DICOM PS3.17 2020a - Explanatory Information​

•​Filter Operations Sequence:​ •​Item 1:​

•​Filter-by Category: "IMAGE_PLANE"​ •​Selector Attribute VR: "CS"​ •​Selector CS Value: "TRANSVERSE"​ •​Filter-by Operator: "MEMBER_OF"​

•​Sorting Operations Sequence:​ •​Item 1:​

•​Sort-by Category: "ALONG_AXIS"​ •​Sorting Direction: "INCREASING"​ •​Display Set Patient Orientation: "L\P"​

•​VOI Type: BRAIN​

•​Show Graphic Annotation Flag: "YES"​ •​Item 22: [CT old two part scrolled, rows 2 & 4]​

•​Display Set Number: 22​ •​Display Set Presentation Group: 4​ •​Image Set Number: 3​

•​Image Boxes Sequence:​

•​Item 1: [row 2 of 2048x2560 space]​ •​Image Box Number: 1​

•​Display Environment Spatial Position: (1024/3072, 1536/2560), (3072/3072, 1024/2560)​ •​Image Box Layout Type: "TILED"​

•​Image Box Tile Horizontal Dimension: 3​ •​Image Box Tile Vertical Dimension: 1​ •​Image Box Scroll Direction: "HORIZONTAL"​ •​Image Box Small Scroll Type: "IMAGE"​ •​Image Box Small Scroll Amount: 1​

•​Image Box Large Scroll Type: "ROW_COLUMN"​ •​Image Box Large Scroll Amount: 1​

•​Item 2: [row 4 (bottom row) of 2048x2560 space]​ •​Image Box Number: 2​

•​Display Environment Spatial Position: (1024/3072, 512/2560), (3072/3072, 0/2560)​ •​Image Box Layout Type: "TILED"​

Page 271​

- Standard -​

Page 272​

DICOM PS3.17 2020a - Explanatory Information​

•​Image Box Tile Horizontal Dimension: 3​

•​Image Box Tile Vertical Dimension: 1​

•​Image Box Scroll Direction: "HORIZONTAL"​

•​Image Box Small Scroll Type: "IMAGE"​

•​Image Box Small Scroll Amount: 1​

•​Image Box Large Scroll Type: "ROW_COLUMN"​

•​Image Box Large Scroll Amount: 1​

•​Filter Operations Sequence:​

•​Item 1:​

•​Filter-by Category: "IMAGE_PLANE"​

•​Selector Attribute VR: "CS"​

•​Selector CS Value: "TRANSVERSE"​

•​Filter-by Operator: "MEMBER_OF"​

•​Sorting Operations Sequence:​

•​Item 1:​

•​Sort-by Category: "ALONG_AXIS"​

•​Sorting Direction: "INCREASING"​

•​Display Set Patient Orientation: "L\P"​

•​VOI Type: BRAIN​

•​Show Graphic Annotation Flag: "YES"​

•​Partial Data Display Handling: "MAINTAIN_LAYOUT"​

•​Synchronized Scrolling Sequence: [Link up (synchronize) the MR and CT tiled scroll panes in Display Sets 15 and 16, and the CT​ new and CT old tiled scroll panes in Display Sets 21 and 22]​

•​Item 1:​

•​Display Set Scrolling Group: 15\16​

•​Item 2:​

•​Display Set Scrolling Group: 21\22​

V.5 Hanging Protocol Query Example​

The following is an example of a general C-FIND Request for the Hanging Protocol Information Model - FIND SOP Class that is​ searching for all Chest related Hanging Protocols for the purpose of reading projection Chest X-ray. The user is at a workstation that​ has two 2Kx2.5K screens.​

