Page 1286​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

122133​

Lesion Morphology​

Lesion Morphology; form and/or structural properties of​

lesion.​

122134​

Vessel Morphology​

Vessel Morphology; form and/or structural properties of​

vessel.​

122138​

Circulatory Support​

Technique (device or procedure) of support for patient​

circulatory system; hemodynamic support.​

122139​

Reason for Exam​

Reason for Exam.​

122140​ Comparison with Prior Exam​

Indicationthatthecurrentexamdatahasbeencompared​

Done​

with prior exam data.​

122141​

Electrode Placement​

Electrocardiographic electrode placement technique.​

122142​

Acquisition Device Type​

Acquisition Device Type.​

122143​

Acquisition Device ID​

Acquisition Device ID.​

122144​

Quantitative Analysis​

Quantitative Analysis, report section.​

122145​

Qualitative Analysis​

Qualitative Analysis, report section.​

122146​

Procedure DateTime​

The date and time on which a procedure was performed​

on a patient.​

122147​

Clinical Interpretation​

Clinical Interpretation, report section.​

122148​

Lead ID​

ECG Lead Identifier.​

122149​

Beat Number​

Beat Number; ordinal of cardiac cycle within an​

acquisition.​

122150​

Compound Statement​

Complex coded semantic unit, consisting of several​

coded components.​

122151​

Trend​

Trend (temporal progression) of a clinical condition,​

finding, or disease.​

122152​

Statement​

Coded semantic unit.​

122153​

Statement Modifier​

Coded modifier for a semantic unit.​

122154​

Conjunctive Term​

Conjunctive term between semantic units.​

122157​

Probability​

Probability.​

122158​

ECG Global Measurements​

ECG Global Measurements, report section.​

122159​

ECG Lead Measurements​

ECG Lead Measurements, report section.​

122160​

Derived Area, Non-Valve​

Derived cross-sectional area of a vessel or anatomic​

feature, other than a cardiac valve.​

122161​

Pulmonary Flow​

Rate of blood flow through Pulmonary artery.​

122162​

Systemic Flow​

Rate of blood flow through the aorta.​

122163​

Discharge DateTime​

DateTime of patient discharge from hospital admission.​

122164​ Coronary Artery Bypass During​Indication that a Coronary Artery Bypass operation was​

This Admission​

performed during the current hospital admission.​

122165​

DateTime of Death​

DateTime of Death.​

122166​

Death During This Admission​ Indicationthatthepatientdiedduringthecurrenthospital​

