Fieldbus coupler / controller

• 87

Fieldbus Controller 750-833







3.2.5Configuration

The configuration of the node is performed in accordance with the physical requirements of the fieldbus controllers and I/O modules.

The fieldbus controller or the process data channel is to be configured on the first slot.

The other slots are configured in accordance with the physical requirements of the I/O modules, whereby only I/O modules with process data are relevant. The supply modules without diagnosis, the supply modules without diagnosis, the bus internal system supply module and the termination module are to be ignored during configuration, as they do not provide any process data.

2 or 3 modules per I/O module are entered in the hardware catalogue. The modules appear as

750-xyz ..., e.g. 750-400 2 DI/24 V DC/3.0 ms. and

PFC 750-xyz ..., e.g.. PFC 750-400 2 DI/24 V DC/3.0 ms.

The identification PFC 750-xyz ... states that the module concerned is exclusively processed by the internal control application. Its process data is not transmitted via the PROFIBUS-DP to the master or to the higher ranking controls.

Alos the entry *750-xyz .... is listed for all binary modules. When using this identification the controller adds the binary information of the current module in a byte previously opened with 750-xyz .... The use of a „*“ module is only permitted when the number of channels is less or identical to the remaining bits in the previously opened byte. The binary I/O modules combined in a byte may be at different locations, i.e. binary I/O modules of a different signal type or byte orientated I/O modules can be connected between.

In order to configure the scope of the connected peripheries individually and independent of the control program, it is possible to parameter the I/O modules in the configuration table as „not plug fitted“. In this manner the process data still on the PROFIBUS DP can be filtered for the individual module and not transmitted to the periphery or read by it.

With the 750-833, after configuration of the connected periphery, the memory area is configured due to the variable arrangement of the fieldbus variables. For this the identification

1 byte PFC outputs, 2 byte PFC outputs to 64 byte PFC outputs

is available for the input image as well as

1 byte PFC inputs, 2 byte PFC inputs to 64 byte PFC inputs

for the output image.

By optionally combining the existing modules it is possible to project the required length on the fieldbus variables for PROFIBUS-DP.

WAGO-I/O-SYSTEM 750

D R A F T

PROFIBUS

2001-02-27

88 • Fieldbus coupler / controller

Fieldbus Controller 750-833

3.2.5.1GSD files

Under PROFIBUS DP the power features of the devices are defined by the manufacturer in the form of a GSD file (device master data) and made available to the user.

Structure, content and coding of this device master data are standardised so that projecting with any DP slaves with projecting data from various manufacturers is possible.

Further information

i The PNO provides information about the GSD files of all listed manufacturers.

GSD and symbol files for the configuration of the I/O modules are available under the order number 750-910 on disk or from the WAGO INTERNET page.

http://www.wago.com

GSD file for I/O module 750-833

WAGOB756.GSD





The GSD file is read by the configuration software and the corresponding settings transferred. For the necessary entries and handling steps please refer to the software user manuals.

D R A F T

WAGO-I/O-SYSTEM 750

2001-02-27

PROFIBUS

Fieldbus coupler / controller

• 89

Fieldbus Controller 750-833







3.2.5.2Identification bytes

The identification bytes contain information about the structure and the scope of the inputs and outputs of the devices. For projecting each I/O module or each channel is allocated an identification (module).

Bit















Meaning

7

6

5

4

3

2

1

0



















Data length









0

0

0

0

1 byte or word









0

0

0

1

2 bytes or words









0

0

1

0

3 bytes or words









...

...

...

...

...









1

1

1

1

16 bytes or 16 words

















Input and output





0

0









Spec. identification formats





0

1









Input





1

0









Output





1

1









Input and output

















Format



0













0 = Byte structure



1













1 = Word structure

















Consistency about

0















Byte or word

1















Total length

For the special identification byte (Bit 4 and 5 = 00) is defined:

Bit















Meaning

7

6

5

4

3

2

1

0



















Length of the manufacturer specific data









0

0

0

0

0 = no manufacturer specific data









0

0

0

1











...

...

...

...

1 ... 14 = Length of the manufacturer specific data









1

1

1

0











1

1

1

1

15 = no manufacturer specific data follows

















Input and output





0

0









Spec. identification formats

















Input and output

0

0













unassigned slot

0

1













a length byte for inputs follows

1

0













a length byte for outputs follows

1

1













a length byte for inputs and outputs follows

Structure of the length byte:

Bit















Meaning

7

6

5

4

3

2

1

0



















Data length





0

0

0

0

1

0

1 byte or word





...

