Page 1146​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

109041​

P wave​

The surface electrocardiogram of the atrial contraction.​

109042​

Q wave​

The first negative deflection of the electrocardiogram​







cause by ventricular depolarization.​



109043​

R wave​

The first positive deflection the electrocardiogram cause​





by ventricular depolarization.​



109044​

S wave​

The first negative deflection after the R wave.​



109045​ Start of atrial contraction​

The beginning of the atrial contraction.​



109046​ Start of atrial contraction​

The beginning of the second atrial contraction of two​





(subsequent)​

consecutive beats.​



109047​ Stimulation at rate 1 interval​

The stimulation interval during cardiac stimulation first​







used in a pacing train.​



109048​ Stimulation at rate 2 interval​

Thestimulationintervaldifferentfromthefirststimulation​





interval used in a pacing train.​



109049​ Stimulation at rate 3 interval​

A stimulation interval different from and subsequent to​







the second interval in a pacing train.​



109050​ Stimulation at rate 4 interval​

Describes a stimulation interval different from and​







subsequent to the third interval in a pacing train.​



109051​

T wave​

The electrocardiogram deflection caused by ventricular​





repolarization.​



109052​

V wave​

The peak pressure of each heart beat monitored in the​





atrium caused by the filling of the atrium.​



109053​ V wave of next beat​

The second V wave measurement of two consecutive​







beats.​



109054​

Patient State​

Adescriptionofthephysiologicalconditionofthepatient.​

109055​

Protocol Stage​

The exercise level during a progressive cardiac stress​







test.​



109056​

Stress Protocol​

A series of physiological challenges designed to​







progressively increase the work of the heart.​



109057​

Catheterization Procedure​

A subpart of a cardiac catheterization procedure​

Retired. Replaced by​



Phase​



(129085009, SCT,​







"Catheterization Procedure​







Phase")​

109058​

Contrast Phase​

The subpart of a cardiac catheterization procedure in​







which a radio-opaque contrast medium is injected into​







the patient.​



109059​

Physiological challenges​

Physical changes administered to a patient in order to​







elicit an physiological response.​



109060​

Procedure Step Number​

Enumerationofasubpartofacatheterizationprocedure.​

109061​

EP Procedure Phase​

A subpart of en electrophysiological procedure.​



109063​

Pulse train definition​

A means of defining a series of cardiac stimulation​







pulses.​



109070​

End of systole​



Retired. Replaced by​







(416430001, SCT, "End​







systole")​

109071​ Indicator mean transit time​

Timeforamedianparticletotravelfrompointofinjection​





to point of detection.​



109072​

Tau​

The time constant of isovolumic pressure fall.​



109073​

V max myocardial​

Maximum velocity of myocardial contractility.​



- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1147​

Code Value​

Code Meaning​

Definition​

Notes​

109080​

Real time acquisition​

Totaltimefortheacquisitionisshorterthancardiaccycle,​





no gating is applied; see Cardiac Synchronization​







Technique (0018,9037).​



109081​

Prospective gating​

Certain thresholds have been set for a gating window​







thatdefinestheacceptanceofmeasurementdataduring​





the acquisition; see Cardiac Synchronization Technique​





(0018,9037).​



109082​

Retrospective gating​

Certain thresholds have been set for a gating window​







that defines the acceptance of measurement data after​





the acquisition; see Cardiac Synchronization Technique​





(0018,9037).​



109083​

Paced​

There is a constant RR interval, which makes​







thresholding not required; see Cardiac Synchronization​





Technique (0018,9037). E.g., Pacemaker.​



109091​

Cardiac Stress State​

Imagingafterinjectionoftracerduringincreasedcardiac​Retired. Replaced by​





workload or increased myocardial blood flow, achieved​(432655005, SCT, "Cardiac​





by either exercise or pharmacologic means.​

stress state").​

109092​

Reinjection State​

Imaging after injection of additional tracer under resting​





conditions.​



109093​

Redistribution State​

Imaging after allowing a moderate amount of time for​







tracer to move from its initial sites of uptake.​



Example: For Thallium imaging this would correspond​ to imaging 2-6 hours after injection.​

109094​ Delayed Redistribution State​ Imaging after allowing an extended amount of time for​ tracer to move from its initial sites of uptake.​

Example: For Thallium imaging this would correspond​ to imaging more than 6 hours after injection.​

