Fieldbus coupler / controller • 117

Fieldbus Controller 750-833

3.2.9.5Device status

The device status includes the required overhead 7 Byte and transmits internal status information as well as information relating to the internal bus, PROFIBUS-DP and the PFC running time system to the master or the higher ranking controls.

Byte

Information









Meaning

























15

0

0

0

0

0

1

1

1

Header byte





















(7 Byte status information



















incl. header)

























16

1

0

1

0

0

0

0

0

Status type





















(manufacturer specific device status)





















17

0

0

0

0

0

0

0

0

Slot number 0





















18

0

0

0

0

0

0

0

0

Status differentiation



















(none)























19

q

q

n

n

n

n

n

n

Status message



















q – Status source



















'00'

Internal status



















'01'

Internal bus status



















'10'

PROFIBUS DP status



















'11' PFC-RTS status



















n – Status number





















20

x

x

x

x

x

x

x

x

Status argument























21

0

0

0

0

0

0

0

0

Reserved

























WAGO-I/O-SYSTEM 750

D R A F T

PROFIBUS

2001-02-27

118 • Fieldbus coupler / controller

Fieldbus Controller 750-833

3.2.9.5.1Internal status messages and arguments

Status

Status

Description

message

argument



0x00

0x00

no fault







0x01

0x00

EEPROM check sum fault / check sum fault in the flash pa-





rameter area







0x01

0x01

Overflow inline code buffer







0x01

0x02

Unknown data type







0x01

0x03

Module type for flash program memory could not be deter-





mined / is incorrect







0x01

0x04

Fault when writing in the FLASH memory







0x01

0x05

Fault when deleting the FLASH memory







0x01

0x06

Changed I/O modules configuration determined after





AUTORESET







0x01

0x07

Fault when writing in the serial EEPROM







0x01

0x08

Invalid firmware







0x02

0x00

Incorrect table entry







0x07

n

Module at position n (n = 1...63) is not supported







3.2.9.5.2Internal bus status messages and arguments

Status

Status

Description

message

argument



0x63

0xFF

At least one module cannot interpret an internal bus command







0x64

0x00

A data fault or a internal bus interruption exists behind the





bus controller







0x64

n

An internal bus interruption exists behind module n







0x65

n

Fault during register communication with module n







D R A F T

WAGO-I/O-SYSTEM 750

2001-02-27

PROFIBUS

Fieldbus coupler / controller • 119

Fieldbus Controller 750-833

3.2.9.5.3PROFIBUS-DP status messages and arguments

Status

Status

Description

message

argument



0x81

0x01

Insufficient parameter data configuration data







0x81

0x02

Excessive parameterisation data







0x82

n

Faulty n. parameterisation byte







0x83

0x01

Insufficient configuration data







0x83

0x02

Excessive configuration data







0x84

n

Faulty n. configuration byte (module)







0x85

0x01

Maximum input data length exceeded







0x85

0x02

Maximum output data length exceeded







0x86

0x01

Compilate buffer overflow for DP process image







0x86

0x02

Compilate buffer overflow for PFC process image







3.2.9.5.4PFC-RTS status messages and arguments

Status

Status

Description

message

argument



0xC1

0x00

t. b. d.







0xC1

0x01

t. b. d.







0xC2

0x00

t. b. d.







WAGO-I/O-SYSTEM 750

D R A F T

PROFIBUS

2001-02-27

120 • Fieldbus coupler / controller

Fieldbus Controller 750-833

3.2.9.6Channel based diagnosis

The channel based diagnosis serves for detailing the identification based diagnosis. A structure is added to the device status for each faulty slot. This comprises of a header byte, a byte, the channel type and the channel number and a third which describes the fault type and the channel organisation.

Byte

Information









Meaning





















22

1

0

x

x

x

x

x

x

Header channel based diagnosis



















(x: 1 to 63, slots of the module)





















23

a

a

x

x

x

x

x

x

Channel type (a) and



















channel number x: 0 to 3



0

1













Input channel



1

0













Output channel



1

1













Input / output channel





















24

t

t

t

x

x

x

x

x

Channel type (t) and



















fault type (x)



0

0

0











No allocation



0

0

1











1 bit



0

1

0











2 bit



0

1

1











4 bit



1

0

0











1 byte



1

0

1











1 word



1

1

0











2 words







25-27

Next channel based diagnosis message (as byte 22 – 24)





28-30

Next channel based diagnosis message (as byte 22 – 24)





















...

...





















61-63

Last representable channel based diagnosis message (as byte 22 – 24)





















D R A F T

WAGO-I/O-SYSTEM 750

2001-02-27

PROFIBUS

Fieldbus coupler / controller • 121

Fieldbus Controller 750-833

3.2.9.6.1Fault types of I/O modules with diagnostic capability

The fault types refer to standardised types.

Fault

Meaning

type



0

Not specified





1

Short circuit





2

Low voltage





3

High voltage





4

Overload





5

Over temperature





6

Line break





7

Upper limit value exceeded





8

Lower limit value exceeded





9

Fault





10 ... 15

Reserved





16 ... 31

Manufacturer specific





17

Field voltage fault





18

Fuse fault





19

Buffer overflow





20

Check sum fault





21

Parity fault





22

Receive Timeout (partner)





23

Receive Timeout





26

SSI_IN fault





27

SSI FRAME fault





31

I/O module fault





WAGO-I/O-SYSTEM 750

D R A F T

PROFIBUS

2001-02-27