...

...

...

...

...

...





1

1

1

1

1

1

63 bytes or 63 words

















Format



0













0 = Byte structur



1













1 = Word structur

















Consistency about

0















Byte or word

1















Total length

WAGO-I/O-SYSTEM 750

D R A F T

PROFIBUS

2001-02-27

90 • Fieldbus coupler / controller

Fieldbus Controller 750-833

This information is saved in the GSD file. For projecting the I/O module is selected in accordance with the article number using the configuration software contained in the hardware catalogue of the I/O module.

Module





Ident.

Module

Ident.

Module



Ident.

750-833 No process data channel

0x00











750-833 2 byte process data

0xB1











channel

















750-400 2

DI/24 V DC/3.0 ms

0x10

*750-400 2 DI/24 V DC/3.0 ms

0x00

PFC 750-400 2 DI/24 V DC/3.0 ms

0x00

750-401 2

DI/24 V DC/0.2 ms

0x10

*750-401 2 DI/24 V DC/0.2 ms

0x00

PFC 750-401 2 DI/24 V DC/0.2 ms

0x00

750-402 4

DI/24 V DC/3.0 ms

0x10

*750-402 4 DI/24 V DC/3.0 ms

0x00

PFC 750-402 4 DI/24 V DC/3.0 ms

0x00

750-403 4

DI/24 V DC/0.2 ms

0x10

*750-403 4 DI/24 V DC/0.2 ms

0x00

PFC 750-403 4 DI/24 V DC/0.2 ms

0x00

750-404 Counter Module

0xF2

PFC 750-404 Counter Module

0x00







750-405 2

DI/230 V AC/10 ms

0x10

*750-405 2 DI/230 V AC/10 ms

0x00

PFC 750-405 2 DI/230 V AC/10 ms

0x00

750-406 2

DI/120 V AC/10 ms

0x10

*750-406 2 DI/120 V AC/10 ms

0x00

PFC 750-406 2 DI/120 V AC/10 ms

0x00

750-408 4

DI/24 V DC/3.0 ms

0x10

*750-408 4 DI/24 V DC/3.0 ms

0x00

PFC 750-408 4 DI/24 V DC/3.0 ms

0x00

750-409 4

DI/24 V DC/0.2 ms

0x10

*750-409 4 DI/24 V DC/0.2 ms

0x00

PFC 750-409 4 DI/24 V DC/0.2 ms

0x00

750-410 2

DI/24 V DC/3.0 ms

0x10

*750-410 2 DI/24 V DC/3.0 ms

0x00

PFC 750-410 2 DI/24 V DC/3.0 ms

0x00

750-411 2

DI/24 V DC/0.2 ms

0x10

*750-411 2 DI/24 V DC/0.2 ms

0x00

PFC 750-411 2 DI/24 V DC/0.2 ms

0x00

750-412 2

DI/48 V DC/3.0 ms

0x10

*750-412 2 DI/48 V DC/3.0 ms

0x00

PFC 750-412 2 DI/48 V DC/3.0 ms

0x00

750-413 2

DI/48 V DC/0.2 ms

0x10

*750-413 2 DI/48 V DC/0.2 ms

0x00

PFC 750-413 2 DI/48 V DC/0.2 ms

0x00

750-414 4

DI/5 V DC/0.2 ms

0x10

*750-414 4 DI/5 V DC/0.2 ms

0x00

PFC 750-414 4 DI/5 V DC/0.2 ms

0x00

750-415 4 DI/24 V AC/DC/20 ms

0x10

*750-415 4 DI/24 V AC/DC/20 ms

0x00

PFC 750-415 4 DI/24 V

0x00













AC/DC/20ms





750-418 2 DI/24 V DC DIA ACK

0x30

*750-418 2 DI/24 V DC DIA ACK

0x00

PFC 750-418 2 DI/24 V DC DIA

0x00













ACK





750-419 2 DI/24 V DC DIA

0x10

*750-419 2 DI/24 V DC DIA

0x00

PFC 750-419 2 DI/24 V DC DIA

0x00

750-423 4 DI/24 V AC/DC/50 ms

0x10

*750-423 4 DI/24 V AC/DC/50 ms

0x00

PFC 750-423 4 DI/24 V

0x00













AC/DC/50ms





750-424 2 DI/24 V DC DIA

0x10

*750-424 2 DI/24 V DC DIA

0x00

PFC 750-424 2 DI/24 V DC DIA

0x00

750-452

2

AI/0-20 mA/diff.

