Page 1226​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

112371​ Manufacturer Implant Template​Implant Template released by the Manufacturer.​

112372​

Derived Planning Images​

Images that are created by a planning application.​

112373​ Other Derived Planning Data​

Data that is created by a planning application.​

112374​

Connected Implantation Plan​

One Implant Component that is connected to another​

Component​

Implant Component.​

112375​

Planning Method​

The method used for planning.​

112376​ Degree of Freedom Exact​

Defines the exact value that was planned for translation.​

Translational Value​

112377​ Degree of Freedom Minimum​ Defines the minimum value that was planned for​

Translational Value​

translation.​

112378​ Degree of Freedom Maximum​Defines the maximum value that was planned for​

Translational Value​

translation.​

112379​ Degree of Freedom Exact​

Defines the exact value that was planned for rotation.​

Rotational Translation Value​

112380​

Degree of Freedom Minimum​ Definestheminimumvaluethatwasplannedforrotation.​

Rotational Value​

112381​ Degree of Freedom Maximum​Definesthemaximumvaluethatwasplannedforrotation.​

Rotational Value​

112700​

Peri-operative Photographic​

Procedure step protocol for photographic imaging of​

Imaging​

surgicalprocedures,includingphotographyofspecimens​

collected.​

112701​

Gross Specimen Imaging​

Procedure step protocol for imaging gross specimens,​

typically with a photographic camera (modality XC), and​

planning further dissection.​

112702​

Slide Microscopy​

Procedure step protocol for imaging slide specimens.​

112703​

Whole Slide Imaging​

Procedure step protocol for imaging slide specimens​

using a whole slide scanner.​

112704​

WSI 20X RGB​

Procedure step protocol for imaging slide specimens​

usingawholeslidescannerwitha20Xnominalobjective​

lens,infullcolor,withasingleimagingfocalplaneacross​

the image.​

112705​

WSI 40X RGB​

Procedure step protocol for imaging slide specimens​

usingawholeslidescannerwitha40Xnominalobjective​

lens,infullcolor,withasingleimagingfocalplaneacross​

the image.​

112706​

Illumination Method​

Technique of illuminating specimen.​

112707​ Number of focal planes​

Number of focal planes for a microscopy image​

acquisition.​

112708​ Focal plane Z offset​

Nominal distance above a reference plane (typically a​

slide glass substrate top surface) of the focal plane.​

112709​

Magnification selection​

Microscope magnification based on nominal objective​

lens power.​

112710​

Illumination wavelength​

Nominalcenterwavelengthforanimagingspectralband.​

112711​

Illumination spectral band​

Name (coded) for an imaging spectral band.​

112712​

Optical filter type​

Type of filter inserted into the optical imaging path.​

112713​

Tissue selection method​

Techniqueforidentifyingtissuetobeimagedversusarea​

of slide not to be imaged.​

112714​

Multiple planes​

Imaging performed at multiple imaging (focal) planes.​

112721​ No empty tile suppression​

Tiles without tissue imaged are not suppressed from​

inclusion in image object.​

113000​

Of Interest​

Of Interest.​

113001​ Rejected for Quality Reasons​ Rejected for Quality Reasons.​

113002​

For Referring Provider​

For Referring Provider.​

113003​

For Surgery​

For Surgery.​

113004​

For Teaching​

For Teaching.​

113005​

For Conference​

For Conference.​

113006​

For Therapy​

For Therapy.​

113007​

For Patient​

For Patient.​

113008​

For Peer Review​

For Peer Review.​

113009​

For Research​

For Research.​

113010​

Quality Issue​

Quality Issue.​

113011​

Document Title Modifier​

Document Title Modifier.​

113012​

Key Object Description​

Key Object Description.​

113013​

Best In Set​

A selection that represents the "best" chosen from a​

larger set of items. E.g., the best images within a Study​

or Series. The criteria against which "best" is measured​

is not defined. Contrast this with the more specific term​

