DICOM PS3.17 2020a - Explanatory Information​

Page 841​

Node​

Code Meaning of Concept Name​

Code or Example Value​

Comment​

1.7​

Radiation Dose Estimate​



TID 10031​

1.7.1​

Radiation Dose Estimate Name​

Dual-source Neck DE_CAROTID CT​TID 10031​





scan Tube A&B​



1.7.2​

Comment​

Tube A and B combined​

TID 10031​

1.7.3​

Radiation Dose Estimation Methodology​

TID 10033​

1.7.3.1​

SR Instance Used​



TID 10033​

1.10.3.1​

SR Instance Used​



Radiation Dose SR​

1.10.3.1.1​

SOP Class UID​

1.2.840.1008.5.1.4.1.1.88.67​



1.10.3.1.2​

SOP Instance UID​

1.2.3.4.566.77.1​



1.7.3.1.1​

Event UID Used​

1.3.12.2.xxxxxx​

TID 10033​

1.7.3.2​

Patient Radiation Dose Model​



TID 10033​

1.7.3.2.1​

Patient Model Type​

(128404, DCM, "Anthropomorphic​

TID 10033​





Model")​



1.7.3.2.2​

Radiation Transport Model Type​

(128421,DCM,"GeometricRadiation​TID 10033​





Transport Model")​



1.7.3.2.3​

Patient Radiation Dose Model Data​

< UID of "Patient Radiation Dose​

TID 10033​





Model Data">​



1.7.3.2.3​

Patient Radiation Dose Model Data​



Parametric map​

1.7.3.2.3.1​

SOP Class UID​

1.2.840.1008.5.1.4.1.1.30​



1.7.3.2.3.2​

SOP Instance UID​

1.2.5.4.6.677​



1.7.3.2.4​

Patient Radiation Dose Model Reference​Cristy et al. 1987​

TID 10033​

1.7.3.2.5​

Patient Model Demographics​



TID 10033​

1.7.3.2.5.1​

Model Minimum Age​

18 (a, UCUM, "year")​

TID 10033​

1.7.3.2.5.2​

Model Maximum Age​

18 (a, UCUM, "year")​

TID 10033​

1.7.3.2.5.3​

Model Patient Sex​

(M, DCM, "Male")​

TID 10033​

1.7.3.2.5.4​

Model Minimum Weight​

75 (kg, UCUM, "kilogram")​

TID 10033​

1.7.3.2.5.5​

Model Maximum Weight​

75 (kg, UCUM, "kilogram")​

TID 10033​

1.7.3.2.5.6​

Model Minimum Height​

165 (cm, UCUM, "Centimeter")​

TID 10033​

1.7.3.2.5.7​

Model Maximum Height​

165 (cm, UCUM, "Centimeter")​

TID 10033​

1.7.3.2.6​

Patient Model Registration​



TID 10033​

1.7.3.2.6.1​

Registration Method​

(125024, DCM, "Image​

TID 10033​





Content-based Alignment")​



1.7.3.2.6.2​

Spatial Registration​

<UID of "Spatial Registration">​

TID 10033​

1.7.3.2.6.2.1​

SOP Class UID​

1.2.840. 1008.5.1.4.1.1.66.1​



1.7.3.2.6.2.2​

SOP Instance UID​

1.4.9.87.11.223.5​



1.7.3.3​

X-Ray Beam Attenuator​



TID 10033​

1.7.3.3.1​

Attenuator Category​

(113771, DCM, "X-Ray Filters")​

TID 10033​

1.7.3.3.2​

Equivalent Attenuator Material​

(12503006, SCT, "Aluminum")​

TID 10033​

1.7.3.3.3​

Equivalent Attenuator Thickness​

1.4 (mm, UCUM, "Millimeter")​

TID 10033​

1.7.3.3.4​

Attenuator Description​

MeanequivalentAluminumthickness​TID 10033​





of bowtie filter​



1.7.3.3.5​

X-Ray Beam Attenuator Model​



TID 10033​

1.7.3.3.5.1​

Radiation Transport Model Type​

(128421,DCM,"GeometricRadiation​TID 10033​





Transport Model")​



- Standard -​

Page 842​

DICOM PS3.17 2020a - Explanatory Information​



Node​

Code Meaning of Concept Name​

Code or Example Value​

Comment​

1.7.3.4​

Radiation Dose Estimate Method​



TID 10033​

1.7.3.4.1​

Radiation Dose Estimate Method Type​ (D009010, MSH, "Monte Carlo")​

TID 10033​

1.7.3.4.2​

Radiation Dose Estimate Parameters​



TID 10034​

1.7.3.4.2.1​

(111634, DCM, "Half Value Layer")​

8.5 (mm, UCUM, "Millimeter")​

TID 10034​

1.7.3.4.3​

Radiation Dose Estimate Method​

Simulation package XX version YY​TID 10033​



Reference​





1.7.4​

Radiation Dose Estimate Representation​

TID 10032​

1.7.4.1​

Distribution Representation​

(128496, DCM, "Dose Point Cloud")​TID 10032​

1.7.4.2​

Radiation Dose Representation Data​



TID 10032​

1.7.3.2.3.1​

SOP Class UID​

1.2.840.1008.5.1.4.1.1.30​

Parametric Map​

1.7.3.2.3.2​

SOP Instance UID​

1.87.2.3.4.11.3​



1.7.4.3​

Organ​

(38266002, SCT, "Entire Body")​

TID 10032​

1.7.5​

Organ Radiation Dose Information​



TID 10031​

1.7.5.1​

Organ​

(39607008, SCT, "Lung")​

TID 10031​

1.7.5.1.1​

(DCM,128533,"MeanAbsorbedRadiation​9.6 (mGy, UCUM, "mGy")​

TID 10031​



Dose")​





- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 843​

HHHH Protocol Approval Examples and​ Concepts (Informative)​

The following example is provided to illustrate the usage of the Protocol Approval IOD.​

This example shows approval of a pair of CT Protocols for routine adult head studies. It is approved by the Chief of Radiology and​ by the Physicist. The Instance UIDs of the two CT Protocols are 1.2.3.456.7.7 and 1.2.3.456.7.8.​

Note that the Institution Code Sequence (0008,0082) inside the Asserter Identification Sequence (0044,0103) communicates that​ Mercy Hospital is the organization to which Dr. Welby is responsible. The Institution Code Sequence (0008,0082) at the end of the​ first Approval Item communicates that Mercy Hospital is the institution for which the protocols are "Approved for use at the institution".​

