Page 646​

DICOM PS3.17 2020a - Explanatory Information​

Display System X





























DSS #1



DSS #2



DSS #3









































DD #6







DD #8

















H: 1536







H: 1536

















V: 2048







V: 2048



































DD #3

























H: 1280

























V: 1024



































































































Legend:

DSS = Display Subsystem

DD = Display Device

Figure PPP.3.1-1. A Typical Display System​

The following is an example of an N-GET Request/Response pair for the Display System SOP Class.​

This example is encoded with Undefined Sequence Length and Undefined Item Length, so it contains Sequence Delimitation Items​ and Item Delimitation Items.​

N-GET:​

ANP​Attribute Not Present.​

VNP​Attribute Present but Value Not Present.​

-​ Not specified.​

Table PPP.3.1-1. N-GET Request/Response Example​

Attribute Name​

Tag​

N-GET​

N-GET Response (SCP)​





Request​





(SCU)​





SOP Common and Workstation Modules​

Specific Character Set​

(0008,0005)​

ANP​

\ISO 2022 IR 87​

Manufacturer​

(0008,0070)​

VNP​

NIPPON Corporation​

Institution Name​

(0008,0080)​

VNP​

JIRA Hospital​

Institution Address​

(0008,0081)​

VNP​

Bunkyo-ku, Tokyo, Japan​

Device Serial Number​

(0018,1000)​

VNP​

SN1234567890​

Station Name​

(0008,1010)​

VNP​

WorkstationX​

Institutional Department Name​

(0008,1040)​

VNP​

Radiology Dept.​

Manufacturer's Model Name​

(0008,1090)​

VNP​

QAStation-Model2013​

Equipment Administrator Sequence​

(0028,7000)​

VNP​



>Item #1 of Equipment Administrator​

(FFFE,E000)​

-​



Sequence​







- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 647​

Attribute Name​

Tag​

N-GET​

N-GET Response (SCP)​





Request​







(SCU)​





>Person Name​

(0040,A123)​

-​

Yamada^Tarou= ^ = ^ ​

>Person Identification Code Sequence​

(0040,1101)​

-​





>>Item #1 of Person Identification Code​

(FFFE,E000)​

-​





Sequence​









>>Code Value​

(0008,0110)​

-​

111111​



>>Coding Scheme Designator​

(0008,0102)​

-​

LOCAL​



>>Code Meaning​

(0008,0104)​

-​

Yamada^Tarou​



>>Item Delimiter of Item #1 of Person​

(FFFE,E00D)​

-​





Identification Code Sequence​









>>SequenceDelimiterofPersonIdentification​

(FFFE,E0DD)​

-​





Code Sequence​









>Person's Address​

(0040,1102)​

-​





>Person's Telephone Number​

(0040,1103)​

-​

EXT. 1234​



>Institution Name​

(0008,0080)​

-​

IT Support Div.​



>Item Delimiter of Item #1 of Equipment​

(FFFE,E00D)​

-​





Administrator Sequence​









>Sequence Delimiter of Equipment​

(FFFE,E0DD)​

-​





Administrator Sequence​











Display System Module​





Number of Display Subsystems​

(0028,7001)​



3​



Display Subsystem Sequence​

(0028,7023)​

VNP​





Item #1 of Display Subsystem Sequence​

(FFFE,E000)​

-​





>Display Subsystem ID​

(0028,7003)​

-​

1​



>Display Subsystem Name​

(0028,7004)​

-​

DSS1ofWSX​



>Display Subsystem Description​

(0028,7005)​

-​ For viewing a list and reports​



>Display Device Type Code Sequence​

(0028,7022)​

-​





>>Item #1 of Display Device Type Code​

(FFFE,E000)​

-​





Sequence​









>>Code Value​

(0008,0100)​

-​

109992​



>>Coding Scheme Designator​

(0008,0102)​

-​

DCM​



>>Code Meaning​

(0008,0104)​

-​

Liquid Crystal Display​



>>ItemDelimiterofItem#1ofDisplayDevice​

(FFFE,E00D)​

-​





Type Code Sequence​









>>SequenceDelimiterofDisplayDeviceType​

(FFFE,E0DD)​

-​





Code Sequence​









>Manufacturer​

(0008,0070)​

-​

Color Monitor Corp.​



>Device Serial Number​

(0018,1000)​

