Page 226​

DICOM PS3.16 2020a - Content Mapping Resource​

TID 3510 Vital Signs​

The Vital Signs Template consists of a CONTAINER containing the various vital signs measurements. These measurements may be​ acquired automatically from patient monitoring equipment, or may be entered based on manual measurements.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3510. Vital Signs​



NL​

Rel with​

VT​

Concept Name​

VM​

Req​Condition​

Value Set Constraint​





Parent​







Type​





1​





CONTAINER​EV (8716-3, LN, "Vital​ 1​

M​













Signs")​









2​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (271649006,​









“Measurement”​





SCT, "Systolic blood pressure")​















$Units = DCID 3500 “Pressure Units”​















$Method = BCID 3560 “Blood​















Pressure Methods”​

3​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (271650006,​









“Measurement”​





SCT, "Diastolic blood pressure")​















$Units = DCID 3500 “Pressure Units”​

4​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8867-4, LN,​









“Measurement”​





"Heart rate")​















$Units = EV ({H.B.}/min, UCUM,​















"BPM")​

5​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8310-5, LN,​









“Measurement”​





"Body temperature")​















$Units = EV (Cel, UCUM, "C")​

6​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = DCID 3526 “Blood​









“Measurement”​





Gas Saturation”​















$Units = EV (%, UCUM, "%")​

7​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement=EV(86290005,SCT,​









“Measurement”​





"Respiration rate")​















$Units = EV (/min, UCUM,​















"breaths/min")​

8​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122195, DCM,​









“Measurement”​





"Pulse Strength")​















$Units = DT ({0:4}, UCUM, "range​















0:4")​



9​

>​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (225908003,​









“Measurement”​





SCT, "Pain Score")​















$Units = DT ({1:10}, UCUM, "range​















1:10")​

10​

>​

CONTAINS​ CODE​

DT (8884-9, LN,​

1​

U​

BCID 3415 “Cardiac Rhythms”​









"Cardiac Rhythm")​









- Standard -​





DICOM PS3.16 2020a - Content Mapping Resource​



Page 227​

NL​

Rel with​

VT​

Concept Name​

VM​

Req​Condition​

Value Set Constraint​



Parent​







Type​





11​ >​

CONTAINS​ CODE​

DT (9304-7, LN,​

1​

U​

BCID 3416 “Respiration Rhythms”​







"Respiration Rhythm")​









TID 3515 Cardiac Output Measurement by Indicator Dilution​

The Cardiac Output Measurement by Indicator Dilution Template consists of a CONTAINER containing the measurement and signi-​ ficant parameters of the technical method. If the measurement is based on a DICOM Hemodynamic Waveform SOP Instance, that​ object may also be referenced.​