Table HHHH-1. Approval by Chief Radiologist​

Attribute​

Tag​

Value​

Manufacturer​

(0008,0070)​

Acme Corp.​

Manufacturer's Model Name​

(0008,1090)​

Primo Protocol Management Workstation Plus​

Device Serial Number​

(0018,1000)​

A59848573​

Software Versions​

(0018,1020)​

V2.3​

SOP Class UID​

(0008,0016)​

1.2.840.10008.5.1.4.1.1.200.3 (Protocol Approval)​

SOP Instance UID​

(0008,0018)​

1.33.9.876.1.1.1​

Approval Subject Sequence​

(0044,0109)​



Item #1​





>Referenced SOP Class UID​

(0008,1150)​

1.2.840.10008.5.1.4.1.1.200.1 (CT Defined​





Procedure Protocol)​

>Referenced SOP Instance UID​

(0008,1155)​

1.2.3.456.7.7​

Item #2​





>Referenced SOP Class UID​

(0008,1150)​

1.2.840.10008.5.1.4.1.1.200.1 (CT Defined​





Procedure Protocol)​

>Referenced SOP Instance UID​

(0008,1155)​

1.2.3.456.7.8​

Approval Sequence​

(0044,0100)​



Item #1​





>Assertion Code Sequence​

(0044,0101)​

(128603,DCM,"Approvedforuseattheinstitution")​

>Assertion UID​

(0044,0102)​

1.2.33.9.876.5.5.5.5.21​

>Asserter Identification Sequence​

(0044,0103)​



>>Observer Type​

(0040,A084)​

PSN​

>>Person Name​

(0040,A123)​

"Welby^Marcus^^Dr.^MD"​

>>Person Identification Code Sequence​

(0040,1101)​

(12345, 99NPI, "Welby^Marcus^^Dr.^MD")​

>>Organizational Role Code Sequence​

(0044,010A)​

(128670, DCM, "Head of Radiology")​

>>Institution Name​

(0008,0080)​

Mercy Hospital, Centerville​

>>Institution Code Sequence​

(0008,0082)​

(000011113, 99NPI, "Mercy Hospital, Centerville")​

>Assertion DateTime​

(0044,0104)​

20150601145327​

>Assertion Expiration DateTime​

(0044,0105)​

20200601000000(basedona5yearlyreviewplan)​

>Institution Code Sequence​

(0008,0082)​

(000011113, 99NPI, "Mercy Hospital, Centerville")​

Item #2​





- Standard -​

Page 844​

DICOM PS3.17 2020a - Explanatory Information​

Attribute​



Tag​

Value​

>Assertion Code Sequence​



(0044,0101)​

(128605, DCM, "Approved for use on pregnant​







patients")​

>Assertion UID​



(0044,0102)​

1.2.33.9.876.5.5.5.5.22​

>Asserter Identification Sequence​



(0044,0103)​



>>Observer Type​



(0040,A084)​

PSN​

>>Person Name​



(0040,A123)​

"Welby^Marcus^^Dr.^MD"​

>>Person Identification Code Sequence​

(0040,1101)​

(12345, 99NPI, "Welby^Marcus^^Dr.^MD")​

>>Organizational Role Code Sequence​

(0044,010A)​

(128670, DCM, "Head of Radiology")​

>>Institution Name​



(0008,0080)​

Mercy Hospital, Centerville​

>>Institution Code Sequence​



(0008,0082)​

(000011113, 99NPI, "Mercy Hospital, Centerville")​

>Assertion DateTime​



(0044,0104)​

20150601145327​

>Assertion Expiration DateTime​



(0044,0105)​

20200601000000(basedona5yearlyreviewplan)​

>Assertion Comments​



(0044,0106)​

"Limited scan range and proper use of abdominal​







shielding result in negligible dose to the fetus."​

