DICOM PS3.16 2020a - Content Mapping Resource​

Page 451​

TID 10021



TID 10022



TID 1002



Radiopharmaceutical





Radiopharmaceutical





Observer Context



Radiation Dose



Administration Event













TID 10024



TID 10023









Imaging Agent



Organ Dose









Administration























Patient Characteristics



















TID 1020















Person Participant

















Figure A-17. Radiopharmaceutical Radiation Dose SR IOD Template Structure​

TID 10021 Radiopharmaceutical Radiation Dose​

This Template defines a container (the root) with subsidiary Content Items, each of which corresponds to a single Radiopharmaceut-​ ical Administration Dose event entry. There is a defined recording observer (the system and/or person responsible for recording the​ assay of the radiopharmaceutical, and the person administered the radiopharmaceutical). Multiple Radiopharmaceutical Radiation​ Dose objects may be created for one study. Radiopharmaceutical Start DateTime in TID 10022 “Radiopharmaceutical Administration​ Event Data” will convey the order of administrations.​

Type:​

Extensible​

Order:​

Significant​

Root:​

Yes​

Table TID 10021. Radiopharmaceutical Radiation Dose​



NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​ Value Set​















Type​

Constraint​

1​





CONTAINER​EV (113500, DCM,​

1​

M​

Root node​











"Radiopharmaceutical Radiation​

















Dose Report")​







1b​

>​

HAS CONCEPT​ INCLUDE​

DTID 1204 “Language of Content​

1​

U​







MOD​





Item and Descendants”​







2​

>​

HAS CONCEPT​ CODE​

EV(363589002,SCT,"Associated​

1​

M​

DCID 3108​





MOD​





Procedure")​





“NM/PET​

















Procedures”​

3​

>>​

HAS CONCEPT​ CODE​

EV (363703001, SCT, "Has​

1​

M​

DCID 3629​





MOD​





Intent")​





“Procedure​

















Intent”​

4​

>​

CONTAINS​

INCLUDE​

DTID10022“Radiopharmaceutical​

1​

M​













Administration Event Data”​







5​

>​

CONTAINS​

INCLUDE​

DTID 10024 “Imaging Agent​

1​

U​













Administration Patient​

















Characteristics”​







6​

>​

CONTAINS​

TEXT​

EV (121106, DCM, "Comment")​

1​

U​



Content Item Descriptions​

Row 2​

The associated procedure is the procedure performed, or if no procedure was performed the procedure​



that was ordered.​

TID 10022 Radiopharmaceutical Administration Event Data​

The Radiopharmaceutical Administration Event conveys the dose and assay and time information of a single radiopharmaceutical​ event. A Radiopharmaceutical Administration event is one radioactive pharmaceutical administered to a patient.​

