DICOM PS3.16 2020a - Content Mapping Resource​

Page 1151​

Code Value​

Code Meaning​

Definition​

Notes​

109812​

TG18-LN8-08 Pattern​

The 8th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109813​

TG18-LN8-09 Pattern​

The 9th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109814​

TG18-LN8-10 Pattern​

The 10th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration series.​

See [AAPM OR 03].​

109815​

TG18-LN8-11 Pattern​

The 11th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109816​

TG18-LN8-12 Pattern​

The 12th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109817​

TG18-LN8-13 Pattern​

The 13th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109818​

TG18-LN8-14 Pattern​

The 14th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109819​

TG18-LN8-15 Pattern​

The 15th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109820​

TG18-LN8-16 Pattern​

The 16th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109821​

TG18-LN8-17 Pattern​

The 17th image in the AAPM TG18-LN8 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109822​

TG18-LN8-18 Pattern​

The 18th image in the AAPM TG18-LN8- set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109823​

TG18-LN12-01 Pattern​

The 1st image in the AAPM TG18-LN12 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109824​

TG18-LN12-02 Pattern​

The 2 nd image in the AAPM TG18-LN12 set used for​

DICOM grayscale calibration.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1153​

Code Value​

Code Meaning​

Definition​

Notes​

109838​

TG18-LN12-16 Pattern​

The 16th image in the AAPM TG18-LN12 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109839​

TG18-LN12-17 Pattern​

The 17th image in the AAPM TG18-LN12 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109840​

TG18-LN12-18 Pattern​

The 18th image in the AAPM TG18-LN12 set used for​

DICOM grayscale calibration.​

See [AAPM OR 03].​

109841​

TG18-UN10 Pattern​

The AAPM TG18-UN10 Pattern used for evaluation of​

luminance and color uniformity, and angular response.​

See [AAPM OR 03].​

109842​

TG18-UN80 Pattern​

The AAPM TG18-UN80 Pattern used for evaluation of​

luminance and color uniformity, and angular response.​

See [AAPM OR 03].​

109843​

TG18-UNL10 Pattern​

The AAPM TG18-UNL10 Pattern is the AAPM TG-18​

UN10 Pattern with added defining lines.​

See [AAPM OR 03].​

109844​

TG18-UNL80 Pattern​

The AAPM TG18-UNL80 Pattern is the AAPM TG-18​

UN80 Pattern with added defining lines.​

See [AAPM OR 03].​

109845​

TG18-AD Pattern​

The AAPM TG18-AD Pattern used for visual evaluation​

of the reflection of ambient light from the display.​

See [AAPM OR 03].​

109846​

TG18-MP Pattern​

The AAPM TG18-MP Pattern used for evaluation of​

Luminance response (bit-depth resolution).​

See [AAPM OR 03].​

109847​

TG18-RH10 Pattern​

TheAAPMTG18-RH10PatternusedforLSF-linespectra​

function-(1k and 2k) evaluation by 5 horizontal lines at​

10% luminance level.​

See [AAPM OR 03].​

109848​

TG18-RH50 Pattern​

TheAAPMTG18-RH50PatternusedforLSF-linespectra​

function-(1k and 2k) evaluation by 5 horizontal lines at​

50% luminance level.​

See [AAPM OR 03].​

109849​

TG18-RH89 Pattern​

TheAAPMTG18-RH89PatternusedforLSF-linespectra​

function-(1k and 2k) evaluation by 5 horizontal lines at​

89% luminance level.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1155​

Code Value​

Code Meaning​

Definition​

Notes​

109859​

TG18-LPV50 Pattern​

The AAPM TG18-LPV50 Pattern used to assess display​

resolution. This pattern has vertical bars consisting of​

alternating single-pixel-wide lines across the faceplate​

ofdisplay.Thelineshavea12%positivecontrastagainst​

50% background level of the maximum pixel value.​

See [AAPM OR 03].​

109860​

TG18-LPV89 Pattern​

The AAPM TG18-LPV89 Pattern used to assess display​

resolution. This pattern has vertical bars consisting of​

alternating single-pixel-wide lines across the faceplate​

ofdisplay.Thelineshavea12%positivecontrastagainst​

89% background level of the maximum pixel value.​

See [AAPM OR 03].​

109861​

TG18-AFC Pattern​

The AAPM TG18-AFC Pattern used to assess display​

noise.​

See [AAPM OR 03]​

109862​

TG18-NS10 Pattern​

The AAPM TG18-NS10 Pattern is AAPM​

TG18-RV10/RH10withonlydifferencebeingtheabsence​

of the single line at the center of the measurement area.​

See [AAPM OR 03].​

109863​

TG18-NS50 Pattern​

The AAPM TG18-NS50 Pattern is AAPM​

TG18-RV50/RH50withonlydifferencebeingtheabsence​

of the single line at the center of the measurement area.​

See [AAPM OR 03].​

109864​

TG18-NS89 Pattern​

The AAPM TG18-NS89 Pattern is AAPM​

TG18-RV89/RH89withonlydifferencebeingtheabsence​

of the single line at the center of the measurement area.​

See [AAPM OR 03].​

109865​

TG18-GV Pattern​

The TG18-GV Pattern used to assess display veiling.​

See [AAPM OR 03].​

109866​

TG18-GVN Pattern​

The TG18-GVN Pattern used to assess display veiling.​

This pattern is identical to AAPM TG18-GV Pattern​

except that the large-diameter white circle is replaced​

with a black circle, creating a completely black pattern​

except for the presence of low-contrast targets.​

See [AAPM OR 03].​

109867​

TG18-GQ Pattern​

TheTG18-GQPatternusedforquantitativeassessment​

of veiling glare. This pattern is identical to TG18-GV​

except that is lacks the central low-contrast objects.​

See [AAPM OR 03].​

109868​

TG18-GQN Pattern​

TG18-GQNPatternusedforthequantitativeassessment​

of veiling glare. This pattern is identical to AAPM​

TG18-GQ Pattern except that the large-diameter white​

circleisreplacedwithablackcircle,creatingacompletely​

black pattern except for the presence of low-contrast​

targets.​
