DICOM PS3.17 2020a - Explanatory Information​

Page 651​

Attribute Name​

>Target Minimum Luminance​

>Target Maximum Luminance​

>Reflected Ambient Light​

>Ambient Light Value Source​

>Item Delimiter of Item #2 of Target​

Luminance Characteristics Sequence​

>Item#3ofTargetLuminanceCharacteristics​ Sequence​

>Luminance Characteristics ID​

>Display Function Type​

>Target Minimum Luminance​

>Target Maximum Luminance​

>Reflected Ambient Light​ >Ambient Light Value Source​

>Item Delimiter of Item #3 of Target​

Luminance Characteristics Sequence​

>Sequence Delimiter of Target Luminance​

Characteristics Sequence​

See Table PPP.3.1-2.​

Tag​

N-GET​

N-GET Response (SCP)​



Request​



(SCU)​



(0028,701D)​

-​

0.75​

(0028,701E)​

-​

521.0​

(2010,0160)​

-​

0.410​

(0028,7025)​

-​

DEFAULT​

(FFFE,E00D)​

-​



(FFFE,E000)​

-​



(0028,7009)​

-​

3​

(0028,7019)​

-​

GSDF​

(0028,701D)​

-​

0.75​

(0028,701E)​

-​

520.0​

(2010,0160)​

-​

0.410​

(0028,7025)​

-​

DEFAULT​

(FFFE,E00D)​

-​



(FFFE,E0DD)​

-​



QA Result Module​

This example is encoded with Undefined Sequence Length and Undefined Item Length , so it contains Sequence Delimitation Items​ and Item Delimitation Items.​

