- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1301​

Code Value​

Code Meaning​

Definition​

Notes​

122665​ Time interval since injection of​Time interval since injection of contrast media.​





contrast media​





122666​

Time relative to R-wave peak​ Time relative to R-wave peak.​



122667​ Bloodvelocityvs.timeofcardiac​Relationship between blood velocity and time relative to​





cycle​

R-wave peak.​



122668​ Time interval since detection of​Time interval since detection of contrast bolus.​





contrast bolus​





122670​

Papillary Muscle​

Indicatesifthepapillarymusclewasincludedorexcluded​





Included/Excluded​

in the measurement.​



122675​

Anterior-Posterior​

Anterior to Posterior direction.​



122680​

endoleak​

Persistent flow of blood into the stent-grafting.​



122683​

Stent Fracture​

Fracture of a stent.​



122684​

Stent Disintegration​

Disintegration of a stent.​



122685​

Stent Composition​

Material that a stent consists of.​



122686​

Parent Vessel Finding​

Finding about the characteristics of the parent vessel of​







a vessel.​



122687​ Site of Lumen Maximum​

Site of Maximal lumen diameter of a vessel.​



122698​

X-Concept​

The physical domain (time, space, etc.) to the horizontal​







axis of the graphical presentation.​



122699​

Y-Concept​

The physical domain (time, space, etc.) to the vertical​







axis of the graphical presentation.​



122700​ Indications for Pharmacological​Indications for Pharmacological Stress.​





Stress​





122701​

Procedure time base​

Reference time for measurement of elapsed time in a​







procedure.​



122702​

Treadmill speed​

Treadmill speed.​



122703​

Treadmill gradient​

Treadmill gradient.​



122704​

Ergometer power​

Ergometer power.​



122705​ Pharmacological Stress Agent​Pharmacological Stress Agent Dose Rate.​





Dose Rate​





122706​ Rating of Perceived Exertion​

Rating of Perceived Exertion.​



122707​ Number of Ectopic Beats​

Number of ectopic beats during a period of collection.​



122708​

Double Product​

Heart rate times systolic blood pressure.​



122709​

Activity workload​

Physical activity workload (intensity) measurement.​



122710​ Time since start of stage​

Elapsed time at stage.​



122711​

Exercise duration after stress​ Exercise duration after stress agent injection.​





agent injection​





122712​

Imaging Start DateTime​

Imaging Start DateTime.​



122713​ Attenuation correction method​Attenuation correction method.​



122715​ Pharmacological Stress Agent​Pharmacological Stress Agent Dose.​





Dose​





122716​

Maximum Power Output​

Maximum power output achieved during course of​





Achieved​

procedure.​



122717​

Peak activity workload​

Peak physical activity intensity measurement during​







course of procedure.​



Page 1302​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

122718​

Peak Double Product​

Peak Double Product measurement during course of​







procedure.​



122720​

OSEM algorithm​

Orderedsubsetsexpectationmaximizationreconstruction​







algorithm.​



122721​

Chang method​

Chang attenuation correction method.​



122726​

Algorithmic attenuation​

Attenuation correction not based on image-based​





correction​

attenuation maps.​



122727​

NM transmission attenuation​

NM transmission attenuation correction.​





correction​





122728​ CT-basedattenuationcorrection​CT-based attenuation correction.​



122729​

No Attenuation Correction​

No attenuation correction.​



122730​

Bazett QTc Algorithm​

Bazett QT Correction Algorithm; QT/(RR ^ 0.5); Bazett​







HC. "An analysis of the time-relations of​







electrocardiograms" Heart7:353-370 (1920).​



122731​

Hodges QTc Algorithm​

Hodges QT Correction Algorithm; QT + 1.75 (heart​







