126806​ IEC61217 Table Top Lateral​

Table Top Lateral Position IEC TABLE TOP Coordinate​

Position​

System [IEC 61217].​

126807​

IEC61217 Table Top​

Table Top Longitudinal Position IEC TABLE TOP​

Longitudinal Position​

Coordinate System [IEC 61217].​

126808​ IEC61217 Table Top Vertical​

Table Top Vertical Position in IEC TABLE TOP​

Position​

Coordinate System [IEC 61217].​

126809​ IEC61217 Gantry Continuous​ GantryContinuousRollAngleindegreesoftheradiation​

Roll Angle​

source, i.e., the rotation about the Y-axis of the IEC​

GANTRY coordinate system [IEC 61217].​

126810​ IEC61217 Gantry Continuous​ GantryPitchContinuousAngleindegreesoftheradiation​

Pitch Angle​

source, i.e., the rotation about the X-axis of the IEC​

GANTRY coordinate system [IEC 61217].​

126811​ IEC61217 Gantry Continuous​ GantryYawContinuousAngleindegreesoftheradiation​

Yaw Angle​

source, i.e., about the Z-axis of the IEC GANTRY​

coordinate system [IEC 61217].​

126830​

left first​

The body position of the imaging subject relative to the​

imaging equipment is with the subject's left side​

positioned towards the front of the equipment viewed​

from the front​

126831​

right first​

The body position of the imaging subject relative to the​

imaging equipment is with the subject's right side​

positioned towards the front of the equipment viewed​

from the front​

126832​

posterior first​

The body position of the imaging subject relative to the​

imagingequipmentiswiththesubject'sposterior(dorsal)​

sidepositionedtowardsthefrontoftheequipmentviewed​

from the front​

126833​

anterior first​

The body position of the imaging subject relative to the​

imagingequipmentiswiththesubject'santerior(ventral)​

sidepositionedtowardsthefrontoftheequipmentviewed​

from the front​

126850​

ILCR​

The International Laboratory Code Registry (ILCR) of​

the Institute of Laboratory Animal Research (ILAR). See​

http://dels.nas.edu/global/ilar/lab-codes.​

127001​ PreclinicalSmallAnimalImaging​Adescriptionoftheconditionspresentduringacquisition​

Acquisition Context​

of images of small animals during preclinical research.​

Page 1332​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

127006​

Phase of animal handling​

A specified phase of handling of an animal (e.g.,​

transport, preparation).​

127010​

Biosafety conditions​

Adescriptionofbiosafetyconditions(e.g.,presentduring​

small animal handling for research).​

127011​

Reason for biosafety controls​ The reason that biosafety controls are in place.​

127040​

Heating conditions​

A description of heating conditions (e.g., present during​

small animal handling for research).​

127050​

Circadian effects​

A description of Circadian effects (e.g., present during​

small animal handling for research).​

127060​

Nose cone​

A form of face mask that fits over the nose used for​

delivery of inhalational anesthesia (usually for small​

animals)​

127061​

Nasal cannula​

Cannula inserted in the nose used for delivery of​

inhalational anesthesia or other inhaled gases.​

127070​

Retro-orbital route​

A route of administration of a substance via the​

retro-orbital venous sinus.​

Yardeni T et al. (2011). Retro-orbital injections in mice.​

LabAnimal,40(5),155-160.doi:10.1038/laban0511-155.​

http://www.ncbi.nlm.nih.gov/pmc/articles/PMC3158461/​

127101​

In home cage​

The phase of handling of an animal that provides their​

normal environment between procedures.​

127102​

During transport​

The phase of handling of an animal that is transport​

between environments.​

127103​

Staging prior to imaging​

The phase of handling of an animal that is staging prior​

to an imaging procedure (e.g., after removal from their​

home environment and transport cage, and awaiting​

preparation,inductionorimaging).Duringthisphasethe​

animals are not subject to intervention (e.g., injection,​

catheterization) (cf. 127104, DCM, "Preparation for​

imaging")).​

127104​

Preparation for imaging​

The phase of handling of an animal that is preparation​

priortoanimagingprocedurethatinvolveshandlingand​

intervention (e.g., such as injection, catheterization) (cf.​

127103, DCM, "Staging prior to imaging")).​

127110​

Housing role​

The phase of handling of an animal during which the​

housing conditions are applicable.​

127120​

Animal housing​

The manner in which animals are housed.​

127121​

Animal room type​

The room type in which racks of animal cages are​

housed.​

127122​

Animal room identifier​

The identifier of the room in which racks of animal cages​

are housed.​

127125​

Housing manufacturer​

The manufacturer of the animal housing.​

127126​

Housing rack product name​

The manufacturer's product name of the animal housing​

rack.​

127127​

Housing rack product code​

The manufacturer's product code of the animal housing​

rack.​

127128​

Housing unit product name​

The manufacturer's product name of the animal housing​

unit (or bottom of unit if separate lid).​

Page 1334​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

127190​

Enrichment material​

Material provided to enrich the environment of a small​

animal for the purpose of reducing stress, improving​

health and/or improving reproducibility of results. E.g.,​

nesting material.​

127191​

Enrichment manufacturer​

The manufacturer of the material provided to enrich the​

environment of a small animal.​

127192​

Enrichment material present​

Whether or not material is provided to enrich the​

environmentofasmallanimalforthepurposeofreducing​

stress,improvinghealthand/orimprovingreproducibility​

of results. E.g., nesting material.​

127193​

Exerciser device present​

Whether or not an exerciser device is present.​

127195​

Shelter type​

Thetypeofshelterprovidedforsmallanimalswithintheir​

housing.​

127196​

Shelter manufacturer​

The manufacturer of the small animal shelter.​

127197​

Shelter product name​

The manufacturer's product name of the small animal​

shelter.​

127198​

Shelter product code​

The manufacturer's product code of the small animal​

shelter.​

127200​

Feed manufacturer​

The manufacturer of the feed.​

127201​

Feed product name​

The manufacturer's product name of the feed.​

127202​

Feed product code​

The manufacturer's product code of the feed.​

127205​

Feed source​

The source of animal feed.​

127210​

Feedback temperature​

Temperatureisregulatedbyfeedbackfromatemperature​

regulation​

sensor used to control an active heating or cooling​

device.​

127214​ Totaldurationoflight-darkcycle​The total duration of single light-dark cycle (e.g., usually​

24 hours).​

127215​

Lights on time of day​

The time of day when the lights are turned on.​

127220​

Igloo​

Igloo shaped small animal shelter​

127221​

Red translucent igloo​

Red translucent igloo-shaped small animal shelter​

127230​

Aspen chip bedding​

Animal bedding material made from aspen chips.​

127231​

Aspen shaving bedding​

Animal bedding material made from aspen shavings.​

127232​

Corn cob bedding​

Animal bedding material made from (milled) corn cobs.​

127233​

Paper-based bedding​

Animal bedding material made from paper.​

127234​

Pine chip bedding​

Animal bedding material made from pine chips.​

127235​

Pine shaving bedding​

Animal bedding material made from pine shavings.​

127240​

Carrier temperature sensor​

A device for measuring the temperature of the carrier​

(holder) used for small animal imaging as a means of​

monitoring or regulating the animal's temperature (e.g.,​

a non-magnetic thermocouple embedded in or attached​

to the carrier for MRI).​

127250​

Forced air heater​

A method or device that uses forced hot air to maintain​

the body temperature of a subject.​

127251​

Heated imaging device​

An imaging device that contains an integrated method​

of temperature regulation for maintaining the body​

temperature of the imaging subject.​