109095​

Peak stress state​

Peak Cardiac stress state​

Retired. Replaced by​







(434161005, SCT, "Peak​







stress state")​

109096​

Recovery state​

Recovery from cardiac stress​

Retired. Replaced by​







(432554001, SCT, "Cardiac​







stress Recovery state")​

109101​

Acquisition Equipment​

Equipmentthatoriginallyacquiredthedatastoredwithin​





composite instances. E.g., a CT, MR or Ultrasound​







modality.​



109102​

Processing Equipment​

Equipment that has processed composite instances to​





createnewcompositeinstances.E.g.,a3DWorkstation.​

109103​

Modifying Equipment​

Equipment that has modified existing composite​







instances (without creating new composite instances).​







E.g., a QA Station or Archive.​



109104​

De-identifying Equipment​

Equipment that has modified an existing composite​







instance to remove patient identifying information.​



109105​ Frame Extracting Equipment​ Equipment that has processed composite instances to​ create new composite instances by extracting selected​ frames from the original instance.​

- Standard -​

Page 1148​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

109106​

Enhanced Multi-frame​

Equipment that has processed composite instances to​



Conversion Equipment​

create new composite instances by converting classic​







single frame images to enhanced multi-frame image, or​





vice versa and updating other instances to maintain​







referential integrity.​



109110​

Voice​

The sound of a human's speech, recorded during a​

May include the patient's​





procedure.​

voice, or the voice of staff​







present in the room, or an​







operator's voice (whether for​







the purpose of recording a​







narrative accompanying a​







procedure or not).​

109111​

Operator's narrative​

The voice of a device operator, recorded during a​







procedure.​



109112​

Ambient room environment​

The ambient sound recorded during a procedure, which​





may or may not include voice and other types of sound.​

109113​

Doppler audio​

The Doppler waveform recorded as an audible signal.​



109114​

Phonocardiogram​

The sound of the human heart beating.​

Such as might be recorded​







from an electronic​







stethoscope.​

109115​ Physiological audio signal​

Any sound made by the human body.​

109116​

Arterial Pulse Waveform​

A digitized signal from the patient arterial system​





collected through pulse oximetry or other means.​

109117​

Respiration Waveform​

A digitized signal from the patient respiratory system​





representing respiration.​

May include the sound of the​ heart, but also sound from​ other organs, such as bowel​ soundsorbruitsfromvessels,​ or sounds of respiration. Not​ intended to include voice.​

109120​ On admission to unit​

The occasion on which a procedure was performed on​





admission to a specialist unit. E.g., intensive care.​

109121​

On discharge​

The occasion on which a procedure was performed on​





discharge from hospital as an in-patient.​

109122​ On discharge from unit​

The occasion on which a procedure was performed on​





discharge from a specialist unit. E.g., intensive care.​

109123​

Pre-intervention​

The occasion on which a procedure was performed​





immediately prior to non-surgical intervention. E.g,​





percutaneous angioplasty, biopsy.​

109124​

Post-intervention​

The occasion on which a procedure was performed​





immediately after to non-surgical intervention. E.g,​





percutaneous angioplasty, biopsy.​

109125​

At last appointment​

The occasion on which a procedure was performed at​





the most recent outpatient visit.​

109132​

Joint position method​

Theactiveorpassivejointpositioningduringacquisition.​

109133​

Physical force​

A physical force applied during acquisition.​

109134​

Prior to voiding​

Prior to voiding urine from the bladder.​

109135​

Post voiding​

Post voiding urine from the bladder.​

109136​ Neutralmusculoskeletalposition​Neutral musculoskeletal position.​

109137​

During voiding​

During voiding urine from the bladder.​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1149​

Code Value​

Code Meaning​

Definition​

Notes​

109200​

America Kennel Club​

America Kennel Club.​



109201​

America's Pet Registry Inc.​

America's Pet Registry Inc.​



109202​ American Canine Association​ American Canine Association.​



109203​

American Purebred Registry​

American Purebred Registry.​



109204​

American Rare Breed​

American Rare Breed Association.​





Association​





109205​

Animal Registry Unlimited​

Animal Registry Unlimited.​



109206​

Animal Research Foundation​

Animal Research Foundation.​



109207​

Canadian Border Collie​

Canadian Border Collie Association.​





Association​





109208​

Canadian Kennel Club​

Canadian Kennel Club.​



109209​

Canadian Livestock Records​

Canadian Livestock Records Association.​





Association​





109210​ Canine Federation of Canada​ Canine Federation of Canada.​



109211​

Continental Kennel Club​

Continental Kennel Club.​



109212​

Dog Registry of America​

Dog Registry of America.​



109213​

Federation of International​

Federation of International Canines.​





Canines​





109214​ International Progressive Dog​ International Progressive Dog Breeders' Alliance.​





