Page 836​

DICOM PS3.17 2020a - Explanatory Information​



Nesting​

Attribute Name​

Tag​

Value​

Comment​

>​

Relative Opacity​

(0070,0403)​

0.7​



>​

Blending Mode​

(0070,1B06)​

FOREGROUND​



>​

Blending Input Number​

(0070,1B02)​

6​

Output is used for later​









Blending​



%enditem 1​









%item 2​







>​

Blending Display Input Sequence​

(0070,1B03)​





>​

%item 2-1​





Parametric series 1​

>>​

Blending Input Number​

(0070,1B02)​

3​



>​

%enditem 2-1​







>​

%item 2-2​





Parametric series 2​

>>​

Blending Input Number​

(0070,1B02)​

4​



>​

%enditem 2-2​







>​

%item 2-3​





Parametric series 3​

>>​

Blending Input Number​

(0070,1B02)​

5​



>​

End Sequence Item 2-3​







>​

Blending Mode​

(0070,1B06)​

EQUAL​



>​

Blending Input Number​

(0070,1B02)​

7​

Output is used for later​









Blending​



%enditem 2​









%item 3​







>​

Blending Display Input Sequence​

(0070,1B03)​





>​

%item 3-1​





Output first blending​









operation, no threshold​

>>​

Blending Input Number​

(0070,1B02)​

6​



>​

%enditem 3-1​







>​

%item 3-2​





Output second blending​









operation, no threshold​

>>​

Blending Input Number​

(0070,1B02)​

7​



>​

%enditem 3-2​







>​

Relative Opacity​

(0070,0403)​

0.6​



>​

Blending Mode​

(0070,1B06)​

FOREGROUND​





%enditem 3​





No Parametric Blending​









Input Number is present as​









this step defines the output​









to be displayed.​

- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 837​

GGGG Patient Radiation Dose Structured​

Report Document (Informative)​

This Annex contains examples of the use of Patient Radiation Dose templates within Patient Radiation Dose Structured Report Doc-​ uments.​

GGGG.1 Skin Dose Map Example​

The following example shows the report of the skin dose map calculated from the dose delivered during an X-Ray interventional car-​ diology procedure.​

The calculation uses a Radiation Dose SR provided by a Single Plane X-Ray Angiography equipment of the manufacturer "A". The​ Radiation Dose SR is created during one procedure step, corresponding to the coronary stenting of an adult male of 83 kg and 179​ cm height.​

The skin dose calculations are performed by an application on a separated workstation of the manufacturer "B", operated by the​ medical physicist, who is logged into the workstation at the time of the creation of the Patient Radiation Dose Structured Report doc-​ ument.​

The dose calculation application generates a Patient Radiation Dose Structured Report document and a Secondary Capture Image​ containing an image of the dose distribution over the deployed skin of the patient model.​

The dose calculation application uses the following settings and assumptions:​

•​RDSR Source Data:​

•​All the Irradiation Event UIDs are used in the calculation of the skin dose map.​

•​Patient Model:​

•​The patient model is a combination of two elliptic cylinders to represent the chest and neck of the patient.​

•​The actual dimensions of the model are determined by the age, gender, height, and weight of the patient.​

•​In this example the exact height and weight of the patient are used to create the model. The resulting elliptic cylinder for the chest​ of the model is 31 cm in the AP dimension and 74 cm in the lateral dimension.​

•​The application creates internally a 3D voxelized model that is stored in a DICOM SOP Instance.​

•​Patient Model Registration:​

•​The distance from the top of the patient's head to the head of the table (measured during the procedure) is known. The location​ of the patient head and table head are stored in a Spatial Fiducials SOP instance.​

•​The application uses fiducials to register the patient model with the data of the source Radiation Dose SR.​

•​A-priori knowledge of the distance from the table head to the system Isocenter at table zero position is calibrated offline.​

•​The table tilt, cradle, and rotation angles are ignored because the description of the acquisition geometry is incomplete in the​ Radiation Dose SR. Only table translations relative to the Isocenter are considered in the calculations.​

•​Beam Attenuators:​

•​A-priori knowledge of the model of the table and mattress (i.e., shape, dimensions, and absorption material) is calibrated offline,​ anditisreferencedinternallybytheapplication.Themodelcontainsthesamecoordinatesystemastheoneusedintheequipment​ referenced in the Radiation Dose SR, so there is no need of another registration SOP instance.​

•​The X-Ray filter information from the source Radiation Dose SR is used by the application. There is no other a-priori knowledge​ of the X-Ray filtration.​