-​

C201300011​



>Manufacturer's Model Name​

(0008,1090)​

-​

1MC​



> System Status​

(0028,7006)​

-​

NORMAL​



> System Status Comment​

(0028,7007)​

-​





>DisplaySubsystemConfigurationSequence​

(0028,700A)​

-​





>>Item #1 of Display Subsystem​

(FFFE,E000)​

-​





Configuration Sequence​









- Standard -​

Page 648​

DICOM PS3.17 2020a - Explanatory Information​

Attribute Name​



Tag​

N-GET​

N-GET Response (SCP)​







Request​







(SCU)​



>> Configuration ID​



(0028,700B)​

-​

1​

>> Configuration Name​



(0028,700C)​

-​

DSS1Config1​

>> Configuration Description​



(0028,700D)​

-​ Configuration1 of Display Subsystem ID1​

>>Referenced Target Luminance​



(0028,700E)​

-​

1​

Characteristics ID​









>>Item Delimiter of Item #1 of Display​



(FFFE,E00D)​

-​



Subsystem Configuration Sequence​









>>SequenceDelimiterofDisplaySubsystem​

(FFFE,E0DD)​

-​



Configuration Sequence​









>Current Configuration ID​



(0028,7002)​

-​

1​

>Measurement Equipment Sequence​



(0028,7012)​

-​



>Sequence Delimiter of Measurement​



(FFFE,E0DD)​

-​



Equipment Sequence​









>Item Delimiter of Item #1 of Display System​

(FFFE,E00D)​

-​



Sequence​









>Item #2 of Display Subsystem Sequence​

(FFFE,E000)​

-​



>Display Subsystem ID​



(0028,7003)​

-​

2​

>Display Subsystem Name​



(0028,7004)​

-​

DSS2ofWSX​

>Display Subsystem Description​



(0028,7005)​

-​

Diagnostic, Monochrome​

>Display Device Type Code Sequence​

(0028,7022)​

-​



>>Item #1 of Display Device Type Code​

(FFFE,E00D)​

-​



Sequence​









>>Code Value​



(0008,0100)​

-​

109992​

>>Coding Scheme Designator​



(0008,0102)​

-​

DCM​

>>Code Meaning​



(0008,0104)​

-​

Liquid Crystal Display​

>>Item Delimiter of Display Device Type​

(FFFE,E00D)​

-​



Code Sequence​









>>SequenceDelimiterofDisplayDeviceType​

(FFFE,E0DD)​

-​



Code Sequence​









>Manufacturer​



(0008,0070)​

-​

Medical Display Corp.​

>Device Serial Number​



(0018,1000)​

-​

3M123456789​

>Manufacturer's Model Name​



(0008,1090)​

-​

3MG​

> System Status​



(0028,7006)​

-​

NORMAL​

> System Status Comment​



(0028,7007)​

-​



>DisplaySubsystemConfigurationSequence​

(0028,700A)​

-​



>>Item #1 of Display Subsystem​



(FFFE,E000)​

-​



Configuration Sequence​









>>Configuration ID​



(0028,700B)​

-​

1​

>> Configuration Name​



(0028,700C)​

-​

DSS2Config1​

>> Configuration Description​



(0028,700D)​

-​ Configuration2 of Display Subsystem ID2​

>>Referenced Target Luminance​



(0028,700E)​

-​

2​

Characteristics ID​









- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 649​

Attribute Name​

Tag​

N-GET​

N-GET Response (SCP)​





Request​







(SCU)​





>>Item #1 of Display Subsystem​

(FFFE,E00D)​

-​





Configuration Sequence​









>>SequenceDelimiterofDisplaySubsystem​

(FFFE,E0DD)​

-​





Configuration Sequence​









>Current Configuration ID​

(0028,7002)​

-​

1​



>Measurement Equipment Sequence​

(0028,7012)​

-​





>>Item #1 of Measurement Equipment​

(FFFE,E000)​

-​





Sequence​









>>Measurement Functions​

(0028,7013)​

-​

PHOTOMETER\COLORIMETER​



>>Measured Characteristics​

(0028,7026)​

-​

UNIFORMITY\LUMINANCE\CHROMATICITY​

>>Measurement Equipment Type​

(0028,7014)​

-​

BUILT_IN_FRONT​



>> Manufacturer​

(0008,0070)​

-​

LuminanceMeasurement Device Inc.​

>> Manufacturer's Model Name​

(0008,1090)​

-​

LC1000​



>> Device Serial Number​

(0018,1000)​

-​

SN99990001​



>> DateTime of Last Calibration​

(0018,1202)​

-​





>>Item Delimiter of Item #1 of Measurement​

(FFFE,E00D)​

-​





Equipment Sequence​