"Best illustration of finding".​

113014​

Study​

A study is a collection of one or more series of medical​

images, presentation states, and/or SR documents that​

are logically related for the purpose of diagnosing a​

patient. A study may include composite instances that​

are created by a single modality, multiple modalities or​

by multiple devices of the same modality. [From​

Section A.1.2.2 “Study IE” in PS3.3]​

113015​

Series​

A distinct logical set used to group composite instances.​

All instances within a Series are of the same modality,​

in the same Frame of Reference (if any), and created by​

the same equipment. [See Section A.1.2.3 “Series IE” in​

PS3.3]​

Page 1228​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

113016​

Performed Procedure Step​

An arbitrarily defined unit of service that has actually​

been performed (not just scheduled). [From​

Section 7.3.1.9 “Modality Performed Procedure Step” in​

PS3.3]​

113017​

Stage-View​

An image or set of images illustrating a specific stage​

(phase in a stress echo exam protocol) and view​

(combination of the transducer position and orientation​

at the time of image acquisition).​

113018​

For Printing​

For Printing.​

113020​

For Report Attachment​

Selection of information objects for attachment to the​

clinical report of the Current Requested Procedure.​

113021​

For Litigation​

List of objects that are related to litigation and should be​

specially handled. E.g., may apply if a complaint has​

been received regarding a patient, or a specific set of​

images has been the subject of a subpoena, and needs​

to be sequestered or excluded from automatic purging​

according to retention policy.​

113022​

CollectionofPresentationStates​This Key Object Selection Document references​

PresentationStateinstancesthatarerelated,whichmay​

or may not share a value of Presentation Display​

Collection UID (0070,1101) or Presentation Sequence​

Collection UID (0070,1102).​

113026​

Double exposure​

Double exposure.​

113030​

Manifest​

A list of objects that have been exported out of one​

organizational domain into another domain. Typically,​

the first domain has no direct control over what the​

second domain will do with the objects.​

113031​

Signed Manifest​

A signed list of objects that have been exported out of​

one organizational domain into another domain,​

referenced securely with either Digital Signatures or​

MACs. Typically, the first domain has no direct control​

over what the second domain will do with the objects.​

113032​

Complete Study Content​

The list of objects that constitute a study at the time that​

the list was created.​

113033​

SignedCompleteStudyContent​The signed list of objects that constitute a study at the​

time that the list was created, referenced securely with​

either Digital Signatures or MACs.​

113034​ Complete Acquisition Content​ The list of objects that were generated in a single​

procedure step.​

113035​

Signed Complete Acquisition​

The signed list of objects that were generated in a single​

Content​

procedure step, referenced securely with either Digital​

Signatures or MACs.​

113036​ Group of Frames for Display​

A list of frames or single-frame or entire multi-frame​

instancesthattogetherconstituteasetforsomepurpose,​

such as might be displayed together in the same​

viewport, as distinct from another set that might be​

displayed in a separate viewport.​

113037​ Rejected for Patient Safety​

List of objects whose use is potentially harmful to the​

Reasons​

patient. E.g., an improperly labeled image could lead to​

dangerous surgical decisions.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1229​

Code Value​

Code Meaning​

Definition​

Notes​

113040​

Lossy Compression​

Lossy compression has been applied to an image.​

113041​

Apparent Diffusion Coefficient​Values are derived by calculation of the apparent​