C-FIND Request:​











Nesting​

Attribute​

Tag​



VR​

VL (hex)​

Value​



Affected SOP Class UID​

(0000,0002)​

UI​



0018​

1.2.840.10008.5.1.4.38.2​

- Standard -​



DICOM PS3.17 2020a - Explanatory Information​

Page 273​

Nesting​

Attribute​

Tag​

VR​

VL (hex)​

Value​



Command Field​

(0000,0100)​

US​

0002​

0020H [C-FIND-RQ]​



Message ID​

(0000,0110)​

US​

0002​

0010H​



Priority​

(0000,0700)​

US​

0002​

0000H [MEDIUM]​



Data Set Type​

(0000,0800)​

US​

0002​

0102H​



SOP Class UID​

(0008,0016)​

UI​

0000​





SOP Instance UID​

(0008,0018)​

UI​

0000​





Hanging Protocol Name​

(0072,0002)​

SH​

0000​





Hanging Protocol Description​

(0072,0004)​

LO​

0000​





Hanging Protocol Level​

(0072,0006)​

CS​

0000​





Hanging Protocol Creator​

(0072,0008)​

LO​

0000​





Hanging Protocol Creation​

(0072,000A)​

DT​

0000​





DateTime​











Hanging Protocol Definition​

(0072,000C)​

SQ​

ffffffff​





Sequence​









%item​











>​

Modality​

(0008,0060)​

CS​

0000​



>​

Anatomic Region Sequence​

(0008,2218)​

SQ​

ffffffff​



%item​











>>​

Code Value​

(0008,0100)​

SH​

0008​

51185008​

>>​

Coding Scheme Designator​

(0008,0102)​

SH​

0004​

SCT​

>>​

Code Meaning​

(0008,0104)​

LO​

0006​

Chest​

%enditem​











%endseq​











>​

Procedure Code Sequence​

(0008,1032)​

SQ​

0000​



>​

Laterality​

(0020,0060)​

CS​

0000​



>​

Reason for Requested Procedure​

(0040,100A)​

SQ​

0000​





Code Sequence​









%enditem​











%endseq​













Hanging Protocol User​

(0072,000E)​

SQ​

0000​





Identification Code Sequence​











Number of Priors Referenced​

(0072,0014)​

US​

0000​





Number of Screens​

(0072,0100)​

US​

0000​





Nominal Screen Definition​

(0072,0102)​

SQ​

0000​





Sequence​









The following is an example of a set of C-FIND Responses for the Hanging Protocol Information Model - FIND SOP Class, answering​ the C-FIND Request listed above. There are a few matches for this general query. The application needs to select the best choice​ among the matches, which is the second response. The first response is for Chest CT, and the third response does not match the​ user's workstation environment as well as does the second.​

