Page 1276​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

121244​ Distance from chest wall​

Indicatesthelocationoftheareaofinterestasmeasured​







from the chest wall.​



121290​ Patient exposure to ionizing​

Patient exposure to ionizing radiation (procedure).​





radiation​





121291​

Results communicated​

The act of communicating actionable findings to a​







responsible receiver.​



121301​

Simultaneous Doppler​

Reference is to a Doppler waveform acquired​







simultaneously with an image.​



121302​

Simultaneous Hemodynamic​

Reference is to a Hemodynamic waveform acquired​







simultaneously with an image.​



121303​

Simultaneous ECG​

ReferenceistoaECGwaveformacquiredsimultaneously​







with an image.​



121304​ Simultaneous Voice Narrative​ Reference is to a voice narrative recording acquired​







simultaneously with an image.​



121305​

Simultaneous Respiratory​

A waveform representing chest expansion and​





Waveform​

contraction due to respiratory activity, measured​







simultaneously with the acquisition of this Image.​



121306​

Simultaneous Arterial Pulse​

Arterial pulse waveform obtained simultaneously with​





Waveform​

acquisition of a referencing image.​



121307​

Simultaneous​

Phonocardiographic waveform obtained simultaneously​



Phonocardiographic Waveform​with acquisition of a referencing image.​

121310​ RT treatment plan for the​ position being verified​

ThereferencedinstanceisanRTtreatmentplanofsome​The referenced Instance​ type, which contains treatment positioning information,​typically will be an RT Plan,​

which has been verified using the information in the​

RT Ion Plan or RT Radiation​

referencing instance.​

Set.​

121311​

Localizer​

Image providing an anatomical reference on the patient​





under examination, for the purpose of defining the​





location of the ensuing imaging.​

121312​

Biopsy localizer​

Image providing an anatomical reference on the patient​





under examination, for the purpose of planning or​





documenting a biopsy.​

121313​

Other partial views​

Image providing a partial view of the target anatomy,​





when the target anatomy is too large for a single image.​

121314​

Other image of biplane pair​

Image providing a view of the target anatomy in a​





different imaging plane, typically from a near​





perpendicular angle.​

121315​ Otherimageofstereoscopicpair​Image providing a view of the target anatomy in a​





different imaging plane, typically with a small angular​





difference.​

121316​

Images related to standalone​ Image related to a non-image information object.​



object​



121317​

Spectroscopy​

Image where signals are identified and separated​





according to their frequencies. E.g., to identify individual​





chemicals, or individual nuclei in a chemical compound.​

121318​

Spectroscopy Data for Water​

MR spectroscopy data acquired to correct the phase of​



Phase Correction​

the diagnostic data for the phase signal of the Water.​

121320​

Uncompressed predecessor​

An image that has not already been lossy compressed​





that is used as the source for creation of a lossy​





compressed image.​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1277​

Code Value​

Code Meaning​

Definition​

Notes​

121321​ Mask image for image​

Image used as the mask for an image processing​





processing operation​

operation, such as subtraction.​



121322​ Source image for image​

Image used as the source for an image processing​





processing operation​

operation.​



121323​ Source series for image​

Series used as the source for an image processing​





processing operation​

operation.​



121324​

Source Image​

Image used as the source for a derived or compressed​







image.​



121325​

Lossy compressed image​

Imageencodedwithalossycompressiontransfersyntax.​



121326​ Alternate SOP Class instance​ SOP Instance encoded with a different SOP Class but​







otherwise equivalent data.​



121327​

Full fidelity image​

Full fidelity image, uncompressed or lossless​







compressed.​



121328​

Alternate Photometric​

Imageencodedwithadifferentphotometricinterpretation.​





Interpretation image​





121329​ Source image for montage​

Image used as a source for a montage (stitched) image.​



121330​ Lossycompressedpredecessor​An image that has previously been lossy compressed​







that is used as the source for creation of another lossy​







compressed image.​



121331​

Equivalent CDA Document​

HL7 Document Architecture (CDA) Document that​







contains clinical content equivalent to the referencing​







Instance.​



121332​ Complete Rendering for​ Presentation​

121333​ Partial Rendering for​ Presentation​

121334​ Extended Rendering for​ Presentation​

121335​ Source Document​

121338​ Anatomic image​ 121339​ Functional image​

121340​ Spectral filtered image​

121341​ Device localizer​

121342​ Dose Image​

121346​ Acquisition frames​ corresponding to volume​

121347​ Volume corresponding to​ spatially-related acquisition​ frames​

Instance that contains a displayable complete rendering​ of the referencing Instance.​

Instance that contains a displayable partial rendering of​ the referencing Instance.​