- Standard -​

DICOM PS3.17 2020a - Explanatory Information​

Page 845​

IIII Encapsulated STL (Informative)​

The goal of encapsulating a Stereolithography (STL) 3D manufacturing model file inside a DICOM instance rather than transforming​ the data into a different representation is to facilitate preservation of the STL file in the exact form that it is used with extant manufac-​ turing devices, while at the same time unambiguously associating it with the patient for whose care the model was created and the​ images from which the model was derived.​

IIII.1 Example of CT Derived Encapsulated STL​

In this example, the patient requires a replacement implant for a large piece of skull on the left side of his head. A 3D manufacturing​ model (encoded in binary STL) was created by mirroring the corresponding section of the patient's right skull hemisphere, and then​ modified by trimming to fit the specific implantation area.​

The model was derived from a series of CT images (CT-01). The STL data in this example is the first version, having no predecessor.​ The STL data was created on November 22, 2017 at 7:10:14 AM and then stored in a DICOM instance at 7:15:23 AM. The CT images​ were acquired weeks earlier.​

The STL data was created in the coordinate system of CT-01; so they share the same Frame of Reference UID value.​

A preview image (optional) showing the rendered 3D object was created and included with the encapsulated STL as an icon image.​

No burned in annotation identifying the patient was included. The region of the skull reconstructed in the model contains no distin-​ guishing facial features of the patient.​

Table IIII.1-1. CT Derived Encapsulated STL Example​

Attribute Name​

Tag​

Example Value​

Comments​

<Patient and General Study Modules not shown for brevity>​





Modality​

(0008,0060)​

M3D​



Series Instance UID​

(0020,000E)​

2.999.89235.5951.35894.0047​

Series Number​

(0020,0011)​

3​



Series Description​

(0008,103E)​

Skull plate​



Instance Number​

(0020,0013)​

1​



Frame of Reference UID​

(0020,0052)​

1.2.3.4.5.6.7.8.99​



Manufacturer​

(0008,0070)​

Acme Additive Inc​



Manufacturer's Model Name​

(0008,1090)​

Implant Maker​



Device Serial Number​

(0018,1000)​

00004367​



Software Versions​

(0018,1020)​

3.0.1​



Content Date​

(0008,0023)​

20171122​



Content Time​

(0008,0033)​

071014​



Acquisition DateTime​

(0008,002A)​

20171122071014​



Image Laterality​

(0020,0062)​

L​



Burned In Annotation​

(0028,0301)​

NO​



Recognizable Visual Features​

(0028,0302)​

NO​



Source Instance Sequence​

(0042,0013)​



A sequence referencing the​







CT-01 source images​

%item​







>Referenced SOP Class UID​

(0008,1150)​

1.2.840.10008.5.1.4.1.1.2.1​

Referenced object is an​







Enhanced CT Image Storage​







Instance​

- Standard -​