Note​





Fick Cardiac Output is encoded in TID 3560

“Derived Hemodynamic Measurements”.​

Type:​

Extensible​



Order:​

Significant​



Root:​

No​



Table TID 3515. Cardiac Output Measurement By Indicator Dilution​



NL​RelwithParent​ VT​

Concept Name​

VM​

Req​ Condition​

Value Set Constraint​













Type​



1​





CONTAINER​EV (117610000, SCT,​

1​

M​











"Cardiac Output​















measurement")​







2​

>​

CONTAINS​

INCLUDE​

DTID 300​

1​

M​

$Measurement = EV (8737-9,​









“Measurement”​





LN, "Cardiac Output by​















Indicator Dilution")​















$Units = EV (l/min, UCUM,​















"l/min")​















$Method = DCID 3628​















“Cardiac Output Methods”​















$WavePurpose=DT(121112,​















DCM, "Source of​















Measurement")​

3​

>​

HAS ACQ​

NUM​

EV (122319, DCM,​

1​

MC​ IFF Row 2​

UNITS=DCID3510“Catheter​





CONTEXT​



"Catheter Size")​



indicates a​

Size Units”​













thermal​















method​



4​

>​

HAS ACQ​

NUM​

EV (122320, DCM,​

1​

MC​ IFF Row 2​

UNITS=EV(Cel,UCUM,"C")​





CONTEXT​



"InjectateTemperature")​



indicates a​















thermal​















method​



5​

>​

HAS ACQ​

NUM​

EV (122321, DCM,​

1​

M​

UNITS = DT (ml, UCUM, "ml")​





CONTEXT​



"Injectate Volume")​







6​

>​

HAS ACQ​

NUM​

EV (122322, DCM,​

1​

M​

UNITS = DT (1, UCUM, "no​





CONTEXT​



"Calibration Factor")​





units")​

TID 3516 Blood Lab Measurements​

The Blood Lab Measurements Template provides for the recording of measurements made on blood samples obtained during a​ catheterization procedure. The type and anatomic source of the blood is recorded as acquisition context. The results from the blood​ chemistry measurement system are quoted; the measurement names may be pre-coordinated with the type or source of the blood,​

- Standard -​

Page 228​

DICOM PS3.16 2020a - Content Mapping Resource​

or generic measurement names may be reported. In the latter case, the full measurement concept name may be effectively post-co-​ ordinated using the recorded acquisition context.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3516. Blood Lab Measurements​



NL​

Rel with​

VT​

Concept Name​

VM​

Req​Condition​ Value Set Constraint​





Parent​







Type​



1​





CONTAINER​EV (122125, DCM,​

1​

M​











"Blood lab​















measurements")​







2​

>​

HAS ACQ​

CODE​

EV (371439000, SCT,​

1​

M​

DCID 3520 “Blood Source Type”​





CONTEXT​



"Specimen Type")​







3​

>​

HAS ACQ​

CODE​

EV (363704007, SCT,​

1​

M​

BCID 3630 “Cardiovascular​





CONTEXT​



"Procedure site")​





Anatomic Locations”​

4​

>​



INCLUDE​

DTID 1000 “Quotation”​

1​

U​



5​

>​

CONTAINS​

INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (718-7, LN,​









“Measurement”​





"Hemoglobin")​















$Units = DT (g/dl, UCUM, "g/dl")​

6​

>​

CONTAINS​

INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3524​









“Measurement”​





“Blood Gas Pressures”​















$Units = DCID 3500 “Pressure​















Units”​

7​

>​

CONTAINS​

INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3525​









“Measurement”​





“Blood Gas Content”​















$Units=DT(ml/dl,UCUM,"ml/dl")​

8​

>​

CONTAINS​

INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3528​









“Measurement”​





“Blood pH”​















$Units = EV ([pH], UCUM, "pH")​

9​

>​

CONTAINS​

INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3526​









“Measurement”​





“Blood Gas Saturation”​















$Units = EV (%, UCUM, "%")​

10​

>​

CONTAINS​

INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3527​









“Measurement”​





“Blood Base Excess”​















$Units = DT (meq/dl, UCUM,​















"meq/dl")​

11​

>​

CONTAINS​

INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122183,​









“Measurement”​





DCM, "Blood temperature")​

$Units = EV (Cel, UCUM, "C")​

TID 3520 Hemodynamic Clinical Context​

The Clinical Context Template allows the recording of information about the patient's clinical state that may affect interpretation of​ thehemodynamicmeasurements.ThisTemplateincludesseveralcodedconditions(e.g.,complications,drugs,physiologicalchallenges,​ etc.), each of which may have a Concept Modifier of "Relative Time". This Modifier indicates the temporal relationship of the hemody-​ namic measurements to the conditions recorded in this Template. E.g., the Content Item structure:​

- Standard -​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 229​

[CONTAINER] "Findings"​

>HAS ACQ CONTEXT "Cath Procedure Phase" "Post-intervention phase"​ >HAS ACQ CONTEXT [CONTAINER] "Clinical Context"​

