Page 1156​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

109869​

TG18-GQB Pattern​

The TG18-GQB Pattern used for the quantitative​

assessment of veiling glare. This pattern is identical to​

AAPM TG18-GQ Pattern except eliminating the central​

black circle.​

See [AAPM OR 03].​

109870​

TG18-GA03 Pattern​

The TG18-GA03 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 3.​

See [AAPM OR 03].​

109871​

TG18-GA05 Pattern​

The TG18-GA05 Pattern This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 5.​

See [AAPM OR 03].​

109872​

TG18-GA08 Pattern​

The TG18-GA08 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 8.​

See [AAPM OR 03].​

109873​

TG18-GA10 Pattern​

The TG18-GA10 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 10.​

See [AAPM OR 03].​

109874​

TG18-GA15 Pattern​

The TG18-GA15 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 15.​

109875​

TG18-GA20 Pattern​

The TG18-GA20 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 20.​

See [AAPM OR 03].​

109876​

TG18-GA25 Pattern​

The TG18-GA25 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 25.​

See [AAPM OR 03].​

109877​

TG18-GA30 Pattern​

The TG18-GA30 Pattern used for quantitative​

assessment of veiling glare. This pattern is identical to​

TG18-GQexceptthattheradiusofthecentralblackcircle​

is varied as r = 30.​

See [AAPM OR 03].​

109878​

TG18-CH Image​

The AAPM TG18-CH Image is a reference anatomical​

PA chest image.​

Page 1158​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

109910​

BN07 Pattern​

The IEC BN07 Pattern is used as an alternative to the​

TG18-LN-07 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109911​

BN08 Pattern​

The IEC BN08 Pattern is used as an alternative to the​

TG18-LN-08 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109912​

BN09 Pattern​

The IEC BN09 Pattern is used as an alternative to the​

TG18-LN-09 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109913​

BN10 Pattern​

The IEC BN10 Pattern is used as an alternative to the​

TG18-LN-10 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109914​

BN11 Pattern​

The IEC BN11 Pattern is used as an alternative to the​

TG18-LN-11 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109915​

BN12 Pattern​

The IEC BN12 Pattern is used as an alternative to the​

TG18-LN-12 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109916​

BN13 Pattern​

The IEC BN13 Pattern is used as an alternative to the​

TG18-LN-13 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109917​

BN14 Pattern​

The IEC BN14 Pattern is used as an alternative to the​

TG18-LN-14 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109918​

BN15 Pattern​

The IEC BN15 Pattern is used as an alternative to the​

TG18-LN-15 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109919​

BN16 Pattern​

The IEC BN16 Pattern is used as an alternative to the​

TG18-LN-16 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

See [IEC 62563-1].​

109920​

BN17 Pattern​

The IEC BN17 Pattern is used as an alternative to the​

TG18-LN-17 Pattern, to avoid the use of a cone or baffle​

with LCDs.​

Page 1160​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

110007​

Report Verification​

Report verification work item.​

110008​

Print​

Print work item.​

110009​

No subsequent Workitems​

There will be no more work items scheduled.​

110010​

Film​

Film type of output.​

110011​

Dictation​

Dictation type of output.​

110012​

Transcription​

Transcription type of output.​

110013​

Media Import​

The procedure to read DICOM instances from DICOM​

interchange media, coerce identifying attributes into the​

local namespace if necessary, and make the instances​

available.​

110020​

Sheet Film Digitized​

Digitization of Sheet Film.​

110021​

Cine Film Digitized​

Digitization of Cine Film.​

110022​

Video Tape Digitized​

Digitization of Video Tape.​

110023​

Paper Digitized​

Digitization of pages of a paper document (Units may be​

specified as Pages, Documents).​

110024​

CD Imported​

Importation of CD.​

110025​

DVD Imported​

Importation of DVD.​

110026​

MOD Imported​

Importation of MOD.​

110027​

Studies Imported​

Importation of DICOM Studies.​

110028​

Instances Imported​

Importation of DICOM Composite Instances.​

110030​

USB Disk Emulation​

A device that connects using the USB hard drive​

interface. These may be USB-Sticks, portable hard​

drives, and other technologies.​

110031​

Email​

Email and email attachments used as a media for data​

transport.​

110032​

CD​

CD-R, CD-ROM, and CD-RW media used for data​

transport.​

110033​

DVD​

DVD, DVD-RAM, and other DVD formatted media used​

for data transport.​

110034​

Compact Flash​

Media that comply with the Compact Flash standard.​

110035​

Multi-media Card​

Media that comply with the Multi-media Card standard.​

110036​

Secure Digital Card​

MediathatcomplywiththeSecureDigitalCardstandard.​

110037​

URI​

URI Identifier for network or other resource, see​

RFC3968.​

110038​

Paper Document​

Any paper or similar document.​

110100​

Application Activity​

Audit event: Application Activity has taken place.​

110101​

Audit Log Used​

Audit event: Audit Log has been used.​

110102​

Begin Transferring DICOM​

Audit event: Storage of DICOM Instances has begun.​

Instances​

110103​

DICOM Instances Accessed​

Auditevent:DICOMInstanceshavebeencreated,read,​

updated, or deleted -audit event.​

110104​ DICOM Instances Transferred​Audit event: Storage of DICOM Instances has been​

completed.​

110105​

DICOM Study Deleted​

Audit event: Entire Study has been deleted.​

110106​

Export​

Audit event: Data has been exported out of the system.​
