DICOM PS3.16 2020a - Content Mapping Resource​

Page 511​

Note​

The concept for syringe (physical object) is used in this context group as distinct from syringe (unit of presentation), which​ is used in Section CID 68. The concept for bottle is used in the context of consumable used during an oral administration of​ contrast.​

CID 70 Flush​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181115​

UID:​

1.2.840.10008.6.1.1260​

Table CID 70. Flush​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

13132007​

Dextran​

C-A7220​

C0086140​

SCT​

262003004​

Saline​

C-70841​

C0445115​

SCT​

347379006​

Lactated Ringer's​

C-70434​

C0073385​

CID 71 Imaging Agent Administration Injector Event Type​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181115​

UID:​

1.2.840.10008.6.1.1261​

Table CID 71. Imaging Agent Administration Injector Event Type​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130150​

Pressure above warning limit​

DCM​

130151​

Pressure above adjustment limit​

DCM​

130152​

Flow rate above warning limit​

DCM​

130153​

Flow rate above adjustment limit​

DCM​

130161​

Keep vein open started​

DCM​

130162​

Keep vein open ended​

DCM​

130175​

Air detected​

DCM​

130155​

Fixed duration pause ended​

DCM​

130163​

Syringe attached​

DCM​

130164​

Syringe detached​

DCM​

110501​

Equipment failure​

DCM​

110527​

Resource inadequate​

DCM​

130156​

Terminated due to pressure above termination limit​

DCM​

130157​

Terminated due to flow rate above termination limit​

DCM​

130176​

Terminated due to air detected​

DCM​

130158​

Terminated due to excessive duration pause​

DCM​

130154​

Terminated due to request from operator​

DCM​

130159​

Terminated due to injector communication loss​

DCM​

130160​

Terminated due to unspecified injector failure​

DCM​

130177​

Terminated by scanner​

- Standard -​

Page 512​

DICOM PS3.16 2020a - Content Mapping Resource​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130178​

Terminated due to critical battery level​

DCM​

130179​

Terminated due to consumable removal​

CID 72 Imaging Agent Administration Step Type​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​



Version:​

20181115​



UID:​

1.2.840.10008.6.1.1262​



Table CID 72. Imaging Agent Administration Step Type​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130247​

Patency Test Injection​

DCM​

130248​

Transit Time Test Injection​

DCM​

130249​

Diagnostic Administration​

DCM​

130251​

Flush Administration​

CID 73 Bolus Shaping Curves​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181115​

UID:​

1.2.840.10008.6.1.1263​

Table CID 73. Bolus Shaping Curves​

Coding Scheme Designator​

Code Value​

Code Meaning​

DCM​

130252​

Negative exponential​

DCM​

130253​

Linear Curve​

CID 74 Imaging Agent Administration Consumable Catheter Type​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20181115​

UID:​

1.2.840.10008.6.1.1264​

Table CID 74. Imaging Agent Administration Consumable Catheter Type​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLS Concept Unique​

Designator​





ID​

SCT​

82449006​

Peripheral intravenous catheter​

SCT​

52124006​

Central venous catheter​

SCT​

398013009​

Implantable venous access port​

SCT​

52124006​

Peripherally inserted central​





catheter​

SCT​

705541005​

Rectal Catheter​

A-26836​

C0179768​

A-26810​

C1145640​

A-1450B​

C1275732​

A-26810​

C1145640​

R-FEAEC​

C0179784​

CID 75 Low-high-equal​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Non-Extensible​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 513​

Version:​

20181115​







UID:​

1.2.840.10008.6.1.1265​







Table CID 75. Low-High-Equal​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









SCT​

62482003​

Low​

G-A374​

C0205251​

SCT​

75540009​

High​

G-A373​

C3163633​

SCT​

9726003​

Equal​

G-A214​

C0205163​

CID 76 Type of Pre-medication​





Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​



Type:​

Extensible​







Version:​

20181115​







UID:​

1.2.840.10008.6.1.1266​







Table CID 76. Type of Pre-Medication​



Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​ UMLSConceptUnique​

Designator​







ID​

DCM​

123012​

Pre-Medication​





DCM​

130259​

Contrast Reaction Prophylactic​







Agent​





SCT​

372614000​

Sedative​

F-6171D​

C0036557​

SCT​

52017007​

Antiemetic​

C-85800​

C0003297​

CID 82 Units of Measurement​

Context Group ID 82 comprises the case-sensitive codes of UCUM. See Section 7.2.2.​

Note​

Equivalent to the HL7 Value Set "Units of Measure case sensitive" 2.16.840.1.113883.11.12839.​

CID 83 Units for Real World Value Mapping​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20080123​