0x51





PFC 750-452

2 AI/0-20 mA/diff.

0x00

750-454

2

AI/4-20 mA/diff.

0x51





PFC 750-454

2 AI/4-20 mA/diff.

0x00

750-456

2

AI/±10 V/diff.

0x51





PFC 750-456

2 AI/±10 V/diff.

0x00

750-461 2

AI/RTD

0x51





PFC 750-461 2 AI/RTD

0x00

750-462 2

AI/TC

0x51





PFC 750-462 2 AI/TC

0x00

750-465 2

AI/0-20 mA/SE

0x51





PFC 750-465 2 AI/0-20 mA/SE

0x00

750-466 2

AI/4-20 mA/SE

0x51





PFC 750-466 2 AI/4-20 mA/SE

0x00

750-467 2

AI/0-10 V/SE

0x51





PFC 750-467 2 AI/0-10 V/SE

0x00

750-468 4

AI/0-10 V/SE

0x53





PFC 750-468 4 AI/0-10 V/SE

0x00

750-469 2 AI/TC/OCM

0x51





PFC 750-469 2 AI/TC/OCM

0x00

750-472 2

AI/0-20 mA/OVLP

0x51





PFC 750-472 2 AI/0-20 mA/OVLP

0x00

750-474 2

AI/4-20 mA/OVLP

0x51





PFC 750-474 2 AI/4-20 mA/OVLP

0x00

750-476 2

AI/±10 V

0x51





PFC 750-476 2 AI/±10 V

0x00

750-478 2

AI/0-10 V

0x51





PFC 750-478 2 AI/0-10 V

0x00

750-501 2 DO/24 V DC/0.5 A

0x20

*750-501 2 DO/24 V DC/0.5 A

0x00

PFC 750-501 2 DO/24 V DC/0.5 A

0x00

750-502 2 DO/24 V DC/2.0 A

0x20

*750-502 2 DO/24 V DC/2.0 A

0x00

PFC 750-502 2 DO/24 V DC/2.0 A

0x00

750-504 4 DO/24 V DC/0.5 A

0x20

*750-504 4 DO/24 V DC/0.5 A

0x00

PFC 750-504 4 DO/24 V DC/0.5 A

0x00

750-506 2 DO/24 V DC/0.5 A DIA

0x20

*750-506 2 DO/24 V DC/0.5 A DIA

0x00

PFC 750-506 2 DO/24 V DC/0.5 A

0x00

750-507 2 DO/24 V DC/2.0 A DIA

0x20

*750-507 2 DO/24 V DC/2.0 A DIA

0x00

PFC 750-507 2 DO/24 V DC/2.0 A

0x00

750-509 2 DO/230 V AC/0.3 A

0x20

*750-509 2 DO/230 V AC/0.3 A

0x00

PFC 750-509 2 DO/230 V AC/0.3 A

0x00

750-511 2 DO 24 V DC/PWM

0xF2





PFC 750-511 2 DO 24 V DC/PWM

0x00

750-512 2 DO Relay/250 V AC

0x20

*750-512 2 DO Relay/250 V AC

0x00

PFC 750-512 2 DO Relay/250 V AC

0x00

750-513 2 DO Relay/250 V AC

0x20

*750-513 2 DO Relay/250 V AC

0x00

PFC 750-513 2 DO Relay/250 V AC

0x00

750-514 2 DO Relay/125 V AC

0x20

*750-514 2 DO Relay/125 V AC

0x00

PFC 750-514 2 DO Relay/125 V AC

0x00

750-516 4 DO/24 V DC/0.5 A

0x20

*750-516 4 DO/24 V DC/0.5 A

0x00

PFC 750-516 4 DO/24 V DC/0.5 A

0x00

750-517 2

DO Relay/230 V AC

0x20

*750-517 2 DO Relay/230 V AC

0x00

PFC 750-517 2 DO Relay/230 V AC

0x00

750-519 4 DO/5 V DC/20 mA

0x20

*750-519 4 DO/5 V DC/20 mA

0x00

PFC 750-519 4 DO/5 V DC/20 mA

0x00

750-522 2

DO/230V AC/0.5 A

0x20

*750-522 2 DO/230V AC/0.5 A

0x00

PFC 750-522 2 DO/230V DC/0.5 A

0x00

DIA







DIA









750-550 2

AO/0-10 V

0x61





PFC 750-550 2 AO/0-10 V

0x00

750-552 2 AO/0-20 mA

0x61





PFC 750-552 2 AO/0-20 mA

0x00

750-554 2 AO/4-20 mA

0x61





PFC 750-554 2 AO/4-20 mA

0x00

750-556 2 AO/±10 V

0x61





PFC 750-556 2 AO/±10 V

0x00

750-610 P supply. 24 V DC/DIA

0x00











750-611 P supply. 230 V AC/DIA

0x00











750-630

SSI-Intf. Standard

0x95

750-630 SSI-Intf. alternative

0x93

PFC 750-630

SS intf.

0x00

750-631

Encoder intf.

0xB5

PFC 750-631 Encoder intf.

0x00







750-650 RS232C-Intf. 5 Byte

0xB5

750-650 RS232C-Intf. 3 Byte

0xB3

PFC 750-650 RS232C intf.

0x00

750-651 TTY-Intf. 5 Byte

0xB5

750-651 TTY-Intf. 3 Byte

0xB3

PFC 750-651 TTY-Intf.

0x00

750-653

RS485-Intf. 5 Byte

0xB5

750-653 RS485 intf. 3 Byte

0xB3

PFC 750-653

RS485intf.

0x00

750-654 Data exch. module

0xF1





PFC 750-654 Data exch. module

0x00













1 Byte PFC-input

0xA0

2 Byte PFC inputs

0xA1

3 Byte PFC inputs

0xA2

4 Byte PFC inputs

0xA3

5 Byte PFC inputs

0xA4

6 Byte PFC inputs

0xA5

7 Byte PFC inputs

0xA6

8 Byte PFC inputs

0xA7

9 Byte PFC inputs

0xA8

D R A F T

WAGO-I/O-SYSTEM 750

2001-02-27

PROFIBUS

















Fieldbus coupler / controller

• 91

















Fieldbus Controller 750-833









































Module

Ident.



Module

Ident.



Module

Ident.