Type:​

Extensible​

Order:​

Significant​

- Standard -​

Page 452​

DICOM PS3.16 2020a - Content Mapping Resource​

Root:​

No​







Table TID 10022. Radiopharmaceutical Administration Event Data​

NL​ Rel with​

VT​

Concept Name​

VM​

Req​ Condition​ Value Set Constraint​

Parent​







Type​

1​

CONTAINER​EV (113502, DCM,​

1​

M​





"Radiopharmaceutical​









Administration")​





2​

>​

CONTAINS​

CODE​

EV (349358000, SCT,​

1​

M​









"Radiopharmaceutical​













agent")​





3​

>>​

HAS​

CODE​

EV (89457008, SCT,​

1​

M​





PROPERTIES​

"Radionuclide")​





4​

>>​

HAS​

NUM​

EV (304283002, SCT,​

1​

M​





PROPERTIES​

"Radionuclide Half Life")​





5​

>​

CONTAINS​

NUM​

EV (123007, DCM,​

1​

U​









"Radiopharmaceutical​













Specific Activity")​





6​

>​

CONTAINS​

UIDREF​

EV (113503, DCM,​

1​

M​









"Radiopharmaceutical​













Administration Event UID")​





7​

>​

CONTAINS​

CODE​

EV (113505, DCM,​

1-n​

U​









"Intravenous Extravasation​













Symptoms")​





8​

>​

CONTAINS​

NUM​

EV (113506, DCM,​

1​

U​









"Estimated Extravasation​













Activity")​





9​

>​

CONTAINS​

DATETIME​ EV (123003, DCM,​

1​

M​









"Radiopharmaceutical Start​













DateTime")​





10​

>​

CONTAINS​

DATETIME​ EV (123004, DCM,​

1​

U​









"Radiopharmaceutical Stop​













DateTime")​





11​

>​

CONTAINS​

NUM​

EV (113507, DCM,​

1​

M​









"Administered activity")​





12​

>​

CONTAINS​

NUM​

EV (123005, DCM,​

1​

U​









"Radiopharmaceutical​













Volume")​





13​

>​

CONTAINS​

NUM​

EV (113508, DCM,​

1​

U​









"Pre-Administration​













Measured Activity")​





14​

>>​

HAS OBS​

CODE​

EV (113540, DCM, "Activity​

1​

U​





CONTEXT​



Measurement Device")​





15​

>>​

HAS OBS​

INCLUDE​

DTID 1002 “Observer​

1-n​

U​





CONTEXT​



Context”​





DCID 25​ “Radiopharmaceuticals”​

DCID 4021 “PET​

Radiopharmaceutical”​

DCID 18 “Isotopes in​ Radiopharmaceuticals”​

DCID 4020 “PET​

Radionuclide”​

UNITS = EV (s, UCUM,​ "seconds")​

UNITS = EV (Bq/mmol,​

UCUM, "Bq/mmol")​

DCID 10043​ “Intravenous​ Extravasation​ Symptoms”​

UNITS = EV(%, UCUM,​ "percent")​

UNITS = EV (MBq,​

UCUM, "MBq")​

UNITS = EV (cm3,​

UCUM, "cm3")​

UNITS = EV (MBq,​

UCUM, "MBq")​

DCID 10041 “Source of​ Radioisotope Activity​ Information”​

- Standard -​







DICOM PS3.16 2020a - Content Mapping Resource​

Page 453​



NL​

Rel with​

VT​

Concept Name​

VM​

Req​ Condition​

Value Set Constraint​





Parent​







Type​



16​

>​

CONTAINS​

NUM​

EV (113509, DCM,​

1​

U​

UNITS = EV (MBq,​









"Post-Administration​





UCUM, "MBq")​









Measured Activity")​







17​

>>​

HAS OBS​

CODE​

EV (113540, DCM, "Activity​

1​

U​

DCID 10041 “Source of​





CONTEXT​



Measurement Device")​





Radioisotope Activity​















Information”​

18​

>>​

HAS OBS​

INCLUDE​

DTID 1002 “Observer​

1-n​

U​







CONTEXT​



Context”​







19​

>​

CONTAINS​

INCLUDE​

DTID 10023 “Organ Dose”​

1-n​

U​



20​

>​

CONTAINS​

CODE​

EV(410675002,SCT,"Route​ 1​

M​

BCID 11 “Route of​









of administration")​





Administration”​

21​

>>​

HAS​

CODE​

EV (272737002, SCT, "Site​

1​

MC​IF Row 20​

DCID 3746​





PROPERTIES​

of")​



equals​

“Percutaneous Entry​













(47625008,​

Site”​













SCT,​















"Intravenous​















route") or​















(78421000,​















SCT,​















"Intramuscular​













route")​



22​

>>>​ HAS​

CODE​

EV (272741003, SCT,​

1​

MC​IF Row 21 has​DCID 244 “Laterality”​





CONCEPT​



"Laterality")​



laterality​







MOD​











23​

>​