Instance that contains a displayable complete rendering​ of the referencing Instance, plus additional content such​ as inline rendering of referenced images.​

Document whose content has been wholly or partially​ transformed to create the referencing document.​

Image showing structural anatomic features.​ Image showing physical or chemical activity.​

Image providing the same view of the target anatomy​ acquired using only a specific imaging wavelength,​ frequency or energy.​

Image providing an anatomical reference on the patient​ under examination, for the purpose of documenting the​ location of device such as a diagnostic or therapeutic​ catheter.​

Image providing a graphic view of the distribution of​ radiation dose.​

The referenced image is the source of spatially-related​ frames from which the referencing 3D volume data was​ derived.​

3D Volume containing the spatially-related frames in the​ referencing instance.​

- Standard -​

Page 1278​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

121348​

Temporal Predecessor​

Instance acquired prior to the referencing instance in a​







set of consecutively acquired instances.​



121349​

Temporal Successor​

Instanceacquiredsubsequenttothereferencinginstance​







in a set of consecutively acquired instances.​



121350​ Same acquisition at lower​

Image of the same target area at lower resolution​





resolution​

acquired in the same acquisition process.​



121351​ Same acquisition at higher​

Image of the same target area at higher resolution​





resolution​

acquired in the same acquisition process.​



121352​ Same acquisition at different​

Image of the same target area at different focal depth​





focal depth​

(Z-plane) acquired in the same acquisition process.​



121353​ Same acquisition at different​

Image of the same target area at different spectral band​





spectral band​

acquired in the same acquisition process.​



121354​

Imaged container label​

Image specifically targeting the container label.​



121358​

For Processing predecessor​

SourceimagefromwhichFORPRESENTATIONimages​







were created.​



121360​

Replaced report​

The reference is to a predecessor report that has been​







replaced by the current report.​



121361​

Addended report​

The reference is to a predecessor report to which the​







current report provides an addendum.​



121362​

Preliminary report​

A report that precedes the final report and may contain​







only limited information; it may be time sensitive, and it​







is not expected to contain all the reportable findings.​



121363​

Partial report​

A report that is not complete.​



121370​ Composed from prior doses​

The dose object created was calculated by summation​







of existing, previously calculated, RT Dose instances.​



121371​ Composedfrompriordosesand​The dose object created was calculated by summation​





current plan​

of existing, previously calculated, RT Dose instances​







anddosenewlycalculatedbytheapplication.Thenewly​







calculateddosemayormaynotexistasanindependent​







object.​



121372​ Source dose for composing​

RT Dose Instances used as source for calculated dose.​





current dose​





121373​ RT Pre-Treatment Dose Check​An assessment of the dose delivery parameters​







performed before treatment.​



121374​ RT Pre-Treatment Consistency​An assessment of consistency with a previously​





Check​

quality-assured treatment plan performed before​







treatment.​



121375​

Assessment By Comparison​

The basis of the assessment was a comparison object.​



121376​

Assessment By Rules​

The basis of the assessment was a set of rules on​







expected values, ranges and relationships.​



121380​

Active Ingredient Undiluted​

Concentration of the chemically or physically interesting​





Concentration​

(active)ingredientofadrugorcontrastagentasdelivered​







inproductformfromthemanufacturer,typicallyinmg/ml.​



121381​

Contrast/Bolus Ingredient​

X-Ray absorption of the active ingredient of a contrast​





Opaque​

agent ingredient is greater than the absorption of water​







(tissue).​



121382​

Quantity administered​

Number of units of substance administered to a patient.​







E.g., tablets.​



121383​

Mass administered​

Mass of substance administered to a patient.​



- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1279​

Code Value​

Code Meaning​

Definition​

Notes​

121384​

RT Plan Label​

Human readable label of the radiotherapy plan.​



121385​

Current Fraction Number​

The index of the fraction of the radiotherapy plan to be​







delivered.​



121386​ Number of Fractions Planned​ The total number of prescribed radiotherapy fractions.​



121387​

NumberofFractionsCompleted​The number of fully completed radiotherapy fractions of​