rate-60); Hodges M, Salerno Q, Erlien D. "Bazett's QT​







correctionreviewed.EvidencethatalinearQTcorrection​







for heart rate is better." J Am Coll Cardiol1:694 (1983).​



122732​

Fridericia QTc Algorithm​

Fridericia QT Correction Algorithm; QT/(RR ^ 0.333);​







Fridericia LS. "The duration of systole in the​







electrocardiogramofnormalsubjectsandofpatientswith​







heart disease" Acta Med Scand53:469-486 (1920).​



122733​

Framingham QTc Algorithm​

Framingham QT Correction Algorithm; QT + 0.154 (1-​







RR); Sagie A, Larson MG, Goldberg RJ, et al. "An​







improved method for adjusting the QT interval for heart​







rate (the Framingham Heart Study)." Am J​







Cardiol70:797-801(1992).​



122734​

Borg RPE Scale​

Borg Rating of Perceived Exertion Scale, range 6:20.​



122735​

Borg CR10 Scale​

Borgcategoryratioscale,openendedrangewithnominal​







range 0:10.​



122739​

Overall study quality​

Overall study quality.​



122740​

Excellent image quality​

Excellent image quality.​



122741​

Good image quality​

Good image quality.​



122742​

Poor image quality​

Poor image quality.​



122743​

Body habitus attenuation​

Image attenuation due to body physique (overweight).​



122744​

Breast attenuation​

Image attenuation due to breast tissue.​



122745​

Diaphragmatic attenuation​

Image attenuation due to diaphragm.​



122748​ False positive defect finding​

Finding of a defect is incorrect. E.g., from automated​







analysis.​



122750​ Non-diagnostic - low heart rate​ECG is non-diagnostic due to low heart rate.​



122751​

Non-diagnostic - resting ST​

ECG is non-diagnostic due to resting ST abnormalities.​





abnormalities​





122752​ Non-diagnostic - ventricular​

ECG is non-diagnostic due to ventricular pacing or Left​





pacing or LBBB​

Bundle Branch Block.​



122753​

Non-diagnostic ECG​

ECG is non-diagnostic for presence of acute coronary​







syndrome.​



122755​

Strongly positive​

Strongly positive finding.​



- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1303​

Code Value​

Code Meaning​

Definition​

Notes​

122756​ Strongly positive - ST elevation​Strongly positive finding - ST elevation.​



122757​

ST Depression - Horizontal​

Finding of ST segment depression with no slope.​



122758​

ST Depression - Upsloping​

Finding of ST segment depression with upslope.​



122759​ ST Depression - Downsloping​Finding of ST segment depression with downslope.​



122760​

Stress test score​

Stress test score.​



122762​ Number of diseased vessel​

Number of diseased vessel territories.​





territories​





122764​ Weightexceedsequipmentlimit​Patient weight exceeds equipment limit.​



122768​ Difference in Ejection Fraction​Difference in Ejection Fraction.​



122769​ Difference in ED LV Volume​

Difference in End Diastolic Left Ventricular Volume.​



122770​

Ratio of achieved to predicted​Ratio of achieved to predicted maximal oxygen​





maximal oxygen consumption​consumption.​



122771​

Ratio of achieved to predicted​Ratio of achieved to predicted functional capacity.​





functional capacity​





122772​

Aerobic index​

Workload (Watts) at target heart rate divided by body​







weight.​



122773​

ST/HR Index​

ST depression at peak exercise divided by the​







exercise-induced increase in heart rate [Kligfield P,​







Ameisen O, Okin PM. "Heart rate adjustment of ST​







segment depression for improved detection of coronary​







artery disease." Circulation 1989;79:245-55.].​



122775​

Agreement with prior findings​ Agreement with prior findings.​



122776​ Disagreementwithpriorfindings​Disagreement with prior findings.​



122781​ Rest thallium/stress technetium​Nuclear Medicine Rest thallium/stress technetium​





