DICOM PS3.17 2020a - Explanatory Information​

Page 877​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.4.5.1.1​

Laterality​

(7771000, SCT, "Left")​

TID 11007​

CID 244​

Since "Site of" is "Via arm vein"​

1.21.4.6​

ImagingAgentAdministration​

TID 11008​

Phase​

1.21.4.6.1​

ImagingAgentAdministration​EXTRAVASATION_TEST_PHASE​

TID 11008​

Phase Identifier​

1.21.4.6.2​

ImagingAgentAdministration​1.2.3.4.47110815.6​

TID 11008​

Performed Phase UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.4.6.3​

ImagingAgentAdministration​(130171, DCM, "Automatic with Manual​

TID 11008​

Phase Type​

Inject Phase")​

CID 62​

Since 1.21.4.3 (Administration Mode)​

is "Automated Administration"​

1.21.4.6.4​

ImagingAgentAdministration​

TID 11003​

Activity​

1.21.4.6.4.1​

Referenced Imaging Agent​ INJECTOR_FLUSH_AGENT​

TID 11003​

Identifier​

Value of 1.15.1​

1.21.4.6.4.2​

Volume Administered​

30​

TID 11003​

UNITS = EV (ml, UCUM, "ml")​

Same value as 1.21.4.6.5 and​

1.21.4.9.1​

1.21.4.6.4.3​

Starting Flow Rate of​

3​

TID 11003​

administration​

UNITS = EV (ml/s, UCUM "ml/s")​

1.21.4.6.4.4​

Peak Flow Rate in Phase​

3​

TID 11003​

Activity​

UNITS = EV (ml/s, UCUM "ml/s")​

Page 878​

DICOM PS3.17 2020a - Explanatory Information​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.4.6.4.6​

Initial Volume of Imaging​

197​

TID 11003​

Agent in Container​

UNITS = EV (ml, UCUM, "ml")​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.4.6.4.7​

Residual Volume of Imaging​167​

TID 11003​

Agent in Container​

UNITS = EV (ml, UCUM, "ml")​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.4.6.4.8​

DateTime Started​

20181012121537​

TID 11003​

Since root Concept Name is​

"Performed Imaging Agent​

Administration"​

1.21.4.6.4.9​

Duration​

10​

TID 11003​

UNITS = EV (s, UCUM, "s")​

Since root Concept Name is​

"Performed Imaging Agent​

Administration"​

1.21.4.6.5​

Total Phase Volume​

30​

TID 11008​

Administered​

UNITS = EV (ml, UCUM, "ml")​

In this case the same value as​

1.21.4.6.4.2 and 1.21.4.9.1​

1.21.4.6.6​

DateTime Started​

20181012121537​

TID 11008​

Since root Concept Name Code​

Sequenceis"PerformedImagingAgent​

Administration"​

1.21.4.6.7​

Duration​

10​

TID 11008​

UNITS = EV (s, UCUM, "s")​

Since root Concept Name Code​

Sequenceis"PerformedImagingAgent​

Administration")​

1.21.4.7​

Number of Injector Heads​

2​

TID 11007​

1.21.4.8​

Programmable Device​

(373066001, SCT, "Yes")​

TID 11007​

CID 231​

1.21.4.9​

Manually triggered injection​

TID 11007​

information​

Since 1.21.4.3 (Administration Mode)​

is"AutomatedAdministration"androot​

DICOM PS3.17 2020a - Explanatory Information​

Page 879​

Node​

Code Meaning of Concept​ Code Meaning or Example Value​

Reference to TID/ CID/ Comments​

Name​

1.21.4.9.1​

Total Step Volume​

30​

TID 11007​

Administered​

UNITS = EV (ml, UCUM, "ml")​

In this case the same value as​

1.21.4.6.4.2 and 1.21.4.6.5​

1.21.4.9.2​

Total number of manually​

1​

TID 11007​

triggered injections​

1.21.5​

ImagingAgentAdministration​

TID 11007​

Step​

1.21.5.1​

ImagingAgentAdministration​DELAY_ESTIMATE_STEP_3​

TID 11007​

Step Identifier​

1.21.5.2​

ImagingAgentAdministration​1.2.3.4.47110815.7​

TID 11007​

Performed Step UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​

1.21.5.3​

Administration Mode​

(130173,DCM,"AutomatedAdministration")​TID 11007​

CID 63​

1.21.5.4​

Administration Step Type​

(130248,DCM,"TransitTimeTestInjection")​TID 11007​

CID 72​

1.21.5.5​

Pressure Limit​

15​

TID 11007​

UNITS = EV (kPa, UCUM "kPa")​

Since 1.21.5.3 is "Automated​

Administration"​

1.21.5.6​

Route of Administration​

(47625008, SCT, "Intravenous route")​

TID 11007​

CID 11​

1.21.5.6.1​

Site of​

(261459001, SCT, "Via arm vein")​

TID 11007​

CID 3746​

Since "Route of Administration" is​

"Intravenous route"​

1.21.5.6.1.1​

Laterality​

(7771000, SCT, "Left")​

TID 11007​

CID 244​

Since "Site of" is "Via arm vein"​

1.21.5.7​

ImagingAgentAdministration​

TID 11008​

Phase​

1.21.5.7.1​

ImagingAgentAdministration​DELAY_ESTIMATE_PHASE_1​

TID 11008​

Phase Identifier​

1.21.5.7.2​

ImagingAgentAdministration​1.2.3.4.47110815.8​

TID 11008​

Performed Phase UID​

Since "Root Concept Name Code​

Sequence" is "Performed Imaging​

Agent Administration"​