Table PPP.3.1-2. Example of N-GET Request/Response for QA Result Module​

Attribute Name​

Tag​

N-GET​

N-GET Response (SCP)​





Request​





(SCU)​





QA Result Module​





QA Results Sequence​

(0028,700F)​

VNP​



>Item #1 of QA Results Sequence​

(FFFE,E000)​

-​



>Display Subsystem ID​

(0028,7003)​

-​

2​

>Display Subsystem QA Results Sequence​

(0028,7010)​

-​



>>Item #1 of Display System QA Results Sequence​

(FFFE,E000)​

-​



>>Configuration ID​

(0028,700B)​

-​

1​

>>Configuration QA Results Sequence​

(0028,7011)​

-​



>>>Item #1 of Configuration QA Results Sequence​

(FFFE,E000)​

-​



>>>Display Calibration Result Sequence​

(0028,7016)​

-​



>>>>Item #1 of Display Calibration Result Sequence​



-​



>>>>Performed Procedure Step Start DateTime​

(0040,4050)​

-​

20130610191010​

>>>>Performed Procedure Step End DateTime​

(0040,4051)​

-​

20130610192030​

>>>>Actual Human Performer Sequence​

(0040,4035)​

-​



>>>>Item #1 of Actual Human Performer Sequence​

(FFFE,E000)​

-​



- Standard -​

Page 652​

DICOM PS3.17 2020a - Explanatory Information​



Attribute Name​



Tag​

N-GET​

N-GET Response (SCP)​







Request​







(SCU)​



>>>>>Human Performer's Name​



(0040,4037)​

-​

Kido^Kousei​

>>>>>Human Performer's Organization​

(0040,4036)​

-​

QA Dept.​

>>>>> Item Delimiter of Item #1 of Actual Human​

(FFFE,E00D)​

-​



Performer Sequence​









>>>>>SequenceDelimiterofActualHumanPerformer​

(FFFE,E0DD)​

-​



Sequence​









>>>>Measurement Equipment Sequence​

(0028,7012)​

-​



>>>>>Item #1 of Measurement Equipment Sequence​

(FFFE,E000)​

-​



>>>>>Measurement Functions​



(0028,7013)​

-​

PHOTOMETER​

>>>>>Measured Characteristics​



(0028,7026)​

-​

LUMINANCE​

>>>>>Measurement Equipment Type​



(0028,7014)​

-​

NEAR_RANGE​

>>>>>Manufacturer​



(0008,0070)​

-​

LUXDEVICE COMPANY​

>>>>>Manufacturer's Model Name​



(0008,1090)​

-​

PHOTOMETER MODEL1​

>>>>>Device Serial Number​



(0018,1000)​

-​

PM1-141421356​

>>>>>DateTime of Last Calibration​



(0018,1202)​

-​

201303310900​

>>>>> Item Delimiter of Item #1 of Measurement​

(FFFE,E00D)​

-​



Equipment Sequence​









>>>>>SequenceDelimiterofMeasurementEquipment​

(FFFE,E0DD)​

-​



Sequence​









>>>>Luminance Characteristics ID​



(0028,7009)​

-​

2​

>>>>Item #1 of Display Calibration Result Sequence​

(FFFE,E00D)​

-​



>>>>SequenceDelimiterofDisplayCalibrationResult​

(FFFE,E0DD)​

-​



Sequence​









>>>Visual Evaluation Result Sequence​

(0028,7015)​

-​



>>>>Item #1 of Visual Evaluation Result Sequence​

(FFFE,E000)​

-​



>>>>Performed Procedure Step Start DateTime​

(0040,4050)​

-​

201307150900​

>>>>Performed Procedure Step End DateTime​

(0040,4051)​

-​

201307150910​

>>>>Actual Human Performer Sequence​

(0040,4035)​

-​



>>>>Item #1 of Actual Human Performer Sequence​

(FFFE,E000)​

-​



>>>>>Human Performer's Name​



(0040,4037)​

-​

Mokushi^Shirou​

>>>>>Human Performer's Organization​

(0040,4036)​

-​

Radiology Dept.​

>>>>> Item Delimiter of Item #1 of Actual Human​

(FFFE,E00D)​

-​



Performer Sequence​









>>>>>SequenceDelimiterofActualHumanPerformer​

(FFFE,E0DD)​

-​



Sequence​









>>>>Visual Evaluation Test Sequence​



(0028,7028)​

-​



>>>>>Item #1 of Visual Evaluation Test Sequence​

(FFFE,E000)​

-​



>>>>>Test Result​



(0028,7029)​

-​

PASS​

>>>>>Test Result Comment​



(0028,702A)​

-​ All appearances were OK.​

>>>>>Test Pattern Code Sequence​



(0028,702C)​

-​



>>>>>>Item #1 of Test Pattern Code Sequence​

(FFFE,E000)​

-​



>>>>>>Code Value​



(0008,0100)​

-​

109801​

- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 653​

