NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​ValueSetConstraint​

Type​

1​

HASCONCEPTMOD​CODE​

$LocationName​

1​

M​

$LocationValue​

2​

>​

HASCONCEPTMOD​CODE​

EV (106233006, SCT,​

1​

U​

BCID 3019​

"Topographical modifier")​

“Cardiovascular​

Anatomic Location​

Modifiers”​

3​

HASACQCONTEXT​CODE​

EV (370129005, SCT,​

1​

U​

BCID 3241​

"Measurement Method ")​

“Hemodynamic​

Measurement​

Techniques”​

4​

HASACQCONTEXT​WAVEFORM​DT(121112,DCM,"Source​ 1​

UC​

XOR Row​

of Measurement")​

5​

5​

HASACQCONTEXT​TCOORD​

DT(121112,DCM,"Source​ 1​

UC​

XOR Row​

of Measurement")​

4​

6​

>​

SELECTED FROM​ WAVEFORM​

1​

M​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

NL​ Rel with​

VT​

Concept Name​

VM​

Req​Condition​

Value Set Constraint​

Parent​

Type​

1​

CONTAINS​ INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3611 “Pressure​

“Measurement”​

Measurements”​

$Units = DCID 3500 “Pressure Units”​

2​

CONTAINS​ INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3612 “Blood​

“Measurement”​

Velocity Measurements”​

$Units = EV (mm/s, UCUM, "mm/s")​

3​

CONTAINS​ INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3613​

“Measurement”​

“Hemodynamic Time Measurements”​

$Units = DT (ms, UCUM, "ms")​

4​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (82799009, SCT,​

“Measurement”​

"Cardiac Output")​

$Units = EV (l/min, UCUM, "l/min")​

5​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (90096001, SCT,​

“Measurement”​

"Stroke Volume")​

$Units = DT (ml, UCUM, "ml")​

6​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (10230-1, LN, "LV​

“Measurement”​

Ejection Fraction")​

Page 232​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​ Rel with​

VT​

Concept Name​

VM​

Req​Condition​

Value Set Constraint​

Parent​

Type​

7​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement=EV(8867-4,LN,"Heart​

“Measurement”​

rate")​

$Units = DT ({H.B.}/min, UCUM, "BPM")​

8​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (86290005, SCT,​

“Measurement”​

"Respiration rate")​

$Units=DT(/min,UCUM,"breaths/min")​

9​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (109025, DCM,​

“Measurement”​

"Max dp/dt")​

$Units = DT (mm[Hg]/s, UCUM,​

"mmHg/s")​

10​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (109026, DCM,​

“Measurement”​

"Max neg dp/dt")​

$Units = DT (mm[Hg]/s, UCUM,​

"mmHg/s")​

11​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122190, DCM,​

“Measurement”​

"Max dp/dt/P")​

$Units = DT (/s, UCUM, "/s")​

12​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122192, DCM,​

“Measurement”​

"Indicator appearance time")​

$Units = DT (s, UCUM, "s")​

13​

CONTAINS​ INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122193, DCM,​

“Measurement”​

"Maximum pressure acceleration")​

$Units = DT (mm[Hg]/s2, UCUM,​

"mmHg/s/s")​

14​

CONTAINS​ INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3617 “Valve​

“Measurement”​

Flows”​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 3560. Derived Hemodynamic Measurements​

NL​ Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

1​

CONTAINER​EV (122126, DCM,​

1​ U​

"Derived​

Hemodynamic​

Measurements")​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 233​

NL​ Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

2​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement=DCID3614“ValveAreas,​

“Measurement”​

Non-mitral”​

$Units = EV (cm2, UCUM, "cm2")​

$Equation = DT (122262, DCM, "Area =​

Flow / 44.5 * sqrt(Gradient[mmHg]) ")​

3​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (251012002, SCT,​

“Measurement”​

"Mitral Valve Area")​

$Units = EV (cm2, UCUM, "cm2")​

$Equation = DT (122263, DCM, "MVA =​

Flow / 38.0 * sqrt(Gradient[mmHg]) ")​

4​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement=DCID3615“ValveAreas”​

“Measurement”​

$ModType = EV (121425, DCM, "Index")​

$ModValue = EV (8277-6, LN, "Body​

Surface Area")​

$Units = DT (cm2/m2, UCUM, "cm2/m2")​

5​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3616​

“Measurement”​

“Hemodynamic Period Measurements”​

$Units = DT (s/min, UCUM, "s/min")​

6​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement=DCID3617“ValveFlows”​

