DICOM PS3.16 2020a - Content Mapping Resource​

Page 1291​

Code Value​

Code Meaning​

Definition​

Notes​

122277​

Skin Condition Flush​

Skin Condition Flush.​

122278​

Skin Condition Mottled​

Skin Condition Mottled.​

122279​

Skin Condition Pale​

Skin Condition Pale.​

122281​

Airway unobstructed​

Airway unobstructed.​

122282​

Airway partially obstructed​

Airway partially obstructed.​

122283​

Airway severely obstructed​

Airway severely obstructed.​

122288​

Not Visualized​

Anatomy could not be visualized for the purpose of​

evaluation.​

122291​

Quantitative Arteriography​

Quantitative Arteriography Report.​

Report​

122292​ Quantitative Ventriculography​ Quantitative Ventriculography Report.​

Report​

122301​

Guidewire crossing lesion​

Guidewire crossing lesion unsuccessful.​

unsuccessful​

122302​

Guidewire crossing lesion​

Guidewire crossing lesion successful.​

successful​

122303​

Angioplasty balloon inflated​

Angioplasty balloon inflated.​

122304​

Angioplasty balloon deflated​

Angioplasty balloon deflated.​

122305​

Device deployed​

Device deployed.​

122306​

Stent re-expanded​

Stent re-expanded.​

122307​

Object removed​

Object removed.​

122308​

Radiation applied​

Radiation applied.​

122309​

Radiation removed​

Radiation removed.​

122310​ Interventionaldeviceplacement​Interventional device placement unsuccessful.​

unsuccessful​

122311​

Interventional device placed​

Interventional device placed.​

122312​

Intervention performed​

Intervention performed.​

122313​ Interventional device withdrawn​Interventional device withdrawn.​

122319​

Catheter Size​

Catheter Size.​

122320​

Injectate Temperature​

Injectate Temperature.​

122321​

Injectate Volume​

Injectate Volume.​

122322​

Calibration Factor​

Factor by which a measured or calculated value is​

multiplied to obtain the estimated real-world value.​

122325​

IVUS Report​

Intravascular Ultrasound Report.​

122330​

EEM Diameter​

External Elastic Membrane (EEM) diameter measured​

through the center point of the vessel. Center point of​

the vessel is defined as the center of gravity of the EEM​

area. The EEM is a discrete interface at the border​

between the media and the adventitia.​

122331​ Plaque Plus Media Thickness​ The distance from intimal leading edge to the external​

elastic membrane along any line passing through the​

luminal center, which is defined as the center of gravity​

of the lumen area.​

122332​

Lumen Perimeter​

Planimetered perimeter of the lumen.​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1293​