Breeders' Alliance​





109215​

National Kennel Club​

National Kennel Club.​



109216​ North American Purebred Dog​North American Purebred Dog Registry.​





Registry​





109217​

United All Breed Registry​

United All Breed Registry.​



109218​

United Kennel Club​

United Kennel Club.​



109219​

Universal Kennel Club​

Universal Kennel Club International.​





International​





109220​ Working Canine Association of​Working Canine Association of Canada.​





Canada​





109221​

World Kennel Club​

World Kennel Club.​



109222​

World Wide Kennel Club​

World Wide Kennel Club.​



109701​ Overallimagequalityevaluation​Evaluationofoverallimagequalityasdescribedinsection​







7.3.2 of [IEC 62563-1].​



109702​ Grayscale resolution evaluation​Visualverificationofsufficientgrayscaleresolutionbased​







on 8 and 10-bit markers as described in section 7.3.3 of​







[IEC 62563-1].​



109703​ Luminanceresponseevaluation​Visual evaluation of luminance response using the​







TG18-CT test pattern as described in section 7.3.4 of​







[IEC 62563-1].​



109704​ Luminanceuniformityevaluation​Visual detection of luminance non-uniformities as​







described in section 7.3.5 of [IEC 62563-1].​



109705​

Chromaticity evaluation​

Visual verification of color uniformity as described in​







section 7.3.6 of [IEC 62563-1].​



109706​

Pixel faults evaluation​

Visualdetectionofdefectivepixelsondark(TG18-UN80)​







and bright (TG18-UN10) images as described in section​







7.3.7 of [IEC 62563-1].​



- Standard -​

Page 1150​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

109707​

Veiling glare evaluation​

Visual evaluation of veiling glare by looking at low​







contrastobjectson2testpatternsasdescribedinsection​







7.3.8 of [IEC 62563-1].​



109708​ Geometrical image evaluation​Visual evaluation of geometry, phase/clock correction​







and clipping as described in section 7.3.9 of [IEC​







62563-1].​



109709​

Angular viewing evaluation​

Visualevaluationofviewingangleasdescribedinsection​







7.3.10 of [IEC 62563-1].​



109710​

Clinical evaluation​

Visual evaluation of the appearance of clinical images​







as described in section 7.3.11 of [IEC 62563-1].​



109801​

TG18-QC Pattern​

AAPMTG18-QCPatternusedforevaluationofresolution,​







luminance, distortion, artifacts.​







See [AAPM OR 03].​



109802​

TG18-BR Pattern​

AAPM TG18-BR Pattern used for the evaluation of the​







display of low-contrast, fine-detail image structures​







See [AAPM OR 03].​



109803​

TG18-PQC Pattern​

AAPM TG18-PQC Pattern used for evaluation of​







resolution, luminance, contrast transfer for prints.​







See [AAPM OR 03].​



109804​

TG18-CT Pattern​

AAPMTG18-CTPatternusedforevaluationofluminance​







response.​







See [AAPM OR 03].​



109805​

TG18-LN8-01 Pattern​

The 1st image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​







See [AAPM OR 03].​



109806​

TG18-LN8-02 Pattern​

The 2nd image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​







See [AAPM OR 03].​



109807​

TG18-LN8-03 Pattern​

The 3rd image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​







See [AAPM OR 03].​



109808​

TG18-LN8-04 Pattern​

The 4th image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​







See [AAPM OR 03].​



109809​

TG18-LN8-05 Pattern​

The 5th image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​







See [AAPM OR 03].​



109810​

TG18-LN8-06 Pattern​

The 6th image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​







See [AAPM OR 03].​



109811​

TG18-LN8-07 Pattern​

The 7th image in the AAPM TG18-LN8 set used for​







DICOM grayscale calibration.​



See [AAPM OR 03].​

- Standard -​

Источник: https://studfile.net/preview/14585769/

Смотрите также:

08_Вероятн произведения событий
1
1 Кариес зубов Задача 1
144969
16.04.20 г. Определение цены и объёма сбыта
1655
16фз
2_5298781932820103487
20. Ступенчатая диссоциация многоосновных кислот и многокислотных оснований
217