>>Sequence Delimiter of Measurement​

(FFFE,E0DD)​

-​





Equipment Sequence​









>Item Delimiter of Item #2 of Display​

(FFFE,E00D)​

-​





Subsystem Sequence​









>Item #3 of Display Subsystem Sequence​

(FFFE,E000)​

-​





>Display Subsystem ID​

(0028,7003)​

-​

3​



>Display Subsystem Name​

(0028,7004)​

-​

DSS3ofWSX​



>Display Subsystem Description​

(0028,7005)​

-​

Diagnostic, Monochrome​



>Display Device Type Code Sequence​

(0028,7022)​

-​





>>Item #1 of Display Device Type Code​

(FFFE,E000)​

-​





Sequence​









>>Code Value​

(0008,0100)​

-​

109992​



>>Coding Scheme Designator​

(0008,0102)​

-​

DCM​



>>Code Meaning​

(0008,0104)​

-​

Liquid Crystal Display​



>>ItemDelimiterofItem#1ofDisplayDevice​

(FFFE,E00D)​

-​





Type Code Sequence​









>>SequenceDelimiterofDisplayDeviceType​

(FFFE,E0DD)​

-​





Code Sequence​









>Manufacturer​

(0008,0070)​

-​

Medical Display Corp.​



>Device Serial Number​

(0018,1000)​

-​

3M123456790​



>Manufacturer's Model Name​

(0008,1090)​

-​

3MG​



>System Status​

(0028,7006)​

-​

NORMAL​



>System Status Comment​

(0028,7007)​

-​





>DisplaySubsystemConfigurationSequence​

(0028,700A)​

-​





>>Item #1 of Display Subsystem​

(FFFE,E000)​

-​





Configuration Sequence​









- Standard -​

Page 650​

DICOM PS3.17 2020a - Explanatory Information​

Attribute Name​



Tag​

N-GET​

N-GET Response (SCP)​







Request​







(SCU)​



>> Configuration ID​



(0028,700B)​

-​

1​

>> Configuration Name​



(0028,700C)​

-​

DSS3Config1​

>> Configuration Description​



(0028,700D)​

-​ Configuration3 of Display Subsystem ID3​

>>Referenced Target Luminance​



(0028,700E)​

-​

3​

Characteristics ID​









>>Item Delimiter of Item #1 of Display​



(FFFE,E00D)​

-​



Subsystem Configuration Sequence​









>>SequenceDelimiterofDisplaySubsystem​

(FFFE,E0DD)​

-​



Configuration Sequence​









>Current Configuration ID​



(0028,7002)​

-​

1​

>Measurement Equipment Sequence​



(0028,7012)​

-​



>>Item #1 of Measurement Equipment​



(FFFE,E000)​

-​



Sequence​









>>Measurement Functions​



(0028,7013)​

-​

PHOTOMETER\COLORIMETER​

>>Measured Characteristics​



(0028,7026)​

-​

UNIFORMITY\LUMINANCE\CHROMATICITY​

>>Measurement Equipment Type​



(0028,7014)​

-​

BUILT_IN_FRONT​

>> Manufacturer​



(0008,0070)​

-​

LuminanceMeasurement Device Inc.​

>>Manufacturer's Model Name​



(0008,1090)​

-​

LC1000​

>> Device Serial Number​



(0018,1000)​

-​

SN99990011​

>> DateTime of Last Calibration​



(0018,1202)​

-​



>>Item Delimiter of Item #1 of Measurement​

(FFFE,E00D)​

-​



Equipment Sequence​









>>Sequence Delimiter of Measurement​

(FFFE,E0DD)​

-​



Equipment Sequence​









>Item Delimiter of Item #3 of Display​



(FFFE,E00D)​

-​



Subsystem Sequence​









>Sequence Delimiter of Display Subsystem​

(FFFE,E0DD)​

-​



Sequence​











Target Luminance Characteristics Module​

TargetLuminanceCharacteristicsSequence​

(0028,7008)​

VNP​



>Item#1ofTargetLuminanceCharacteristics​

(FFFE,E000)​

-​



Sequence​









>Luminance Characteristics ID​



(0028,7009)​

-​

1​

>Display Function Type​



(0028,7019)​

-​

GAMMA​

>Target Minimum Luminance​



(0028,701D)​

-​

0.75​

>Target Maximum Luminance​



(0028,701E)​

-​

250​

>Gamma Value​



(0028,701A)​

-​

2.2​

>Item Delimiter of Item #1 of Target​



(FFFE,E00D)​

-​



Luminance Characteristics Sequence​









>Item#2ofTargetLuminanceCharacteristics​

(FFFE,E000)​

-​



Sequence​









>Luminance Characteristics ID​



(0028,7009)​

-​

2​

>Display Function Type​



(0028,7019)​

-​

GSDF​

- Standard -​
