Материал: The_Future_of_Hydrogen-IEA-2020

Roland Berger (2017), “Development of business cases for fuel cells and hydrogen applications for regions and cities: Hydrogen injection into the natural gas grid”, Fuel Cells and Hydrogen 2 Joint Undertaking, www.fch.europa.eu/sites/default/files/FCH%20Docs/171121_FCH2JU_ApplicationPackage_WG5_P2H_Hydrogen%20into%20gas%20grid%20%28ID%202910558%29%20%28ID%2 02911642%29.pdf (accessed 5 April 2019).

Reuß, M. et al. (2017), “Seasonal storage and alternative carriers: A flexible hydrogen supply chain model”, Applied Energy, Vol. 200, pp. 290–302, http://dx.doi.org/10.1016/j.apenergy.2017.05.050.

Reuß, M. et al. (2019), “A hydrogen supply chain with spatial resolution: Comparative analysis of infrastructure technologies in Germany”, Applied Energy, Vol. 247, pp. 438–53, https://doi.org/10.1016/j.apenergy.2019.04.064.

Shell (2017), Shell Hydrogen Study: Energy of the Future?, https://www.shell.de/medien/shell- publikationen/shell-hydrogen-study/_jcr_content/par/toptasks_e705.stream/ 1497968967778/1c581c203c88bea74d07c3e3855cf8a4f90d587e/shell-hydrogen-study.pdf, (accessed 5 April 2019).

Snam, IGU (International Gas Union) and BCG (Boston Consulting Group) (2018), Global Gas Report 2018, www.snam.it/export/sites/snam-rp/repository/file/gas_naturale/global-gas- report/global_gas_report_2018.pdf (accessed 5 April 2019).

Speirs, J. et al. (2017), A Greener Gas Grid: What are the Options? Sustainable Gas Institute, Imperial College London, www.sustainablegasinstitute.org/wp-content/uploads/2017/12/SGI-A-greener- gas-grid-what-are-the-options-WP3.pdf?noredirect=1 (accessed 5 April 2019).

Staffell, I. et al. (2019), “The role of hydrogen and fuel cells in the global energy system”, Energy and Environmental Science, Vol. 12, pp. 463–91, doi: 10.1039/C8EE01157E.

United Nations (2014), UN Regulation No. 110 – Compressed and Liquefied Natural Gas System Components, Addendum 109, Revision 3, Annex 3A, p. 62, www.unece.org/fileadmin/DAM/trans/main/wp29/wp29regs/2015/R110r3e.pdf.

Weidner, E. et al. (2016), “Sector Forum Energy Management/Working Group Hydrogen Final Report”, Joint Research Centre (JRC).

Wulf, C. and P. Zapp (2018), “Assessment of system variations for hydrogen transport by liquid organic hydrogen carriers”, International Journal of Hydrogen Energy, Vol. 43, pp. 11884–95, https://doi.org/10.1016/j.ijhydene.2018.01.198.

Chapter 4: Present and potential industrial uses of hydrogen

•Hydrogen use today is dominated by industrial applications. The top four single uses of hydrogen today (in both pure and mixed forms) are: oil refining (33%), ammonia production (27%), methanol production (11%) and steel production via the direct reduction of iron ore (3%). Virtually all of this hydrogen is supplied using fossil fuels. These existing uses of hydrogen underpin many aspects of the global economy and our daily lives. Their future growth depends on the evolution of demand for downstream products, notably refined fuels for transport, fertilisers for food production, and construction materials for buildings.

•More than 60% of hydrogen used in refineries today is produced using natural gas. Tougher

air pollutant standards could increase the use of hydrogen in refining by 7% to 41 MtH2/yr by 2030, although further policy changes to curb increases in oil demand could dampen the pace of growth. Current global refining capacity is generally thought sufficient to meet rising oil demand, which implies that the majority of future hydrogen demand is likely to arise from existing facilities already equipped with hydrogen production units. This suggests an opportunity for retrofitting CCUS as a suitable option to reduce related emissions.

•Demand for ammonia and methanol is expected to increase over the short to medium term, with new capacity additions offering an important opportunity to scale up low-emissions hydrogen pathways. Greater efficiency can reduce overall levels of demand, but this will only partially offset demand growth. Whether via natural gas with CCUS or electrolysis, the technology is available to provide the additional hydrogen demand growth projected for

ammonia and methanol (up 14 MtH2/yr by 2030) in a low-carbon manner. As a priority, substituting low-emissions pathways for any further coal-based production without CCUS would significantly help cut emissions.

•In the longer term, steel and high-temperature heat production offer vast potential for lowemissions hydrogen demand growth. Assuming that the technological challenges that currently inhibit the widespread adoption of hydrogen in these areas can be overcome, the key challenges will be reducing costs and scaling up. In the long term it should be technically possible to produce all primary steel with hydrogen, but this would require vast amounts of lowcarbon electricity (around 2 500 TWh/yr, or around 10% of global electricity generation today) and would only be economic without policy support at very low electricity prices.

Most hydrogen today is used in three industrial sectors: oil refining, chemicals and iron and steel. Production of hydrogen to meet the needs of these sectors is at a commercial scale and is almost entirely from natural gas, coal and oil today, with associated environmental impacts. However, the technologies are available to avoid the emissions from this fossil fuel use by producing and supplying low-carbon hydrogen. In some cases these alternatives are already deployed where policy and economics are supportive. Table 4 provides an overview of the current and likely future industrial uses of hydrogen.

This chapter explores how hydrogen is currently used in the refining, chemicals and iron and steel sectors. It reviews the current trends for hydrogen demand in these sectors and the options for addressing the emissions related to supplying hydrogen for these existing uses. It concludes with a discussion of the ways in which significant new markets for hydrogen in industrial applications could emerge if hydrogen were used to satisfy a much higher share of the inputs to steelmaking globally or as a source of high-temperature heat with no direct emissions.
