

415770004​

Ultraviolet​

R-102BF​

C1532472​

CID 8123 Microscopy Illumination Method​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20100824​

UID:​

1.2.840.10008.6.1.900​

Table CID 8123. Microscopy Illumination Method​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

111741​

Transmission illumination​

DCM​

111742​

Reflection illumination​

DCM​

111743​

Epifluorescence illumination​

DCM​

111744​

Brightfield illumination​

DCM​

111745​

Darkfield illumination​

DCM​

111746​

Oblique illumination​

DCM​

111747​

Phase contrast illumination​

DCM​

111748​

Differential interference contrast​

DCM​

111749​

Total internal reflection fluorescence​

CID 8124 Microscopy Filter​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20100824​

UID:​

1.2.840.10008.6.1.901​

Table CID 8124. Microscopy Filter​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique​

Designator​





ID​

SCT​

445465004​

Green optical filter​

SCT​

445279009​

Red optical filter​

SCT​

445084008​

Blue optical filter​

SCT​

445169002​

Infrared optical filter​

SCT​

445391002​

Polarizing optical filter​

SCT​

445278001​

Violet optical filter​

SCT​

445254006​

Ultraviolet optical filter​

SCT​

445316008​

Dichroic beamsplitter​

A-010E2​

C2919396​

A-010DF​

C2919397​

A-010DA​

C2919751​

A-010DC​

C2919637​

A-010E1​

C2919554​

A-010DE​

C2919567​

A-010DD​

C2919555​

A-0010F​

C2919671​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1003​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique​

Designator​







ID​

SCT​

445635004​

Hoffman modulator​

SCT​

445624009​

Darkfield stop​

SCT​

445623003​

Rheinberg filter​

SCT​

445625005​

Phase contrast plate​

SCT​

445634000​

Condenser annulus​

SCT​

445633006​

Nomarski prism​

SCT​

445663002​

de Sénarmont compensator​

DCM​

111609​

No filter​

A-00121​

C2919672​

A-0011D​

C2919815​

A-0011C​

C2919816​

A-0011E​

C2919530​

A-00120​

C2919531​

A-0011F​

C2919532​

A-00123​

C2919789​

CID 8125 Microscopy Illuminator Type​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20100824​

UID:​

1.2.840.10008.6.1.902​

Table CID 8125. Microscopy Illuminator Type​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

445679001​

Tungsten halogen lamp​

A-00125​

C2919726​

SCT​

445685008​

Mercury arc lamp​

A-00127​

C2919809​

SCT​

445671003​

Xenon arc lamp​

A-00124​

C2919810​

SCT​

445683001​

Light emitting diode​

A-00126​

C2919811​

SCT​

122456005​

Laser​

A-23000​

C0023089​

CID 8130 Staining Protocols​

This Context Group is intended for use in the Scheduled Protocol Code Sequence (0040,0008) and the Performed Protocol Code​ Sequence (0040,0260) attributes for an automated slide stainer. When so used, an Item with value (127790008, SCT, "Staining") will​ also include a Protocol Context Sequence (0040,0440) using TID 8003 “Specimen Staining” to identify the specific stain substance.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20111028​

UID:​

1.2.840.10008.6.1.944​

Table CID 8130. Staining Protocols​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLSConceptUniqueID​

Designator​









SCT​

127790008​

Staining​

P3-00003​

C0487602​

SCT​

104210008​

Hematoxylin and eosin stain​

P3-50495​

C0523207​





method​





CID 8131 Pathology Imaging Protocols​

This Context Group is intended for use in the Scheduled Protocol Code Sequence (0040,0008) and the Performed Protocol Code​ Sequence(0040,0260).Whensoused,anItemwithvalue(112703,DCM,"WholeSlideImaging")mayalsoincludeaProtocolContext​ Sequence (0040,0440) using TID 8010 “Slide Imaging Parameters”.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

- Standard -​

Page 1004​

DICOM PS3.16 2020a - Content Mapping Resource​



Type:​

Extensible​









Version:​

20120605​









UID:​

1.2.840.10008.6.1.948​









Table CID 8131. Pathology Imaging Protocols​



Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​



112700​



Peri-operative Photographic Imaging​

DCM​



112701​



Gross Specimen Imaging​



DCM​



112702​



Slide Microscopy​



DCM​



112703​



Whole Slide Imaging​



DCM​



112704​



WSI 20X RGB​



DCM​



112705​



WSI 40X RGB​



CID 8132 Magnification Selection​







Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​









Version:​

20120605​









UID:​

1.2.840.10008.6.1.949​









Table CID 8132. Magnification Selection​



Coding Scheme Designator​



Code Value​

Code Meaning​

DCM​





112715​

5X​



DCM​





112716​

10X​



DCM​





112717​

20X​



DCM​





112718​

40X​



CID 8133 Tissue Selection​









Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​









Version:​

20120605​









UID:​

1.2.840.10008.6.1.950​









Table CID 8133. Tissue Selection​



Coding Scheme Designator​

Code Value​



Code Meaning​

DCM​



112719​

Nominal empty tile suppression​

DCM​



112720​

High threshold empty tile suppression​

DCM​



112721​

No empty tile suppression​



CID 8201 Surface Scan Acquisition Types​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​









Version:​

20121129​









UID:​

1.2.840.10008.6.1.953​









Table CID 8201. Surface Scan Acquisition Types​



Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​



114201​



Time of flight​



- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1005​

Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



114202​

Interferometry​



DCM​



114203​

Laser scanning​



DCM​



114204​

Pattern projection​



DCM​



114205​

Shape from shading​



DCM​



114206​

Shape from motion​



DCM​



114207​

Confocal imaging​



DCM​



114208​

Point Cloud Algorithmic​



CID 8202 Surface Scan Mode Types​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20121129​







UID:​

1.2.840.10008.6.1.954​







Table CID 8202. Surface Scan Mode Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



114209​

Turntable Scan Method​



DCM​



114210​

High resolution​



DCM​



114211​

Fast mode​



DCM​



114216​

Checkerboard​



CID 8203 Surface Scan Registration Method Types​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20121129​







UID:​

1.2.840.10008.6.1.956​





Table CID 8203. Surface Scan Registration Method Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



114213​

Iterative Closest Point​



DCM​



125022​

Fiducial Alignment​



DCM​



114215​

Freehand​



CID 8300 Visual Evaluation Methods​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20140331​







UID:​

1.2.840.10008.6.1.980​







Table CID 8300. Visual Evaluation Methods​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



109701​

Overall image quality evaluation​



DCM​



109702​

Grayscale resolution evaluation​



DCM​



109703​

Luminance response evaluation​



DCM​



109704​

Luminance uniformity evaluation​



- Standard -​