admission.​

122167​

Death During Catheterization​

Indication that the patient died during the current​

Catheterization procedure.​

122170​ Type of Myocardial Infarction​

Finding of type of Myocardial Infarction.​

122171​ Coronary lesion > = 50%​

Finding of Coronary lesion with greater than 50%​

stenosis​

stenosis.​

successful​

procedure,wheretheresidualpostinterventionstenosis​

is less than or equal to 50% of the arterial luminal​

diameter, TIMI Flow is 3 and the minimal decrease in​

stenosis was 20%.​

122177​

Procedure Result​

Overall success of interventional procedure.​

122179​

Peri-procedural MI occurred​

Indication that Myocardial Infarction occurred during​

current procedure.​

122180​

CK-MB baseline​

Creatine Kinase-MB value at baseline (start of​

procedure).​

122181​

CK-MB peak​

Creatine Kinase-MB highest value measured during​

procedure.​

122182​

R-R interval​

TimeintervalbetweenECGR-wavepeaksinsubsequent​

cardiac cycles.​

122183​

Blood temperature​

Blood temperature.​

122185​

Blood Oxygen content​

Blood Oxygen content.​

122188​

Pulmonary Arterial Content​

Pulmonary Arterial Content (FCpa).​

(FCpa)​

122189​

Pulmonary Venous Content​

Pulmonary Venous Content (FCpv).​

(FCpv)​

122190​

Max dp/dt/P​

Max dp/dt/P.​

122191​

Ventricular End Diastolic​

Ventricular End Diastolic pressure.​

pressure​

122192​

Indicator appearance time​

Elapsed time from injection of an indicator bolus until it​

is observed at another location.​

122194​

Ventricular Systolic blood​

Ventricular Systolic blood pressure.​

pressure​

122195​

Pulse Strength​

Pulse Strength; palpable strength of systolic flow.​

122196​

C wave pressure​

The secondary peak pressure in the atrium during atrial​

contraction.​

122197​

Gradient pressure, average​

Gradient pressure, average.​

122198​

Gradient pressure, peak​

Gradient pressure, peak.​

122199​ Pressure at dp/dt max​

Pressure at dp/dt max.​

122202​ Diastolic blood velocity, peak​

Diastolic blood velocity, peak.​

122203​ Systolic blood velocity, mean​

Systolic blood velocity, mean.​

122204​ Systolic blood velocity, peak​

Systolic blood velocity, peak.​

Page 1288​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

122205​

Blood velocity, mean​

Blood velocity, mean.​

122206​

Blood velocity, minimum​

Blood velocity, minimum.​

122207​

Blood velocity, peak​

Blood velocity, peak.​

122208​

x-descent pressure​

Venous or atrial pressure minimum during ventricular​

systole, after A-wave.​

122209​

y-descent pressure​

Venous or atrial pressure minimum when tricuspid valve​

opens during diastole, after V-wave.​

122210​

z-point pressure​

Atrialpressureuponclosureoftricuspidandmitralvalves.​

122211​ Left Ventricular ejection time​

Left Ventricular ejection time.​

122212​ Left Ventricular filling time​

Left Ventricular filling time.​

122213​ Right Ventricular ejection time​Right Ventricular ejection time.​

122214​ Right Ventricular filling time​

Right Ventricular filling time.​

122215​

Total Pulmonary Resistance​

Total Pulmonary Resistance.​

122216​

Total Vascular Resistance​

Total Vascular Resistance.​

122217​

Coronary Flow reserve​

Coronary Flow reserve.​

122218​ Diastolic/Systolic velocity ratio​Diastolic/Systolic velocity ratio.​

122219​

Hyperemic ratio​

Hyperemic ratio.​

122220​ HemodynamicResistanceIndex​Hemodynamic Resistance Index.​

122221​

Thorax diameter, sagittal​

Thorax diameter, sagittal.​

122222​

Procedure Environmental​

Environmental characteristics in the procedure room.​

Characteristics​

122223​

Room oxygen concentration​

Oxygen concentration in the procedure room.​

122224​

Room temperature​

Temperature in the procedure room.​

122225​

Room Barometric pressure​

Barometric pressure in the procedure room.​

122227​ Left to Right Flow​

Left to Right Flow.​

122228​ Right to Left Flow​

Right to Left Flow.​

122229​

Arteriovenous difference​

Arteriovenous oxygen content difference.​

122230​ 10 Year CHD Risk​

Framingham Study 10 Year CHD Risk.​

122231​ Comparative Average10 Year​ Framingham Study Comparative Average10 Year CHD​

CHD Risk​

Risk.​

122232​ Comparative Low10 Year CHD​FraminghamStudyComparativeLow10YearCHDRisk.​

Risk​

122233​ LDLCholesterolScoreSheetfor​Framingham Study LDL Cholesterol Score Sheet for​

Men​

Men.​

122234​ LDLCholesterolScoreSheetfor​Framingham Study LDL Cholesterol Score Sheet for​