- Standard -​

Page 838​ DICOM PS3.17 2020a - Explanatory Information​

Table GGGG.1-1. Skin Dose Map Example​

Node​

Code Meaning of Concept Name​

Code or Example Value​

Comment​

1​

Patient Radiation Dose Report​



TID 10030​

1.1​

Language of Content Item and​

(En, IETF4646, "English")​

TID 1204​



Descendants​





1.2​

Observer Type​

(121007, DCM, "Device")​

TID 1002​

1.3​

Device Observer UID​

1.2.3.4.566.1.5​

TID 1004​

1.4​

Device Observer Name​

MedPhys-01​

TID 1004​

1.5​

Device Observer Manufacturer​

Manufacturer B​

TID 1004​

1.6​

Device Observer Model Name​

Dose Workstation v1​

TID 1004​

1.7​

Observer Type​

(121006, DCM, "Person")​

TID 1002​

1.8​

Person Observer Name​

Doe^John^^Dr^PhD​

TID 1003​

1.9​

Person Observer's Role in the​

(C1708969, UMLS, "Medical​

TID 1003​



Organization​

Physicist")​



1.10​

Radiation Dose Estimate​



TID 10031​

1.10.1​

Radiation Dose Estimate Name​

Skin Dose Map​

TID 10031​

1.10.2​

Comment​

Single Plane XA​

TID 10031​

1.10.3​

Radiation Dose Estimate Methodology​



TID 10033​

1.10.3.1​

SR Instance Used​



Radiation Dose SR #1​

1.10.3.1.1​

SOP Class UID​

1.2.840.1008.5.1.4.1.1.88.67​



1.10.3.1.2​

SOP Instance UID​

1.2.3.4.566.77.1​



1.10.3.1.3​

Spatial Fiducials​



Spatial Fiducials​

1.10.3.1.3.1​

SOP Class UID​

1.2.840. 1008.5.1.4.1.1.66.2​



1.10.3.1.3.2​

SOP Instance UID​

1.2.3.4.44.222.33.1​



1.10.3.2​

Patient Radiation Dose Model​



TID 10033​

1.10.3.2.1​

Patient Model Type​

(128418, DCM, "Simple Object​

TID 10033​





Model")​



1.10.3.2.2​

Radiation Transport Model Type​

(128422,DCM,"VoxelizedRadiation​TID 10033​





Transport Model")​



1.10.3.2.3​

Patient Radiation Dose Model Data​



Parametric map​

1.10.3.1.3.1​

SOP Class UID​

1.2.840.1008.5.1.4.1.1.30​



1.10.3.1.3.2​

SOP Instance UID​

1.2.3.43.44.55.1​



1.10.3.2.4​

Patient Radiation Dose Model Reference​DOI:1.2.3.4​

TID 10033​

1.10.3.2.5​

Comment​

Combined Elliptic Cylinders​

TID 10033​

1.10.3.2.6​

Patient Model Demographics​



TID 10033​

1.10.3.2.6.1​

Model Minimum Age​

18 (a, UCUM, "year")​

TID 10033​

1.10.3.2.6.2​

Model Maximum Age​

90 (a, UCUM, "year")​

TID 10033​

1.10.3.2.6.3​

Model Patient Sex​

(M, DCM, "Male")​

TID 10033​

1.10.3.2.6.4​

Model Minimum Weight​

83 (kg, UCUM, "kilogram")​

TID 10033​

1.10.3.2.6.5​

Model Maximum Weight​

83 (kg, UCUM, "kilogram")​

TID 10033​

1.10.3.2.6.6​

Model Minimum Height​

179 (cm, UCUM, "Centimeter")​

TID 10033​

1.10.3.2.6.7​

Model Maximum Height​

179 (cm, UCUM, "Centimeter")​

TID 10033​

1.10.3.2.7​

Patient Model Registration​



TID 10033​

- Standard -​



DICOM PS3.17 2020a - Explanatory Information​

Page 839​

Node​

Code Meaning of Concept Name​

Code or Example Value​

Comment​

1.10.3.2.7.1​

Comment​

Distance from the top of patient's​

TID 10033​





headtotheheadofthetable=10cm​

1.10.3.2.7.2​

Registration Method​

(125022,DCM,"FiducialAlignment")​TID 10033​

1.10.3.2.7.3​

Spatial Registration​



Spatial Registration​

1.10.3.1.3.1​

SOP Class UID​

1.2.840. 1008.5.1.4.1.1.66.1​



1.10.3.1.3.2​

SOP Instance UID​

1.2.3.4.44.3.2.11​



1.10.3.3​

X-Ray Beam Attenuator​



TID 10033​

1.10.3.3.1​

Attenuator Category​

(128459, DCM, "Table")​

TID 10033​

1.10.3.3.2​

Equivalent Attenuator Material​

(256501007, SCT, "Carbon fiber")​ TID 10033​

1.10.3.3.3​

Equivalent Attenuator Thickness​

100 (mm, UCUM, "Millimeter")​

TID 10033​

1.10.3.3.4​

Attenuator Description​

X-Ray Table with Mattress​

TID 10033​

1.10.3.3.5​

X-Ray Beam Attenuator Model​



TID 10033​

1.10.3.3.5.1​

Radiation Transport Model Type​

(128421,DCM,"GeometricRadiation​TID 10033​





Transport Model")​



1.10.3.3.5.2​

X-RayBeamAttenuatorModelReference​DOI:1.4.2.3​

TID 10033​

1.10.3.4​

Radiation Dose Estimate Method​



TID 10033​

1.10.3.4.1​

Radiation Dose Estimate Method Type​ (128480, DCM, "Analytical​

TID 10033​





Algorithm")​



1.10.3.4.2​

Radiation Dose Estimate Parameters​



TID 10034​

1.10.3.4.2.1​

(128433, DCM, "Tissue Air Ratio")​

1.06 ({ratio}, UCUM, "ratio")​

TID 10034​

1.10.3.4.2.1.1​