CONTAINS​

INCLUDE​

DTID 1020 “Person​

1-n​

M​

$PersonProcedureRole​









Participant”​





= EV (113851, DCM,​















"Irradiation​















Administering")​

24​

>​

CONTAINS​

CODE​

EV (121147, DCM, "Billing​

1-n​

U​











Code(s) ")​







25​

>​

CONTAINS​

CODE​

EV (113510, DCM, "Drug​

1-n​

U​











Product Identifier")​







26​

>​

CONTAINS​

TEXT​

EV (111529, DCM, "Brand​

1​

U​











Name")​







27​

>​

CONTAINS​

TEXT​

EV (113511, DCM,​

1​

U​











"Radiopharmaceutical​















Dispense Unit Identifier")​







28​

>>​

CONTAINS​

TEXT​

EV (113512, DCM,​

1-n​

U​











"Radiopharmaceutical Lot​















Identifier")​







29​

>>​

CONTAINS​

TEXT​

EV(113513,DCM,"Reagent​1-n​

U​











Vial Identifier")​







30​

>>​

CONTAINS​

TEXT​

EV (113514, DCM,​

1-n​

U​











"Radionuclide Identifier")​







31​

>​

CONTAINS​

TEXT​

EV (113516, DCM,​

1​

U​











"Prescription Identifier")​







32​

>​

CONTAINS​

TEXT​

EV (121106, DCM,​

1​

U​











"Comment")​







Content Item Descriptions​

- Standard -​

Page 454​





DICOM PS3.16 2020a - Content Mapping Resource​



Row 4​

The value of Half-life that was used for computing the decay of the administered radiopharmaceutical. It​





is not intended for use by the receiver for any further computation.​



Row 5​

Activity per unit mass of the radiopharmaceutical at Radiopharmaceutical Start Time​

Row 6​

Unique identification of a single radiopharmaceutical administration event.​



Row 8​

The estimated percentage of administered activity lost at the injection site. The estimation includes​





extravasation, paravenous administration and leakage at the injection site.​



Row 9​

The time the radiopharmaceutical was administered to the patient for imaging purposes.​

Row 11​

TotalamountofradioactivityadministeredtothepatientatRadiopharmaceuticalStartTime.Itisacomputed​





field from the TID 10022 Pre-Administration Measured Activity Row 13, TID 10022 Post-Administration​





Measured Activity Row 17, Radionuclide Half Life Row 4 and Radiopharmaceutical Start Time Row 9.​





Does not include estimated extravasation activity.​







Rows 13, 16​

Observation DateTime (0040,A032) shall be used to record when the measurement was taken.​

Row 23​

Identifies the person administering the product.​







Row 24​

The billing codes for the preparation and administration of the radiopharmaceutical. It does not include​





performance and interpretation of the imaging.​







Row 25​

Registered drug establishment code for the product. A coding scheme example is NDC, WHO-DDE or​





RxNorm. Multiple entries can be used for equivalent drug product codes.​



Row 27​

The human readable identification of the specific radiopharmaceutical quantity (dose) administered to the​





patient.​











Row 28​

Identifies the vial, batch or lot number from which the individual radiopharmaceutical quantity (dose) was​





produced. Row 27 the Radiopharmaceutical Identifier records the identification for each individual dose.​

Row 29​

Identifies the lot or unit serial number for the reagent component for the radiopharmaceutical identified in​





row 27.​











Row 30​

Identifiesthelotorunitserialnumberfortheradionuclidecomponentfortheradiopharmaceuticalidentified​





in row 27.​











TID 10023 Organ Dose​











This Template conveys the information about the dose to a single organ.​







Type:​



Extensible​









Order:​



Significant​









Root:​



No​

















Table TID 10023. Organ Dose​







NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​ Condition​Value Set Constraint​















