Row 11​ These are measurements from a standardized list of pre-coordinated codes. See CID 12300 “Core Echo​ Measurements”. Measurements which do not correspond to the full semantics of one of the pre-coordinated codes​ in CID 12300 can likely be encoded in Row 13 instead.​

Multiple instances of the same measurement code may be present in the container. Each instance represents a​ different sample or derivation.​

This template makes no requirement that any or all samples be sent. For example, a mean value of all the samples​ ofagivenmeasurementcouldbesentwithoutsendingalloranyofthesamplesfromwhichthemeanwascalculated.​ Device configuration and/or operator interactions determine what measurements are sent.​

Row 13​ These are measurements that can be encoded using a standardized structure of post-coordinated codes.​ Measurements which correspond to the full semantics of one of the pre-coordinated codes in CID 12300 “Core​ Echo Measurements” should be encoded in Row 11 instead.​

$Measurement shall be provided, but is not constrained to a CID.​

Multiple instances of the same measurement code may be present in the container. Each instance represents a​ different sample or derivation.​

This template makes no requirement that any or all samples be sent. For example, a mean value of all the samples​ ofagivenmeasurementcouldbesentwithoutsendingalloranyofthesamplesfromwhichthemeanwascalculated.​ Device configuration and/or operator interactions determine what measurements are sent.​

Row 15​ These are adhoc measurements encoded with minimal semantics.​

Row 13 can be used to encode measurements with more complete semantics.​

$Units shall be provided, but is not constrained to a CID.​

Device configuration and/or operator interactions determine what measurements are sent.​

Rows 17-24​ When present, these rows contain measurements and associate them with a specific stage of a staged procedure.​

- Standard -​

TID 5301 Pre-coordinated Echo Measurement​

This template codes numeric echo measurements where most of the details about the nature of the measurement have been pre-​ coordinated in the measurement code. In contrast, see TID 5302 “Post-coordinated Echo Measurement”.​

The pre-coordinated measurement code is provided when this Template is included from a parent Template.​

Content Item Descriptions​

Row 2​ The reason that this value was selected as the preferred value for the measured concept.​

The parent template may allow TID 5301 “Pre-coordinated Echo Measurement” to be included multiple times with the​ same Measurement Concept Name, for example to allow multiple samples of the measurement.​

A given Measurement Concept Name might appear only once in the instance, in which case this this row may or may​ notbepresent.AgivenMeasurementConceptNamemayappearmultipletimes,howeverthisrowshallnotbepresent​ for more than one value of the given Measurement Concept Name. E.g. multiple measurements of (11706-9, LN,​ "Aortic Valve Peak Systolic Flow") may be present, but only one may be selected as preferred.​

- Standard -​

Row 3​ The method used to derive this measurement value from multiple samples of the Measurement Concept Name.​

If Row 3 is not present, then this measurement value is simply a single sample of the Measurement Concept Name.​

Note​

A measurement value that is a mean value of other measurements and was also selected as the preferred​ value because it is the mean will have both Row 2 and Row 3 present.​

Row 6​ This may be used to label the measurement value when space is limited on the screen or report page. E.g. a Short​ Label of "LVIDD" might be provided for a measurement of the left ventricle internal diameter at end diastole.​

Note​

Short Labels are not standardized and may omit details of the measurement, thus it is not recommended to​ use them for purposes such as matching.​

TID 5302 Post-coordinated Echo Measurement​

This template codes numeric echo measurements where most of the details about the nature of the measurement have been post-​ coordinated in modifiers and acquisition context. In contrast, see TID 5301 “Pre-coordinated Echo Measurement” .​

This template is intended to be used for User-defined and Vendor-defined Echo Measurements.​

Several modifier rows are conditional and are omitted when the modifier concept is not significant for the measurement encoded in​ the item. When these modifiers are included by the sender, it indicates that the modifier concept is significant and receivers will gen-​ erally treat the measurements differently than similar measurements sent that omit that modifier.​

Note​

The codes in the CIDs referenced below were sufficient to accurately encode all the best practice echo measurements re-​ commendedbytheASE.If,however,anewcodeisneededtorecordaspecificUser-definedorVendor-definedmeasurement,​ most of the CIDs are extensible. It is not unreasonable to expect that measurements might be made at other Finding Sites​ than those listed in CID 12305 “Basic Echo Anatomic Sites” , or using Measurement Methods beyond those listed in CID​ 12227 “Echocardiography Measurement Method” .​

Theconceptmodifiersinthetemplatebelowweresufficienttoaccuratelyencodeallthebestpracticeechomeasurementsrecommended​ by the ASE. Although TID 5302 “Post-coordinated Echo Measurement” is extensible and adding new modifiers is not prohibited, the​ meaning and significance of such new modifiers will generally not be understood by receiving systems, delaying or preventing import​ of such measurements. Further, adding modifiers that replicate the meaning of an existing modifier is prohibited.​

If such measurements cannot be encoded with the following structure, an implementation may choose to code the measurement in​ TID 5303 “Adhoc Measurement” , or to use TID 5200 “Echocardiography Procedure Report” instead of TID 5300 “Simplified Echo​ Procedure Report” .​

- Standard -​

- Standard -​

Content Item Descriptions​

Row 1​ A fully pre-coordinated code that incorporates all the semantics of Rows 7-17 for this measurement.​

Thecodeisintendedtoallowparserstorecognizepost-coordinatedmeasurementsthathavebeenpreviouslyencountered,​ thus facilitating incorporation of the measurement into databases, report templates, registries, etc. Typically these codes​ will be from a vendor or site specific coding scheme, e.g., 99ACME. Sending the same code consistently in different​ reports will depend on the recording system maintaining a stable list of these pre-coordinated codes. Such a list might​ be configured or internally generated and managed.​

This shall be populated by the recording system. If the recording system does not have a method to ensure that all​ occurrences of the same post-coordinated measurement use the same code, it shall use the code (125304, DCM,​ "Untrackable Measurement").​

Note​

1.​Two measurements with the same pre-coordinated code have, by definition, the same semantics (except​ for "Untrackable Measurements")​

2.​Two measurements with the same constellation of modifier values have the same semantics but may have​ different pre-coordinated codes because they​

•​come from carts of different vendors who don't share the same code table​

•​come from carts of the same vendor, but the carts don't share the same code table​

•​come from the same cart, but it's code table has been modified​

•​come from the same cart, but it does not maintain a code table​

3.​Two measurements with the same constellation of modifier values and different pre-coordinated codes​ have the same semantics and the receiver is entitled to treat them as the same (with respect to the scope​ of those modifiers)​

4.​Recommended units for various Measured Properties (Row 10) can be found in the Units column of CID​ 12304 “Echo Measured Properties” .​

5.​WhentheMeasurementType(Row7)is(125313,DCM,"Indexed"),(118586006,SCT,"Ratio")or(125314,​ DCM, "Fractional Change") , the Units for Row 1 corresponds to the fully calculated $Measurement,​ incorporatingboththenumerator(Row10)andthedenominator(Row17).E.g.ameasureofLeftVentricular​ Outflow Tract Diameter / BSA would have units of (cm/m2, UCUM, "cm/m2") in Row 1, (125313, DCM,​ "Indexed") in Row 7, (81827009, SCT, "Diameter") in Row 10, and (8277-6, LN, "Body Surface Area") in​ Row 17.​

Row 2​ One or more additional fully pre-coordinated codes which are semantically equivalent to the code in Row 1.​

This may be used to communicate known mappings, such as to national registry codes or other vendors' codes.​