Code Value​

Code Meaning​

Definition​

Notes​

122351​

Stent Diameter Ratio​

Stent diameter ratio = Minimum stent diameter /​

Maximum stent diameter, measured at the same cross​

section in the vessel. Stent diameters are measured​

through the center point of the stent, which is defined as​

the center of gravity of the stent area.​

122352​

EEM Diameter Ratio​

EEMdiameterratio=minimumEEMdiameter/maximum​

EEM diameter. Measured at the same cross section in​

the vessel.​

122354​

Plaque Burden​

Fractional area within the External Elastic Membrane​

(EEM) occupied by atheroma. Plaque Burden = (EEM​

area - vessel lumen cross-sectional area) / EEM area.​

122355​

Arc of Calcium​

AngularmeasurementofaCalciumdepositwiththeapex​

located at the center of the lumen, which is defined as​

the center of gravity of the lumen area.​

122356​

Soft plaque​

Plaque characterized by low density or echogenicity.​

122357​

In-Stent Neointima​

Abnormal thickening of the intima within the stented​

segment.​

122360​

True Lumen​

Lumen surrounded by all three layers of the​

vessel-intima, media, and adventitia.​

122361​

False Lumen​

Achannel,usuallyparalleltothetruelumen,whichdoes​

not communicate with the true lumen over a portion of​

its length.​

122363​

Plaque Rupture​

Plaque ulceration with a tear detected in a fibrous cap.​

122364​

Stent Gap​

Length of gap between two consecutive stents.​

122367​

T-1 Worst​

Worst stenosis - the stenosis with the smallest lumen​

size within a vessel segment.​

122368​

T-2 Secondary​

2nd most severe stenosis within a vessel segment.​

122369​

T-3 Secondary​

3rd most severe stenosis within a vessel segment.​

122370​

T-4 Secondary​

4th most severe stenosis within a vessel segment.​

122371​

EEM Volume​

External Elastic Membrane (EEM) volume measured​

withinaspecifiedregion.TheEEMisadiscreteinterface​

at the border between the media and the Adventitia.​

122372​

Lumen Volume​

Lumen volume measured within a specified region.​

122374​

In-Stent Neointimal Volume​

The amount of plaque between the lumen and stent,​

within the stent region; In-stent restenosis. In-Stent​

Neointimal Volume = Stent Volume - Lumen Volume.​

122375​

Native Plaque Volume​

The amount of plaque between the stent and the EEM,​

within the stent region. Native Plaque Volume = EEM​

Volume - Stent Volume.​

122376​

Total Plaque Volume​

TotalamountofplaquebetweentheEEMandtheLumen,​

over the entire region that is measured. Total Plaque​

Volume = EEM Volume - Lumen Volume.​

122380​

Proximal Reference​

Proximalreferencesegmentmeasurementsite.Typically​

the site with the largest lumen proximal to a stenosis but​

within the same segment (usually within 10 mm of the​

stenosis with no major intervening branches).​

122381​

Distal Reference​

Distal reference segment measurement site. Typically​

the site with the largest lumen distal to a stenosis but​

within the same segment (usually within 10 mm of the​

stenosis with no major intervening branches).​

DICOM PS3.16 2020a - Content Mapping Resource​

Page 1295​

Code Value​

Code Meaning​

Definition​

Notes​

122403​

For Attenuation Correction​

The referenced information was used to correct the data​

for differential attenuation through different anatomic​

tissue.​

122404​

Reconstructed​

Valueestimatedforavesselintheabsenceofastenosis.​

122405​

Algorithm Manufacturer​

Manufacturer of application used.​

122406​ Left Atrial Ejection Fraction by​Left Atrial Ejection Fraction by Angiography.​

Angiography​

122407​

Left Atrial ED Volume​

Left Atrial End Diastolic Volume.​

122408​

Left Atrial ES Volume​

Left Atrial End Systolic Volume.​

122410​

Contour Realignment​

Contour repositioning of End Diastolic relative to End​

Systolic contour.​

122411​

Threshold Value​

The minimum standard deviation to define the​

hypokinesis and hyperkinesis.​

122417​ Regional Abnormal Wall Motion​Report of differentiation of wall motion compared to​

normal.​

122421​

Calibration Object​

Object used for Calibration.​

122422​

Calibration Method​

Method used for Calibration.​

122423​

Calibration Object Size​

Size of calibration object.​

122428​

Area Length Method​

Method how long axis is positioned.​

122429​

Volume Method​

Model for cardiac chamber volume calculation.​

122430​

Reference Method​

Method to define original diameter of the artery.​

122431​

Regression Slope ED​

Relation between calculated End Diastolic volume and​

ventricular End Diastolic volume. The specific meaning​

is dependent on volume method used.​

122432​

Regression Offset ED​

CorrectionfactorforthecalculatedEndDiastolicvolume​

and ventricular End Diastolic volume. The specific​

meaning is dependent on volume method used.​

122433​

Regression Slope ES​

Relation between calculated End Systolic volume and​

ventricular End Systolic volume. The specific meaning​

is dependent on volume method used.​

122434​

Regression Offset ES​

Correction factor for the calculated End Systolic volume​

and ventricular End Systolic volume. The specific​

meaning is dependent on volume method used.​

122435​ Regression Volume Exponent​Exponent of volume in regression formula.​

122438​

Reference Points​

Container for spatial locations or coordinates used for​

calculation.​

122445​

Wall Thickness​

Average thickness of the chamber wall in the current​

view.​

122446​

Wall Volume​

Volume of the chamber wall estimated from the current​

view.​

122447​

Wall Mass​

Mass of the chamber wall (myocardium).​

122448​

Wall Stress​

Peak systolic stress of chamber wall.​