UID:​

1.2.840.10008.6.1.24​



Table CID 83. Units for Real World Value Mapping​

Coding Scheme Designator​

Code Value​

Code Meaning​

Include CID 84 “PET Units”​





UCUM​

[hnsf'U]​

Hounsfield unit​

CID 84 PET Units​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.1030​

- Standard -​

Page 514​ DICOM PS3.16 2020a - Content Mapping Resource​

Table CID 84. PET Units​

Coding Scheme Designator​

Code Value​

Code Meaning​

Include CID 85 “SUV Units”​





UCUM​

{counts}​

Counts​

UCUM​

{counts}/s​

Counts per second​

UCUM​

{propcounts}​

Proportional to counts​

UCUM​

{propcounts}/s​

Proportional to counts per second​

UCUM​

cm2​

Centimeter**2​

UCUM​

cm2/ml​

Centimeter**2/milliliter​

UCUM​

%​

Percent​

UCUM​

Bq/ml​

Becquerels/milliliter​

UCUM​

mg/min/ml​

Milligrams/minute/milliliter​

UCUM​

umol/min/ml​

Micromole/minute/milliliter​

UCUM​

ml/min/g​

Milliliter/minute/gram​

UCUM​

ml/g​

Milliliter/gram​

UCUM​

/cm​

/Centimeter​

UCUM​

umol/ml​

Micromole/milliliter​

CID 85 SUV Units​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20161106​

UID:​

1.2.840.10008.6.1.984​

Table CID 85. SUV Units​

Coding Scheme Designator​

Code Value​

Code Meaning​

UCUM​

g/ml{SUVbw}​

Standardized Uptake Value body weight​

UCUM​

g/ml{SUVlbm}​

Standardized Uptake Value lean body mass (James)​

UCUM​

g/ml{SUVlbm(James128)}​

Standardized Uptake Value lean body mass (James 128​





multiplier)​

UCUM​

g/ml{SUVlbm(Janma)}​

Standardized Uptake Value lean body mass (Janma)​

UCUM​

cm2/ml{SUVbsa}​

Standardized Uptake Value body surface area​

UCUM​

g/ml{SUVibw}​

Standardized Uptake Value ideal body weight​

Note​





The formulas for the determination of SUVbw, SUVbsa, SUVlbm (James) and SUVibw are defined in Sugawara et al. Ree-​ valuation of the Standardized Uptake Value for FDG: Variations with Body Weight and Methods for Correction.Radiology,​ 1999 at http://radiology.rsna.org/content/213/2/521.​

Unfortunately, Sugawara used a parameter of 120 rather than 128 for males, propagating an error in Morgan DJ, Bray KM.​ Lean Body Mass as a Predictor of Drug Dosage: Implications for Drug Therapy. Clinical Pharmacokinetics. 1994;26(4):292-​ 307,whichmisquotedtheoriginalLBMdefinitionthatused128inJamesWPT,WaterlowJC.ResearchonObesity:AReport​ of the DHSS/MRC Group. London: Her Majesty’s Stationery Office; 1976. Implementations differ in whether they have used​ 120 or 128 for ({SUVlbm}g/ml{SUVlbm}, UCUM, "Standardized Uptake Value lean body mass (James)"). See Kelly M. SUV:​ Advancing Comparability and Accuracy. Siemens; 2009. Available from: http://www.mpcphysics.com/documents/​ SUV_Whitepaper_Final_11.17.09_59807428_2.pdf.​

- Standard -​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 515​

The Janmahasatian LBM formula is defined in Janmahasatian et al. Quantification of Lean Bodyweight. Clin Pharmacokinet.​ 2005 Oct 1;44(10):1051-65. at http://dx.doi.org/10.2165/00003088-200544100-00004 and its role in SUVlbm(Janma) calcu-​ lation is discussed in Tahari et al. Optimum Lean Body Formulation for Correction of Standardized Uptake Value in PET​ Imaging.JournalofNuclearMedicine.2014Sep1;55(9):1481-4. athttp://jnm.snmjournals.org/content/55/9/1481.Thepatient​ size correction factors are summarized here, where weight is in kg and height is in cm:​

SUVbw: males & females: weight​

SUVlbm (James): males : 1.10 * weight - 120 * (weight/height) ^2​

SUVlbm (James): females: 1.07 * weight - 148 * (weight/height) ^2​

SUVlbm(Janma): males: 9.27E3 * weight / (6.68E3 + 216 * weight / (height^2))​

SUVlbm(Janma): females: 9.27E3 * weight / (8.78E3 + 244 * weight / (height^2))​

SUVbsa: males & females: weight^ 0.425 * height^0.725 * 0.007184​

SUVibw: males: 48.0 + 1.06 * (height - 152)​

females: 45.5 + 0.91 * (height - 152)​

CID 91 Functional Condition Present During Acquisition​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20170914​

UID:​

1.2.840.10008.6.1.891​

Table CID 91. Functional Condition Present During Acquisition​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept​

Designator​







Unique ID​

Include CID 3271 “Hemodynamic Physiological Challenges”​





SCT​

43914001​

Phonation​

F-F7100​

C0031577​

SCT​

87731000​

Weight bearing​

F-12300​

C0231573​

DCM​

109137​

During voiding​





DCM​

109134​

Prior to voiding​





DCM​

109135​

Post voiding​





CID 92 Joint Position During Acquisition​

Resources:​

HTML | FHIR JSON | FHIR XML | IHE SVS XML​

Type:​

Extensible​

Version:​

20100625​

UID:​

1.2.840.10008.6.1.892​

Table CID 92. Joint Position During Acquisition​

Coding Scheme​

Code Value​

Code Meaning​

SNOMED-RT ID​

UMLS Concept Unique ID​

Designator​









DCM​

109136​

Neutral musculoskeletal​









position​





SCT​

9964006​

Flexion​

F-10110​

C0231452​

SCT​

24154002​

Extension​

F-10100​

C0522009​

SCT​

60074003​

Abduction​

F-10120​

C0231456​

- Standard -​