procedure​

procedure.​



122782​

Rest technetium/stress​

Nuclear Medicine Rest technetium/stress technetium 1​





technetium 1 day procedure​

day procedure.​



122783​

Rest technetium/stress​

Nuclear Medicine Rest technetium/stress technetium 2​





technetium 2 day procedure​

day procedure.​



122784​

Stress technetium/rest​

Nuclear Medicine Stress technetium/rest technetium 1​





technetium 1 day procedure​

day procedure.​



122785​

NM Myocardial Viability​

Nuclear Medicine Myocardial Viability procedure.​





procedure​





122791​ PETMyocardialPerfusion,Rest​Positron Emission Tomography Perfusion Imaging​





only​

procedure, rest only.​



122792​

PET Myocardial Perfusion,​

Positron Emission Tomography Perfusion Imaging​





Stress only​

procedure, stress only.​



122793​ PETMyocardialPerfusion,Rest​Positron Emission Tomography Perfusion Imaging​





and Stress​

procedure, rest and stress.​



122795​ PET Myocardial Viability, Rest​Positron Emission Tomography Myocardial Viability​





only​

procedure, rest only.​



122796​ PETMyocardialViability,Stress​Positron Emission Tomography Myocardial Viability​





only​

procedure, stress only.​



122797​ PET Myocardial Viability, Rest​Positron Emission Tomography Myocardial Viability​





and Stress​

procedure, rest and stress.​



- Standard -​

Page 1304​

DICOM PS3.16 2020a - Content Mapping Resource​



Code Value​

Code Meaning​

Definition​

Notes​

122799​

Anginal Equivalent​

Group of symptoms heralding angina pectoris that does​







not include chest pain (dyspnea, diaphoresis, profuse​







vomiting in a diabetic patient, or arm or jaw pain).​



123001​

Radiopharmaceutical​

Activeingredient(molecular)usedforradioactivetracing.​Retired.​







Replaced by (349358000,​





SCT, "Radiopharmaceutical​





agent").​

123003​

Radiopharmaceutical Start​

DateTime of radiopharmaceutical administration to the​



DateTime​

patient for imaging purposes.​

123004​

Radiopharmaceutical Stop​

Ending DateTime of radiopharmaceutical administration​



DateTime​

to the patient for imaging purposes.​

123005​ Radiopharmaceutical Volume​ Volume of radiopharmaceutical administered to the​





patient.​

123006​

Radionuclide Total Dose​

Total amount of radionuclide administered to the patient​





at Radiopharmaceutical Start Time.​

123007​ Radiopharmaceutical Specific​ Activity per unit mass of the radiopharmaceutical at​



Activity​

Radiopharmaceutical Start Time.​

123009​

Radionuclide Syringe Counts​

Pre-injection syringe acquisition count rate.​

123010​ Radionuclide Residual Syringe​Syringeacquisitioncountratefollowingpatientinjection.​