10

Byte PFC inputs

0xA9



11

Byte PFC inputs

0xAA

12

Byte PFC inputs

0xAB



13

Byte PFC inputs

0xAC

14

Byte PFC inputs

0xAD

15

Byte PFC inputs

0xAE



16

Byte PFC inputs

0xAF



17

Byte PFC inputs

0x80

, 0x90

18

Byte PFC inputs

0x80

, 0x91



19

Byte PFC inputs

0x80

, 0x92

20

Byte PFC inputs

0x80

, 0x93

21

Byte PFC inputs

0x80

, 0x94



22

Byte PFC inputs

0x80

, 0x95

23

Byte PFC inputs

0x80

, 0x96

24

Byte PFC inputs

0x80

, 0x97



25

Byte PFC inputs

0x80

, 0x98

26

Byte PFC inputs

0x80

, 0x99

27

Byte PFC inputs

0x80

, 0x9A



28

Byte PFC inputs

0x80

, 0x9B

29

Byte PFC inputs

0x80

, 0x9C

30

Byte PFC inputs

0x80

, 0x9D



31

Byte PFC inputs

0x80

, 0x9E

32 byte PFC inputs

0x80

, 0x9F

33

Byte PFC inputs

0x80

, 0xA0



34

Byte PFC inputs

0x80

, 0xA1

35

Byte PFC inputs

0x80

, 0xA2

36

Byte PFC inputs

0x80

, 0xA3



37

Byte PFC inputs

0x80

, 0xA4

38

Byte PFC inputs

0x80

, 0xA5

39

Byte PFC inputs

0x80

, 0xA6



40

Byte PFC inputs

0x80

, 0xA7

41

Byte PFC inputs

0x80

, 0xA8

42

Byte PFC inputs

0x80

, 0xA9



43

Byte PFC inputs

0x80

, 0xAA

44

Byte PFC inputs

0x80

, 0xAB

45

Byte PFC inputs

0x80

, 0xAC



46

Byte PFC inputs

0x80

, 0xAD

47

Byte PFC inputs

0x80

, 0xAE

48

Byte PFC inputs

0x80

, 0xAF



49

Byte PFC inputs

0x80

, 0xB0

50

Byte PFC inputs

0x80

, 0xB1

51

Byte PFC inputs

0x80

, 0xB2



52

Byte PFC inputs

0x80

, 0xB3

53

Byte PFC inputs

0x80

, 0xB4

54

Byte PFC inputs

0x80

, 0xB5



55

Byte PFC inputs

0x80

, 0xB6

56

Byte PFC inputs

0x80

, 0xB7

57

Byte PFC inputs

0x80

, 0xB8



58

Byte PFC inputs

0x80

, 0xB9

59

Byte PFC inputs

0x80

, 0xBA

60

Byte PFC inputs

0x80

, 0xBB



61

Byte PFC inputs

0x80

, 0xBC

62

Byte PFC inputs

0x80

, 0xBD

63

Byte PFC inputs

0x80

, 0xBE



64

Byte PFC inputs

0x80

, 0xBF







































1 Byte PFC outputs

0x90



2 Byte PFC outputs

0x91



3 Byte PFC outputs

0x92





4 Byte PFC outputs

0x93



5 Byte PFC outputs

0x94



6 Byte PFC outputs

0x95





7 Byte PFC outputs

0x96