“Measurement”​

$Units = DT (ml/s, UCUM, "ml/s")​

7​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (54993008, SCT,​

“Measurement”​

"Cardiac Index")​

$Units = DT (l/min/m2, UCUM, "l/min/m2")​

8​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3529 “Arterial /​

“Measurement”​

Venous Content”​

$Units = DT (ml/dl, UCUM, "ml/dl")​

9​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3618​

“Measurement”​

“Hemodynamic Flows”​

$Units = DT (l/min, UCUM, "l/min")​

10​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8736-1, LN, "FICK​

“Measurement”​

Cardiac Output")​

$Units = DT (l/min, UCUM, "l/min")​

11​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8750-2, LN, "FICK​

“Measurement”​

Cardiac Index")​

$Units = DT (l/min/m2, UCUM, "l/min/m2")​

12​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122229, DCM,​

“Measurement”​

"Arteriovenous difference")​

Page 234​

DICOM PS3.16 2020a - Content Mapping Resource​

NL​ Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

13​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = BCID 3620​

“Measurement”​

“Hemodynamic Ratios”​

$Units = DT ({ratio}, UCUM, "ratio")​

14​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122237, DCM,​

“Measurement”​

"Corrected Sinus Node Recovery Time")​

$Units = DT (ms, UCUM, "ms")​

15​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8861-7, LN, "Left​

“Measurement”​

Ventricular Stroke Work")​

$Units = DT (gf.m, UCUM, "gf.m")​

16​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8862-5, LN, "Right​

“Measurement”​

Ventricular Stroke Work")​

$Units = DT (gf.m, UCUM, "gf.m")​

17​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8863-3, LN, "Left​

“Measurement”​

Ventricular Stroke Work Index")​

$Units = DT (gf.m/m2, UCUM, "gf.m/m2")​

18​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (8864-1, LN, "Right​

“Measurement”​

Ventricular Stroke Work Index")​

$Units = DT (gf.m/m2, UCUM, "gf.m/m2")​

19​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122238, DCM, "Max​

“Measurement”​

volume normalized to 50mmHg pulse​

pressure")​

$Units = DT (ml, UCUM, "ml")​

20​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122239, DCM,​

“Measurement”​

"Oxygen Consumption")​

$Units = DT (ml/min, UCUM, "ml/min")​

$Equation = BCID 3664 “Oxygen​

Consumption Equations and Tables”​

21​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (19217-9, LN,​

“Measurement”​

"Oxygenpartialpressureat50%saturation​

(P50) ")​

$Units = DCID 3500 “Pressure Units”​

$Equation = BCID 3666 “P50 Equations”​

22​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (11556-8, LN, "Blood​

“Measurement”​

Oxygen partial pressure")​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 235​

NL​ Rel with​

VT​

Concept Name​

VM​ Req​Condition​

Value Set Constraint​

Parent​

Type​

23​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3618​

“Measurement”​

“Hemodynamic Flows”​

$ModType = EV (121425, DCM, "Index")​

$ModValue = EV (8277-6, LN, "Body​

Surface Area")​

$Units = DT (l/min/m2, UCUM, "l/min/m2")​

24​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3619​

“Measurement”​

“HemodynamicResistanceMeasurements”​

$Units = DCID 3502 “Hemodynamic​

Resistance Units”​

25​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement = DCID 3619​

“Measurement”​

“HemodynamicResistanceMeasurements”​

$ModType = EV (121425, DCM, "Index")​

$ModValue = EV (8277-6, LN, "Body​

Surface Area")​

$Units = DCID 3503 “Indexed​

Hemodynamic Resistance Units”​

26​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (122227, DCM, "Left​

“Measurement”​

to Right Flow")​

$Units = DT (l/min, UCUM, "l/min")​

27​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement=EV(122228,DCM,"Right​

“Measurement”​

to Left Flow")​

$Units = DT (l/min, UCUM, "l/min")​

28​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (90096001, SCT,​

“Measurement”​

"Stroke Volume")​

$Units = DT (ml, UCUM, "ml")​

29​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (90096001, SCT,​

“Measurement”​

"Stroke Volume")​

$ModType = EV (121425, DCM, "Index")​

$ModValue = EV (8277-6, LN, "Body​

Surface Area")​

$Units = DT (ml/m2, UCUM, "ml/m2")​

30​

>​

CONTAINS​INCLUDE​

DTID 300​

1​

U​

$Measurement = EV (268384009, SCT,​

“Measurement”​

"Total blood volume")​

$Units = DT (l, UCUM, "l")​

31​

>​

CONTAINS​INCLUDE​

DTID 300​

1-n​

U​

$Measurement=DCID3667“Framingham​

“Measurement”​

Scores”​