RadiationDoseEstimateParameterType​(C70774, NCIt, "Unit Conversion​

TID 10034​





Factor")​



1.10.3.4.2.2​

(128408, DCM, "Patient AP Dimension")​31 (cm, UCUM, "Centimeter")​

TID 10034​

1.10.3.4.2.2.1​

RadiationDoseEstimateParameterType​(121206, DCM, "Distance")​

TID 10034​

1.10.3.4.2.3​

(128409, DCM, "Patient Lateral​

74 (cm, UCUM, "Centimeter")​

TID 10034​



Dimension")​





1.10.3.4.2.3.1​

RadiationDoseEstimateParameterType​(121206, DCM, "Distance")​

TID 10034​

1.10.3.4.2.4​

(MyCode001, 99MyScheme, "Linear​

0.010536(/cm,UCUM,"/Centimeter")​TID 10034​



attenuation coefficient of the table and​







mattress")​





1.10.3.4.3​

Radiation Dose Estimate Method​

DOI:4.2.13.4​

TID 10033​



Reference​





1.10.4​

Radiation Dose Estimate Representation​

TID 10032​

1.10.4.1​

Distribution Representation​

(128485, DCM, "Skin Dose Map")​

TID 10032​

1.10.4.2​

Radiation Dose Representation Data​



TID 10032​

1.10.4.2.1​

SOP Class UID​

1.2.840.10008.5.1.4.1.1.7​

Secondary Capture​

1.10.4.2.2​

SOP Instance UID​

1.2.3.1.2.3.3​



1.10.4.3​

Organ​

(181469002, SCT, "Skin")​

TID 10032​

1.10.4.4​

Comment​

2D map of the dose on the deployed​TID 10032​





skin​



1.10.5​

Organ Radiation Dose Information​



TID 10031​

1.10.5.1​

Organ​

(181469002, SCT, "Skin")​

TID 10031​

1.10.5.2​

Comment​

Skin in the area of the chest and​

TID 10031​





neck​



- Standard -​

Page 840​

DICOM PS3.17 2020a - Explanatory Information​



Node​

Code Meaning of Concept Name​

Code or Example Value​

Comment​

1.10.5.3​

(DCM, 128531, "Maximum Absorbed​

3000 (mGy, UCUM, "mGy")​

TID 10031​



Radiation Dose")​





1.10.5.3.1​

(371884006, SCT, "+/-, range of​

750 (mGy, UCUM, "mGy")​

TID 10031​



measurement uncertainty")​





1.11​

Comment​

Skin Dose Map Report​

TID 10030​

GGGG.2 Dual-source CT Organ Radiation Dose Example​

The following example shows the report of the organ dose calculated for a dual-source CT scan.​

The calculation uses a Radiation Dose SR provided by a CT system that has dual X-Ray tubes. The Radiation Dose SR is created​ during the acquisition of Neck DE_CAROTID CT scan of an adult male of 75 kg and 165 cm height.​

ThedosecalculationsareperformedontheCTsystem.ThedosecalculationapplicationgeneratesaPatientRadiationDoseStructured​ Report document and a Dose Point Cloud containing an image of the dose distribution for the patient model.​

The dose calculation application uses the following settings and assumptions:​

•​RDSR Source Data:​

•​The Irradiation Events associated with the CT Localizer Radiograph are excluded.​

•​The Irradiation Event UID from the helical CT series is used in the calculation of the organ dose.​

•​Patient Model:​

•​The patient model is a stylized anthropomorphic model of the patient.​

•​Organs are represented by simple geometric shapes described by mathematical equations. The parameters of the equations​ describing the location, shape, and dimension of the organs are stored in a DICOM SOP Instance.​

•​In this example the gender and age of the patient are used to select the appropriate phantom from the existing phantom library.​

•​Patient Model Registration:​

•​Image Content-based Alignment between the CT images Frame of Reference and the 3D stylized model Frame of Reference is​ used for registration.​

•​Beam Attenuators:​

•​Additional Aluminum filtration is used in the methodology and the equivalent HVL for the scanner model used in the method is​ given.​

Table GGGG.2-1. Dual-source CT Organ Radiation Dose Example​

Node​

Code Meaning of Concept Name​

Code or Example Value​

Comment​

1​

Patient Radiation Dose Report​



TID 10030​

1.1​

Language of Content Item and​

(En, IETF4646, "English")​

TID 1204​



Descendants​





1.1.1​

Country of Language​

(CA, ISO3166_1, "Canada")​

TID 1204​

1.2​

Observer Type​

(121007, DCM, "Device")​

TID 1002​

1.3​

Device Observer UID​

2.13.4.5.2.33.5​

TID 1004​

1.4​

Device Observer Name​

RUMC-213​

TID 1004​

1.5​

Device Observer Manufacturer​

Manufacturer DEX​

TID 1004​

1.6​

Device Observer Model Name​

Scanner 4500​

TID 1004​

- Standard -​