Graessner J. Frequently​

diffusion coefficient. This concept may be used for the​Asked Questions:​

diffusion coefficient of various different models, e.g.,​

Diffusion-Weighted Imaging​

mono-exponential (ADCm), kurtosis (ADCk),​

(DWI). MAGNETOM Flash.​

stretched-exponential (ADCs).​

Siemens. 2011 Jan. http://​

The "apparent" appellation is because the diffusion​

clinical-mri.com/wp-content/​

uploads/​

images from which the ADC is computed may also be​software_hardware_updates/​

affected by T2 contrast (T2 "shine-through"), so this​

Graessner.pdf​

conceptisdistinguishedfroma"pure"diffusioncoefficient​

that is not so affected.​

Toivonen J, Merisaari H,​

PesolaM,TaimenP,Boström​

PJ, Pahikkala T, et al.​

Mathematical models for​

diffusion-weightedimagingof​

prostate cancer using b​

values up to 2000 s/mm2:​

Correlation with Gleason​

score and repeatability of​

region of interest analysis.​

Magnetic Resonance in​

Medicine.​

2015;74(4):1116-24. http://​

dx.doi.org/10.1002/​

mrm.25482​

113042​

Pixel by pixel addition​

Values are derived by the pixel by pixel addition of two​

images.​

113043​

Diffusion weighted​

Values are derived by calculation of the diffusion​

weighting.​

113044​

Diffusion Anisotropy​

Values are derived by calculation of the diffusion​

anisotropy.​

113045​

Diffusion Attenuated​

Values are derived by calculation of the diffusion​

attenuation.​

113046​

Pixel by pixel division​

Values are derived by the pixel by pixel division of two​

images.​

113047​

Pixel by pixel mask​

Values are derived by the pixel by pixel masking of one​

image by another.​

113048​

Pixel by pixel Maximum​

Values are derived by calculating the pixel by pixel​

maximum of two or more images.​

113049​

Pixel by pixel mean​

Valuesarederivedbycalculatingthepixelbypixelmean​

of two or more images.​

113050​

Metabolite Maps from​

Valuesarederivedbycalculatingfromspectroscopydata​

spectroscopy data​

pixel values localized in two dimensional space based​

on the concentration of specific metabolites (i.e, at​

specific frequencies).​

113051​

Pixel by pixel Minimum​

Values are derived by calculating the pixel by pixel​

minimum of two or more images.​

Page 1230​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

113052​

Mean Transit Time​

The time required for blood to pass through a region of​

tissue.​

113053​

Pixel by pixel multiplication​

Values are derived by the pixel by pixel multiplication of​

two images.​

brain as volume per mass per unit of time. The mass​

divisor may be approximated by a measurement of​

volume assuming a tissue density of 1.​

113056​ RegionalCerebralBloodVolume​Theabsolutevolumeofbloodperfusingaregionofbrain​Retired.​

as volume per mass. The mass divisor may be​

approximated by a measurement of volume assuming a​

tissue density of 1.​

113057​

R-Coefficient​

Correlation Coefficient, r.​

113058​

Proton Density​

Values are derived by calculating proton density values.​

113059​

Signal Change​

The relative change in signal.​

113060​

Signal to Noise​

The ratio of the desired signal to the level of noise.​

113061​

Standard Deviation​

Values are derived by calculating the standard deviation​

of two or more images.​

113062​ Pixel by pixel subtraction​

Values are derived by the pixel by pixel subtraction of​

two images.​

113063​

T1​

The time constant for the decay of longitiudinal​

magnetization caused by spin-lattice relaxation. The​

inverse of the longitudinal relaxation rate constant, i.e.,​

T1 = 1/R1.​

113064​

T2*​

The time constant for the decay of transverse​

magnetization caused by a combination of spin-spin​

relaxationandmagneticfieldinhomogeneity.Theinverse​

of the transverse relaxation rate constant, i.e., T2* =​

1/R2*.​

113065​

T2​

The time constant for the decay of transverse​

magnetization caused by spin-spin relaxation. The​

inverse of the transverse relaxation rate constant, i.e.,​

T2 = 1/R2.​

113066​ Time Course of Signal​

The time course of signal.​

113067​

Temperature encoded​

Values are derived by calculating values based on​

temperature encoding.​

113068​

Student's T-Test​

Values are derived by calculating the value of the​

Student's T-Test statistic from multiple image samples.​

113069​

Time To Peak​

The time from the start of the contrast agent injection to​

the maximum enhancement value.​

113070​

Velocity encoded​

Values are derived by calculating values based on​

velocity encoded. E.g., phase contrast.​

113071​

Z-Score​

ValuesarederivedbycalculatingthevalueoftheZ-Score​

statistic from multiple image samples.​

113072​

Multiplanar reformatting​

Values are derived by reformatting in a flat plane other​

than that originally acquired.​
