DICOM PS3.16 2020a - Content Mapping Resource​

Page 1011​

Type:​

Extensible​







Version:​

20160601​







UID:​

1.2.840.10008.6.1.1120​







Table CID 9233. Requested Report Types​



Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​



121362​

Preliminary Report​



DCM​



128005​

Final Report​



CID 9241 Radiotherapy General Workitem Definition​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20151110​







UID:​

1.2.840.10008.6.1.931​





Table CID 9241. Radiotherapy General Workitem Definition​



CodingSchemeDesignator​

Code Value​



Code Meaning​



DCM​

121701​

RT Patient Setup​



DCM​

121722​

RT Patient Position Adjustment​



DCM​

121723​

RT Patient Position In-treatment-session Review​



DCM​

121724​

RT Treatment Simulation with Internal Verification​



DCM​

121725​

RT Treatment Simulation with External Verification​



DCM​

121726​

RT Treatment with Internal Verification​



DCM​

121727​

RT Treatment with External Verification​



DCM​

121728​

RT Treatment QA with Internal Verification​



DCM​

121729​

RT Treatment QA with External Verification​



DCM​

121730​

RT Machine QA​





DCM​

121731​

RT Treatment QA by RT Plan Dose Check​



DCM​

121732​

RT Treatment QA by RT Plan Difference Check​



DCM​

121733​

RT Treatment QA by RT Ion Plan Dose Check​



DCM​

121734​

RT Treatment QA by RT Ion Plan Difference Check​



DCM​

121735​

RT Brachy Treatment​



CID 9242 Radiotherapy Acquisition Workitem Definition​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20110406​







UID:​

1.2.840.10008.6.1.932​





Table CID 9242. Radiotherapy Acquisition Workitem Definition​



CodingSchemeDesignator​

Code Value​



Code Meaning​



DCM​

121702​

RT Patient Position Acquisition, single plane MV​



DCM​

121703​

RT Patient Position Acquisition, dual plane MV​



DCM​

121704​

RT Patient Position Acquisition, single plane kV​



DCM​

121705​

RT Patient Position Acquisition, dual plane kV​



DCM​

121706​

RT Patient Position Acquisition, dual plane kV/MV​



- Standard -​

Page 1012​

DICOM PS3.16 2020a - Content Mapping Resource​

CodingSchemeDesignator​

Code Value​

Code Meaning​

DCM​

121707​

RT Patient Position Acquisition, CT kV​

DCM​

121708​

RT Patient Position Acquisition, CT MV​

DCM​

121709​

RT Patient Position Acquisition, Optical​

DCM​

121710​

RT Patient Position Acquisition, Ultrasound​

DCM​

121711​

RT Patient Position Acquisition, Spatial Fiducials​

CID 9243 Radiotherapy Registration Workitem Definition​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​



Version:​

20110406​



UID:​

1.2.840.10008.6.1.933​



Table CID 9243. Radiotherapy Registration Workitem Definition​

CodingSchemeDesignator​

Code Value​

Code Meaning​

DCM​

121712​

RT Patient Position Registration, single plane​

DCM​

121713​

RT Patient Position Registration, dual plane​

DCM​

121714​

RT Patient Position Registration, 3D CT general​

DCM​

121715​

RT Patient Position Registration, 3D CT marker-based​

DCM​

121716​

RT Patient Position Registration, 3D CT volume-based​

DCM​

121717​

RT Patient Position Registration, 3D on 2D reference​

DCM​

121718​

RT Patient Position Registration, 2D on 3D reference​

DCM​

121719​

RT Patient Position Registration, Optical​

DCM​

121720​

RT Patient Position Registration, Ultrasound​

DCM​

121721​

RT Patient Position Registration, Spatial Fiducials​

CID 9250 Scheduled Processing Parameter Concept Codes for RT Treatment​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170413​

UID:​

1.2.840.10008.6.1.971​

Table CID 9250. Scheduled Processing Parameter Concept Codes for RT Treatment​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

121740​

Treatment Delivery Type​

CID 9300 Procedure Discontinuation Reasons​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181115​

UID:​

1.2.840.10008.6.1.533​

Table CID 9300. Procedure Discontinuation Reasons​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

110526​

Resource pre-empted​

DCM​

110527​

Resource inadequate​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​



Page 1013​

Coding Scheme Designator​

Code Value​



Code Meaning​



DCM​



110533​

Workitem expired​



DCM​



110528​

Discontinued Procedure Step rescheduled​

DCM​



110529​

Discontinued Procedure Step rescheduling​







recommended​





DCM​



110530​

Workitem assignment rejected by assigned resource​

Include CID 9301 “Modality PPS Discontinuation Reasons”​







Include CID 9302 “Media Import PPS Discontinuation Reasons”​







Include CID 60 “Imaging Agent Administration Adverse Events”​







CID 9301 Modality PPS Discontinuation Reasons​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​





Type:​

Extensible​









Version:​

20140419​









UID:​

1.2.840.10008.6.1.812​









Table CID 9301. Modality PPS Discontinuation Reasons​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT​UMLSConcept​