Women​

Women.​

122235​ Total Cholesterol Score Sheet​Framingham Study Total Cholesterol Score Sheet for​

for Men​

Men.​

122236​ Total Cholesterol Score Sheet​Framingham Study Total Cholesterol Score Sheet for​

for Women​

Women.​

122237​ CorrectedSinusNodeRecovery​Corrected Sinus Node Recovery Time.​

Time​

122238​ Max volume normalized to​

Max volume normalized to 50mmHg pulse pressure.​

50mmHg pulse pressure​

122239​

Oxygen Consumption​

Oxygen Consumption.​

FE02)​

VeSTPD * 10 * (FIO2 - FE02).​

122250​ VO2 = 152 * BSA​

Equation for estimated oxygen consumption: VO2 = 152​

* BSA.​

122251​ VO2 = 175 * BSA​

Equation for estimated oxygen consumption: VO2 = 175​

* BSA.​

122252​ VO2 = 176 * BSA​

Equation for estimated oxygen consumption: VO2 = 176​

* BSA.​

Page 1290​

DICOM PS3.16 2020a - Content Mapping Resource​

Code Value​

Code Meaning​

Definition​

Notes​

122253​

Robertson & Reid table​

Robertson & Reid Table for estimated oxygen​

consumption.​

122254​

Fleisch table​

Fleisch table for estimated oxygen consumption.​

122255​

Boothby table​

Boothby table for estimated oxygen consumption.​

122256​ if(premage<3days)P50=19.9​Estimate of Oxygen partial pressure at 50% saturation​

for premature infants less than 3 days old: P50 = 19.9.​

122257​

if (age < 1day) P50 = 21.6​

Estimate of Oxygen partial pressure at 50% saturation​

for infants less than 1 day old: P50 = 21.6.​

122258​

if (age < 30day) P50 = 24.6​

Estimate of Oxygen partial pressure at 50% saturation​

for infants less than 30 days old: P50 = 24.6.​

122259​

if (age < 18y) P50 = 27.2​

Estimate of Oxygen partial pressure at 50% saturation​

for patients less than 18 years old: P50 = 27.2.​

122260​

if (age < 40y) P50 = 27.4​

Estimate of Oxygen partial pressure at 50% saturation​

for patients less than 40 years old: P50 = 27.4.​

122261​

if (age > 60y) P50 = 29.3​

Estimate of Oxygen partial pressure at 50% saturation​

for patients more than 60 years old: P50 = 29.3.​

122265​ BMI = Wt / Ht ^ 2​

BodyMassIndexcomputedfromweightandheight:BMI​

= Wt/Ht^2.​

122266​

BSA = 0.007358*WT^0.425​

Body Surface Area computed from patient height and​

*HT^0.725​

weight: BSA = 0.007358*WT[kg]^0.425*HT[cm]^0.725​

(for East Asian adult, aged 15+ years) [Kanai Izumi,​

Masamitsu Kanai, 'Clinical examination method​

summary'].​

122267​

BSA = 0.010265*WT^0.423​

Body Surface Area computed from patient height and​

*HT^0.651​

weight: BSA = 0.010265*WT[kg]^0.423*HT[cm]^0.651​

(For East Asian child aged 12-14 years).​

122268​

BSA = 0.008883*WT^0.444​

Body Surface Area computed from patient height and​

*HT^0.663​

weight: BSA = 0.008883*WT[kg]^0.444*HT[cm]^0.663​

(For East Asian child aged 6-11 years).​

122269​

BSA = 0.038189*WT^0.423​

Body Surface Area computed from patient height and​

*HT^0.362​

weight: BSA = 0.038189*WT[kg]^0.423*HT[cm]^0.362​

(For East Asian child aged 1-5 years).​

122270​

BSA = 0.009568*WT^0.473​

Body Surface Area computed from patient height and​

*HT^0.655​

weight: BSA = 0.009568*WT[kg]^0.473*HT[cm]^0.655​

(For East Asian child aged 0-12 months).​

122271​

Skin Condition Warm​

Skin Condition Warm.​

122272​

Skin Condition Cool​

Skin Condition Cool.​

122273​

Skin Condition Cold​

Skin Condition Cold.​

122274​

Skin Condition Dry​

Skin Condition Dry.​

122275​

Skin Condition Clammy​

Skin Condition Clammy.​

122276​

Skin Condition Diaphoretic​

Skin Condition Diaphoretic.​
