DICOM PS3.16 2020a - Content Mapping Resource​

Page 501​

Note​

1.​In a prior version of this table, the code G-A117 was specified for the concept Transaxial, and R-11300 was specified​ for the concept Transverse. Since these concepts are synonymous in nuclear projections, and since SNOMED assigns​ G-A117 to the concept Transverse, the use of R-11300 is deprecated. Although there is minimal possibility of misinter-​ pretationwithSOPInstancesthatmayincludethedeprecateduse,receivingapplicationsshouldbeawareofthischange;​ see Annex J.​

2.​The following Code Values were formerly included in CID 26 “Nuclear Medicine Projections” and are retired:​

SRT​

G-5200​

Antero-posterior​

SRT​

G-5201​

Postero-anterior​

SRT​

G-5203​

Frontal oblique​

SRT​

G-5204​

Antero-posterior Oblique​

SRT​

G-5205​

Postero-anterior Oblique​

SRT​

G-5211​

Frontal-oblique axial​

SRT​

G-5213​

Submento-vertex axial​

SRT​

G-5214​

Oblique submento-vertex​

SRT​

G-5226​

Right to left oblique​

SRT​

G-5227​

Left to right oblique​

CID 27 Basic Cardiac Views​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20120822​

UID:​

1.2.840.10008.6.1.957​

Table CID 27. Basic Cardiac Views​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

103340004​

Short Axis​

G-A186​

C0522488​

SCT​

131185001​

Vertical Long Axis​

G-A18A​

C1295721​

SCT​

131186000​

Horizontal Long Axis​

G-A18B​

C1295722​

CID 29 Acquisition Modality​

This Context Group includes codes that may be used to identify the type of diagnostic equipment, or function or technique of that​ equipment, that originally acquired, through interaction with a patient or specimen, the data used to create the instance. These codes​ are used in Attribute Modality (0008,0060) of a Modality Worklist Scheduled Procedure Step or a Composite SOP Instance (see​ PS3.3). It generally corresponds to a class of diagnostic equipment, or to a specific acquisition function or technique in a device. his​ Context Group may be used as the value set for HL7 v2 Table 0259 (see HL7 v2.6 Chapter 8 Section 8.8.8.47).​

Note​

This Context Group is not the complete set of codes that may appear in the Attribute Modality (0008,0060); these are only​ the codes associated with orderable acquisition processes (not pre-acquisition activities or post-processing).​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190327​

UID:​

1.2.840.10008.6.1.19​

- Standard -​

Page 502​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 29. Acquisition Modality​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

AR​

Autorefraction​

DCM​

BDUS​

Ultrasound Bone Densitometry​

DCM​

BI​

Biomagnetic Imaging​

DCM​

BMD​

Bone Mineral Densitometry​

DCM​

CR​

Computed Radiography​

DCM​

CT​

Computed Tomography​

DCM​

DG​

Diaphanography​

DCM​

DX​

Digital Radiography​

DCM​

ECG​

Electrocardiography​

DCM​

EPS​

Cardiac Electrophysiology​

DCM​

ES​

Endoscopy​

DCM​

GM​

General Microscopy​

DCM​

HD​

Hemodynamic Waveform​

DCM​

IO​

Intra-oral Radiography​

DCM​

IVOCT​

Intravascular Optical Coherence Tomography​

DCM​

IVUS​

Intravascular Ultrasound​

DCM​

KER​

Keratometry​

DCM​

LEN​

Lensometry​

DCM​

LS​

Laser Scan​

DCM​

MG​

Mammography​

DCM​

MR​

Magnetic Resonance​

DCM​

NM​

Nuclear Medicine​

DCM​

OAM​

Ophthalmic Axial Measurements​

DCM​

OCT​

Optical Coherence Tomography​

DCM​

OP​

Ophthalmic Photography​

DCM​

OPM​

Ophthalmic Mapping​

DCM​

OPT​

Ophthalmic Tomography​

DCM​

OPTBSV​

Ophthalmic Tomography B-scan Volume Analysis​

DCM​

OPTENF​

Ophthalmic Tomography En Face​

DCM​

OPV​

Ophthalmic Visual Field​

DCM​

OSS​

Optical Surface Scanner​

DCM​

PT​

Positron emission tomography​

DCM​

PX​

Panoramic X-Ray​

DCM​

RESP​

Respiratory Waveform​

DCM​

RF​

Radiofluoroscopy​

DCM​

RG​

Radiographic imaging​

DCM​

RTIMAGE​

RT Image​

DCM​

SM​

Slide Microscopy​

DCM​

SRF​

Subjective Refraction​

DCM​

TG​

Thermography​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 503​

Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​

US​

Ultrasound​



DCM​

VA​

Visual Acuity​



DCM​

XA​

X-Ray Angiography​



DCM​

XC​

External-camera Photography​



CID 30 DICOM Devices​





This Context Group includes codes that may be used to identify a class of equipment that uses DICOM.​



Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​





Version:​

20190327​





UID:​

1.2.840.10008.6.1.20​







Table CID 30. DICOM Devices​



Coding Scheme Designator​

Code Value​

Code Meaning​



Include CID 29 “Acquisition Modality”​





DCM​

ARCHIVE​

Archive​



DCM​

CAD​

Computer Assisted Detection/Diagnosis​



DCM​

CAPTURE​

Image Capture​



DCM​

COMP​

Computation Server​



DCM​

DSS​

Department System Scheduler​



DCM​

FILMD​

Film Digitizer​



DCM​

LOG​

Procedure Logging​



DCM​

M3D​

3D Manufacturing Modeling System​



DCM​

MCD​

Media Creation Device​



DCM​

PRINT​

Hard Copy Print Server​



DCM​

RT​

Radiation Therapy Device​



DCM​

STAIN​

Automated Slide Stainer​



DCM​

WSD​

Workstation​



CID 31 Abstract Priors​

This Context Group includes codes that may be used to identify imaging procedures that may be referred to as priors for the purpose​ of image set selection in Hanging Protocols.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.21​

Table CID 31. Abstract Priors​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLSConceptUnique​

Designator​







ID​

SCT​

278307001​

On admission​

R-40553​

C0457453​

SCT​

277671009​

Intraoperative​

R-400B2​

C0456904​

SCT​

281379000​

Pre-admission​

R-41FD9​

C0559269​

SCT​

255235001​

Pre-dose​

R-411C0​

C0439565​

- Standard -​

Page 504​

DICOM PS3.16 2020a - Content Mapping Resource​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLSConceptUnique​

Designator​







ID​

SCT​

255566006​

Post-dose​

R-404DA​

C0439568​

SCT​

262068006​

Pre-operative​

R-413C5​

C0445204​

SCT​

262061000​

Post-operative​

R-413B7​

C0032790​

DCM​

109120​

On admission to unit​





DCM​

109121​

On discharge​





DCM​

109122​

On discharge from unit​





DCM​

109123​

Pre-intervention​





DCM​

109124​

Post-intervention​





DCM​

109125​

At last appointment​





CID 32 Non-Acquisition Modality​

This Context Group includes codes that may be used to identify the type of equipment, or function or technique of that equipment,​ that created the data used to create an instance, other than by means of acquisition through interaction with a patient or specimen.​

Note​

Many Composite SOP Instances with the Attribute Modality (0008,0060) code values from this Context Group are the result​ of post-processing, and are not directly associated with an orderable acquisition process.​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20200118​

UID:​

1.2.840.10008.6.1.1282​

Table CID 32. Non-Acquisition Modality​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

ASMT​

Content Assessment Result​

DCM​

AU​

Basic Voice Audio​

DCM​

CTPROTOCOL​

CT Protocol​

DCM​

DOC​

Document​

DCM​

FID​

Spatial Fiducials​

DCM​

HC​

Hard Copy​

DCM​

IOL​

Intraocular Lens Calculation​

DCM​

KO​

Key Object Selection​

DCM​

M3D​

Model for 3D Manufacturing​

DCM​

OT​

Other​

DCM​

PLAN​

Plan​

DCM​

PR​

Presentation State​

DCM​

REG​

Registration​

DCM​

RTDOSE​

RT Dose​

DCM​

RTPLAN​

RT Plan​

DCM​

RTRECORD​

RT Treatment Record​

DCM​

RTSTRUCT​

RT Structure Set​

DCM​

RWV​

Real World Value Map​

DCM​

SEG​

Segmentation​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 505​

Coding Scheme Designator​

Code Value​

Code Meaning​



DCM​

SMR​

Stereometric Relationship​



DCM​

SR​

Structured Report Document​



DCM​

STAIN​

Automated Slide Stainer​



DCM​

TEXTUREMAP​

Texture Map​



CID 33 Modality​

This Context Group includes codes that may be used to identify the type of equipment, or function or technique of that equipment,​ that created the data used to create an instance.​

Note​

This Context Group contains the complete set of defined codes that may appear in the Attribute Modality (0008,0060).​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20190327​

UID:​

1.2.840.10008.6.1.1283​



Table CID 33. Modality​

CodingSchemeDesignator​ Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique ID​

Include CID 29

“Acquisition Modality”​





Include CID 32

“Non-Acquisition Modality”​





CID 42 Numeric Value Qualifier​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20020114​

UID:​

1.2.840.10008.6.1.22​

Table CID 42. Numeric Value Qualifier​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

114000​

Not a number​

DCM​

114001​

Negative Infinity​

DCM​

114002​

Positive Infinity​

DCM​

114003​

Divide by zero​

DCM​

114004​

Underflow​

DCM​

114005​

Overflow​

DCM​

114006​

Measurement failure​

DCM​

114007​

Measurement not attempted​

DCM​

114008​

Calculation failure​

DCM​

114009​

Value out of range​

DCM​

114010​

Value unknown​

DCM​

114011​

Value indeterminate​

CID 50 Instance Availability Status​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Non-Extensible​

- Standard -​