Designator​







ID​

Unique ID​

DCM​

110500​

Doctor canceled procedure​





DCM​

110501​

Equipment failure​







DCM​

110502​

Incorrect procedure ordered​





DCM​

110503​

Patient allergic to media/contrast​





DCM​

110504​

Patient died​







DCM​

110505​

Patient refused to continue procedure​





DCM​

110506​

Patient taken for treatment or surgery​





DCM​

110507​

Patient did not arrive​





DCM​

110508​

Patient pregnant​







DCM​

110509​

Change of procedure for correct charging​



DCM​

110510​

Duplicate order​







DCM​

110511​

Nursing unit cancel​







DCM​

110512​

Incorrect side ordered​





DCM​

110513​

Discontinued for unspecified reason​





DCM​

110514​

Incorrect worklist entry selected​





DCM​

110515​

Patient condition prevented continuing​





DCM​

110516​

Equipment change​







SCT​

95384003​

Injection Site Extravasation​

D0-B0330​

C0521500​

SCT​

292094009​

Radiopharmaceutical Adverse Reaction​

DF-10780​

C0569412​

CID 9302 Media Import PPS Discontinuation Reasons​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​





Type:​

Extensible​









Version:​

20090616​









UID:​

1.2.840.10008.6.1.813​







- Standard -​

Page 1014​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 9302. Media Import PPS Discontinuation Reasons​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

110521​

Objects incorrectly formatted​

DCM​

110522​

Object Types not supported​

DCM​

110523​

Object Set incomplete​

DCM​

110524​

Media Failure​

DCM​

110501​

Equipment failure​

DCM​

110510​

Duplicate order​

DCM​

110513​

Discontinued for unspecified reason​

DCM​

110514​

Incorrect worklist entry selected​

CID 9303 Interpretation Request Discontinuation Reasons​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20171122​

UID:​

1.2.840.10008.6.1.1198​

Table CID 9303. Interpretation Request Discontinuation Reasons​

Coding Scheme​

Code Value​

Code Meaning​

Designator​





DCM​

110526​

Resource pre-empted​

DCM​

110500​

Doctor canceled procedure​

DCM​

110502​

Incorrect procedure ordered​

DCM​

110504​

Patient died​

DCM​

110509​

Change of procedure for correct charging​

DCM​

110510​

Duplicate order​

DCM​

110513​

Discontinued for unspecified reason​

DCM​

110530​

Workitem assignment rejected by assigned resource​

DCM​

110523​

Object Set incomplete​

DCM​

110531​

Insufficient quality for interpretation​

DCM​

110532​

Interpretation requires specialist expertise​

CID 9401 IEC61217 Device Position Parameters​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20130518​

UID:​

1.2.840.10008.6.1.1023​



Table CID 9401. IEC61217 Device Position Parameters​

Coding Scheme Designator​ Code Value​ Code Meaning​

Include CID 9402 “IEC61217 Gantry Position Parameters”​ Include CID 9403 “IEC61217 Patient Support Position Parameters”​

CID 9402 IEC61217 Gantry Position Parameters​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1015​

Type:​

Extensible​



Version:​

20130518​



UID:​

1.2.840.10008.6.1.1024​



Table CID 9402. IEC61217 Gantry Position Parameters​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

126809​

IEC61217 Gantry Continuous Roll Angle​

DCM​

126810​

IEC61217 Gantry Continuous Pitch Angle​

DCM​

126811​

IEC61217 Gantry Continuous Yaw Angle​

CID 9403 IEC61217 Patient Support Position Parameters​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20130518​

UID:​

1.2.840.10008.6.1.1025​

Table CID 9403. IEC61217 Patient Support Position Parameters​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

126801​

IEC61217 Patient Support Continuous Yaw Angle​

DCM​

126802​

IEC61217 Table Top Continuous Pitch Angle​

DCM​

126803​

IEC61217 Table Top Continuous Roll Angle​

DCM​

126804​

IEC61217 Table Top Eccentric Axis Distance​

DCM​

126805​

IEC61217 Table Top Continuous Eccentric Angle​

DCM​

126806​

IEC61217 Table Top Lateral Position​

DCM​

126807​

IEC61217 Table Top Longitudinal Position​

DCM​

126808​

IEC61217 Table Top Vertical Position​

CID 9500 Dosimetric Objective Types​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181112​

UID:​

1.2.840.10008.6.1.1210​

Table CID 9500. Dosimetric Objective Types​

Coding Scheme Designator​

Code Value​

Code Meaning​

Include CID 9532

“No-Parameter Dosimetric Objectives”​



Include CID 9529

“Single Dose Dosimetric Objectives”​



Include CID 9530

“Percentage and Dose Dosimetric Objectives”​



Include CID 9531

“Volume and Dose Dosimetric Objectives”​



DCM​

130074​

Specified Conformity Index​

DCM​

130075​

Specified Healthy Tissue Conformity Index​

DCM​

130076​

Specified Conformation Number​

DCM​

130077​

Specified Homogeneity Index​

CID 9501 Prescription Anatomy Categories​

Resources:​ HTML | FHIR JSON | FHIR XML | IHE SVS XML​

- Standard -​