Attribute Name​

Tag​

N-GET​

N-GET Response (SCP)​





Request​





(SCU)​



>>>>>>Coding Scheme Designator​

(0008,0102)​

-​

DCM​

>>>>>>Code Meaning​

(0008,0104)​

-​

TG18-QC Pattern​

>>>>>>ItemDelimiterofItem#1ofTestPatternCode​

(FFFE,E00D)​

-​



Sequence​







>>>>>>Sequence Delimiter of Test Pattern Code​

(FFFE,E0DD)​

-​



Sequence​







>>>>>Visual Evaluation Method Code Sequence​

(0028,702E)​

-​



>>>>>>Item #1 of Visual Evaluation Method Code​

(FFFE,E000)​

-​



Sequence​







>>>>>>Code Value​

(0008,0100)​

-​

109701​

>>>>>>Coding Scheme Designator​

(0008,0102)​

-​

DCM​

>>>>>>Code Meaning​

(0008,0104)​

-​ Overall image quality evaluation​

>>>>>> Item Delimiter of Item #1 of Visual Evaluation​

(FFFE,E00D)​

-​



Method Code Sequence​







>>>>>>Sequence Delimiter of Visual Evaluation​

(FFFE,E0DD)​

-​



Method Code Sequence​







>>>> Item Delimiter of Item #1 of Visual Evaluation​

(FFFE,E00D)​

-​



Test Sequence​







>>>Sequence Delimiter of Visual Evaluation Test​

(FFFE,E0DD)​

-​



Sequence​







>>>Luminance Uniformity Result Sequence​

(0028,7027)​

-​



>>>>Item#1ofLuminanceUniformityResultSequence​

(FFFE,E000)​

-​



>>>>Performed Procedure Step Start DateTime​

(0040,4050)​

-​

20130610195000​

>>>>Performed Procedure Step End DateTime​

(0040,4051)​

-​

20130610195900​

>>>>Actual Human Performer Sequence​

(0040,4035)​

-​



>>>>Item #1 of Actual Human Performer Sequence​

(FFFE,E000)​

-​



>>>>>Human Performer's Name​

(0040,4037)​

-​

Kido^Kousei​

>>>>>Human Performer's Organization​

(0040,4036)​

-​

QA Dept.​

>>>>>Item Delimiter of Item #1 of Actual Human​

(FFFE,E00D)​

-​



Performer Sequence​







>>>>>SequenceDelimiterofActualHumanPerformer​

(FFFE,E0DD)​

-​



Sequence​







>>>>Measurement Equipment Sequence​

(0028,7012)​

-​



>>>>>Item #1 of Measurement Equipment Sequence​

(FFFE,E000)​

-​



>>>>>Measurement Functions​

(0028,7013)​

-​

PHOTOMETER\COLORIMETER​

>>>>>Measured Characteristics​

(0028,7026)​

-​

LUMINANCE\CHROMATICITY​

>>>>>Measurement Equipment Type​

(0028,7014)​

-​

NEAR_RANGE​

>>>>>Manufacturer​

(0008,0070)​

-​

LUXDEVICE COMPANY​

>>>>>Manufacturer's Model Name​

(0008,1090)​

-​

PHOTOMETER MODEL1​

>>>>>Device Serial Number​

(0018,1000)​

-​

PM1-141421356​

>>>>>DateTime of Last Calibration​

(0018,1202)​

-​

201303310900​

>>>>>Item Delimiter of Item #1 of Measurement​

(FFFE,E00D)​

-​



Equipment Sequence​







- Standard -​

Page 654​

DICOM PS3.17 2020a - Explanatory Information​



Attribute Name​



Tag​

N-GET​

N-GET Response (SCP)​







Request​







(SCU)​



>>>>>SequenceDelimiterofMeasurementEquipment​

(FFFE,E0DD)​

-​



Sequence​









>>>>Number of Luminance Points​



(0028,701B)​

-​

5​

>>>>Measurement Pattern Code Sequence​

(0028,702D)​

-​



>>>>>Item #1 of Measurement Pattern Code​

(FFFE,E000)​

-​



Sequence​









>>>>>Code Value​



(0008,0100)​

-​

109844​

>>>>>Coding Scheme Designator​



(0008,0102)​

-​

DCM​

>>>>>Code Meaning​



(0008,0104)​

-​

TG18-UNL80 Pattern​

>>>>>Item Delimiter of Item #1 of Measurement​

(FFFE,E00D)​

-​



Pattern Code Sequence​









>>>>>Sequence Delimiter of Measurement Pattern​

(FFFE,E0DD)​

-​



Code Sequence​









>>>>DDL Value​



(0028,7017)​

-​

204​

>>>>White Point Flag​



(0028,7021)​

-​

YES​

>>>>Luminance Response Sequence​



(0028,701C)​

-​



>>>>>Item #1 of Luminance Response Sequence​

(FFFE,E000)​

-​



>>>>>Luminance Value​



(0028,701F)​

-​

191.5​

>>>>>CIExy White Point​



(0028,7018)​

-​

0.940694\1.455249​

>>>>>Item Delimiter of Item #1Luminance Response​