Counts​



123011​

Contrast/Bolus Agent​

Contrast or bolus agent.​

123012​

Pre-Medication​

Medication to be administered at the beginning of the​





Scheduled Procedure Step.​

123014​

Target Region​

Anatomic Region to be imaged.​

123015​

Imaging Direction​

Direction of imaging (includes view, transducer​





orientation, patient orientation, and/or projection).​

123016​

Imaging Conditions​

Imaging condition for refinement of protocol (includes​





secondary posture, instruction, X-Ray / electron beam​





energy or nuclide, and ultrasound modes), as used in​





JJ1017 v3.0.​

123019​

Caudal 10 degree​

Caudal 10 degree distal-cranioproximal oblique​



distal-cranioproximal oblique​

radiographic projection, defined per Smallwood et al.​

123101​

Neighborhood Analysis​

Surfaceprocessingutilizingpredefinedweightingfactors​





(i.e., kernels) applied to different data values depending​





on their location relative to other data values within the​





data domain. Includes Low Pass, High Pass, Gaussian,​





Laplacian, etc.​

123102​

Adaptive Filtering​

Surfaceprocessingappliednon-uniformlyutilizingapriori​





knowledge of the system and/or relative locations of the​





data values within the data domain. Example:​





Neighborhood analysis where weighting factors are​





modified continuously based on predefined criteria.​

123103​

Edge Detection​

Surface processing through the exploitation of​





discontinuities in the data values within their domain.​





Includes Gradient filters.​

123104​

Morphological Operations​

Surface processing based on the connectivity of values​





basedontheshapeorstructureofthedatavalueswithin​





their domain. Includes erode, dilate, etc.​

- Standard -​



DICOM PS3.16 2020a - Content Mapping Resource​

Page 1305​

Code Value​

Code Meaning​

Definition​

Notes​

123105​

Histogram Analysis​

Surfaceprocessingappliedtothedistributionofthedata​







values. Includes thresholding, Bayesian Classification,​







etc.​



123106​ Multi-Scale/Resolution Filtering​Surface processing accomplished through varying the​







data domain size. Include deformable models.​



123107​

Cluster Analysis​

Surface processing accomplished by combining data​







valuesbasedontheirrelativelocationwithintheirdomain​







or value distribution. Includes K- and C-means, Fuzzy​







Analysis, Watershed, Seed Growing, etc.​



123108​

Multispectral Processing​

Surface processing accomplished through the weighted​







combination of multiple sets of data. Includes Principle​







Component Analysis, linear and non-linear weighed​







combinations, etc.​



123109​

Manual Processing​

Surface processing accomplished through human​







interaction. Region drawing.​



123110​

Artificial Intelligence​

Surface processing using Artificial Intelligence​







techniques,suchasMachineLearning,NeuralNetworks,​







etc.​



123111​

Deformable Models​

SurfaceprocessingusingDeformableModeltechniques,​







such as Point Distribution Models, Level Sets, Simplex​







Meshes, etc.​



125000​ OB-GYN Ultrasound Procedure​Document Title of OB-GYN procedure report.​





Report​





125001​

Fetal Biometry Ratios​

Reportsectionforassessmentoffetalgrowthusingratios​







and indexes.​



125002​

Fetal Biometry​

Report section for assessment of fetal growth.​



125003​

Fetal Long Bones​

Report section for assessment of fetal growth by long​







bone measurements.​



125004​

Fetal Cranium​

Report section for assessment of fetal cranium growth.​



125005​

Biometry Group​

Biometric assessment of.​



125006​

Biophysical Profile​

Report section for assessment of biophysical​







observations that evaluate fetal well-being according to​







Manning, Antepartum Fetal Evaluation: Development of​







aFetalBiophysicalProfileScore,Am.JObstetGynecol,​







1980;136:787.​



125007​

Measurement Group​

A grouping of related measurements and calculations​







that share a common context.​



125008​

Fetus Summary​

Report section for fetus specific procedure summary​







observations.​



125009​

Early Gestation​

Report section for assessment of early gestation fetus.​



125010​

Identifier​

A name to differentiate between multiple instances of​







some item.​



125011​

Pelvis and Uterus​

Report section for assessment of pelvis and uterus.​



125012​

Growth Percentile rank​

The rank of a measured growth indicator relative to a​







normal distribution expressed as a percentage.​



125013​

Growth Z-score​

The rank of a measured growth indicator relative to a​







normal distribution expressed as the dimensionless​







quantity z = (x-m) /s where (x-m) is the deviation of the​







value x, from the distribution mean, m, and s is the​







standard deviation of the distribution.​



- Standard -​

Источник: https://studfile.net/preview/14585769/

Смотрите также:

08_Вероятн произведения событий
1
1 Кариес зубов Задача 1
144969
16.04.20 г. Определение цены и объёма сбыта
16фз
2_5298781932820103487
20. Ступенчатая диссоциация многоосновных кислот и многокислотных оснований
217
26. Гормоны 2