8 Byte PFC outputs

0x97



9 Byte PFC outputs

0x98





10

Byte PFC outputs

0x99



11

Byte PFC outputs

0x9A



12

Byte PFC outputs

0x9B





13

Byte PFC outputs

0x9C



14

Byte PFC outputs

0x9D



15

Byte PFC outputs

0x9E





16

Byte PFC outputs

0x9F



17

Byte PFC outputs

0x40

, 0x90

18

Byte PFC outputs

0x40

, 0x91



19

Byte PFC outputs

0x40

, 0x92

20

Byte PFC outputs

0x40

, 0x93

21

Byte PFC outputs

0x40

, 0x94



22

Byte PFC outputs

0x40

, 0x95

23

Byte PFC outputs

0x40

, 0x96

24

Byte PFC outputs

0x40

, 0x97



25

Byte PFC outputs

0x40

, 0x98

26

Byte PFC outputs

0x40

, 0x99

27

Byte PFC outputs

0x40

, 0x9A



28

Byte PFC outputs

0x40

, 0x9B

29

Byte PFC outputs

0x40

, 0x9C

30

Byte PFC outputs

0x40

, 0x9D



31

Byte PFC outputs

0x40

, 0x9E

32

Byte PFC outputs

0x40

, 0x9F

33

Byte PFC outputs

0x40

, 0xA0



34

Byte PFC outputs

0x40

, 0xA1

35

Byte PFC outputs

0x40

, 0xA2

36

Byte PFC outputs

0x40

, 0xA3



37

Byte PFC outputs

0x40

, 0xA4

38

Byte PFC outputs

0x40

, 0xA5

39

Byte PFC outputs

0x40

, 0xA6



40

Byte PFC outputs

0x40

, 0xA7

41

Byte PFC outputs

0x40

, 0xA8

42

Byte PFC outputs

0x40

, 0xA9



43

Byte PFC outputs

0x40

, 0xAA

44

Byte PFC outputs

0x40

, 0xAB

45

Byte PFC outputs

0x40

, 0xAC



46

Byte PFC outputs

0x40

, 0xAD

47

Byte PFC outputs

0x40

, 0xAE

48

Byte PFC outputs

0x40

, 0xAF



49

Byte PFC outputs

0x40

, 0xB0

50

Byte PFC outputs

0x40

, 0xB1

51

Byte PFC outputs

0x40

, 0xB2



52

Byte PFC outputs

0x40

, 0xB3

53

Byte PFC outputs

0x40

, 0xB4

54

Byte PFC outputs

0x40

, 0xB5



55

Byte PFC outputs

0x40

, 0xB6

56

Byte PFC outputs

0x40

, 0xB7

57

Byte PFC outputs

0x40

, 0xB8



58

Byte PFC outputs

0x40

, 0xB9

59

Byte PFC outputs

0x40

, 0xBA

60

Byte PFC outputs

0x40

, 0xBB



61

Byte PFC outputs

0x40

, 0xBC

62

Byte PFC outputs

0x40

, 0xBD

63

Byte PFC outputs

0x40

, 0xBE



64

Byte PFC outputs

0x40

, 0xBF

















WAGO-I/O-SYSTEM 750

D R A F T

PROFIBUS

2001-02-27

Источник: https://studfile.net/preview/16369742/