>>CONTAINS [CODE] "Complication" "Arrhythmia"​

>>>HAS CONCEPT MOD [CODE] "Relative Time" "After"​ >CONTAINS [CONTAINER] "Arterial Measurements"…​

conveys the semantics that this group of measurements for the post-intervention phase of a cath procedure was made after an occur-​ rence of arrhythmia in the patient.​

In the absence of a Relative Time modifier, the acquisition context is during the identified event or state.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3520. Hemodynamic Clinical Context​



NL​

Rel with​

VT​

Concept Name​

VM​

Req​Condition​

Value Set Constraint​





Parent​







Type​





1​





CONTAINER​EV (122127, DCM,​

1​

M​













"Clinical Context")​









2​

>​

CONTAINS​ CODE​

EV (109054, DCM,​

1-n​

U​

BCID 3602 “Hemodynamic Patient​









"Patient State")​





State”​

3​

>​

CONTAINS​ TEXT​

EV (109054, DCM,​

1​

U​













"Patient State")​









4​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName = EV (116224001,​









Time”​





SCT, "Complication of Procedure")​















$ConditionValue = DCID 3413​















“Adverse Outcomes”​

5​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName=EV(122086,DCM,​









Time”​





"Contrast administered")​















$ConditionValue = BCID 12​















“Radiographic Contrast Agent”​

6​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName=EV(122083,DCM,​









Time”​





"Drug administered")​















$ConditionValue = BCID 10​















“Interventional Drug”​

7​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName=EV(109059,DCM,​









Time”​





"Physiological challenges")​















$ConditionValue = BCID 3271​















“Hemodynamic Physiological​















Challenges”​

8​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName=EV(122138,DCM,​









Time”​





"Circulatory Support")​

$ConditionValue = DCID 3553​

“Circulatory Support”​

- Standard -​

Page 230​



DICOM PS3.16 2020a - Content Mapping Resource​





NL​

Rel with​

VT​

Concept Name​

VM​

Req​Condition​

Value Set Constraint​





Parent​







Type​





9​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName = EV (243147009,​









Time”​





SCT, "Controlled ventilation")​















$ConditionValue = DCID 3554​















“Ventilation”​

10​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName = EV (18590009,​









Time”​





SCT, "Cardiac Pacing")​















$ConditionValue = BCID 3555​















“Pacing”​

11​

>​

CONTAINS​ INCLUDE​

DTID 3521 “Relative​

1-n​

U​

$ConditionName = EV (71388002,​









Time”​





SCT, "Procedure")​

$ConditionValue = BCID 3405​

“Procedure Action Values”​

TID 3521 Relative Time​

TheRelativeTimeTemplateisinvokedby3520HemodynamicAcquisitionContextTemplate.Itspecifiesanapplicableclinicalcontext​ condition and the time of the current measurements relative to that condition.​





Table TID 3521. Parameters​





Parameter Name​





Parameter Usage​



$ConditionName​

Coded term for Concept Name of condition​



$ConditionValue​

Context Group for condition values​



Type:​

Non-Extensible​







Order:​

Significant​







Root:​

No​













Table TID 3521. Relative Time​



NL​

Rel with Parent​ VT​

Concept Name​

VM​

Req Type​Condition​Value Set Constraint​

1​

CODE​

$ConditionName​

1​

M​

$ConditionValue​

2​ >​

HAS CONCEPT​CODE​

EV (118578006, SCT,​

1​

U​

BCID 3600 “Relative​



MOD​

"Relative time")​





Times”​

TID 3530 Hemodynamic Acquisition Context​

The Hemodynamic Acquisition Context Template is invoked by the various hemodynamic measurement Templates.​



Table TID 3530. Parameters​

Parameter Name​

Parameter Usage​

$LocationName​



Coded term for Concept Name of measurement location​

$LocationValue​



Context Group for appropriate anatomic locations​

Type:​

Extensible​



Order:​

Significant​



Root:​

No​



- Standard -​
