DICOM PS3.17 2020a - Explanatory Information​

Page 941​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

0xc714​50964​Image​ ForwardMatrix1​

SRational​This tag defines a matrix​

that maps white balanced​

camera colors to XYZ D50​

colors.​

0xc715​50965​Image​ ForwardMatrix2​

SRational​This tag defines a matrix​

that maps white balanced​

camera colors to XYZ D50​

colors.​

-​

-​

-​

0xc716​50966​Image​ Preview​

Byte​

A UTF-8 encoded string​

ApplicationName​

containing the name of the​

applicationthatcreatedthe​

preview stored in the IFD.​

-​

-​

-​

0xc717​50967​Image​ Preview​

Byte​

A UTF-8 encoded string​

ApplicationVersion​

containing the version​

number of the application​

that created the preview​

stored in the IFD.​

-​

-​

-​

0xc718​50968​Image​ PreviewSettingsName​

Byte​

A UTF-8 encoded string​

containing the name of the​

conversion settings (for​

example, snapshot name)​

usedforthepreviewstored​

in the IFD.​

-​

-​

-​

0xc719​50969​Image​ PreviewSettingsDigest​ Byte​

A unique ID of the​

conversion settings (for​

example,MD5digest)used​

to render the preview​

stored in the IFD.​

-​

-​

-​

0xc71a​50970​Image​ PreviewColorSpace​

Long​

This tag specifies the color​

space in which the​

rendered preview in this​

IFD is stored. The default​

value for this tag is sRGB​

forcolorpreviewsandGray​

Gamma 2.2 for​

monochrome previews.​

-​

-​

-​

0xc71b​50971​Image​ PreviewDateTime​

Ascii​

This tag is an ASCII string​

containing the name of the​

date/time at which the​

preview stored in the IFD​

was rendered. The​

date/timeisencodedusing​

ISO 8601 format.​

Page 942​

DICOM PS3.17 2020a - Explanatory Information​

DICOM Tag​

Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

-​

-​

-​

0xc71c​50972​Image​ RawImageDigest​

Undefined​This tag is an MD5 digest​

of the raw image data. All​

pixels in the image are​

processed in row-scan​

order. Each pixel is zero​

padded to 16 or 32 bits​

deep (16-bit for data less​

than or equal to 16 bits​

deep, 32-bit otherwise).​

The data for each pixel is​

processed in little-endian​

byte order.​

-​

-​

-​

0xc71d​50973​Image​ OriginalRawFileDigest​Undefined​This tag is an MD5 digest​

of the data stored in the​

OriginalRawFileData tag.​

0xc71e​50974​Image​ SubTileBlockSize​

Long​

Normally, the pixels within​

a tile are stored in simple​

row-scan order. This tag​

specifies that the pixels​

within a tile should be​

grouped first into​

rectangular blocks of the​

specified size. These​

blocks are stored in​

row-scan order. Within​

each block, the pixels are​

stored in row-scan order.​

The use of a non-default​

value for this tag requires​

setting the DNGBackward​

Version tag to at least​

1.2.0.0.​

0xc71f​50975​Image​ RowInterleaveFactor​

Long​

Thistagspecifiesthatrows​

of the image are stored in​

interleaved order. The​

value of the tag specifies​

the number of interleaved​

fields. The use of a​

non-default value for this​

tag requires setting the​

DNGBackwardVersion tag​

to at least 1.2.0.0.​

0xc725​50981​Image​ ProfileLookTableDims​

Long​

This tag specifies the​

numberofinputsamplesin​

eachdimensionofadefault​

"look" table. The data for​

this table is stored in the​

ProfileLookTableData tag.​

Page 943​

DICOM Tag​ Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

0xc726​50982​Image​ ProfileLookTableData​

Float​

This tag contains a default​

"look" table that can be​

applied while processing​

the image as a starting​

point for user adjustment.​

This table uses the same​

format as the tables stored​

in the ProfileHueSat​

MapData1 and Profile​

HueSatMapData2 tags,​

and is applied in the same​

color space. However, it​

should be applied later in​

the processing pipe, after​

any exposure​

compensation and/or fill​

lightstages,butbeforeany​

tone curve stage. Each​

entry of the table contains​

three 32-bit IEEE​

floating-point values. The​

first entry is hue shift in​

degrees, the second entry​

isasaturation scale factor,​