(FFFE,E00D)​

-​



Sequence​









>>>>>Item #2 of Luminance Response Sequence​

(FFFE,E000)​

-​



>>>>>Luminance Value​



(0028,701F)​

-​

176.1​

>>>>>CIExy White Point​



(0028,7018)​

-​

0.932555\1.421037​

>>>>>Item Delimiter of Item #2 Luminance Response​

(FFFE,E00D)​

-​



Sequence​









>>>>>Item #3 of Luminance Response Sequence​

(FFFE,E000)​

-​



>>>>>Luminance Value​



(0028,701F)​

-​

197.2​

>>>>>CIExy White Point​



(0028,7018)​

-​

0.918886\1.416465​

>>>>>Item Delimiter of Item #3 of Luminance​

(FFFE,E00D)​

-​



Response Sequence​









>>>>>Item #4 of Luminance Response Sequence​

(FFFE,E000)​

-​



>>>>>Luminance Value​



(0028,701F)​

-​

202.5​

>>>>>CIExy White Point​



(0028,7018)​

-​

0.940709\1.434902​

>>>>>Item Delimiter of Item #4 Luminance Response​

(FFFE,E00D)​

-​



Sequence​









>>>>>Item #5 of Luminance Response Sequence​

(FFFE,E000)​

-​



>>>>>Luminance Value​



(0028,701F)​

-​

195.8​

>>>>>CIExy White Point​



(0028,7018)​

-​

0.946154\1.477551​

>>>>>Item Delimiter of Item #5Luminance Response​

(FFFE,E00D)​

-​



Sequence​









>>>>>Sequence Delimiter of Luminance Response​

(FFFE,E0DD)​

-​



Sequence​









- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 655​

Attribute Name​

Tag​

N-GET​

N-GET Response (SCP)​





Request​





(SCU)​



>>>Luminance Result Sequence​

(0028,7024)​

-​



>>>>Item #1 of Luminance Result Sequence​

(0028,e000)​

-​



>>>>Performed Procedure Step Start DateTime​

(0040,4050)​

-​

20130610194000​

>>>>Performed Procedure Step End DateTime​

(0040,4051)​

-​

20130610195500​

>>>>Actual Human Performer Sequence​

(0040,4035)​

-​



>>>>Item #1 of Actual Human Performer Sequence​

(FFFE,E000)​

-​



>>>>>Human Performer's Name​

(0040,4037)​

-​

Kido^Kousei​

>>>>>Human Performer's Organization​

(0040,4036)​

-​

QA Dept.​

>>>>>Item Delimiter of Item #1 of Actual Human​

(FFFE,E00D)​

-​



Performer Sequence​







>>>>>SequenceDelimiterofActualHumanPerformer​

(FFFE,E0DD)​

-​



Sequence​







>>>>Measurement Equipment Sequence​

(0028,7012)​

-​



>>>>>Item #1 of Measurement Equipment Sequence​

(FFFE,E000)​

-​



>>>>>Measurement Functions​

(0028,7013)​

-​

PHOTOMETER\COLORIMETER​

>>>>>Measured Characteristics​

(0028,7026)​

-​

LUMINANCE\CHROMATICITY​

>>>>>Measurement Equipment Type​

(0028,7014)​

-​

NEAR_RANGE​

>>>>>Manufacturer​

(0008,0070)​

-​

LUXDEVICE COMPANY​

>>>>>Manufacturer's Model Name​

(0008,1090)​

-​

PHOTOMETER MODEL1​

>>>>>Device Serial Number​

(0018,1000)​

-​

PM1-141421356​

>>>>>DateTime of Last Calibration​

(0018,1202)​

-​

201303310900​

>>>>>Item Delimiter of Item #1 of Measurement​

(FFFE,E00D)​

-​



Equipment Sequence​







>>>>>SequenceDelimiterofMeasurementEquipment​

(FFFE,E0DD)​

-​



Sequence​







>>>>Number of Luminance Points​

(0028,701B)​

-​

18​

>>>>Luminance Response Sequence​

(0028,701C)​

-​



>>>>>Item #1 of Luminance Result Sequence​

(FFFE,E000)​

-​



>>>>>DDL Value​

(0028,7017)​

-​

0​

>>>>>Luminance Value​

(0028,701F)​

-​

0.64​

>>>>>Item Delimiter of Item #1 of Luminance Result​

(FFFE,E00D)​

-​



Sequence​







>>>>>Item #2 of Luminance Result Sequence​

(FFFE,E000)​

-​



>>>>>DDL Value​

(0028,7017)​

-​

15​

>>>>>Luminance Value​

(0028,701F)​

-​

2.03​

>>>>>Item Delimiter of Item #2 of Luminance Result​

(FFFE,E00D)​

-​



Sequence​







>>>>>Item #3 of Luminance Result Sequence​

(FFFE,E000)​

-​



>>>>>DDL Value​

(0028,7017)​

-​

30​

>>>>>Luminance Value​

(0028,701F)​

-​

4.17​

>>>>>Item Delimiter of Item #3 of Luminance Result​

(FFFE,E00D)​

-​



Sequence​







- Standard -​