Type​



1​





CONTAINER​EV (113517, DCM, "Organ​

1​

M​













Dose Information")​







2​

>​

HAS CONCEPT​ CODE​

EV (363698007, SCT,​

1​

M​

DCID 10044​





MOD​





"Finding Site")​





“Radiosensitive​

















Organs”​

3​

>​

HAS CONCEPT​ CODE​

EV (272741003, SCT,​

1​

MC​ IFF​

DCID 244 “Laterality”​





MOD​





"Laterality")​



anatomy​

















has​

















laterality​



4​

>​

CONTAINS​

NUM​

EV (118538004, SCT,​

1​

U​

UNITS = EV (g,​











"Mass")​





UCUM, "grams")​

5​

>>​

HAS CONCEPT​ TEXT​

EV (370129005, SCT,​

1​

M​







MOD​





"Measurement Method")​







- Standard -​









DICOM PS3.16 2020a - Content Mapping Resource​

Page 455​



NL​

Rel with Parent​

VT​

Concept Name​

VM​

Req​

Condition​Value Set Constraint​















Type​



6​

>​

CONTAINS​

NUM​

EV (113518, DCM, "Organ​

1​

M​

UNITS = EV (mGy,​











Dose")​





UCUM, "mGy")​

7​

>>​

HAS​

CODE​

EV (121406, DCM,​

1​

MC​ XORRow8​BCID 10040​





PROPERTIES​





"Reference Authority")​





“Radiopharmaceutical​

















OrganDoseReference​

















Authority”​

8​

>>​

HAS​

TEXT​

EV (121406, DCM,​

1​

MC​ XORRow7​





PROPERTIES​





"Reference Authority")​







Content Item Descriptions​













Row 3​

For paired organs, use (51440002, SCT, "Bilateral") to report the estimated absorbed dose for both​





organs.​











Row 4​

The estimated mass of organ in grams used when calculating the organ dose.​

Row 5​

Method used to obtain the estimate. This could include a method that does not involve performing a​





measurement (e.g., Standard Organ Mass Tables).​





Row 6​

Organ dose (in units of mGy). Organ is specified by row 2.​



TID 10024 Imaging Agent Administration Patient Characteristics​

This Template describes the characteristics of the patient that are specific to the current clinical presentation (visit). In the case of​ radiopharmaceuticals, the characteristics noted may affect the activity received, and how dose is calculated for the patient. Patient​ Characteristic concepts in this Template, which may replicate attributes in the Patient Study Module, are included here as possible​ targets of by-reference relationships from other Content Items in the SR tree.​

Type:​

Extensible​

Order:​

Significant​

Root:​

No​

Table TID 10024. Imaging Agent Administration Patient Characteristics​



NL​ Rel with Parent​ VT​

Concept Name​

VM​

Req​Condition​ Value Set Constraint​













Type​



1​





CONTAINER​EV (121118, DCM, "Patient​















Characteristics")​







2​

>​

CONTAINS​

CODE​

EV (109054, DCM, "Patient​ 1-n​

U​

DCID 10045​









state")​





“Radiopharmaceutical​















Patient State”​















DCID 64 “Imaging Agent​















Administration Patient​















State”​

3​

>​

CONTAINS​

NUM​

EV (121033, DCM, "Subject​ 1​

U​

UNITS = DCID 7456 “Units​









Age")​





of Measure for Age”​

4​

>​

CONTAINS​

CODE​

EV (121032, DCM, "Subject​ 1​

U​

DCID 7455 “Sex”​









Sex")​







5​

>​

CONTAINS​

NUM​

EV (8302-2, LN, "Patient​

1​

U​

UNITS = EV (cm, UCUM,​









Height")​





"cm")​

6​

>​

CONTAINS​

NUM​

EV (29463-7, LN, "Patient​

1​

U​

UNITS = EV (kg, UCUM,​









Weight")​





"kg").​

7​

>​

CONTAINS​

NUM​

EV (8277-6, LN, "Body​

1​

U​

UNITS = EV (m2, UCUM,​









Surface Area")​





"m^2")​

- Standard -​

Источник: https://studfile.net/preview/14585769/

Смотрите также:

08_Вероятн произведения событий
1
1 Кариес зубов Задача 1
144969
16.04.20 г. Определение цены и объёма сбыта
16фз
2_5298781932820103487
20. Ступенчатая диссоциация многоосновных кислот и многокислотных оснований
217
26. Гормоны 2