theradiotherapyplantobedelivered.Partiallycompleted​







fractions are not included.​



121388​

Checked-In Status​

Whetherornotthepatienthasbeenchecked-in,i.e.,are​







physically present and are waiting to be called in to the​







treatment room.​



121389​

Referenced Beam Number​

The referenced beam number within the radiotherapy​







plan to be delivered.​



121401​

Derivation​

Methodofderivingorcalculatingameasuredvalue.E.g.,​







mean, or maximum of set.​



121402​

Normality​

Assessmentofameasurementrelativetoanormalrange​







of values; may be considered subtype of term​







(363713009, SCT, "has interpretation").​



121403​

Level of Significance​

Significance of a measurement.​



121404​

Selection Status​

Status of selection of a measurement for further​







processing or use.​



121405​

Population description​

Description of a population of measurements.​



121406​

Reference Authority​

Bibliographic or clinical reference for a Description of a​







population of measurements.​



121407​

Normal Range description​

Description of a normal range of values for a​







measurement concept.​



121408​

Normal Range Authority​

Bibliographic or clinical reference for a Description of a​







normal range of values.​



121410​

User chosen value​

Observationvalueselectedbyuserforfurtherprocessing​







or use, or as most representative.​



121411​ Most recent value chosen​

Observationvalueistherecentlyobtained,andhasbeen​







selected for further processing or use.​



121412​

Mean value chosen​

Observationvalueisthemeanofseveralmeasurements,​







and has been selected for further processing or use.​



121414​

Standarddeviationofpopulation​Standard deviation of a measurement in a reference​







population.​



121415​

Percentile Ranking of​

Percentile Ranking of an observation value with respect​





measurement​

a reference population.​



121416​

Z-Score of measurement​

Z-scoreofanobservationvaluewithrespectareference​







population, expressed as the dimensionless quantity​







(x-m) /s, where (x-m) is the deviation of the observation​







value (x) from the population mean (m), and s is the​







standard deviation of the population.​



121417​ 2 Sigma deviation of population​2 Sigma deviation of a measurement in a reference​







population.​



121420​

Equation​

Formula used to compute a derived measurement.​



121421​

Equation Citation​

Bibliographic reference to a formula used to compute a​







derived measurement; reference may be to a specific​







equation in a journal article.​



- Standard -​

Page 1280​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

121422​ Table of Values Citation​

BibliographicreferencetoaTableofValuesusedtolook​





up a derived measurement.​



121423​

Method Citation​

Bibliographic reference to a method used to compute a​





derived measurement.​



121424​

Table of Values​

A Table of Values used to look up a derived​







measurement.​



121425​

Index​

Factor (divisor or multiplicand) for normalizing a​







measurement. E.g., body surface area used for​







normalizing hemodynamic measurements.​



121427​

Estimated​

Measurement obtained by observer estimation, rather​Retired. Replaced by​





than with a measurement tool or by calculation​

(414135002, SCT,​







"Estimated")​

121428​

Calculated​

Measurement obtained by calculation​

Retired. Replaced by​







(258090004, SCT,​







"Calculated")​

121430​

Concern​

Identified issue about a state or process that has the​







potential to require intervention or management.​



121431​

DateTime Concern Noted​

DateTime concern noted (noted by whom is determined​





by context of use).​



121432​

DateTime Concern Resolved​

DateTime the concern was resolved.​



121433​

DateTime Problem Resolved​

DateTime the problem was resolved.​



121434​

Service Delivery Location​

Place at which healthcare services may be provided.​



121435​

Service Performer​

Identification of a healthcare provider who performed a​





healthcare service; may be either a person or an​







organization.​



121436​

Medical Device Used​

Type or identifier of a medical device used on, in, or by​





a patient.​



121437​

Pharmacologic and exercise​

Cardiac stress test using pharmacologic and exercise​ Retired. Replaced by​



stress test​

stressors​

(428813002, SCT,​







"Pharmacologicandexercise​







stress test")​

121438​

Paced stress test​

Cardiacstresstestusinganimplantedorexternalcardiac​Retired. Replaced by​





pacing device​

(428685003, SCT, "Stress​







test using cardiac pacing")​

121439​

Correction of congenital​

Procedure for correction of congenital cardiovascular​

Retired.​



cardiovascular deformity​

deformity​

Replaced by (428613004,​













SCT, "Correction of​







congenital cardiovascular​







deformity")​

121701​

RT Patient Setup​

Process of placing patient in the anticipated treatment​







position,includingspecificationandlocationofpositioning​





aids, and other treatment delivery accessories.​



121702​ RT Patient Position Acquisition,​Acquisition of patient positioning information prior to​ single plane MV​ treatment delivery, using single-plane megavoltage​

imaging.​

121703​ RT Patient Position Acquisition,​Acquisition of patient positioning information prior to​ dual plane MV​ treatment delivery, using dual-plane megavoltage​

imaging.​

- Standard -​

Источник: https://studfile.net/preview/14585769/

Смотрите также:

08_Вероятн произведения событий
1
1 Кариес зубов Задача 1
144969
16.04.20 г. Определение цены и объёма сбыта
16фз
2_5298781932820103487
20. Ступенчатая диссоциация многоосновных кислот и многокислотных оснований
217
26. Гормоны 2