and the third entry is a​

value scale factor. The​

table entries are stored in​

the tag in nested loop​

order, with the value​

divisions in the outer loop,​

the hue divisions in the​

middle loop, and the​

saturation divisions in the​

inner loop. All zero input​

saturation entries are​

required to have a value​

scale factor of 1.0.​

0xc740​51008​Image​ OpcodeList1​

Undefined​Specifies the list of​

opcodes that should be​

applied to the raw image,​

as read directly from the​

file.​

0xc741​51009​Image​ OpcodeList2​

Undefined​Specifies the list of​

opcodes that should be​

applied to the raw image,​

just after it has been​

mappedtolinearreference​

values.​

Page 944​

DICOM PS3.17 2020a - Explanatory Information​

DICOM Tag​ Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

0xc74e​51022​Image​ OpcodeList3​

Undefined​Specifies the list of​

opcodes that should be​

applied to the raw image,​

just after it has been​

demosaiced.​

0xc761​51041​Image​ NoiseProfile​

Double​NoiseProfile describes the​

amount of noise in a raw​

image.Specifically,thistag​

models the amount of​

signal-dependent photon​

(shot) noise and​

signal-independentsensor​

readout noise, two​

common sources of noise​

in raw images. The model​

assumes that the noise is​

white and spatially​

independent,ignoringfixed​

pattern effects and other​

sourcesofnoise(e.g.,pixel​

response non-uniformity,​

spatially-dependent​

thermal effects, etc.).​

(0016,0070)​GPSVersionID​VL​

0x0000​ 0​ GPSInfo​GPSVersionID​

Byte​

Indicates the version of​

Photographic​

<GPSInfoIFD>. The​

Geolocation​

version is given as 2.0.0.0.​

Module​

Thistagismandatorywhen​

<GPSInfo> tag is present.​

(Note: The​

<GPSVersionID> tag is​

given in bytes, unlike the​

<ExifVersion> tag. When​

the version is 2.0.0.0, the​

tag value is 02000000.H).​

(0016,0071)​GPS Latitude​ VL​

0x0001​ 1​ GPSInfo​GPSLatitudeRef​

Ascii​

Indicates whether the​

Ref​

Photographic​

latitude is north or south​

Geolocation​

latitude. The ASCII value​

Module​

'N' indicates north latitude,​

and 'S' is south latitude.​

DICOM PS3.17 2020a - Explanatory Information​

Page 945​

DICOM Tag​ Attribute​

DICOM​

EXIF​ EXIF​EXIF or​ EXIF or TIFF Key​

EXIF or​

EXIF or TIFF Tag​

Name​

Module​

orTIFF​ or​

TIFF​

TIFFType​

Description​

Tag​ TIFF​

IFD​

(hex)​ Tag​

(dec)​

(0016,0072)​GPS Latitude​ VL​

0x0002​ 2​ GPSInfo​GPSLatitude​

Rational​Indicates the latitude. The​

Photographic​

latitude is expressed as​

Geolocation​

three RATIONAL values​

Module​

giving the degrees,​

minutes, and seconds,​

respectively. When​

degrees, minutes and​

seconds are expressed,​

the format is​

dd/1,mm/1,ss/1. When​

degrees and minutes are​

used and, for example,​

fractions of minutes are​

given up to two decimal​

places, the format is​

dd/1,mmmm/100,0/1.​

(0016,0073)​GPS Longitude​VL​

0x0003​ 3​ GPSInfo​GPSLongitudeRef​

Ascii​

Indicates whether the​

Ref​

Photographic​

longitude is east or west​

Geolocation​

longitude. ASCII 'E'​

Module​

indicates east longitude,​

and 'W' is west longitude.​

(0016,0074)​GPS Longitude​VL​

0x0004​ 4​ GPSInfo​GPSLongitude​

Rational​Indicates the longitude.​

Photographic​

Thelongitudeisexpressed​

Geolocation​

asthreeRATIONALvalues​

Module​

giving the degrees,​

minutes, and seconds,​

respectively. When​

degrees, minutes and​

seconds are expressed,​

the format is​

ddd/1,mm/1,ss/1. When​

degrees and minutes are​

used and, for example,​

fractions of minutes are​

given up to two decimal​

places, the format is​

ddd/1,mmmm/100,0/1.​

(0016,0075)​GPS Altitude​ VL​

0x0005​ 5​ GPSInfo​GPSAltitudeRef​

Byte​

Indicates the altitude used​

Ref​

Photographic​

as the reference altitude. If​

Geolocation​

the reference is sea level​

Module​

and the altitude is above​

sea level, 0 is given. If the​

altitude is below sea level,​

a value of 1 is given and​

the altitude is indicated as​

an absolute value in the​

GSPAltitude tag. The​

reference unit is meters.​