C-FIND Response #1:​









Nesting​

Attribute​

Tag​

VR​

VL (hex)​

Value​



Affected SOP Class UID​

(0000,0002)​

UI​

0018​

1.2.840.10008.5.1.4.38.2​



Command Field​

(0000,0100)​

US​

0002​

8020H [C-FIND-RSP]​

- Standard -​

Page 274​

DICOM PS3.17 2020a - Explanatory Information​



Nesting​

Attribute​

Tag​

VR​

VL (hex)​

Value​



Message ID Being​

(0000,0120)​

US​

0002​

0010H​



Responded To​











Data Set Type​

(0000,0800)​

US​

0002​

0102H​



Status​

(0000,0900)​

US​

0002​

FF00H [Pending]​



SOP Class UID​

(0008,0016)​

UI​

0018​

1.2.840.10008.5.1.4.38.1​



SOP Instance UID​

(0008,0018)​

UI​

0024​

1.2.840.10008.5.1.4.1.1.76392.999.2​



Hanging Protocol Name​

(0072,0002)​

SH​

000a​

CT 1 prior​



Hanging Protocol Description​

(0072,0004)​

LO​

0038​

Dual screen layout for current and​











single prior chest CT​



Hanging Protocol Level​

(0072,0006)​

CS​

000c​

SINGLE_USER​



Hanging Protocol Creator​

(0072,0008)​

LO​

0008​

Dr. Chan​



Hanging Protocol Creation​

(0072,000A)​

DT​

000c​

200408210718​



DateTime​











Hanging Protocol Definition​

(0072,000C)​

SQ​

ffffffff​





Sequence​









%item​











>​

Modality​

(0008,0060)​

CS​

0002​

CT​

>​

Anatomic Region Sequence​

(0008,2218)​

SQ​

ffffffff​



%item​











>>​

Code Value​

(0008,0100)​

SH​

0008​

51185008​

>>​

Coding Scheme Designator​

(0008,0102)​

SH​

0004​

SCT​

>>​

Code Meaning​

(0008,0104)​

LO​

0006​

Chest​

%enditem​











%endseq​











>​

Procedure Code Sequence​

(0008,1032)​

SQ​

0000​



>​

Laterality​

(0020,0060)​

CS​

0000​



>​

Reason for Requested​

(0040,100A)​

SQ​

0000​





Procedure Code Sequence​









%enditem​











%endseq​













Hanging Protocol User​

(0072,000E)​

SQ​

0000​





IdentificationCodeSequence​









%item​











>​

Code Value​

(0008,0100)​

SH​

000a​

58489749P​

>​

Coding Scheme Designator​

(0008,0102)​

SH​

0008​

HOSP_ID​

>​

Code Meaning​

(0008,0104)​

LO​

000e​

Susan H. Chan​

%enditem​











%endseq​













Number of Priors Referenced​

(0072,0014)​

US​

0002​

1​



Number of Screens​

(0072,0100)​

US​

0002​

2​



Nominal Screen Definition​

(0072,0102)​

SQ​

0000​





Sequence​









C-FIND Response #2:​

- Standard -​



DICOM PS3.17 2020a - Explanatory Information​

Page 275​

Nesting​

Attribute​

Tag​

VR​

VL (hex)​

Value​



Affected SOP Class UID​

(0000,0002)​

UI​

0018​

1.2.840.10008.5.1.4.38.2​



Command Field​

(0000,0100)​

US​

0002​

8020H [C-FIND-RSP]​



Message ID Being Responded​

(0000,0120)​

US​

0002​

0010H​



To​











Data Set Type​

(0000,0800)​

US​

0002​

0102H​



Status​

(0000,0900)​

US​

0002​

FF00H [Pending]​



SOP Class UID​

(0008,0016)​

UI​

0018​

1.2.840.10008.5.1.4.38.1​



SOP Instance UID​

(0008,0018)​

UI​

0020​

1.2.840.123456.20030822.223344.1​



Hanging Protocol Name​

(0072,0002)​

SH​

000c​

Chest X-ray​



Hanging Protocol Description​

(0072,0004)​

LO​

0026​

Current and Prior Chest PA and​











Lateral​



Hanging Protocol Level​

(0072,0006)​

CS​

0004​

SITE​



Hanging Protocol Creator​

(0072,0008)​

LO​

0012​

Senior Radiologist​



Hanging Protocol Creation​

(0072,000A)​

DT​

000e​

20020823133455​



DateTime​











Hanging Protocol Definition​

(0072,000C)​

SQ​

ffffffff​





Sequence​









%item​











>​

Modality​

(0008,0060)​

CS​

0000​



>​

Anatomic Region Sequence​

(0008,2218)​

SQ​

ffffffff​



%item​











>>​

Code Value​

(0008,0100)​

SH​

0008​

51185008​

>>​

Coding Scheme Designator​

(0008,0102)​

SH​

0004​

SCT​

>>​

Code Meaning​

(0008,0104)​

LO​

0006​

Chest​

%enditem​











%endseq​











>​

Procedure Code Sequence​

(0008,1032)​

SQ​

0000​



>​

Laterality​

(0020,0060)​

CS​

0000​



>​

Reason for Requested​

(0040,100A)​

SQ​

0000​





Procedure Code Sequence​









%enditem​











%endseq​













Hanging Protocol User​

(0072,000E)​

SQ​

0000​





Identification Code Sequence​











Number of Priors Referenced​

(0072,0014)​

US​

0002​

1​



Number of Screens​

(0072,0100)​

US​

0002​

0002H​



Nominal Screen Definition​

(0072,0102)​

SQ​

ffffffff​





Sequence​









%item​











>​

Number of Vertical Pixels​

(0072,0104)​

US​

0002​

2560​

>​

Number of Horizontal Pixels​

(0072,0106)​

US​

0002​

2048​

>​

Display Environment Spatial​

(0072,0108)​

FD​

0020​

0.0\1.0\0.5\0.0​



Position​









- Standard -​
